maximo-mcp-server

An MCP (Model Context Protocol) server for IBM Maximo Application Suite. It gives AI agents a governed way to discover Maximo metadata, build validated OSLC queries, and stage, preview, and commit business-data changes -- without hand-written REST calls.

Key capabilities

• Metadata-aware discovery and OSLC query construction, validated against live Maximo schema
• A stateful Working Set model: load records, stage changes, preview a diff, then commit
• Business process tools for status transitions and workflow approvals
• Built-in OAuth 2.0 authorization server for HTTP transport
• Strict tool schemas compatible with IBM watsonx Orchestrate
• Resumable metadata sync with per-stage checkpoints, safe to interrupt and restart
• Optional read-only mode and diagnostic tools for operational visibility

This package is the public edition, covering the full data-access surface described below. A premium edition adds a set of Maximo configuration-management tools on top of the same base; see Premium edition.

Architecture

AI Agent (MCP Client)
        |
        | MCP (stdio / http + OAuth 2.0)
        v
maximo-mcp-server
  |- Metadata Engine       (SQLite, resumable sync, optional vector search)
  |- OS Query Builder      (metadata-validated OSLC queries)
  |- Working Set Engine    (stateful session, staged changes, audit)
  |- Business Process Tools (status change, workflow)
  |- OAuth 2.0 Server      (client_credentials grant, JWT, HTTP transport)
  |- Diagnostic Tools      (log streaming, server status)
        |
        v
IBM Maximo REST / OSLC APIs

Prerequisites

• Node.js 20 or later
• npm 10 or later
• Network access to your Maximo instance
• The MAXMCPMETADATA automation script deployed in Maximo (mandatory, see below)

node -v   # must be >= 20
npm -v

Deploy the MAXMCPMETADATA automation script (mandatory)

The metadata engine requires this script to extract object and attribute metadata from Maximo. Without it the server starts, but metadata sync fails and every tool call returns metadata_sync_in_progress.

• Script name: MAXMCPMETADATA
• Source: https://raw.githubusercontent.com/soumyaprasadrana/maximo-mcp-server/refs/heads/main/MAXMCPMETADATA.py

Deploy steps in Maximo Administration:

1. Go to System Configuration -> Platform Configuration -> Automation Scripts
2. Create a new script named MAXMCPMETADATA
3. Paste the content from the URL above
4. Activate the script

Installation

npm install -g @soumyaprasadrana/maximo-mcp-server

Verify:

maximo-mcp-server --version
maximo-mcp-server --help

Starting the server

Option 1: environment variables

export MAXIMO_URL="https://your-maximo-host/maximo"
export MAXIMO_API_KEY="your-api-key"
export MCP_DATA_BASE_DIR="/opt/maximo-mcp"
export MCP_LOGS_DIR="/opt/maximo-mcp/logs"

maximo-mcp-server

Windows PowerShell:

$env:MAXIMO_URL        = "https://your-maximo-host/maximo"
$env:MAXIMO_API_KEY    = "your-api-key"
$env:MCP_DATA_BASE_DIR = "C:\maximo-mcp"
$env:MCP_LOGS_DIR      = "C:\maximo-mcp\logs"

maximo-mcp-server

Option 2: CLI flags

maximo-mcp-server \
  --maximo-url     "https://your-maximo-host/maximo" \
  --maximo-api-key "your-api-key" \
  --data-dir       /opt/maximo-mcp \
  --logs-dir       /opt/maximo-mcp/logs

HTTP transport with diagnostics enabled:

maximo-mcp-server \
  --maximo-url     "https://your-maximo-host/maximo" \
  --maximo-api-key "your-api-key" \
  --transport      http \
  --port           8001 \
  --data-dir       /opt/maximo-mcp \
  --logs-dir       /opt/maximo-mcp/logs \
  --dev-mode

Read-only surface (query and working-set reads plus diagnostics, no write tools):

maximo-mcp-server \
  --maximo-url     "https://your-maximo-host/maximo" \
  --maximo-api-key "your-api-key" \
  --data-dir       /opt/maximo-mcp \
  --logs-dir       /opt/maximo-mcp/logs \
  --readonly

Force a full metadata re-sync:

maximo-mcp-server \
  --maximo-url     "https://your-maximo-host/maximo" \
  --maximo-api-key "your-api-key" \
  --data-dir       /opt/maximo-mcp \
  --force-reconcile

Option 3: .env file

MAXIMO_URL=https://your-maximo-host/maximo
MAXIMO_API_KEY=your-api-key
MCP_DATA_BASE_DIR=/opt/maximo-mcp
MCP_LOGS_DIR=/opt/maximo-mcp/logs
MCP_TRANSPORT=stdio

Then start with no extra arguments:

maximo-mcp-server

Persistent storage (required)

Linux / macOS:

mkdir -p /opt/maximo-mcp/data /opt/maximo-mcp/logs

Windows PowerShell:

New-Item -ItemType Directory -Force -Path C:\maximo-mcp, C:\maximo-mcp\data, C:\maximo-mcp\logs

Claude Desktop (stdio)

Add to claude_desktop_config.json:

• Windows: %APPDATA%\Claude\claude_desktop_config.json
• macOS: ~/Library/Application Support/Claude/claude_desktop_config.json

{
  "mcpServers": {
    "maximo": {
      "command": "maximo-mcp-server",
      "env": {
        "MAXIMO_URL": "https://your-maximo-host/maximo",
        "MAXIMO_API_KEY": "your-api-key",
        "MCP_DATA_BASE_DIR": "C:\\maximo-mcp",
        "MCP_LOGS_DIR": "C:\\maximo-mcp\\logs"
      }
    }
  }
}

Restart Claude Desktop after saving.

IBM watsonx Orchestrate

Set MCP_STRICT_TOOL_SCHEMA=true when registering the server with IBM watsonx Orchestrate. This switches all tool inputs to strict (no-nullable, no-union) JSON Schemas, which Orchestrate's tool import requires.

{
  "mcpServers": {
    "maximo": {
      "command": "maximo-mcp-server",
      "env": {
        "MAXIMO_URL": "https://your-maximo-host/maximo",
        "MAXIMO_API_KEY": "your-api-key",
        "MCP_DATA_BASE_DIR": "C:\\maximo-mcp",
        "MCP_LOGS_DIR": "C:\\maximo-mcp\\logs",
        "MCP_STRICT_TOOL_SCHEMA": "true"
      }
    }
  }
}

For HTTP transport with Orchestrate, also configure OAuth (see below).

OAuth 2.0 setup (HTTP transport only)

When MCP_TRANSPORT=http, the server enforces OAuth 2.0 Bearer token authentication on every MCP connection. Clients use the client_credentials grant to obtain a JWT and send it as Authorization: Bearer <token>.

Step 1: create an OAuth client

maximo-mcp-server \
  --setup-oauth \
  --data-dir /opt/maximo-mcp \
  --maximo-url "https://your-maximo-host/maximo" \
  --maximo-api-key "your-api-key"

This prints client_id and client_secret to stdout. Save the secret; it is shown only once. If MCP_OAUTH_CREDS_DIR is set, the credentials are also written to oauth-credentials.json in that directory.

Step 2: obtain a token at runtime

curl -X POST http://localhost:8001/oauth/token \
  -d "grant_type=client_credentials" \
  -d "client_id=<your-client-id>" \
  -d "client_secret=<your-client-secret>"

Response:

{
  "access_token": "eyJ...",
  "token_type": "bearer",
  "expires_in": 3600
}

Step 3: connect the MCP client

Send the token as Authorization: Bearer <access_token> on every MCP HTTP request.

Managing clients

# List registered clients (secrets not shown)
maximo-mcp-server --list-oauth-clients --data-dir /opt/maximo-mcp \
  --maximo-url "..." --maximo-api-key "..."

# Remove a client
maximo-mcp-server --delete-oauth-client <client-id> --data-dir /opt/maximo-mcp \
  --maximo-url "..." --maximo-api-key "..."

OAuth environment variables

Metadata sync

On first startup the server downloads all Maximo Object Structure metadata. This can take several minutes on large Maximo environments. Sync is resumable: if the server restarts mid-sync, the next startup resumes from the last completed stage.

Sync stages:

While sync is running, tool calls return a metadata_sync_in_progress response with the current stage and percentage. Enable --dev-mode and use mcp_server_status / mcp_read_logs to monitor sync from within the agent.

Sync startup modes

Background worker example (Claude Desktop):

{
  "mcpServers": {
    "maximo": {
      "command": "maximo-mcp-server",
      "env": {
        "MAXIMO_URL": "https://your-maximo-host/maximo",
        "MAXIMO_API_KEY": "your-api-key",
        "MCP_DATA_BASE_DIR": "C:\\maximo-mcp",
        "MCP_LOGS_DIR": "C:\\maximo-mcp\\logs",
        "MCP_BG_SYNC_WORKER": "true"
      }
    }
  }
}

Configuration reference

Required

Transport

Logging

Metadata sync

Embeddings

none is recommended for production. Local embeddings require native dependencies that may not build on every platform.

Audit

Diagnostics

When MCP_ENABLE_DEV_MODE=true, two additional MCP tools are registered:

• mcp_server_status: a full diagnostic snapshot (sync stage/progress, database counts, checkpoint state, log file list)
• mcp_read_logs: tail recent log entries, with an optional level filter

These tools bypass the metadata sync guard, so they work even during an active sync. --readonly registers them as well, without requiring --dev-mode.

Read-only mode

When enabled, write tools are not registered. The live surface is maximo_get_metadata, os_query_builder (opAction=query only), ws_load, ws_get_records, ws_list_attachments, ws_get_attachment, plus mcp_server_status and mcp_read_logs. Working-set writes, context tools, audit, status/workflow, and premium configuration tools are omitted.

Maximo Developer Copilot mode

When enabled, the server exposes Migration Manager Object Structures for discovery and Working Set edits. This mode targets coding agents that develop, configure, and validate Maximo as a platform, using the server's existing metadata discovery, staging, preview, and commit lifecycle.

Migration Manager Object Structures must be enabled for OSLC discovery: ensure the Maximo system property mxe.oslc.validusewith includes MIGRATIONMGR.

INTEGRATION,OSLC,REPORTING,MIGRATIONMGR

This is an experimental feature intended for development environments. Review every Working Set preview and validation warning before committing configuration changes.

Tool reference

Metadata and discovery

maximo_get_metadata

Resolves maximo:// URIs for Object Structure discovery and schema lookup.

Start here before building queries. Prefer the maximo://os/... URIs, which are scoped by object-structure security. relationships/compact is useful mainly to name a relationship that relatedObjects does not list.

os_query_builder

Builds a validated OSLC query URL and creates the Working Set session (wsId). This is the standard Working Set creation path.

Supports where conditions, select, orderBy, pageSize, childOptions, childCollection, and savedQuery, plus two additional parent-level filters:

• Timeline filters (tlrange / tlattribute): a date-math range around an index date, for example tlrange="-3M", tlattribute="reportdate" for "reported in the last 3 months". tlrange follows <sign><n><unit>, where sign is +, -, or +-, and unit is one of D (days), W (weeks), M (months), Y (years), h (hours), m (minutes), or s (seconds). The two fields are required together.
• Synonym-domain internal filters (domaininternalwhere): filters on the internal value of an attribute bound to a synonym domain (for example WOSTATUS) rather than its external display value. Format is <attrName>=val1,val2,... for an IN match, or <attrName>!=val1,val2,... for a NOT IN match. It is independent of where and is combined with it using AND.

Related data is available three ways, and each wants a different name; the wrong one returns empty rows rather than an error:

Filtering child rows requires childCollection; childOptions and dot notation cannot page or count them (dot notation filters parents by child values, it does not trim child rows). Aggregation is not available; _dbcount and similar are accepted and silently dropped, so collectioncount is the only supported count.

Working Set tools

A Working Set is a stateful, in-memory session tied to query context. All mutations are staged and must be explicitly committed.

Read and load

Both ws_load and ws_get_records support useLean=true for a large reduction in token usage on large result sets.

When the query sets collectioncount: true, ws_load returns meta.totalCount (total records matching in Maximo), meta.count (rows in this page), and meta.hasMore. Totals survive lean encoding, so answer "how many" from totalCount, never from the page length.

Stage changes

Review and finalize

ws_preview_changes runs a full validation pass (domain values, read-only flags, type checks) and returns the results in validation_warnings; present these to the user before deciding whether to adjust or proceed. ws_commit does not re-run validation; it goes directly to plan and execute, letting Maximo act as the final authority.

Attachments

Audit

Business process tools

Status change

Status changes are executed through Maximo's changeStatus action, not as field updates. Use the two-tool pattern below to enforce user review before execution.

maximo_plan_status_change validates a proposed status transition and returns a preview without making any changes. It fetches the current status, checks allowedactions to confirm changeStatus is permitted, and returns the current status, target status, transition verdict, and the full allowed-actions list. Always call this first, and show the result to the user before proceeding.

maximo_change_status executes the status transition after user confirmation. It calls getAllowedActions again immediately before execution to guard against race conditions, and rejects the request if changeStatus is not in the allowed actions.

Example flow:

1. os_query_builder -- find the work order, get wsId + restId
2. maximo_plan_status_change osName=MXAPIWO restId=12345 newStatus=CLOSE memo="Job complete"
3. -- show the plan to the user, get confirmation
4. maximo_change_status osName=MXAPIWO restId=12345 newStatus=CLOSE memo="Job complete"

Workflow

maximo_get_workflow_assignments queries the MXAPIWFASSIGNMENT object structure to list pending workflow tasks. Filters: personId, roleId, processName, ownerTable, pageSize. Use includeAllowedActions=true to fetch the allowed actions on each owning record in one call.

maximo_send_workflow_response invokes a workflow action on the owning record (work order, service request, and so on). It calls getAllowedActions before execution and rejects the request if the action is not available. Omit actionName to get a discovery response listing only the allowed actions.

Common action names (these vary by workflow configuration):

Example flow:

1. maximo_get_workflow_assignments personId=JSMITH includeAllowedActions=true
2. -- returns ownerid=5678, ownertable=WORKORDER, _allowedActions=[wfappr, wfcanreq]
3. maximo_send_workflow_response osName=MXAPIWO restId=5678 actionName=wfappr params={memo:"Approved"}

Context session store

Six lightweight key-value tools for storing agent state across tool calls within a conversation.

Useful for caching intermediate query results, tracking multi-step workflow state, or storing user preferences without round-tripping to Maximo.

Diagnostic tools (--dev-mode, or automatically with --readonly)

mcp_server_status returns a full diagnostic snapshot: server version, transport, PID, uptime, live sync progress, checkpoint state, database record counts, active configuration, and the log file list.

mcp_read_logs tails log entries from the MCP server log files.

Orchestration patterns

Pattern A: read-only analysis

1. maximo_get_metadata  maximo://os/search/work+order
2. maximo_get_metadata  maximo://os/{osName}/schema
3. os_query_builder     with status/priority/site filters
4. ws_load              useLean=true
5. ws_get_records       analyze and report
6. ws_remove            cleanup

Pattern B: governed field update

1. os_query_builder
2. ws_load
3. ws_update_field / ws_multi_update / ws_batch_update
4. ws_preview_changes   -- show diff and any validation_warnings to the user
5. ws_commit            -- persist, after user confirmation
6. ws_remove

Pattern C: create a new record

1. ws_init_new_record   osName=MXAPISR
   -- returns wsId, draftRecord skeleton, metadata
2. ws_update_draft      wsId, fields={description:"...", reportedby:"...", ...}
3. ws_preview_changes   -- review the draft and any validation_warnings
4. ws_commit            -- creates the record in Maximo
5. ws_remove

Pattern D: status transition

1. os_query_builder            -- find the record, get restId
2. maximo_plan_status_change   osName, restId, newStatus
3. -- show the plan to the user, wait for confirmation
4. maximo_change_status        osName, restId, newStatus, memo

Pattern E: workflow approval

1. maximo_get_workflow_assignments  personId={me} includeAllowedActions=true
2. -- identify the assignment: note ownerid, ownertable, _allowedActions
3. -- present to the user, e.g. "Work order WO-1234 is waiting for your approval"
4. maximo_send_workflow_response    osName, restId=ownerid, actionName=wfappr

Pattern F: diagnose a stalled sync

1. mcp_server_status
   -- read sync.currentStageName, sync.progress.percentComplete
   -- read sync.checkpoint (last persisted stage)
   -- read sync.lastError
2. mcp_read_logs  level=error  lines=50
   -- look for network errors, script failures, or auth issues

Operational notes

• First metadata sync takes several minutes on large Maximo environments; subsequent startups skip it once the completed flag is persisted.
• Sync is resumable: if the server stops mid-sync, the next startup resumes from the last completed stage.
• Always set MCP_DATA_BASE_DIR and MCP_LOGS_DIR to persistent paths outside the process working directory in orchestrated environments.
• MCP_EMBEDDINGS_MODE=none (default) is recommended for production; local embeddings require native dependencies that may not build on every platform.
• Lean mode (useLean=true on ws_load / ws_get_records) meaningfully reduces token usage on large result sets.
• OAuth client secrets are hashed in the SQLite database and cannot be recovered. If a secret is lost, delete the client and create a new one.

Premium edition

The same base layer described in this document is also available as a premium edition that adds a set of Maximo configuration-management tools: Configure Database, Admin Mode control, system property management, read-only SQL, cache reload, automation-script invocation, Application Designer presentation editing, and configuration safety guards. These tools are not included in this npm package.

For access to the premium edition, or for evaluation, partnership, or a tailored build, contact soumyaprasad.rana@gmail.com.

Support

• GitHub issues: https://github.com/soumyaprasadrana/maximo-mcp-server/issues
• Changelog: CHANGELOG.md
• Related project: maximo-kit, a Spec Kit extension that drives this server through a design-first, recipe-driven configuration workflow

Contact

soumyaprasad.rana@gmail.com
