FastMCP BYOA Demo

A demo showing how to add Scalekit MCP Auth to a FastMCP server that wraps an existing B2B app (Express.js + Passport.js) as MCP tools.

This demonstrates the Bring Your Own Auth (BYOA) pattern: your B2B app keeps its own authentication (Passport.js), while Scalekit handles OAuth 2.1 for MCP clients connecting to your tools.

Architecture

MCP Client (Claude Desktop, etc.)
    |
    | 1. OAuth 2.1 /authorize
    v
Scalekit (Authorization Server)
    |
    | 2. Redirect to B2B app login with login_request_id & state
    v
B2B Todo App (Express.js, port 3001)
    |  3. User authenticates via Passport.js (HTML login form)
    |  4. POST user details to Scalekit via Node SDK
    |  5. Redirect user back to Scalekit callback with state
    v
Scalekit (completes consent + token exchange)
    |
    | 6. Access token issued to MCP client
    v
FastMCP Server (Python, port 8000)
    |  7. Validates Scalekit JWT, extracts user identity
    |  8. Calls B2B Todo App API with API key + user ID
    v
B2B Todo App (serves CRUD responses)

Project Structure

.
├── .env                    # Configuration (you create this)
├── .gitignore
├── README.md
├── todo-app/               # B2B Todo App (Node.js/Express)
│   ├── package.json
│   └── server.js           # Passport.js auth + CRUD API + Scalekit BYOA
└── mcp-server/             # FastMCP Server (Python)
    └── server.py           # 4 MCP tools + ScalekitProvider auth

Prerequisites

• Node.js v18+ (nodejs.org)
• Python 3.9+ (python.org)
• A Scalekit account (scalekit.com)

Setup

1. Clone the repo

git clone <your-repo-url>
cd "FastMCP BYOA Demo"

2. Install Python dependencies

python3 -m venv .venv
source .venv/bin/activate
pip install fastmcp httpx python-dotenv

3. Install Node.js dependencies

cd todo-app
npm install
cd ..

4. Create the .env file

Create a .env file in the project root with the following:

# ── Scalekit MCP Auth (read by FastMCP's ScalekitProvider) ──
FASTMCP_SERVER_AUTH_SCALEKITPROVIDER_ENVIRONMENT_URL=https://<your-env>.scalekit.dev
FASTMCP_SERVER_AUTH_SCALEKITPROVIDER_RESOURCE_ID=<your-resource-id>
FASTMCP_SERVER_AUTH_SCALEKITPROVIDER_BASE_URL=http://localhost:8000

# ── Scalekit SDK Credentials (used by the B2B app for BYOA) ──
SCALEKIT_ENVIRONMENT_URL=https://<your-env>.scalekit.dev
SCALEKIT_CLIENT_ID=<your-client-id>
SCALEKIT_CLIENT_SECRET=<your-client-secret>
SCALEKIT_CONNECTION_ID=<your-connection-id>

# ── B2B Todo App ──
TODO_APP_PORT=3001
TODO_APP_BASE_URL=http://localhost:3001
TODO_APP_API_KEY=demo-api-key-12345
SESSION_SECRET=keyboard-cat-secret

# ── MCP Server ──
MCP_SERVER_PORT=8000

You'll fill in the Scalekit values in the next step.

5. Configure the Scalekit Dashboard

1. Register an MCP Server

   • Go to app.scalekit.com and navigate to MCP Servers
   • Register a new MCP Server with URL: http://localhost:8000
   • Note the Resource ID (starts with res_...)

2. Create a custom auth connection

   • In the MCP Server settings, under authentication, choose "Use your own authentication service"
   • Set the Login Endpoint URL to: http://localhost:3001/auth/mcp-login
   • Note the Connection ID from the User Info Post URL (starts with conn_...)

3. Get API credentials

   • Go to Settings > API Credentials
   • Note the Client ID (starts with skc_...) and Client Secret

4. Update .env with all the values you noted:

   • FASTMCP_SERVER_AUTH_SCALEKITPROVIDER_ENVIRONMENT_URL and SCALEKIT_ENVIRONMENT_URL = your Scalekit environment URL
   • FASTMCP_SERVER_AUTH_SCALEKITPROVIDER_RESOURCE_ID = Resource ID from step 1
   • SCALEKIT_CLIENT_ID = Client ID from step 3
   • SCALEKIT_CLIENT_SECRET = Client Secret from step 3
   • SCALEKIT_CONNECTION_ID = Connection ID from step 2

Running the Demo

Open two terminals:

Terminal 1 — B2B Todo App (port 3001):

cd todo-app
node server.js

Output: Todo App running on http://localhost:3001

Terminal 2 — FastMCP Server (port 8000):

cd mcp-server
../.venv/bin/python server.py

Output: Uvicorn running on http://0.0.0.0:8000

Connecting an MCP Client

Claude Desktop

Add this to your Claude Desktop config (~/Library/Application Support/Claude/claude_desktop_config.json on macOS):

{
  "mcpServers": {
    "todo": {
      "url": "http://localhost:8000/mcp"
    }
  }
}

Restart Claude Desktop. When it connects:

1. A browser window opens for Scalekit OAuth
2. Scalekit redirects to the Todo app's login form
3. Enter credentials (see Demo Users below)
4. Authentication completes and tools become available
5. Ask Claude: "List my todos" or "Create a todo called Review PR"

Demo Users

Alice has 2 pre-seeded todos. Bob has 1.

MCP Tools

Testing the Todo API Directly

You can test the B2B app's REST API independently using API key auth:

# List todos for Alice (user 1)
curl 'http://localhost:3001/api/todos' \
  -H 'x-api-key: demo-api-key-12345' \
  -H 'x-user-id: 1'

# Create a todo
curl -X POST 'http://localhost:3001/api/todos' \
  -H 'x-api-key: demo-api-key-12345' \
  -H 'x-user-id: 1' \
  -H 'Content-Type: application/json' \
  -d '{"title": "Test from curl"}'

# Update a todo
curl -X PUT 'http://localhost:3001/api/todos/todo-1' \
  -H 'x-api-key: demo-api-key-12345' \
  -H 'x-user-id: 1' \
  -H 'Content-Type: application/json' \
  -d '{"completed": true}'

# Delete a todo
curl -X DELETE 'http://localhost:3001/api/todos/todo-1' \
  -H 'x-api-key: demo-api-key-12345' \
  -H 'x-user-id: 1'

How the Auth Flow Works

When an MCP client connects to the FastMCP server, the following happens:

1. MCP client discovers the server at http://localhost:8000/mcp and fetches /.well-known/oauth-protected-resource to find Scalekit as the authorization server.

2. MCP client initiates OAuth 2.1 with Scalekit (authorization code flow + PKCE).

3. Scalekit redirects the user's browser to the B2B Todo app's login endpoint: http://localhost:3001/auth/mcp-login?login_request_id=...&state=...

4. Todo app renders a login form. The user enters their username and password.

5. Passport.js authenticates the user using its LocalStrategy (same auth the B2B app uses for its own users).

6. Todo app calls scalekit.auth.updateLoginUserDetails() via the Scalekit Node SDK to POST the authenticated user's sub and email to Scalekit.

7. Todo app redirects the user back to Scalekit's callback URL with the state parameter.

8. Scalekit completes consent and token exchange, issuing a JWT access token to the MCP client.

9. MCP client includes the JWT as a Bearer token in all subsequent MCP requests.

10. FastMCP server validates the JWT using Scalekit's JWKS endpoint (handled automatically by ScalekitProvider), extracts the user identity from the sub claim, and calls the Todo app's REST API with API key auth on behalf of that user.
