Yuerenge Database MCP

Package Structure

The package follows a modular architecture organized as:

yuerenge_database_mcp/
├── config/          # Configuration management
├── db_tools/        # Database operations and tools
│   ├── connections/ # Connection management
│   ├── core/        # Core database functionality
│   ├── formatting/  # Data formatting utilities
│   ├── operations/  # Database operations
│   └── utils/       # Utility functions
└── server_lifecycle.py # Server lifecycle management

A database management tool based on the Model Context Protocol (MCP).

This package follows a modular architecture with separate modules for configuration management, database operations, and server lifecycle management.

Features

Support for multiple databases (MySQL, Oracle, PostgreSQL, SQLite, SQL Server)
Connection management
Table structure operations
Data querying and manipulation
Advanced configuration management with validation
Database adapter pattern for easy extension

Installation

pip install yuerenge-database-mcp

Package Modules

The package is organized into several modules:

config: Handles database configuration loading, validation, and management
db_tools: Contains all database operation tools and utilities
- connections: Manages database connections and adapters
- core: Core database management functionality
- formatting: Data formatting utilities for different output formats
- operations: Data and table operation implementations
- utils: Utility functions including logging and specialized utilities

Quick Start

Install the package:
```
pip install yuerenge-database-mcp
```
Run the server directly:
```
yuerenge-database-mcp
```
Or run with Python module syntax:
```
python -m yuerenge_database_mcp
```

Create a configuration file (optional, uses defaults if not provided):

{
  "connections": [
    {
      "name": "my_mysql_db",
      "type": "mysql",
      "host": "localhost",
      "port": 3306,
      "username": "user",
      "password": "password",
      "database": "mydb",
      "enabled": true
    }
  ]
}

Run the server:
```
yuerenge-database-mcp
```

Or run with a specific configuration:

DATABASE_CONFIG_PATH=/path/to/your/config.json yuerenge-database-mcp

Usage

After installation, you can run the database MCP server:

yuerenge-database-mcp

Or with a specific configuration file:

DATABASE_CONFIG_PATH=/path/to/your/config.json yuerenge-database-mcp

You can also run the server using the Python module syntax:

python -m yuerenge_database_mcp

Or using the run_server.py script:

python run_server.py

Configuration

The tool uses a JSON configuration file to store database connection information.

Configuration priority (highest to lowest):

Environment variable DATABASE_CONFIG_PATH
Default configuration file (config/database_config.json)

Configuration Validation

The configuration manager validates all connection configurations to ensure:

All required fields are present
Port numbers are valid (1-65535)
Database types are supported
Enabled flags are boolean values

Supported Database Types

MySQL
Oracle
PostgreSQL
SQLite
SQL Server

Connection Pool Settings

You can configure connection pool settings for each database connection:

{
  "connections": [
    {
      "name": "my_mysql_db",
      "type": "mysql",
      "host": "localhost",
      "port": 3306,
      "username": "user",
      "password": "password",
      "database": "mydb",
      "enabled": true,
      "pool_size": 5,
      "max_overflow": 10,
      "pool_timeout": 30,
      "pool_recycle": 3600
    }
  ]
}

Available connection pool settings:

pool_size: The number of connections to keep open inside the connection pool (default: 10)
max_overflow: The number of connections to allow in connection pool "overflow" (default: 20)
pool_timeout: The number of seconds to wait before giving up on getting a connection from the pool (default: 30)
pool_recycle: Number of seconds after which to recreate idle connections (default: 3600)

Environment Variables

The server supports the following environment variables:

DATABASE_CONFIG_PATH: Specifies the path to the database configuration file
ERROR_LOG_PATH: Specifies the directory where error logs will be stored (default: ./error_logs)

MCP Server Configuration

To use this as an MCP server, add the following configuration to your MCP client configuration.

Important: Only use uvx yuerenge-database-mcp if the package has been published to PyPI. If you are using a local checkout (like this repository), point the client at your local interpreter and the package directly instead, otherwise the client won't be able to find the server.

Local source checkout (Windows, recommended)

{
  "yuerenge-database-mcp": {
    "command": "D:\\File\\Workspace\\MCP\\yuerenge_database_mcp\\.venv\\Scripts\\python.exe",
    "args": [
      "run_server.py"
    ],
    "cwd": "D:\\File\\Workspace\\MCP\\yuerenge_database_mcp",
    "env": {
      "DATABASE_CONFIG_PATH": "D:\\File\\Workspace\\MCP\\yuerenge_database_mcp\\src\\yuerenge_database_mcp\\config\\database_config.json",
      "ERROR_LOG_PATH": "D:\\File\\Workspace\\MCP\\yuerenge_database_mcp\\error_logs"
    }
  }
}

Installed package (PyPI)

If you have installed the package from PyPI (or built and installed the wheel in dist/), you can use the console script directly:

{
  "yuerenge-database-mcp": {
    "command": "uvx",
    "args": [
      "yuerenge-database-mcp"
    ],
    "env": {
      "DATABASE_CONFIG_PATH": "path/to/config.json",
      "ERROR_LOG_PATH": "path/to/log/directory"
    }
  }
}

Tools Provided

This MCP server provides the following tools:

Connection Management Tools
- add_database_connection: Add a database connection
- remove_database_connection: Remove a database connection
- list_database_connections: List all active connections
Configuration Management Tools
- list_configured_connections: List all connections from the configuration file
- enable_configured_connection: Enable a connection in the configuration
- disable_configured_connection: Disable a connection in the configuration
- reload_configurations: Reload connections from the configuration file
Table Structure Tools
- list_tables: List all tables in the database
- get_table_structure: Get table structure information
- create_table: Create a new table
- drop_table: Drop a table
- alter_table: Alter table structure
Data Query Tools
- execute_query: Execute raw SQL queries
- select_data: Select data from a table and format it intelligently
Data Manipulation Tools
- insert_data: Insert data into a table
- batch_insert_data: Batch insert data
- update_data: Update data in a table
- batch_update_data: Batch update data
- delete_data: Delete data from a table
- batch_delete_data: Batch delete data
Advanced Query Tools
- select_data_smart: Format table data intelligently
- select_data_paged: Display table data in pages
- select_data_summary: Display summary of table data
- select_data_html: Display table data as HTML and open in browser

These tools are implemented across multiple modules within the db_tools package:

Core database operations are in the db_tools.core module
Connection management is in the db_tools.connections module
Data operations are in the db_tools.operations module
Data formatting is in the db_tools.formatting module
Utility functions are in the db_tools.utils module

Usage Examples

Adding a Database Connection

# Using the MCP client to call the tool
add_database_connection(
    name="mysql_test",
    db_type="mysql",
    host="localhost",
    port=3306,
    username="root",
    password="password",
    database="testdb",
    save_to_config=True
)

Querying Data

# Select data from a table
select_data(connection_name="mysql_test", table_name="users", conditions={"age": 25}, limit=10)

Inserting Data

# Insert a single record
insert_data(connection_name="mysql_test", table_name="users", data={
    "name": "John Doe",
    "age": 30,
    "email": "john@example.com"
})

Batch Operations

# Batch insert multiple records
batch_insert_data(connection_name="mysql_test", table_name="users", data_list=[
    {"name": "Jane Smith", "age": 28, "email": "jane@example.com"},
    {"name": "Bob Johnson", "age": 32, "email": "bob@example.com"}
])

Advanced Queries

# Smart formatting of query results
select_data_smart(connection_name="mysql_test", table_name="users", max_columns=8)

# Paged display of large datasets
select_data_paged(connection_name="mysql_test", table_name="large_table",
                  columns_per_page=5, rows_per_page=15)

# Display as HTML and open in browser
select_data_html(connection_name="mysql_test", table_name="users")

Best Practices

Connection Management
- Use configuration files to manage database connections, avoiding hardcoded sensitive information
- Set appropriate connection pool parameters for performance optimization
- Regularly use the reload_configurations tool to update connection settings
Data Operations
- For bulk data insertion, prefer the batch_insert_data tool
- Use the conditions parameter for precise queries to avoid full table scans
- Before executing update or delete operations, first use select_data to verify conditions
Data Presentation
- For tables with many columns, use select_data_paged or select_data_summary tools
- For data analysis scenarios, use select_data_html for better visualization
- Choose appropriate limit parameters based on data volume to prevent memory overflow
