Chaos Toolkit AWS MCP Server

An MCP server that generates Chaos Toolkit experiments for AWS and drives the chaos CLI to validate, run and roll them back.

Every generated activity maps onto a function that really exists in chaosaws (chaostoolkit-aws) or azchaosaws (aws-az-failure-chaostoolkit), and the arguments follow those function signatures. The test suite imports both packages and asserts this for every tool, so an experiment that this server generates will not fail with ActivityFailed: module 'chaosaws...' has no attribute ....

Safety model

Chaos experiments break production on purpose, so the server is deliberately conservative:

• Dry run by default. fail_az is generated with dry_run: true, and chaos_run_experiment runs chaos run --dry activities unless you pass both dry_run: false and confirm_destructive: true.
• Confined file access. Every path the server reads or writes must stay inside a base directory: $CHAOS_MCP_WORKDIR, defaulting to the process working directory. ../escape.json and /etc/anything are rejected.
• Validated shell input. Values interpolated into SSM shell commands (paths, process names, interfaces) are pattern-checked and shlex-quoted, so path="/tmp; rm -rf /" is refused instead of ending up in AWS-RunShellScript.
• Rollbacks where they exist. Stopping instances generates start_instances, suspending ASG processes generates resume_processes, revoking a security group rule generates the matching authorise, tc netem and disk-fill experiments clean up after themselves. When no rollback is possible (termination, pkill) the response says so explicitly.
• Validated AWS identifiers. Instance, volume, security group, VPC ids, AZ names and ports are checked before an experiment is written.

Installation

git clone https://github.com/RadiumGu/chaostoolkit-aws-mcp-server.git
# or the China mirror: https://gitee.com/radiumgu/chaostoolkit-aws-mcp-server.git
cd chaostoolkit-aws-mcp-server

uv sync --all-groups          # runtime + dev dependencies

uv sync installs chaostoolkit, chaostoolkit-aws and aws-az-failure-chaostoolkit; no extra pip install step is needed. Python 3.10+ is required, and the MCP SDK is pinned to >=1.0,<2 because the low level decorator API used here was removed in mcp 2.x.

Configure AWS credentials as usual, for example for AWS China:

aws configure --profile awscn   # region cn-north-1

MCP client configuration

{
  "chaostoolkit-aws-mcp-server": {
    "command": "uv",
    "args": [
      "--directory",
      "/path/to/chaostoolkit-aws-mcp-server",
      "run",
      "chaostoolkit-aws-mcp-server"
    ],
    "env": {
      "AWS_REGION": "cn-north-1",
      "AWS_PROFILE": "awscn",
      "CHAOS_MCP_WORKDIR": "/path/to/experiments"
    }
  }
}

AWS_REGION (or AWS_DEFAULT_REGION) becomes the default configuration.aws_region of generated experiments. CHAOS_MCP_WORKDIR is where experiments, journals and state files are written and the only directory the server may touch.

Tools

All generation tools accept title (required), tags, health_check_url, health_check_status, health_check_timeout, health_check_method, health_check_verify_tls, output_file and aws_region. A health_check_url becomes a steady state hypothesis using the Chaos Toolkit HTTP provider with the status code as tolerance.

Two things to know about that probe: it is evaluated before the method, so a failing probe aborts the run before any chaos is injected; and the provider follows redirects, so the tolerance must match the final status. Raw load balancer DNS names that redirect to HTTPS usually present a certificate for a different hostname — pass health_check_verify_tls: false for those.

Availability zone failure — azchaosaws

fail_az applies its filters to different resources depending on failure_type: network filters subnets (describe_subnets), instance filters instances. A tag that only exists on your instances therefore matches no subnets and fail_az fails with No subnets found!. Without filters it adds tag:AZ_FAILURE=True. The generated warnings state which resource your filters will hit.

state_path is written into the experiment as an absolute path: chaos run resolves relative paths against its own working directory, and a state file recover_az cannot find means the rollback silently does nothing. A state file produced with dry_run: true cannot be rolled back — recover_az refuses it, and chaos_rollback_from_state skips it with an explanation.

EC2 — chaosaws.ec2.actions

Auto Scaling groups — chaosaws.asg.actions

SSM — chaosaws.ssm.actions.send_command

send_command targets instances through targets=[{"Key": "InstanceIds", "Values": [...]}], which is what the real signature takes. SSM commands run as root and require the SSM agent, an instance profile with AmazonSSMManagedInstanceCore, and stress-ng/iproute2 for the stress tools.

RDS and load balancing

Lifecycle

Deprecated aliases

They still work and the response says which tool to use instead.

Not implemented

There is no upstream primitive for these, so the server does not pretend to offer them: packet loss and corruption, memory and IO stress, detaching an internet gateway, modifying target group health checks, DB connection limits and DB latency injection. chaos_ssm_send_command is the escape hatch for anything that can be expressed as a shell command.

Example session

1. chaos_generate_az_failure_experiment
   title="Production AZ failure", az="cn-north-1a",
   health_check_url="https://my-app.example.com/health"

2. chaos_validate_experiment
   experiment_file="./az-failure-experiment.json"

3. chaos_run_experiment                      # dry run, nothing is touched
   experiment_file="./az-failure-experiment.json"

4. chaos_generate_az_failure_experiment      # regenerate for a real run
   title="Production AZ failure", az="cn-north-1a", dry_run=false

5. chaos_run_experiment
   experiment_file="./az-failure-experiment.json",
   dry_run=false, confirm_destructive=true, journal_path="./journal.json"

6. chaos_rollback_from_state                 # if the rollback did not run
   state_files=["./fail_az.ec2.json"]

examples/example_usage.py does the same thing in Python.

Development

uv sync --all-groups
uv run pytest --cov --cov-branch --cov-report=term-missing
uv run ruff check .
uv run mypy src/ tests/

148 tests, 89% statement/branch coverage. The suite includes an end-to-end test that starts the server as a subprocess and speaks MCP over stdio, and a test that asserts every generated activity resolves to an existing chaosaws/azchaosaws function with accepted argument names. CI runs lint, types and tests on Python 3.10-3.12.

License

Apache-2.0
