PostgreSQL MCP Server for Home Assistant Add-on Repository

This repository contains a Home Assistant addon that provides a Model Context Protocol (MCP) server for PostgreSQL database access with authentication through Home Assistant's API token system.

Features

🏠 Home Assistant Integration: Uses Home Assistant's authentication system
🗄️ PostgreSQL Database Access: Direct database connection for MCP tools
🔐 Secure Authentication: Validates Home Assistant API tokens, with optional OAuth 2.1 for clients that require it (e.g. claude.ai custom connectors)
🛡️ SQL Injection Protection: Built-in query validation and sanitization
⚙️ Write Operation Control: Enable/disable write operations via addon configuration
🐳 Docker Support: Packaged as a Home Assistant addon
☁️ Cloudflare Tunnel Ready: Designed to work with Home Assistant's cloudflare addon

Installation

Step 1: Add Repository to Home Assistant

Go to Settings > Add-ons > Add-on Store in your Home Assistant
Click the ⋮ (three dots) menu in the top right corner
Select Repositories

Add this repository URL:

https://github.com/jodur/mcp-addon-postgresql-homeassistant

Click Add

Step 2: Install the Add-on

Find "PostgreSQL MCP Server" in the add-on store
Click on it and then click Install
Wait for the installation to complete

Step 3: Configure and Start

Go to the Configuration tab
Configure the addon with your PostgreSQL connection details
Click Save
Go to the Info tab and click Start

Configuration

Addon Configuration

Configure the addon through the Home Assistant UI:

database_url: "postgresql://username:password@host:5432/database"
log_level: "info"
max_connections: 10
enable_write_operations: false
ha_base_url: "http://homeassistant:8123"  # Home Assistant API URL
enable_timescale: false
public_url: ""              # optional, only needed for OAuth (see below)
ha_public_url: ""           # optional, only needed for OAuth (see below)
allowed_redirect_uris: ""   # optional, only needed for OAuth (see below)

The MCP server always listens on container port 3000 internally — use the addon's Network tab in Home Assistant to change the externally reachable host port. There is no server_port option; changing the internal port independently of the fixed 3000/tcp container mapping would silently break connectivity, so it was removed.

Environment Variables

The addon supports the following environment variables:

DATABASE_URL: PostgreSQL connection string
LOG_LEVEL: Logging level (debug, info, warn, error)
MAX_CONNECTIONS: Maximum database connections
ENABLE_WRITE_OPERATIONS: Enable write operations (true/false)
HA_BASE_URL: Home Assistant API base URL (default: http://homeassistant:8123)
ENABLE_TIMESCALE: Enable TimescaleDB-specific tool descriptions (true/false)
PUBLIC_URL: Override for this addon's own public URL (optional; auto-detected per-request if blank) — only relevant for OAuth
HA_PUBLIC_URL: Override for Home Assistant's public URL (optional; auto-detected via the Supervisor API if blank) — only relevant for OAuth
OAUTH_ALLOWED_REDIRECT_URIS: Comma-separated extra trusted OAuth redirect URIs beyond claude.ai's own and localhost loopback

Note: The primary authentication path is service-based using Home Assistant tokens; see Authentication below for the additional OAuth 2.1 option and its requirements.

Usage

Available MCP Tools

1. `listTables`

Lists all tables in the database with schema information.

{
  "method": "tools/call",
  "params": {
    "name": "listTables",
    "arguments": {
      "schema": "public"
    }
  }
}

2. `queryDatabase`

Execute read-only SQL queries.

{
  "method": "tools/call",
  "params": {
    "name": "queryDatabase",
    "arguments": {
      "sql": "SELECT table_name FROM information_schema.tables WHERE table_schema = 'public'"
    }
  }
}

3. `executeDatabase`

Execute write operations (INSERT, UPDATE, DELETE, DDL). Only available when enable_write_operations is set to true in addon configuration.

{
  "method": "tools/call",
  "params": {
    "name": "executeDatabase",
    "arguments": {
      "sql": "CREATE TABLE example (id SERIAL PRIMARY KEY, name VARCHAR(100))"
    }
  }
}

Authentication

The server supports two authentication methods:

1. Bearer token (default, unchanged) — include your Home Assistant long-lived access token in the Authorization header:

Authorization: Bearer YOUR_HOME_ASSISTANT_TOKEN

This works with Claude Desktop/Code, curl, SuperGateway, and any client that lets you set a custom header.

2. OAuth 2.1 (for clients that require it, e.g. claude.ai web/mobile custom connectors) — the addon proxies Home Assistant's own OAuth2 authorization-code flow, so no separate login system or client registration is needed on your end. To enable it:

Add public_url, ha_public_url, and allowed_redirect_uris in the addon's Configuration (all optional; auto-detected if left blank)
The addon requires homeassistant_api: true to obtain a Supervisor-injected token used only to auto-detect Home Assistant's external URL
The addon must be reachable at a public HTTPS URL (e.g. via a Cloudflare Tunnel) for the browser-based login redirect and for claude.ai's callback
Supports Dynamic Client Registration (RFC 7591), PKCE (mandatory), and refresh tokens — no manual client ID/secret setup required in claude.ai
See Claude.ai Custom Connector below for setup steps

MCP Client Configuration

For HTTP-based MCP clients, use the REST API endpoints:

Local Access:

# List available tools
curl -X POST http://your-ha-instance:3000/mcp \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_HA_TOKEN" \
  -d '{"method": "tools/list"}'

# Call a tool
curl -X POST http://your-ha-instance:3000/mcp \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_HA_TOKEN" \
  -d '{"method": "tools/call", "params": {"name": "listTables"}}'

Cloudflare Tunnel Access (HTTPS):

# List available tools via Cloudflare tunnel
curl -X POST https://your-tunnel-domain.cloudflareaccess.com/mcp \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_HA_TOKEN" \
  -d '{"method": "tools/list"}'

# Call a tool via Cloudflare tunnel
curl -X POST https://your-tunnel-domain.cloudflareaccess.com/mcp \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_HA_TOKEN" \
  -d '{"method": "tools/call", "params": {"name": "listTables"}}'

Integration with AI Tools

The MCP server can be integrated with various AI tools and platforms that support the Model Context Protocol over HTTP endpoints.

Claude Desktop Integration via SuperGateway

You can use this MCP server with Claude Desktop through SuperGateway, which provides a bridge between HTTP-based MCP servers and Claude Desktop's stdio-based MCP client.

Setup Instructions:

Install SuperGateway:

npm install -g @supercorp-ai/supergateway

Configure Claude Desktop: Add the following configuration to your Claude Desktop MCP settings file:

On macOS: ~/Library/Application Support/Claude/claude_desktop_config.json On Windows: %APPDATA%\Claude\claude_desktop_config.json

{
  "mcpServers": {
    "postgresql-ha": {
      "command": "supergateway",
      "args": [
        "--url", "http://your-ha-instance:3000/mcp",
        "--header", "Authorization: Bearer YOUR_HOME_ASSISTANT_TOKEN",
        "--header", "Content-Type: application/json"
      ]
    }
  }
}

For Cloudflare Tunnel (HTTPS) access:

{
  "mcpServers": {
    "postgresql-ha": {
      "command": "supergateway",
      "args": [
        "--url", "https://your-tunnel-domain.cloudflareaccess.com/mcp",
        "--header", "Authorization: Bearer YOUR_HOME_ASSISTANT_TOKEN",
        "--header", "Content-Type: application/json"
      ]
    }
  }
}

Restart Claude Desktop to load the new MCP server configuration.

Usage in Claude Desktop:

Once configured, you can use natural language commands in Claude Desktop like:

"List all tables in the database"
"Show me the schema for the users table"
"Query the database to find all active users"
"Create a new table for storing product information" (if write operations are enabled)

Benefits of this Integration:

🤖 Natural Language Interface: Use conversational commands instead of JSON API calls
🔄 Real-time Database Access: Claude can directly query and analyze your PostgreSQL data
🛡️ Secure Authentication: All requests use your Home Assistant token for secure access
☁️ Remote Access: Works with both local and Cloudflare tunnel connections
📊 Data Analysis: Claude can perform complex analysis on your database contents

Example Conversation:

You: "What tables are available in my database?"
Claude: [Uses listTables tool] "I can see you have the following tables: users, products, orders, and logs. Would you like me to examine the schema of any specific table?"

You: "Show me the structure of the users table"
Claude: [Uses queryDatabase tool] "The users table has columns: id (primary key), username, email, created_at, and is_active. There are currently 150 users in the table."

Claude.ai Custom Connector (OAuth)

claude.ai's web/mobile custom connectors only support OAuth 2.0/2.1 — they don't accept static bearer tokens or custom headers. This addon supports that by proxying Home Assistant's own OAuth authorization-code flow, so no separate login system or manual client registration is required.

Setup Instructions:

Enable a public HTTPS URL for the addon (e.g. via Home Assistant's Cloudflare Tunnel addon). claude.ai must be able to reach it for the login redirect and callback.
Configure the addon options (Configuration tab): leave public_url, ha_public_url, and allowed_redirect_uris blank to auto-detect, or set them explicitly if auto-detection doesn't work for your setup. homeassistant_api: true must be enabled (already the addon's default) so Home Assistant's external URL can be auto-detected via the Supervisor API.
In claude.ai, go to Settings → Connectors → Add custom connector, and enter your addon's public URL followed by /mcp (e.g. https://your-domain.example.com/mcp).
Authorize: claude.ai will register itself automatically (Dynamic Client Registration), redirect you to log into Home Assistant in your browser, and then complete the connection — no client ID/secret entry needed.
Once connected, claude.ai stores a refresh token and renews its access token automatically in the background; you should not need to reconnect unless you revoke access in Home Assistant or remove the connector in claude.ai.

Note: this is entirely separate from the bearer-token method above — Claude Desktop/Code, curl, and SuperGateway continue to work exactly as before, unaffected by whether OAuth is used.

Security

SQL Query Validation

The server includes basic SQL query validation designed for LLM-generated queries:

Pattern-based validation for obviously dangerous constructs (e.g., xp_cmdshell, malformed queries)
Operation type detection to distinguish read vs write operations
Multiple statement prevention to block query chaining
Basic syntax validation to catch malformed SQL

Important Security Notes:

⚠️ This is NOT comprehensive SQL injection protection. The validation is designed to:

Prevent accidental execution of dangerous administrative commands
Ensure write operations respect the enable_write_operations setting
Catch basic malformed queries from LLM generation errors

⚠️ Trust Model: This MCP server assumes queries come from trusted sources (authenticated AI assistants, not untrusted user input). The validation primarily prevents:

Accidental destructive operations
LLM hallucinations that generate dangerous SQL patterns
Configuration errors (write ops when disabled)

For Production Use:

Use database-level permissions to restrict what the connection user can access
Consider read-only database replicas for query-only operations
Monitor query logs for unexpected patterns
Implement network-level access controls

Access Control

Authentication: All requests require valid Home Assistant tokens (bearer token or OAuth-issued, see Authentication)
Write Operations: Controlled by the enable_write_operations addon setting
Audit Logging: All database operations are logged with request context
Connection Limits: Configurable connection pooling
Rate Limiting: The OAuth endpoints (/register, /authorize, /token) are rate-limited per-IP to prevent abuse of these unauthenticated-by-design endpoints
Scoped CORS: /token and /register restrict cross-origin responses to trusted origins (claude.ai, localhost loopback, configured allowed_redirect_uris) rather than the open policy used by the /mcp endpoint

Security Model & Trust Assumptions

This MCP server is designed for service-to-service communication with AI assistants, not direct user input:

✅ Trusted Sources:

Authenticated AI assistants (Claude, ChatGPT, etc.)
MCP clients with valid Home Assistant tokens
Automated tools using proper authentication

❌ NOT suitable for:

Direct user SQL input without validation
Public-facing SQL interfaces
Untrusted third-party applications

Recommended Security Practices:

Database Permissions: Grant minimal necessary permissions to the PostgreSQL user
Network Security: Use firewalls and VPNs to restrict database access
Monitoring: Log and monitor all database operations
Separate Environments: Use read-only replicas for query-heavy operations
Regular Updates: Keep PostgreSQL and dependencies updated

Development

Prerequisites

Node.js 18+
TypeScript
Docker (for addon packaging)
Home Assistant development environment

Building

# Install dependencies
npm install

# Build TypeScript
npm run build

# Run in development mode
npm run dev

# Start the server
npm start

Testing

# Build the addon
npm run build

# Test with curl
curl -X POST http://localhost:3000/mcp \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_HA_TOKEN" \
  -d '{"method": "tools/list"}'

Cloudflare Tunnel Integration

This addon is designed to work with Home Assistant's cloudflare addon for secure external access:

Install and configure the Home Assistant cloudflare addon
Configure the tunnel to expose the MCP server port (3000)
Use the HTTPS URL for remote MCP client connections

Cloudflare Tunnel Configuration

When using Cloudflare tunnel, your MCP server will be accessible via HTTPS:

# In your Cloudflare tunnel configuration
tunnel: your-tunnel-id
credentials-file: /etc/cloudflared/your-tunnel.json
ingress:
  - hostname: your-domain.cloudflareaccess.com
    service: http://localhost:3000
  - service: http_status:404

Benefits of Cloudflare Tunnel:

HTTPS encryption - All traffic is automatically encrypted
Global CDN - Fast access from anywhere in the world
DDoS protection - Built-in security against attacks
Access control - Optional Cloudflare Access integration
No port forwarding - No need to open firewall ports

External URL: https://your-tunnel-domain.cloudflareaccess.com/mcp

Architecture

┌─────────────────┐    ┌─────────────────┐    ┌─────────────────┐
│   MCP Client    │────│  Home Assistant │────│   PostgreSQL    │
│   (HTTP/HTTPS)  │    │   MCP Server    │    │    Database     │
└─────────────────┘    └─────────────────┘    └─────────────────┘
         │                        │                        │
         │                        │                        │
    Local: HTTP           Home Assistant           Database
    Tunnel: HTTPS         Authentication              Pool
    via Cloudflare        Token Validation         Management

Troubleshooting

Common Issues

Connection refused: Check if the addon is running and port is accessible. The MCP server always listens on container port 3000 internally — the externally reachable port is set via the addon's Network tab, not a config option.
Port already in use / can't start: Another add-on or service on your Home Assistant host may already be bound to the chosen host port. Check the Network tab of each installed add-on, or use docker ps via the Terminal & SSH add-on to see what's bound to a given port.
Authentication failed: Verify your Home Assistant token is valid (bearer token method), or that the OAuth login completed successfully (OAuth method — check for a clear error in the addon logs, e.g. from /authorize or /token)
claude.ai "Couldn't register with ... sign-in service": the addon's public URL must be reachable and correctly routed (check /health and /.well-known/oauth-authorization-server respond over your public URL, not just locally)
OAuth /authorize fails with a 401 or "auto-detect" error: confirm homeassistant_api: true is set and the addon was reinstalled/rebuilt (not just reconfigured) so a SUPERVISOR_TOKEN is injected; or set ha_public_url manually
Database connection failed: Check PostgreSQL connection string
Write operations disabled: Ensure enable_write_operations is set to true in addon configuration if you need to execute write queries

Logs

Check addon logs through Home Assistant:

Supervisor → Add-ons → PostgreSQL MCP Server → Logs

Health Check

The server provides a health check endpoint:

curl http://localhost:3000/health

Contributing

Fork the repository
Create a feature branch
Make your changes
Add tests if applicable
Submit a pull request

License

MIT License - see LICENSE file for details.

Support

For issues and questions:

GitHub Issues: Create an issue
Home Assistant Community: Forum discussion

使用说明

PostgreSQL MCP Server for Home Assistant Add-on Repository

Features

Installation

Step 1: Add Repository to Home Assistant

Step 2: Install the Add-on

Step 3: Configure and Start

Configuration

Addon Configuration

Environment Variables

Usage

Available MCP Tools

1. listTables

2. queryDatabase

3. executeDatabase

Authentication

MCP Client Configuration

Integration with AI Tools

Claude Desktop Integration via SuperGateway

Setup Instructions:

Usage in Claude Desktop:

Benefits of this Integration:

Example Conversation:

Claude.ai Custom Connector (OAuth)

Setup Instructions:

Security

SQL Query Validation

Access Control

Security Model & Trust Assumptions

Development

Prerequisites

Building

Testing

Cloudflare Tunnel Integration

Cloudflare Tunnel Configuration

Architecture

Troubleshooting

Common Issues

Logs

Health Check

Contributing

License

Support

Related Projects

相关 MCP

PostgreSQL管理服务器

Postgres MCP Pro 数据库优化工具

本地化Claude上下文服务器

PostgreSQL数据库交互服务

MySQL数据库访问服务

MCP长期记忆服务器

1. `listTables`

2. `queryDatabase`

3. `executeDatabase`
