🧠 MemFS

A knowledge graph management system based on MCP server-memory, deeply refactored with filesystem-inspired design

💡 Acknowledgments: Original @modelcontextprotocol/server-memory
Inspired by it, though heavily reimagined.


🎯 One-Line Description

Bringing modern filesystem concepts to knowledge graph management, combined with BM25 + fuzzy search for intelligent retrieval, designed for LLM-assisted humanities and social sciences research.


🚀 Quick Start

Prerequisites

# Check Node.js version
node --version  # Must be v22.0.0 or higher

Installation & Run

Quickest way (npx):

npx @qty/memfs

Or clone and run:

# 1. Clone or download the project
cd MemFS

# 2. Install dependencies
npm install

# 3. Run server
node index.js

# Or with CLI args (recommended)
node index.js --memory-dir ~/my-knowledge --git-autocommit --duplicates --autogc

# Or via environment variables (legacy)
MEMORY_DIR=~/my-knowledge GITAUTOCOMMIT=true node index.js

Configure as MCP Server

OpenCode format:

{
  "mcpServers": {
    "memory": {
      "type": "local",
      "command": ["npx", "-y", "@qty/memfs"],
      "enabled": true
    }
  }
}

VSCode / ClaudeCode / Cherry Studio / AstrBot format:

{
  "mcpServers": {
    "memory": {
      "command": "npx",
      "args": ["-y", "@qty/memfs"],
      "enabled": true
    }
  }
}

📰 What's New in v3.7.12

CLI Args > Env Vars

All configuration now supports CLI arguments with args > env > default priority:

node index.js --memory-dir ~/my-knowledge --git-autocommit --duplicates --autogc
Arg Env fallback Description
--memory-dir <path> MEMORY_DIR Data directory
--git-autocommit GITAUTOCOMMIT=true Enable git auto-commit
--mode sse — Legacy SSE HTTP mode (/sse + /message)
--mode http — Streamable HTTP mode (/mcp)
--mode both — SSE + Streamable HTTP on the same port
--port <n> — HTTP server port
--token <str> — HTTP auth token (query ?token= or Bearer header)
--duplicates — Enable analyzeDuplicates dedup tool
--autogc <N> — Auto git gc --auto every N commits

HTTP Modes

Three HTTP modes share the same port and token auth (query ?token= or Authorization: Bearer):

  • --mode sse — legacy HTTP+SSE transport (GET /sse + POST /message?sessionId=), for old MCP clients
  • --mode http — Streamable HTTP transport (GET/POST/DELETE /mcp, stateful sessions via the mcp-session-id header)
  • --mode both — both transports on the same instance, so old and new clients can connect simultaneously

Examples: --mode sse --port 3100 --token mytoken, --mode http --port 3100 --token mytoken, --mode both --port 3100 --token mytoken.

entityType Multi-Dimensional Paths

Filesystem-style taxonomy: /社会学/人物/|/经济学/人物/ — Zod auto-formats, BM25 indexes path nodes, listNode returns directory tree.

XX Semantic Mark Tag

Markdown bold as semantic tag — BM25 weight ×1.5, transparent to search, zero schema change.

analyzeDuplicates Dedup Tool

BM25 mean-similarity dedup for observations/entities/relations (opt-in via --duplicates flag). Worker thread parallel compute, distribution histogram for threshold tuning.

--autogc Auto-GC Counter

Fire-and-forget git gc --auto every N auto-commits (default 20). Keeps the git repo lean.

18 MCP Tools

New: analyzeDuplicates, --autogc git gc. listNode defaults to directory tree view.

Time Parameter Cleanup

time=false omits createdAt/updatedAt entirely; time=true omits updatedAt when null.


📖 Core Concepts

Concept Description Analogy
Entity Nodes in the knowledge graph File
Observation Properties/descriptions of entities inode
Relation Connections between entities Soft link
Reference Pointers from entities to observations Hard link

💡 Core Design Philosophy

1. Transformer-Ready: On-Demand Retrieval

flowchart TD
    LLM["LLM"]
    ATT["Attention Mechanism"]
    MCP["MCP Protocol"]
    MEM["MemFS\nOn-demand structured data"]

    LLM --> ATT --> MCP --> MEM
    MEM -.-> |Returns results| LLM

Core principle: Don't stuff all knowledge into context—retrieve on demand.

2. Lightweight Design

Dimension Traditional Solution MemFS
Deployment Database + Vector Engine Pure Node.js
Resources GPU recommended, high memory CPU only
Explainability Black-box models BM25 transparent & controllable

3. Local JSONL Storage

{"type":"entity","name":"Weber","entityType":"person","definition":"German sociologist","observationIds":[1,2]}
{"type":"observation","id":1,"content":"Author of 'The Protestant Ethic'","createdAt":{"utc":"2026-02-08T13:53:07Z","timezone":"Asia/Shanghai"}}
{"type":"relation","from":"Weber","to":"Durkheim","relationType":"contemporary"}

Advantages: Editable with any text editor, Git-version-controllable, printable.

4. Humanities & Social Sciences Customization

Requirement Type Traditional MemFS
Knowledge units Functions/Classes Concepts/People/Documents
Relationship types Function calls Influence/Reference/Comparison
Update frequency High-frequency Low-frequency add, high-frequency reference

📦 Complete API Tools (18 total)

Create

Tool Function Example
createEntity Batch create entities (with observations) Add concepts, people, documents
createRelation Create relations between entities Mark references, comparisons, influences
addObservation Add observations to existing entities Supplement reading notes

Read

Tool Function Example
searchNode BM25 + Fuzzy hybrid search Intelligent knowledge search
readNode Read complete entity information Get detailed attributes and relations
readObservation Batch read observations by ID Verify specific observations
listNode List all entity overviews Browse knowledge structure
listGraph Read entire knowledge graph Batch export, migration
howWork Get recommended workflow guidance Learn how to use the system

Update

Tool Function Example
updateNode Update entities and observations (Copy-on-Write) Modify definitions, update notes
updateObservation Batch update observation content Batch correct information

Delete

Tool Function Example
deleteEntity Delete entities and relations Remove outdated entries
deleteRelation Delete specific relations Unlink entities
unlinkObservation Unlink observations (preserve observation) Remove references
getOrphanObservation Find orphan observations Discover invalid data
recycleObservation Permanently delete observations Clean up unused data

Auxiliary

Tool Function Example
getConsole Get console messages and Git commit logs View auto-commit history
analyzeDuplicates BM25 dedup analysis (needs --duplicates flag) Find near-duplicate observations

🔍 Hybrid Search (searchNode)

Core Features

Feature Description
BM25 Considers term frequency and document frequency
Fuzzy Search Tolerates typos, supports approximate matching
Query Tokenization Tokenize → Search individually → Aggregate → Deduplicate
Weighted Fusion BM25 0.7 + Fuzzy 0.3, combined ranking

Parameters

// Default hybrid search
await searchNode("functionalism");  // BM25 + Fuzzy

// Traditional keyword search
await searchNode("functionalism", { basicFetch: true });

// Custom parameters
await searchNode("sociology", {
    limit: 15,          // Return count
    bm25Weight: 0.7,    // BM25 weight
    fuzzyWeight: 0.3,   // Fuzzy search weight
    minScore: 0.01      // Minimum relevance threshold
});

Field Weights

Field Weight Description
name 5.0 Highest - entity name
entityType 2.5 Entity type
definition 2.5 Definition description
definitionSource 1.5 Definition source
observation 1.0 Observation content

🔧 Filesystem-Inspired Design

Architecture Analogy

Filesystem Concept MemFS Implementation Solves
Inode Table Centralized observation storage Data redundancy
Hard Links Multiple entities reference same observation Shared reuse
Soft Links Entity relations Flexible associations
Copy-on-Write Copy-on-Write updates Concurrency safety
Orphan Detection Orphan observation cleanup Resource recovery

Observation Sharing

// Create two entities sharing the same observation
await createEntity([
  { name: "Zhang San", observations: ["Programmer"] },
  { name: "Li Si", observations: ["Programmer"] }
]);

// Under the hood: same observation ID is reused
{
  entities: [
    { name: "Zhang San", observationIds: [1] },
    { name: "Li Si", observationIds: [1] }
  ],
  observations: [
    { id: 1, content: "Programmer" }
  ]
}

Copy-on-Write

// Update a shared observation
await updateNode({
  entityName: "Zhang San",
  observationUpdates: [
    { oldContent: "Programmer", newContent: "Senior Programmer" }
  ]
});

// Result: Zhang San gets new observation, Li Si keeps original
{
  observations: [
    { id: 1, content: "Programmer" },      // Li Si uses
    { id: 2, content: "Senior Programmer" } // Zhang San's new observation
  ]
}

📁 Data Format

JSONL Storage

{"type":"entity","name":"Weber","entityType":"person","definition":"German sociologist","definitionSource":"Wikipedia","observationIds":[1,2]}
{"type":"entity","name":"Durkheim","entityType":"person","definition":"French sociologist","definitionSource":"Wikipedia","observationIds":[3]}
{"type":"observation","id":1,"content":"Author of 'The Protestant Ethic'","createdAt":{"utc":"2026-02-08T13:53:07Z","timezone":"Asia/Shanghai"}}
{"type":"observation","id":2,"content":"Contemporary with Durkheim and Marx","createdAt":{"utc":"2026-02-08T14:00:00Z","timezone":"Asia/Shanghai"},"updatedAt":{"utc":"2026-02-09T10:30:00Z","timezone":"Asia/Shanghai"}}
{"type":"observation","id":3,"content":"Author of 'The Division of Labor in Society'","createdAt":{"utc":"2026-02-08T15:00:00Z","timezone":"Asia/Shanghai"}}
{"type":"relation","from":"Weber","to":"Durkheim","relationType":"contemporary"}

Storage Locations

Method Path
Default ~/.memory/memory.jsonl
Custom directory MEMORY_DIR=/path/to/data

CLI Arguments

Arg Env fallback Description Default
--memory-dir <path> MEMORY_DIR Data storage directory ~/.memory
--git-autocommit GITAUTOCOMMIT=true Enable Git auto-commit false
--duplicates — Enable analyzeDuplicates dedup tool off
--autogc <N> — Auto git gc --auto every N commits 20
--mode sse — Legacy SSE HTTP mode (/sse + /message) stdio
--mode http — Streamable HTTP mode (/mcp) stdio
--mode both — SSE + Streamable HTTP on the same port stdio
--port <n> — HTTP server port 3100
--token <str> — HTTP auth token (query or Bearer) none

🔄 Git Auto-Sync

When enabled (--git-autocommit or GITAUTOCOMMIT=true), every save to the memory file is automatically committed to Git for version control.

# Via CLI arg (recommended)
node index.js --memory-dir /path/to/data --git-autocommit

# Via environment variable
GITAUTOCOMMIT=true node index.js

Auto-GC

With --autogc <N>, git gc --auto runs automatically every N auto-commits (default 20). Fire-and-forget, non-blocking.

Commit Format

auto-commit:[operationContext] at [utc:YYYY-MM-DDTHH:mm:ss.SSSZ] [tz:Asia/Shanghai]

Example:

auto-commit:[createEntity "Weber"] at [utc:2026-03-22T09:15:30.123Z] [tz:Asia/Shanghai]
auto-commit:[updateNode "Durkheim"] at [utc:2026-03-22T09:16:45.456Z] [tz:Asia/Shanghai]
auto-commit:[deleteRelation "Weber"→"Durkheim"] at [utc:2026-03-22T09:17:00.789Z] [tz:Asia/Shanghai]

View Commit History

Use getConsole tool:

await getConsole()
// Returns text content with buffered logs and Git commits prefixed by "[Git]"

📦 Legacy Version

The v1.3.0 code is available on the legacy branch:

git clone https://github.com/Qtgcy08/MemFS.git
cd MemFS
git checkout legacy

🧪 Testing

# Full test suite (29 tests, SSE skipped by default)
MEMORY_DIR=test_cache node test_mcp_full.mjs

# analyzeDuplicates dedup (standalone)
node test_mcp_dedup.mjs

# Hybrid search
MEMORY_DIR=test_cache node test_mcp_hybrid_search.mjs

# Git Sync tests
node test_gitsync.mjs

# SSE tests (opt-in)
TEST_SSE=true MEMORY_DIR=test_cache node test_mcp_full.mjs

⚙️ Comparison with Original MCP Memory

Dimension Original MemFS
Observation Storage Embedded in entities Centralized + ID reference
Data Sharing Not supported Hard-link style sharing
Update Mechanism Direct overwrite Copy-on-Write
Search Capability Simple keyword BM25 + Fuzzy
Orphan Detection 理论上不存在孤儿观察 Supported
Cache Mechanism None 30s TTL
Windows Compatibility Unknown Graceful degradation

📚 Design Philosophy

What? You're still reading? Well, alright.

Honestly, this project started because:

  1. LLM context is limited — can't stuff all knowledge into prompts
  2. Filesystem is a great invention — handling "multiple data sharing same content" is mature
  3. Humanities research has special needs — concepts, literature, citation relationships
  4. Controllability > SOTA — no need for black-box vector models

So:

  • Borrow filesystem wisdom: inode table, hard links, copy-on-write
  • Search uses BM25 + Fuzzy: lightweight, explainable, transparent, controllable
  • Expose as tools: 18 MCP tools, LLM calls on demand

Result? — A quiet, efficient, unobtrusive knowledge management tool.


📄 License

Apache License 2.0


Manage knowledge the filesystem way—bringing order to chaos.
