MCP-PowerBi-Finvision

A production-ready Model Context Protocol (MCP) server for Power BI Desktop. Drives the live model and PBIP files via .NET interop — DAX execution and debugging, TOM CRUD, TMDL automation, PBIR report authoring, BPA, query plans, codemods, dependency graphs, and a live Power BI Desktop bridge (in-place reload + screenshot).

28 tools across 11 categories, all running locally over stdio. No exposed ports, no cloud calls.

Highlights

• Live model CRUD via TOM — tables, columns, measures, relationships, calc groups, RLS, perspectives, cultures, OLS, field parameters, annotations
• DAX: execution with auto-trace, query-plan capture/parse/analyze (logical, physical, xmSQL), benchmarks, codemods (inline_measure, extract_measure, replace_pattern, move_measure_batch, swap_table_reference), dependency graph, impact analysis
• TMDL automation: export, find/replace, bulk rename, migration, daxformatter.com integration
• PBIP/PBIR authoring: page CRUD, visual CRUD with field binding, themes, conditional formatting, bookmarks, slicer config, Q&A linguistic schema
• Debugging: visual debugger fusing PBIP layout + live model data, SE/FE trace, cross-visual validation, filter permutation, decomposition, root-cause, page profiling
• Live Desktop loop: 17_Desktop_Bridge reloads a running Desktop in place (report, or metadata-only TMDL with include_model: true behind a change classifier), saves via UI automation with on-disk verification, screenshots pages / individual visuals; fail-closed guard against discarding unsaved work (Microsoft Desktop Bridge CLI ≥ 1.0.0 supported)
• Analysis & reporting: BPA (curated ~72-rule set + Microsoft/Tabular Editor rulesets), model comparison, structured dependency graph, Word documentation, interactive HTML reports

Requirements

Quick start

1. Install

From package (recommended):

1. Download the latest .mcpb from releases
2. Open Claude Desktop → Settings → MCP Servers → Install from file
3. Select the .mcpb file

From source with the setup script (recommended): Run MCP Server Setup.bat from a clone of this repo, or on its own: it then clones this repo for you (set MCP_CLONE_DIR=C:\repos skips the folder dialog; MCP_REPO_URL points it at a fork). It installs Python 3.12+ and uv if missing, builds venv\ (a re-run reuses it), installs requirements.txt (including the vendored pbi-perf-core\) and the optional masking engines (requirements-optional.txt; skip with set MCP_SETUP_SKIP_OPTIONAL=1), verifies the imports, registers the server in Claude Desktop, in Claude Code (when the claude CLI is present) and in VS Code for GitHub Copilot agent mode (when the code CLI is present, via code --add-mcp), and sets up client masking on demand. Restart the client afterwards. Clone to a short path (the deepest file is ~135 characters) or enable git config --global core.longpaths true.

From source by hand:

git clone https://github.com/bibiibjorn/mcp-powerbi-finvision.git MCP-PowerBi-Finvision
cd MCP-PowerBi-Finvision
python -m venv venv
venv\Scripts\activate
pip install -r requirements.txt

Add to your MCP client config:

{
  "mcpServers": {
    "mcp-powerbi-finvision": {
      "command": "python",
      "args": ["path/to/MCP-PowerBi-Finvision/src/run_server.py"],
      "env": { "PYTHONIOENCODING": "utf-8" }
    }
  }
}

2. Connect to a running PBI Desktop instance

01_Connection { operation: "detect" }
01_Connection { operation: "connect", model_index: 0 }

3. Inspect

02_Model_Operations { object_type: "table",   operation: "list" }
02_Model_Operations { object_type: "measure", operation: "list" }
04_Run_DAX         { query: "EVALUATE TOPN(10, 'Sales')" }

4. Common workflows

Analyze a measure:

05_DAX_Intelligence { expression: "[Total Sales]", analysis_mode: "all" }

Debug a slow visual (PBIP-aware — set path once, reuse):

09_Debug_Operations { operation: "set_path", pbip_path: "C:/path/to/Report.pbip" }
09_Debug_Operations { operation: "visual", page_name: "Overview", visual_name: "Sales by Region", trace: true }

Capture a query plan:

13_Query_Plan { operation: "capture", dax_query: "EVALUATE …" }
13_Query_Plan { operation: "analyze", capture_id: "<id-from-capture>" }

Bulk-add visuals to a page (UTF-8 safe via pbir CLI):

11_PBIP_Authoring { operation: "pbir_add_visuals",
                    pbip_path: "...",
                    page: "Overview",
                    visuals: [{ visual_type: "card", x: 16, y: 16,
                                width: 220, height: 100,
                                fields: { Data: "Measures[Total Sales]" } }] }

Reload the running Desktop after file edits and look at the result:

17_Desktop_Bridge { operation: "reload_and_screenshot", pbip_path: "...", page_name: "Overview" }
17_Desktop_Bridge { operation: "reload", pbip_path: "...", include_model: true }   # metadata-only TMDL edits

For a comprehensive walkthrough of every tool with worked examples, see docs/GUIDE.md (Part I, the user guide; python build/md_to_pdf.py exports the whole guide to a PDF).

Tool catalog

28 tools across 11 categories. Names follow NN_Tool_Name where NN reflects category order.

Full per-operation reference (every parameter, every gotcha): Part III of docs/GUIDE.md; in-server: 10_Show_User_Guide tool=<name>.

Safety: gate policy

Destructive operations are gated by MCP_AUTONOMOUS_GATE_POLICY:

Break-glass: confirm_destructive=true per call.

Reload hints

PBIP-disk-write ops (visual/page/authoring/theme/TMDL/bookmark) return:

{ "...": "...", "reload_required": true,
  "reload_op_chain": ["17_Desktop_Bridge:reload_and_screenshot"] }

Live-TOM ops (02_Model_Operations) propagate immediately — no reload needed.

Architecture

┌──── MCP stdio (Claude / any MCP client) ────┐
│                                              │
│  src/run_server.py → pbixray_server_enhanced │
│           │                                  │
│           ▼                                  │
│   server/ (MCP protocol layer)               │
│      ├── registry.py     (HandlerRegistry)   │
│      ├── dispatch.py     (ToolDispatcher)    │
│      ├── middleware.py   (truncation, json)  │
│      ├── pbip_cache.py   (LRU PBIP cache)    │
│      └── handlers/       (28 tool handlers)  │
│           │                                  │
│           ▼                                  │
│   core/  (domain logic, no MCP awareness)    │
│      ├── infrastructure/ (TOM, ADOMD, DLL)   │
│      ├── operations/     (CRUD managers)     │
│      ├── dax/            (analyzer, codemods)│
│      ├── tmdl/           (parser, models)    │
│      ├── pbip/           (PBIR engines)      │
│      ├── analysis/       (BPA)               │
│      ├── comparison/     (model diff)        │
│      └── autonomous/     (bridge, gating)    │
│                                              │
│   lib/dotnet/  (AMO + ADOMD DLLs)            │
└──────────────────────────────────────────────┘

Bootstrap asserts exactly 28 tools registered, fails fast on mismatch.

For full architecture, file paths, class names, and gotchas: CLAUDE.md.

Development

Run tests

python run_tests.py              # canonical entrypoint (preferred)
python run_tests.py --fast       # skip @pytest.mark.slow
python run_tests.py --verbose --cov
python run_tests.py --file test_foo
pytest                           # also works

Lint and type check

black --check --line-length 100 core server src client_gateway hooks tools tests pbi-perf-core
flake8 core server src client_gateway hooks tools tests pbi-perf-core   # .flake8
mypy core server src client_gateway                                      # mypy.ini: strict modules + legacy baseline

Package

mcpb pack                        # @anthropic-ai/mcpb: builds a .mcpb from manifest.json

Project structure

MCP-PowerBi-Finvision/
├── src/                  # entrypoint (run_server.py)
├── server/               # MCP protocol layer
│   ├── registry.py       # HandlerRegistry, ToolDefinition, ToolCategory
│   ├── dispatch.py       # ToolDispatcher (cached security flags)
│   ├── middleware.py     # token estimation + key compaction
│   ├── pbip_cache.py     # PbipModelCache LRU
│   └── handlers/         # 28 tool handlers + sub-handlers
├── core/                 # domain logic, no MCP awareness
│   ├── infrastructure/   # connection, query exec, DLL loading
│   ├── operations/       # CRUD managers (TOM)
│   ├── dax/              # analyzer, plans, codemods, RLS
│   ├── tmdl/             # parser, models, generators
│   ├── pbip/             # scanner, deps, authoring engines
│   ├── analysis/         # BPA analyzer
│   ├── comparison/       # model diff/compare
│   ├── config/           # config_manager + default_config.json
│   ├── utilities/        # json_utils, mermaid, html
│   └── autonomous/       # desktop bridge, gating, evidence, reload hints
├── config/               # default + local overrides
├── lib/dotnet/           # AMO + ADOMD DLLs
├── tests/                # pytest suite
├── docs/                 # GUIDE.md (the one guide), visual-catalog, design-principles
├── build/                # packaging scripts
├── manifest.json         # MCP manifest
└── CLAUDE.md             # exhaustive project reference

Documentation

• CLAUDE.md — exhaustive project reference (every tool, every operation, every parameter, every gotcha, every internal helper)
• docs/GUIDE.md — the one guide: user guide with worked examples and workflows, client masking, tool reference (every operation), architecture, PBIR reference (file format + pbir CLI) and the agentic stack index
• docs/visual-catalog/ — per-visual-type reference (43 files)
• docs/design-principles/ — reasoning + self-audit checklists (7 topics)

What's new in 7.21

7.21.0 adds the universal masking gateway (client gateway 1.7.0); details in Part II of docs/GUIDE.md.

• Masking on demand (2026-10-08) — in Claude Code the user types masking on: the gateway starts and that chat's folder is routed through it; masking off sends it direct again and the gateway stops by itself. Nothing runs until then.
• Desktop apps (opt-in, setup --desktop-apps) — VS Code Copilot and ChatGPT in the browser are masked and restored through a local TLS front end with one adapter per wire format; switched off only by the user typing masking off.
• Routing and lifecycle — a name-constrained local CA, a per-user PAC that sends only the AI hosts to the gateway, a gateway that lives and dies with the Power BI MCP (no service, no autostart), exact backup and restore of the proxy settings.
• python -m client_gateway setup — one human-run command: a plan by default, --yes to apply, --remove to undo, --status, --register for Claude Desktop / VS Code / Claude Code, managed-PC check.
• 00_Client_Mode setup and selftest, generic and finvision profiles, a format-agnostic leak scan and a per-app replay self-test (update-proofing).

What's new in 7.20

7.20.0 is the release that follows 7.16.0 (git labels v7.17-v7.19 were internal milestones, so the number stays monotonic). Highlights of the 2026-10 deep-review work, newest first:

• Safety — preview-with-diff on every live write, a data/metadata permission split with policy rules, request_id on every result, compare_models on compare_targets, graph direction aliases.
• Trace and perf — trace-to-visual mapping, perf record/regress history, progress + cancel on long operations, a soft inline-result budget, a 04_Run_DAX batch mode.
• BPA — select/patch engine that applies BPA FixExpressions; 06_Analysis_Operations ruleset=audit with the audit taxonomy.
• Testing, API, report and model features — F-01..F-34 subset (persisted test suites, offline PBIP model lane, XMLA read-only gate, journal undo/replay hardening, fail-closed reload classifier).
• DAX — canon-conformant analyzer and BPA, safe codemods, find_clones / extract_udf, explain, a local formatter.
• Client gateway — recognition, state, control-surface and engine-matching fixes (G-01..G-28).
• Performance and cleanup — PBIP watcher-validated caches, memoised graph/lineage/TMSL, faster CLR conversion, one DAX validation per query, orjson; about 4k dead lines removed, then a final pass (unused code, quoting helpers, AMO mixins, module splits).
• Lint truth — root mypy.ini (strict for the clean new modules, legacy modules listed with ignore_errors), .flake8, a black pass at --line-length 100; see Lint and type check below.

Version history

v7.x (current)

• v14 expansion (24 → 28 tools) — added 02_QA_Linguistic (Q&A linguistic schema CRUD), 13_Query_Plan (DAX query-plan capture/analyze), 15_DAX_Refactor (bulk DAX refactor transforms with plan_hash check, was 15_DAX_Codemods), 16_Dependency_Graph (structured queryable graph). Calc-group migration was merged into 02_Model_Operations object_type='calculation_group' (detect/scaffold/list_patterns). v7.6 trim removed SVG_Visual_Operations (unused) → 27 tools.
• 02_Model_Operations extensions — measure/set_format_string_expression (CL 1606+ dynamic format string), culture/bulk_set_translations, perspective membership ops, field-parameter mutations (add_field/remove_field/reorder_fields), calculation_group/set_precedence.
• 04_Query_Operations extensions — dmv_probe + list_dmv_probes (8 probes incl. vertipaq_columns, calc_dependency, sessions, refresh_policies). simulate_as_user (Desktop RLS workaround). impersonate_run for Service/SSAS impersonation.
• Cascade rename — 02_Model_Operations table/column/measure rename now accepts pbip_path and rewrites PBIR JSON references via CascadeRenameEngine.apply_renames_typed (parent-kind aware — column rename of Foo doesn't touch field.Measure.Property == "Foo").
• Semantic git diff — 07_PBIP_Operations:git_diff populates per-file details with {measures, columns, relationships, roles} added/modified/removed.
• Version labels — the server version is 7.21.0 (src/__version__.py, manifest.json, python/pyproject.toml). Git commit messages that say v7.17-v7.19 were internal milestones (trace fixes and a since-removed masking design), not releases; 7.20.0 is the next release after 7.16.0.
• Visual catalog & design principles — A-layer + B-layer references under docs/.

v13 consolidation

• 38 tools → 24 across 11 categories
• 01_Connection (detect+connect merged)
• 02_Model_Operations (5→1 for CRUD)
• 03_Batch_Operations (transactions internalized)
• 07_Visual_Operations dispatches to 3 sub-handlers (visual_layout_handler, visual_config_handler, visual_creation_handler)

v5.x

• Hybrid analysis features
• Token-optimized response format
• Pattern-based fuzzy search

Contributing

PRs welcome. Before adding a new tool or operation, check CLAUDE.md §5 for the registration pattern and gating helper. The bootstrap assertion in server/handlers/__init__.py enforces a known tool count — bump it when adding a tool.

License

MIT — see LICENSE.

Author

Finvision — @bibiibjorn

Issues and feature requests: GitHub issues.

Acknowledgments

• Model Context Protocol
• pythonnet — .NET interop
• PBIXRay — model analysis primitives
• pbir CLI — PBIR authoring

Note: This server runs entirely locally. No data leaves your machine — all communication is stdio between the MCP client and the server.
