Plant-Gene-Copilot-MCP-server

A lightweight, open-source MCP (Model Context Protocol) frontend for structured plant genomics research.
It connects to a backend MCP server that provides unified function-style tools for gene lookup, identifier normalization, multi-source annotation retrieval (NCBI/UniProt/KEGG/InterPro/Pfam), genome localization (GFF-derived), and literature search (PubMed), enabling LLM agents to access plant genomic knowledge in a consistent and reproducible way.

Key Features

  • Unified MCP tool interfaces for plant functional genomics workflows
  • Gene-centric retrieval: gene search, ID normalization, cross-database aliases
  • Annotation integration: NCBI Gene, UniProt, KEGG, InterPro + Pfam/CDD/SMART mappings
  • Genome context: chromosome coordinates, neighborhood genes, genomic location visualization
  • Protein interaction utilities via STRING (resolution, network, enrichment)
  • Literature retrieval via PubMed (basic + advanced query + article details)
  • Designed for tool-augmented LLM agents and reproducible bioinformatics pipelines

Architecture

This repository provides the MCP frontend (MCP tool client).
The backend MCP server (not included unless you add it) bridges MCP tool calls to an intermediary API service and underlying MySQL repositories.

High-level flow

  1. MCP Frontend (this repo)
  2. MCP Server endpoints (tool definitions)
  3. Intermediary API service (query optimization + data integrity)
  4. MySQL knowledge bases + external sources integrations

Backend Knowledge Bases (for reference)

  • Functional Knowledgebase (9 tables; 1,535,469 records)
    • genes, main_entry, uniprot, kegg_details, ncbi_gene_details, interpro_main, interpro_pfam, interpro_cdd, interpro_smart
  • Annotation Module / GFF database (7 species tables; 294,808 records)
    • GFF-derived gene features for: Arabidopsis thaliana, Zea mays, Solanum lycopersicum, Populus nigra, Populus trichocarpa, Oryza sativa ssp. japonica, Marchantia polymorpha
  • Total: 16 tables; 1,830,277 records (~1.83M)

Tool List (MCP Functions)

The tools below are grouped by function. Names shown in code are the friendly/logical names; the exact names registered with the MCP client are the Python function names in mcp_server.py, which use snake_case (e.g. geneSearch below is exposed as gene_search). Verify against the @mcp.tool() decorated functions in the source before scripting.

1) Gene lookup & identifier normalization

  • geneSearch(gene_name, extended_search=false)
    Search genes by symbol/name/gene_id; supports multiple queries separated by ;.
    Returns curated gene records and RefSeq links when available.

  • fetchGeneId(gene_name)
    Resolve gene name → gene_id(s).

  • entrezgeneId(gene_id)
    Convert internal gene_id (e.g., AT1G01060) → NCBI Entrez Gene numeric ID (required by NCBI tools).

  • fetchExternaldbs(gene_id, max_results=10, compact=true)
    Retrieve aliases/synonyms and cross-database identifiers (TAIR/Araport/etc.) from NCBI mappings.

2) Genome annotation & localization (GFF)

  • fetchGffAnnotation(gene_id)
    Returns chromosome coordinates, genomic neighborhood context, and genome-location visualization URL(s).

3) NCBI Gene: structure & transcripts

  • fetchNcbiInfo(entrezgene_id)
    Gene summary and an exon–intron structure visualization (image link) from NCBI Gene.

  • fetchGeneStructureDetails(entrezgene_id)
    Transcript/exon/intron coordinate details for alternative splicing analyses.

4) UniProt protein metadata

  • fetchUniprotEntry(gene_id, extentional_search=false)
    Resolve gene_id(s) → UniProt entry/entries.

  • fetchUniprotDetails(entries)
    Retrieve detailed UniProt annotations for entries (includes UniProt links).

5) KEGG functional annotation

  • fetchKeggInfo(kegg_id)
    Retrieve pathways, orthology, GO terms, enzyme/reaction, and DB links.

6) InterPro / Pfam domain & family annotation

  • fetchInterpro(interpro)
    InterPro entry details.

  • fetchPfam(pfam)
    Pfam domain details.

7) PubMed literature retrieval

  • fetchPmid(query, max_results=20)
    Basic PubMed query → PMIDs and titles.

  • pubmedAdvancedSearch(query, page=1, sort="relevance", date_from="", date_to="", article_type="")
    Advanced PubMed search with pagination and filters.

  • fetchDetails(pmid)
    Retrieve full article metadata (title/authors/abstract/DOI/etc.) for PMID list.

8) STRING protein interaction utilities

  • stringQuerySpecies(species_text)
    Resolve species name/taxon hints for STRING.

  • stringResolveProteins(proteins, species, show_sequence)
    Map identifiers → STRING IDs.

  • stringInteractionsQuerySet(proteins, species, required_score, network_type, extend_network)
    Get interactions among a given query set.

  • stringAllInteractionPartners(identifiers, species, required_score, network_type)
    Retrieve all partners for proteins.

  • stringEnrichment(proteins, species)
    Functional enrichment over a protein list.

  • stringFunctionalAnnotation(identifiers, species)
    Retrieve functional annotations.

  • stringVisualNetwork(proteins, species, required_score, network_type, network_flavor, extend_network, hide_disconnected_nodes)
    Generate a network image URL.

  • stringNetworkLink(proteins, species, required_score, network_type, network_flavor, extend_network, hide_disconnected_nodes)
    Generate an interactive network link.

  • stringInteractionEvidence(identifier_a, identifiers_b, species)
    Evidence pages for edges.

  • stringHomology(proteins, species, species_b)
    Homolog lookup.

  • stringPpiEnrichment(identifiers, species, required_score)
    Check PPI enrichment.

  • stringProteinsForTerm(species, term_text)
    Proteins annotated with a given functional term.

  • stringSequenceSearch(sequences, species)
    Sequence-based lookup in STRING.

  • stringEnrichmentImageUrl(identifiers, species, category)
    Enrichment plot URL.

  • stringHelp(topic)
    Help for STRING tool features.

9) Service health

  • checkInitialization()
    Whether the backend services are initialized and reachable.

Quick Start

The server needs Python 3.10+. It talks to an existing backend API (http://api.plantgenecopilot.top, overridable in config/server.config) plus the public STRING and NCBI E-utilities services.

1. Install dependencies

Using uv (recommended):

curl -LsSf https://astral.sh/uv/install.sh | sh        # macOS / Linux
# or: powershell -ExecutionPolicy ByPass -c "irm https://astral.sh/uv/install.ps1 | iex"

Or with pip + venv (no extra tooling):

python -m venv .venv
source .venv/bin/activate          # macOS / Linux
# .venv\Scripts\Activate.ps1        # Windows (PowerShell)
pip install -r requirements.txt

2. Configure API access

Edit config/server.config before running:

  • ncbi_config.email — a valid email (required by NCBI E-utilities policy).
  • ncbi_config.api_key — your NCBI API key (optional, raises rate limits). Obtainable at https://www.ncbi.nlm.nih.gov/account/settings/.
  • api_base_url — backend API address. Change it if you run your own backend instead of the hosted one. The base_url, server_port and timeout entries tune the STRING service.

3. Run

python mcp_server.py

The server starts over HTTP transport on 0.0.0.0:1154 (see the log output). Point any MCP-compatible client (Claude Desktop, Dify, or a FastMCP client) at that endpoint to begin querying plant-genomics tools. Press q to stop.

Calling a tool from your own code

With a FastMCP/anyio MCP client, connect to the endpoint and call a tool by its registered name, for example gene_search(gene_name="AtDCL1"):

import asyncio
from fastmcp import Client

async def main():
    async with Client("http://localhost:1154") as client:
        resp = await client.call_tool("gene_search", {"gene_name": "AtDCL1"})
        print(resp)

asyncio.run(main())

Note: tool names use snake_case as registered in mcp_server.py (e.g. gene_search, fetch_gene_id, fetch_pmid). The full annotated tool list is in the next section.

本项目的 AI API 支持由 Tokeness.io 赞助提供。

Benchmark & Reproducibility

This manuscript evaluates PGCopilot with two complementary experiments, and this repository makes both fully reproducible.

Automated evaluation measures whether adding the MCP tool layer improves the accuracy of six LLMs on 565 expert-written plant-biology multiple-choice questions (308 "target-plant" + 257 "non-target" subsets). Expert evaluation then checks that this improvement is not just answer-key accuracy, by having 15 plant researchers blind-score the full agent on 10 open-ended questions. Both rely only on the files under workflow_evaluation/ and expert_evaluation/.

  • benchmark/model_outputs/ — per-question outputs for 6 models x 2 datasets (agent mode = LLM + MCP tools; LLM mode = no tools), with judge and objective correctness.
  • benchmark/summary_tables/ — Table 1 (performance comparison with McNemar significance), Table 2 (area breakdown), species-stratified accuracies with 95% Wilson CI, per-domain sample sizes, and a per-question answer table.
  • analysis/run_dify_evaluation.py — reproduces the evaluation by calling the Dify workflow API.
  • analysis/compute_summary_tables.py — reproduces the summary tables from model_outputs/.
  • analysis/mixed_effects_bootstrap.py — mixed-effects and clustered-bootstrap analyses of the expert evaluation.
  • analysis/eval_mcp_workflow_target.yml — the exported Dify workflow DSL.

1) Automated workflow evaluation — workflow_evaluation/

What it measures. Each model runs each question in two modes — agent mode (LLM + MCP tools) and plain LLM mode (no tools) — and we compare accuracy. The questions come from the Expert MoBiPlant benchmark (Burda et al., 2025), written and reviewed by plant biologists.

Inputs & outputs (machine-readable, no guessing):

  • datasets/ — the benchmark as JSON. expert_mobi.json (all 565), plus the two subsets used in the paper: filtered_species.json (308 questions on model/species covered by PGCopilot's databases) and other_species.json (257 non-target/species-specific questions). Every entry carries the full question, the 3 answer choices, the correct-answer index, the target species, research area, and its provenance (source/doi/journal/year/citations).
  • model_outputs/ — one CSV per model × dataset with the raw per-question response and correctness in both modes (6 models × 2 datasets = 12 files).
  • summary_tables/ — the derived tables used in the paper: overall performance with McNemar significance, per-research-area and per-species accuracies with 95% Wilson confidence intervals, per-domain sample sizes, and a merged per-question answer table.
  • analysis/ — the scripts that reproduce the whole pipeline.

To re-run a model (requires a Dify app with your own LLM key):

cd workflow_evaluation/analysis
python run_dify_evaluation.py \
    --benchmark ../datasets/filtered_species.json \
    --dataset target \
    --model-label DeepSeek-V3.2 \
    --output ../model_outputs/DeepSeek-V3.2_target.csv

To regenerate every summary table from the raw outputs (no API calls):

cd workflow_evaluation/analysis
python compute_summary_tables.py --inputs ../model_outputs/ --outdir ../summary_tables/

2) Human expert evaluation — expert_evaluation/

What it measures. 15 plant researchers (PIs, PhD and master's students) scored PGCopilot and three comparison systems on 10 open-ended questions, across 7 criteria (relevance, factual accuracy, completeness, citation verifiability, evidence support, hallucination control, research utility) on a 0–10 scale — 1,050 ratings in total. The panel was blinded to which system produced each answer.

  • system/ — the Flask + MySQL web app that collected the (blinded) ratings.
  • data/expert_scores_anonymized.xlsx — all 1,050 ratings, rater identities replaced by Rater01–Rater15, plus the ICC, significance-test, scoring rubric and benchmark-question sheets.
  • analysis/mixed_effects_bootstrap.py — mixed-effects + clustered-bootstrap analysis of the model contrasts (Table S11 in the manuscript).

To re-run the statistics (reads the anonymized workbook, writes a table + forest plot):

cd expert_evaluation/analysis
python mixed_effects_bootstrap.py

Outputs are written to expert_evaluation/results/.
