# Model Context Protocol (MCP) Integration

This project demonstrates an advanced architectural pattern using the **Model Context Protocol (MCP)** within the Google ADK framework. Unlike standard Function Calling (where logic is embedded in the agent's code), this project decouples the **Tool Logic (Server)** from the **Agent Logic (Client)**.

## 🧠 Logic & Visualization

To understand MCP, we use the **"Universal USB Driver" Analogy**:

- **MCP Servers (The Flash Drives):** Standalone processes containing specific capabilities. We have two:
    1.  **Math Server:** Logic for calculations (`add_numbers`).
    2.  **Filesystem Server:** Logic for accessing local files (`list_files`).
- **MCP Client/Agent (The Computer):** Connects to the servers via standard ports (Stdio), "reads" the available tools, and dynamically adds them to its toolset.
- **Transport (The USB Cable):** The communication layer. In this project, we use standard input/output (`Stdio`) pipes to send JSON-RPC messages.

### Architecture Diagram

The Agent spawns multiple Servers as subprocesses and communicates via JSON-RPC protocol simultaneously.

sequenceDiagram
    participant Agent as ADK Agent (Client)
    participant Transport as Stdio Pipes
    participant Server1 as Math MCP Server
    participant Server2 as Filesystem MCP Server

    Note over Agent, Server2: Initialization Phase
    Agent->>Transport: Spawn Process 1 (simple_mcp.py)
    Agent->>Transport: Spawn Process 2 (filesystem_server.py)
    Server1-->>Agent: List Tools [add_numbers, get_time...]
    Server2-->>Agent: List Tools [list_files]

    Note over Agent, Server2: Execution Phase
    Agent->>Agent: LLM needs to calculate
    Agent->>Server1: JSON-RPC (add_numbers)
    Server1-->>Agent: Result (155)

    Agent->>Agent: LLM needs file list
    Agent->>Server2: JSON-RPC (list_files)
    Server2-->>Agent: Result (['file1.txt', 'src'...])

.
├── Makefile                        # Automation: install, lint, format, run
├── pyproject.toml                  # Dependencies (mcp, google-adk)
├── src
│   └── mcp_agent
│       ├── agent.py                # CLIENT: The ADK Agent that consumes tools
│       ├── config.py               # CONFIG: Pydantic settings
│       └── servers
│           ├── simple_mcp.py       # SERVER 1: Math & Time utilities
│           └── filesystem_server.py# SERVER 2: Filesystem operations
└── tests                           # Unit Tests

make install

GOOGLE__API_KEY=your_actual_api_key
GOOGLE__GENAI_USE_VERTEXAI=false

make run

USER: Calculate 100 + 55 using the tools, and give the current time, and give files to the path '../', and then echo the result.
AGENT:
[SYSTEM: Calling MCP Tool 'add_numbers']
[SYSTEM: Calling MCP Tool 'get_current_time']
[SYSTEM: Calling MCP Tool 'list_files']
[SYSTEM: Calling MCP Tool 'get_echo']
Echo from MCP: 155, Time: 15/12/2025 10:00, Files: ['Makefile', 'pyproject.toml', 'src'...]
[SYSTEM: Closing MCP connection...]

@mcp.tool()
def add_numbers(a: int, b: int) -> int:
    return a + b

from mcp.server.fastmcp import FastMCP
import os

mcp = FastMCP("FileSystemServer")

@mcp.tool()
def list_files(directory: str) -> dict:
    """Echoes directories files."""
    return {"files": str(os.listdir(directory))}

# 1. Define Servers
server_params_math = StdioServerParameters(command="python", args=[".../simple_mcp.py"])
server_params_fs = StdioServerParameters(command="python", args=[".../filesystem_server.py"])

# 2. Initialize Toolsets
math_toolset = McpToolset(connection_params=StdioConnectionParams(server_params_math))
fs_toolset = McpToolset(connection_params=StdioConnectionParams(server_params_fs))

# 3. Agent consumes both
agent = LlmAgent(
    name="McpConsumer",
    tools=[math_toolset, fs_toolset], # <--- Multi-source tools
    # ...
)
