Yukta

A reactive, DAG-based workflow orchestration server.
Define a workflow once as JSON. Run it from a script, a CI pipeline, a web UI or an AI agent.

Quick start · Examples · Plugins · MCP · REST API · Contributing

Why Yukta

Most workflow engines make you pick: a heavy platform you have to operate, or a script you cannot observe. Yukta is a small server that sits between the two.

• Workflows are data. A workflow is a JSON graph of nodes and edges. There is no DSL to learn, and a graph is easy for people, tools and AI agents to generate and review.
• One definition, many callers. Start the same workflow from REST, the web UI, the Go CLI or an MCP client such as Claude.
• Reactive end to end. Built on Spring WebFlux and Project Reactor. Nodes are non-blocking streams, and I/O runs on virtual threads.
• Observable and controllable. Live DAG view, SSE log and status streams, and run controls: pause, resume, stop, restart, skip, retry, step and breakpoints.
• Extensible. Plugins are Spring beans implementing a small interface from plugin-api. Adding one does not touch core.
• Safe to start with. It binds to loopback by default, and an API key guards /api/** and /mcp when you expose it.

Project status

Yukta is in alpha (0.1.0-alpha.2). The engine, plugins, REST API and MCP server run and are covered by tests. The first release ships a native Linux (amd64) server, a Docker image and the client; expect breaking changes to the workflow JSON schema and the APIs before v0.1.0.

Path to beta: more platforms (ARM Linux, macOS, Windows) · CHANGELOG.md · user-facing docs · stable workflow schema and REST/MCP contracts.

Quick start

The quickest way is the one-command installer (installs the server yukta and the client yukta-cli, no Java needed): curl -fsSL https://github.com/infenia/yukta/releases/download/v0.1.0-alpha.2/install.sh | sh on Linux (the alpha installs the client only on macOS). Or use Docker: docker run --rm -p 127.0.0.1:8080:8080 -e YUKTA_API_KEY=change-me ghcr.io/infenia/yukta:0.1.0-alpha.2 (add -H "X-API-Key: change-me" to the curl commands below). To run from source instead you need JDK 25 and curl:

git clone https://github.com/infenia/yukta.git
cd yukta
./gradlew bootRun

Then open the web UI at http://localhost:8080/ or the API docs at http://localhost:8080/swagger-ui.html.

Create a session with one workflow, start it and read the result:

# 1. Create a session containing a workflow
curl -X POST http://localhost:8080/api/sessions -H "Content-Type: application/json" -d '{
  "sessionId": "demo",
  "name": "Quick demo",
  "description": "Quick demo",
  "initiator": "me",
  "projectPath": "/tmp/demo",
  "workflows": {
    "hello": {
      "workflowId": "hello",
      "description": "Echo a greeting",
      "nodes": [
        { "nodeId": "start", "type": "CONSTANT_SOURCE", "config": {} },
        { "nodeId": "echo",  "type": "PROCESS_EXECUTOR", "config": { "command": ["echo", "Hello from Yukta!"] } },
        { "nodeId": "done",  "type": "CONSOLE_TERMINAL", "config": {} }
      ],
      "edges": [
        { "source": "start", "target": "echo" },
        { "source": "echo",  "target": "done" }
      ]
    }
  }
}'

# 2. Start it (returns 202 with data.executionId)
curl -X POST http://localhost:8080/api/workflow/start -H "Content-Type: application/json" \
  -d '{ "sessionId": "demo", "workflowId": "hello" }'

# 3. Check the status, or follow it live over SSE
curl http://localhost:8080/api/executions/{executionId}
curl -N http://localhost:8080/api/executions/{executionId}/status/stream

Sessions are held in memory, so apply them again after a restart.

More examples

examples/ has ten ready-to-run workflows, each with a config, a trigger and a test script:

Run them all against a local server with examples/run-all.sh.

How it works

A session groups workflows. A workflow is a DAG of nodes and edges. Each node is a plugin instance with its own config. A run is an execution that you can watch, pause, stop and restart.

 Transport      REST API (web) · MCP server (mcp) · Web UI (ui) · CLI (cli)
                                    │
 Orchestration  core: DAG validator → compiler → reactive executor (Project Reactor)
                                    │
 Plugins        plugin-api + plugins: Trigger → Processor → Terminal
                ExecutionSupervisor (control bus)

Every workflow needs at least one trigger (no inbound edges) and at least one terminal (no outbound edges), with processors in between. The orchestrator checks reachability, cycles and entry points before it runs anything.

Processors can expose named output ports (for example success and failure, or one port per BRANCH case), so one node can route messages down different paths.

Plugins

34 built-in plugins. Type strings are used exactly as written below; their case and separators are not consistent yet.

Triggers start a workflow

Processors transform, route and call out

Terminals end a branch

Supervisors observe and gate control-bus commands. plugins/supervisors/rule-supervisor runs declarative rules from a JSON file; enable it with yukta.supervisor.rules.file. Control planes (plugins/control-planes) decide one command per event: rule-control-plane (the same rules), model-control-plane (a small model; yukta.control-plane.model.name) and rules-first-control-plane (rules first, model only when no rule fired).

Write your own

Implement TriggerPlugin, ProcessorPlugin or TerminalPlugin from plugin-api and register it as a Spring bean. See plugin-api/CLAUDE.md and plugins/CLAUDE.md, or ask the MCP tool get_plugin_creation_guide for a template. GET /api/plugins/{type} shows the configuration schema of any installed plugin.

MCP server

Yukta runs an MCP server in the same process, always on at http://localhost:8080/mcp (streamable HTTP; /sse is an alias). Point any MCP client at it so an agent can create sessions, start workflows and read logs.

claude mcp add --transport http yukta http://localhost:8080/mcp

• 17 tools: list_sessions, get_session_details, create_session, get_session_creation_instructions, get_workflow_details, start_workflow, get_workflow_status, get_workflow_history, control_workflow, control_node, set_node_breakpoint, signal_node, get_execution_logs, list_plugins, get_plugin_details, get_plugin_creation_guide, get_control_bus_status
• 2 prompts: debug-workflow, create-session-config
• 3 resources: yukta://overview, yukta://architecture, yukta://sessions/{sessionId}/executions/{executionId}/logs

MCP uses the REST keys (yukta.api-key, yukta.api-keys) plus the optional yukta.mcp.api-key, sent as Authorization: Bearer <key> (or X-API-Key); each tool call needs the key's role (VIEWER reads, OPERATOR also starts and controls, ADMIN everything) and, for a session-limited key, its own sessionId. It is open only on loopback with no key.

REST API

Base path /api. Interactive docs are at /swagger-ui.html.

List endpoints take ?limit=&cursor= and return the next page in the X-Next-Cursor header. The older /api/workflow/{sid}/{eid}/… paths still work as deprecated aliases.

Security

The server listens on 127.0.0.1 by default. To expose it, set YUKTA_SERVER_ADDRESS=0.0.0.0 and yukta.api-key (the server refuses to start on another address without a key; the Docker image needs -e YUKTA_API_KEY=<key>); clients then send Authorization: Bearer <key> (or X-API-Key) on every /api/** call. For several people or agents use yukta.api-keys[i].name/key/role with VIEWER (read), OPERATOR (also start and control executions) or ADMIN (everything); control commands are then audited as key:<name>. PROCESS_EXECUTOR refuses every command until you set yukta.process.allowed-commands or, for trusted authors only, yukta.process.allow-any=true. Some plugins run processes, scripts and SQL, so treat workflow authorship as a trusted operation. Report vulnerabilities as described in SECURITY.md.

Web UI and CLI

• Web UI: a React 19 + Vite + Tailwind CSS 4 app served at /. Browse sessions, watch a live DAG view of a run, see execution history, use the control console and build workflows with a form-based editor.
• CLI: a Go + Cobra client for a remote Yukta server, in cli/.

Building from source

./gradlew bootRun          # run the server
./gradlew nativeCompile    # optional GraalVM native image (needs a GraalVM JDK)
./gradlew check            # tests + Checkstyle + PMD + SpotBugs + JaCoCo (+ OpenGrep if installed); with Yukta: yk check
./gradlew spotlessApply    # format before committing; with Yukta: yk gradle spotlessApply

These plain Gradle commands work anywhere; in Claude Code the build, test and check ones go through yk.

Developing Yukta with Yukta. Contributors (and Claude Code, which is held to it by hooks) run builds, tests and checks through examples/11-dogfood/yk. Each Gradle call becomes a Yukta workflow on a local dev server that is always built from origin/main and listens on http://127.0.0.1:9858 (web UI, REST and MCP; YUKTA_DEV_PORT overrides). yk check is the staged, self-healing quality gate; see examples/11-dogfood/README.md.

Persistence. By default sessions, workflow definitions and the execution log live in memory; yukta.session.store-type=file and yukta.execution-log.dir keep them on disk in the Plus build (-Pyukta.edition=plus, AGPL-3.0-only; see LICENSING.md). For PostgreSQL build with ./gradlew bootJar -Pyukta.persistence=postgres and run with SPRING_PROFILES_ACTIVE=prod,postgres, SPRING_R2DBC_URL=r2dbc:postgresql://host:5432/yukta (run time, reactive) and SPRING_FLYWAY_URL=jdbc:postgresql://host:5432/yukta (schema migrations only, since Flyway has no R2DBC support), with the matching *_USERNAME/*_PASSWORD (SPRING_FLYWAY_USER/SPRING_FLYWAY_PASSWORD). Tests of this module need Docker.

Built with Java 25, Spring Boot 4.1 (WebFlux), Gradle 9.8, Project Reactor, Spring AI MCP, GraalVM, React 19 and Go.

Repository layout

Each module has its own CLAUDE.md with build commands and architecture notes.

Contributing

Contributions are welcome: bug reports, plugins, docs and tests.

1. Read CONTRIBUTING.md and the Code of Conduct.
2. Branch from main, run ./gradlew spotlessApply, and make sure ./gradlew check passes.
3. Use Conventional Commits and open a pull request.

Open an issue for bugs and feature requests.

License

Apache License 2.0 for the Community edition. The plus/ directory (single-node durable storage on disk) is AGPL-3.0-only, with a commercial licence available. See LICENSING.md and LICENSE. The repository follows the REUSE specification.

Developed by Infenia Private Limited. Yukta (युक्त) is Sanskrit for "united" or "joined."
