WhatsApp消息发送与流程自动化MCP服务

WapiSender MCP 是一个官方 MCP 服务器，支持登录 WapiSender 账号、管理多个 WhatsApp 实例、发送文本/媒体/交互消息、管理联系人与 Webhook，并通过流程和 AI 凭证实现自动化。

  • by Wapi-Sender
  • TypeScript
  • 本地部署
  • 2 星标
  • 更新于
在 GitHub 查看 Wapi-Sender/WapiSender-MCP

使用说明

WapiSender MCP

Official MCP server for WapiSender. Use it from Claude Code, Codex, and other MCP-compatible clients to manage WhatsApp instances, send messages, manage contacts, configure webhooks, and build flows.

What This MCP Does

WapiSender MCP gives your MCP client access to the WapiSender platform through a stateful session.

It supports:

  • Logging into your WapiSender account with an MCP token
  • Listing and switching between WhatsApp instances
  • Refreshing live instance status and metadata
  • Sending text, media, voice notes, stickers, locations, buttons, lists, reactions, contact cards, and polls
  • Searching contacts and changing contact block status
  • Creating, updating, cloning, simulating, activating, and inspecting flows
  • Managing instance webhooks
  • Managing AI provider credentials used by flows

What's New in v0.2.0

This release realigns the MCP with the current WapiSender application and expands the catalog from 25 to 42 tools.

Messaging

  • Added voice-note, sticker, button, list, reaction, contact-card, poll, bulk-text, and personalized-template tools.
  • Updated interactive button payloads to use reply buttons shaped as type, displayText, and id.
  • Updated list rows to use rowId and list footers to use footerText.
  • Corrected the current reaction, poll, contact-card, audio, media, and location payload contracts.
  • Message tools now distinguish API acceptance from recipient-visible delivery.

Flows

  • Added current message_received and manual trigger types.
  • Added the current webhook and human-handoff node definitions.
  • Added atomic full-flow creation and cloning.
  • Added race-safe single-node updates through the dedicated node route.
  • Added simulate_flow and get_flow_logs for testing and execution inspection.

Contacts, instances, and webhooks

  • Added live instance refresh through ?live=true.
  • Added client-side contact search and pagination over WapiSender's normalized contact response.
  • Replaced the unsupported contact upsert with set_contact_block_status.
  • Corrected webhook updates to send the nested { webhook: ... } contract.

AI providers and self-hosting

  • Added Ollama, Mistral, DeepSeek, Groq, Kimi, and Hugging Face alongside the existing providers.
  • Added credential updates for API-key rotation, base URLs, models, labels, and active state.
  • Added WAPISENDER_BASE_URL for self-hosted WapiSender deployments.

Compatibility cleanup

  • Removed MCP tools for application routes that do not currently exist: QR retrieval, disconnect, number checking, chat history, mark-as-read, and contact deletion.
  • Added 30-second API request timeouts and clearer HTTP error handling.
  • Replaced duplicated test-only schemas with contract tests against the actual registered tools and emitted payloads.

Requirements

Installation Model

You do not need to install this package globally.

Most clients can run it directly with:

npx wapisender-mcp@latest

If you prefer a local installation, install it from npm:

npm install -g wapisender-mcp@latest

After installing globally you can run the CLI and server directly:

wapisender-mcp
wapisender-mcp-server

The package includes:

  • wapisender-mcp: CLI entrypoint
  • wapisender-mcp-server: MCP server entrypoint over stdio

For a self-hosted WapiSender deployment, set WAPISENDER_BASE_URL for both the CLI login and the MCP server process:

export WAPISENDER_BASE_URL="https://your-wapisender.example.com"

Quick Start

1. Generate your MCP token

Go to:

https://wapisender.com/dashboard/settings/mcp-token

2. Save your credentials locally

npx wapisender-mcp login --token <your-mcp-token>

This validates the token and stores it at:

~/.config/wapisender-mcp/credentials.json

3. Add the MCP server to your client

Codex

Add this to ~/.codex/config.toml:

[mcp_servers.wapisender]
command = "npx"
args = ["wapisender-mcp@latest"]

Explicit server form:

[mcp_servers.wapisender]
command = "npx"
args = ["-y", "-p", "wapisender-mcp@latest", "wapisender-mcp-server"]

Claude Code

Add this to ~/.claude/settings.json:

{
  "mcpServers": {
    "wapisender": {
      "command": "npx",
      "args": ["wapisender-mcp@latest"]
    }
  }
}

Explicit server form:

{
  "mcpServers": {
    "wapisender": {
      "command": "npx",
      "args": ["-y", "-p", "wapisender-mcp@latest", "wapisender-mcp-server"]
    }
  }
}

4. Use it in your MCP client

Natural-language examples:

login to wapisender
list my instances
switch to instance WABZ3
show me the current instance status
send a WhatsApp message to +5491112345678 saying "Hello from WapiSender MCP"
list my flows
create a support flow that asks whether the user needs sales or billing help

Tool-call examples for the same session:

login

{}

switch_instance

{
  "instanceIdOrName": "WABZ3"
}

send_text

{
  "to": "5491112345678",
  "message": "Hello from WapiSender MCP"
}

How Authentication Works

The CLI stores only your MCP token locally. The MCP server loads that token and creates an in-memory session when you call login.

The session tracks:

  • Your WapiSender account
  • The list of instances available to that account
  • The active instance used by all instance-scoped tools

If your account has exactly one instance, it is auto-selected during login.

If your account has more than one instance, you should call:

  1. list_instances
  2. switch_instance

After that, all instance-scoped tools use the selected instance.

Multiple Instances

Yes, multi-instance accounts are supported.

Typical workflow

  1. Log in
  2. List your instances
  3. Pick the instance you want to work on
  4. Switch to it
  5. Run your messaging, flow, webhook, or contact tools

Example:

login to wapisender
list my instances
switch to instance Sales-BR
send a message to 5491112345678 saying "Hello from the Brazil sales number"

Tool-call example:

list_instances

{}

switch_instance

{
  "instanceIdOrName": "Sales-BR"
}

Expected behavior:

  • login auto-selects the instance if the account has only one
  • switch_instance accepts either the instance name or the instance ID
  • All subsequent tool calls use the new active instance

CLI Commands

npx wapisender-mcp
npx wapisender-mcp serve
npx wapisender-mcp login --token <your-mcp-token>
npx wapisender-mcp logout
npx wapisender-mcp status

CLI examples

Save credentials:

npx wapisender-mcp login --token wapi_xxxxxxxxxxxxxxxxx

Check whether credentials are saved:

npx wapisender-mcp status

Remove saved credentials:

npx wapisender-mcp logout

Available Tools

There are 42 tools grouped into 7 areas. The catalog is generated from routes that currently exist in WapiSender; unsupported chat-history, contact-delete, QR, disconnect, and number-check routes are intentionally not exposed.

Auth

login

Loads saved credentials and connects to your WapiSender account.

Notes:

  • No arguments
  • Auto-selects the active instance if your account has only one instance

Example:

{}

logout

Clears the current WapiSender session.

Example:

{}

list_instances

Lists all WhatsApp instances on your WapiSender account.

Example:

{}

switch_instance

Sets the active instance by ID or by instance_name.

Example:

{
  "instanceIdOrName": "WABZ3"
}

refresh_instances

Re-fetches the instance list from the API and updates the session — without requiring a full re-login. Useful after adding a new instance.

Example:

{}

get_session_info

Returns the current session state: who you are logged in as, all instances, and which instance is active. Makes no API calls — reads local session only.

Example:

{}

Instance

get_instance_status

Returns the connection state for the active instance, including phone number and battery level when available.

Example:

{}

Messaging

send_text

Submits a text WhatsApp message. API acceptance does not prove recipient delivery.

Example:

{
  "to": "5491112345678",
  "message": "Hello from WapiSender MCP"
}

send_media

Sends an image, video, or document from a public URL. caption is optional and omitted when not provided.

Example image:

{
  "to": "5491112345678",
  "type": "image",
  "url": "https://example.com/banner.jpg",
  "caption": "Campaign preview"
}

Example document:

{
  "to": "5491112345678",
  "type": "document",
  "url": "https://example.com/invoice.pdf",
  "caption": "Invoice attached"
}

send_audio

Sends a WhatsApp audio/voice note from a public URL.

Example:

{
  "to": "5491112345678",
  "url": "https://example.com/voice-note.ogg"
}

send_sticker

Submits a WhatsApp sticker from a public image URL.

{
  "to": "5491112345678",
  "url": "https://example.com/sticker.webp"
}

send_location

Sends a WhatsApp location pin.

Example:

{
  "to": "5491112345678",
  "lat": -34.6037,
  "lng": -58.3816,
  "name": "Buenos Aires Office",
  "address": "Buenos Aires, Argentina"
}

send_buttons

Sends an interactive button message. The recipient sees up to 3 tappable buttons.

Example:

{
  "to": "5491112345678",
  "title": "Choose an option",
  "body": "How can we help you today?",
  "footer": "WapiSender Support",
  "buttons": [
    { "id": "sales", "title": "Sales" },
    { "id": "support", "title": "Support" },
    { "id": "billing", "title": "Billing" }
  ]
}

send_list

Sends an interactive list message. A button opens a scrollable menu of options.

Example:

{
  "to": "5491112345678",
  "title": "Our Services",
  "body": "Please select a department:",
  "footer": "We reply within 1 hour",
  "buttonText": "View options",
  "sections": [
    {
      "title": "Support",
      "rows": [
        { "id": "tech", "title": "Technical Support", "description": "Hardware & software issues" },
        { "id": "billing", "title": "Billing", "description": "Invoices & payments" }
      ]
    }
  ]
}

send_reaction

Reacts to a WhatsApp message with an emoji. Pass an empty string "" to remove a reaction.

Example:

{
  "to": "5491112345678",
  "messageId": "ABC123DEF456",
  "emoji": "👍"
}

send_contact_card

Sends a WhatsApp contact card (vCard). Shares a contact's name and phone number.

Example:

{
  "to": "5491112345678",
  "contactName": "Alice Smith",
  "contactPhone": "5491187654321",
  "organization": "Acme Corp"
}

send_poll

Sends a WhatsApp poll with a question and 2-12 options.

Example:

{
  "to": "5491112345678",
  "question": "Which plan do you prefer?",
  "options": ["Starter", "Pro", "Enterprise"],
  "selectableCount": 1
}

send_bulk_text

Sends the same text to multiple recipients and returns a per-recipient success/failure summary.

Example:

{
  "recipients": ["5491112345678", "5491187654321"],
  "message": "Hello from WapiSender MCP",
  "dedupe": true
}

send_template_text

Sends personalized text messages by replacing {{placeholders}} with each recipient's variables.

Example:

{
  "template": "Hi {{name}}, your verification code is {{code}}.",
  "recipients": [
    { "to": "5491112345678", "variables": { "name": "Ana", "code": 123456 } },
    { "to": "5491187654321", "variables": { "name": "Leo", "code": 654321 } }
  ],
  "dedupe": true
}

Contacts

list_contacts

Lists contacts on the active instance. Supports search, limit, and offset for pagination, and returns a compact formatted summary.

Example:

{
  "limit": 20,
  "offset": 0
}

Page 2 example:

{
  "limit": 20,
  "offset": 20
}

Example with search:

{
  "search": "gilad",
  "limit": 10
}

get_contact

Looks up a single contact by phone number.

Example:

{
  "phone": "5491112345678"
}

set_contact_block_status

Blocks or unblocks a WhatsApp contact using the current WapiSender contact route.

Example:

{
  "phone": "5491112345678",
  "status": "block"
}

Flows

list_flows

Lists all flows on the active instance and returns a compact formatted summary (id | name | status | trigger).

Example:

{}

get_flow

Returns the full definition and health status of a flow.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c"
}

create_flow

Creates an empty flow shell. Current trigger types are message_received and manual; keyword matching belongs in a trigger node's data.

Example:

{
  "name": "Support Router",
  "description": "Routes inbound messages to sales or support",
  "triggerType": "message_received",
  "triggerConfig": {}
}

update_flow_definition

Replaces the full node and edge graph of an existing flow.

Minimal example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "nodes": [
    {
      "id": "trigger-1",
      "type": "trigger",
      "position": { "x": 250, "y": 100 },
      "data": { "match": "any", "keywords": [] }
    },
    {
      "id": "message-1",
      "type": "send_message",
      "position": { "x": 250, "y": 350 },
      "data": {
        "messageType": "text",
        "text": "Hello. Reply with sales or support."
      }
    },
    {
      "id": "end-1",
      "type": "end",
      "position": { "x": 250, "y": 600 },
      "data": {}
    }
  ],
  "edges": [
    { "id": "e1", "source": "trigger-1", "target": "message-1" },
    { "id": "e2", "source": "message-1", "target": "end-1" }
  ]
}

update_flow_node

Updates just one node inside an existing flow.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "nodeId": "message-1",
  "data": {
    "text": "Hello. Reply with sales, support, or billing."
  }
}

generate_and_save_flow

Generates a complete WhatsApp flow from a plain-English description and saves it fully in one step — including the node graph. The AI generates the nodes and edges, then this tool creates and saves everything atomically.

Example:

{
  "name": "Lead Qualification",
  "description": "A flow that greets the user, asks for their company size, and routes enterprise leads to sales.",
  "triggerType": "message_received",
  "triggerConfig": {},
  "nodes": [ ... ],
  "edges": [ ... ]
}

Natural-language example:

Generate and save a WhatsApp flow named "Lead Qualification" that greets the user, asks for company size, and routes enterprise leads to sales.

rename_flow

Renames an existing flow without touching its node graph or activation state.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "name": "New Flow Name"
}

activate_flow

Enables a flow after a health check.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c"
}

deactivate_flow

Disables a flow.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c"
}

Flow node schema

update_flow_definition and generate_and_save_flow use these node types:

trigger:      { type: "trigger", data: { match: "any"|"contains"|"exact"|"regex", keywords: string[] } }
send_message: { type: "send_message", data: { messageType: "text"|"image"|"video"|"document"|"audio"|"voice"|"buttons"|"list"|"location"|"poll"|"sticker", text?: string } }
condition:    { type: "condition", data: { source: "last_message"|"custom", variableName?: string, operator: "equals"|"contains"|"starts_with"|"ends_with"|"regex", value: string } }
delay:        { type: "delay", data: { amount: number, unit: "seconds"|"minutes"|"hours"|"days" } }
webhook:      { type: "webhook", data: { method: string, url: string, headers?: object, body?: string, responseVariable?: string } }
wait_for_reply:{ type: "wait_for_reply", data: {} }
human_handoff:{ type: "human_handoff", data: { message?: string, resumeAfterMinutes: number } }
ai_agent:     { type: "ai_agent", data: { mode: "reply"|"router"|"extract", credentialId: string, provider: string, model: string, systemPrompt: string, promptTemplate: string, outputVariable: string } }
end:          { type: "end", data: {} }

Edge format:

{ id: "e1", source: "nodeId", target: "nodeId", sourceHandle?: "true"|"false" }

Recommended positioning:

Start near { x: 250, y: 100 } and space nodes vertically by about 250px.

delete_flow

Permanently deletes a flow. This cannot be undone.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c"
}

clone_flow

Duplicates an existing flow under a new name. The clone starts inactive so you can edit before activating.

Example:

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "name": "Support Router v2"
}

simulate_flow

Simulates an incoming message and returns flow logs without sending WhatsApp messages.

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "message": "I need support",
  "from": "5491112345678"
}

get_flow_logs

Returns recent execution logs for a flow.

{
  "flowId": "a07692d5-a56c-4027-9cb9-19b44c33eb2c",
  "limit": 50
}

Webhooks

get_webhook

Returns the current webhook configuration for the active instance.

Example:

{}

set_webhook

Creates or updates the webhook URL and event subscriptions. The events array accepts only known event types:

MESSAGES_UPSERT         — new message received or sent
MESSAGES_UPDATE         — message status update
MESSAGE_RECEIPT_UPDATE  — delivery/read receipt updates
CONNECTION_UPDATE       — connection state changes
QRCODE_UPDATED          — new QR code available
CONTACTS_UPSERT         — contact added or updated
CONTACTS_UPDATE         — contact updated
PRESENCE_UPDATE         — user presence changes
CHATS_UPSERT            — chat metadata updates
GROUPS_UPSERT           — group created or updated
GROUP_PARTICIPANTS_UPDATE — group participant changes

Example:

{
  "url": "https://example.com/api/webhooks/wapisender",
  "enabled": true,
  "byEvents": false,
  "base64": false,
  "events": ["MESSAGES_UPSERT", "CONNECTION_UPDATE"]
}

AI Credentials

list_ai_credentials

Lists saved AI credentials for the active instance. Keys are masked.

Example:

{}

add_ai_credential

Adds an AI provider credential to the active instance.

Supported providers:

  • openai
  • anthropic
  • gemini
  • xai
  • openrouter
  • ollama
  • mistral
  • deepseek
  • groq
  • kimi
  • huggingface

Example:

{
  "provider": "openai",
  "apiKey": "sk-...",
  "label": "OpenAI Production",
  "defaultModel": "gpt-4o-mini"
}

test_ai_credential

Runs a live verification for a saved AI credential.

Example:

{
  "credentialId": "cred_12345678"
}

delete_ai_credential

Removes a saved AI provider credential from the active instance.

Example:

{
  "credentialId": "cred_12345678"
}

update_ai_credential

Updates the label, default model, base URL, active state, or API key of an existing AI provider credential.

Example:

{
  "credentialId": "cred_12345678",
  "label": "OpenAI Staging",
  "defaultModel": "gpt-4o"
}

End-to-End Usage Examples

Example 1: Send a WhatsApp message

login to wapisender
list my instances
switch to instance WABZ3
send a WhatsApp message to +5491112345678 saying "Hello from the MCP"

Example 2: Configure a webhook

login to wapisender
switch to instance Support-Number
set the webhook to https://example.com/api/webhooks/wapisender and subscribe to MESSAGES_UPSERT

Equivalent tool call:

{
  "url": "https://example.com/api/webhooks/wapisender",
  "enabled": true,
  "events": ["MESSAGES_UPSERT"]
}

Example 3: Create and activate a simple support flow

login to wapisender
switch to instance Support-Number
create a flow named "Support Router"
update that flow so it greets the user and asks whether they need sales or support
activate the flow

Example 4: Add and test an AI credential

login to wapisender
switch to instance Demo-Instance
add an OpenAI credential labeled "OpenAI Production" using model gpt-4o-mini
list my AI credentials
test the credential I just added

Common Usage Patterns

Pattern: Start every session cleanly

login to wapisender
list my instances
switch to instance <name>
get the instance status

Pattern: Work with multiple instances safely

list my instances
switch to instance Sales-AR
send a message to 5491112345678 saying "Sales team checking in"
switch to instance Support-AR
send a message to 5491112345678 saying "Support team following up"

Pattern: Build a flow incrementally

create a flow named "Lead Capture"
get the flow details
update a single node
activate the flow

Troubleshooting

Not authenticated or Not logged in

Save credentials first:

npx wapisender-mcp login --token <your-mcp-token>

Then call login again inside your MCP client.

No active instance. Call switch_instance() or login() first.

Your account probably has multiple instances and none is selected yet.

Run:

list my instances
switch to instance <instance name or id>

Instance "<name>" not found in your account.

Use list_instances first and copy the exact instance name or ID.

Invalid token or network error

Check:

  • The token was copied correctly
  • The token is still valid in WapiSender
  • The client machine can reach wapisender.com

Security Notes

  • The CLI stores your MCP token locally in ~/.config/wapisender-mcp/credentials.json
  • AI provider API keys passed through add_ai_credential are encrypted server-side by WapiSender
  • The MCP server keeps active session state in memory while it is running

Package Metadata

This repository publishes the npm package:

wapisender-mcp

The top-level README.md is the package README used by npm and by MCP clients that display package documentation, so keeping this file current keeps the Codex-facing package docs current as well.

License

MIT

相关 MCP
