RCAC MCP Server

Purdue RCAC MCP Server: Enables agentic development with HPC clusters and storage services.

Quick Start (Desktop Clients)

For MCP-enabled desktop applications like Claude Desktop, Cursor, or Warp, add this server to your MCP configuration with an SSH host pointing at your cluster:

{
  "mcpServers": {
    "rcac": {
      "command": "uvx",
      "args": ["git+https://github.com/purduercac/rcac-mcp", "--ssh-host", "cluster.rcac.purdue.edu"]
    }
  }
}

This runs the server locally in stdio mode, executing commands on the cluster over SSH using your existing ~/.ssh/config and keys.

Alternatively, set RCAC_SSH_HOST in your environment and omit --ssh-host from the args.

If the server cannot connect, your client shows the reason as the error to its first request: cannot connect to <host>: <cause> (unknown host or SSH alias, connection refused, authentication failed, connection closed during authentication, or timed out after 15 seconds per step unless your SSH config sets ConnectTimeout). Check that --ssh-host names the SSH host or ~/.ssh/config alias you use with ssh, not the MCP server's name.

The cluster's rules, in the instructions

Cluster administrators can publish rules for agents as Markdown files in /etc/agents.d. At startup the server reads every *.md file directly in that directory except the assembled AGENTS.md (which repeats the others), once (on the cluster in ssh mode, on the server's own host in local and delegate modes), and serves them after its own instructions, so the agent sees the site's rules without asking. Files go in whole, each under a  header, in the byte order of their names (LC_ALL=C sort): an administrator who wants a file first gives it a name that sorts first, such as one starting 00-. An edit takes effect at the next start. A control character in a file name (a line break, for instance) is shown as an escape such as \x0a, and a backslash as \x5c, so a name always stays on its one line. Names are shown by their decoded text, so two names that differ only in bytes that are not valid UTF-8 (each read as U+FFFD) can show alike; they are still two files.

In delegate mode one server serves many accounts, so it serves only what every account could read: the owner, the group and others must each be able to read every file, read and search the directory, and search every directory above it (through any symlink on the way), and none of these may carry an ACL entry. Otherwise the server serves a line saying the rules could not be read instead of any of them. In local and ssh modes the server reads as the user it serves, and the file system decides.

The instructions stay within 4,096 characters by default, because Claude Code cuts server instructions there. Whatever does not fit is named, and the cluster_context tool (and the rcac://context resource) returns all of it. To serve everything to Claude Code, raise both limits, the server's and Claude Code's:

add "--instructions-budget", "16384" to the server's args (or set RCAC_INSTRUCTIONS_BUDGET=16384);
set CLAUDE_CODE_MAX_MCP_DESCRIPTION_LENGTH=16384 in the shell that starts Claude Code, or in the env block of its settings.json. It raises Claude Code's limits on server instructions and on tool descriptions together (the variable needs Claude Code 2.1.280 or later; before 2.1.296 the default cut is 2,048 characters). /context shows what was loaded.

Execution Modes

The server supports three execution modes:

ssh (default for stdio) — Execute commands on a remote HPC cluster via SSH.
local — Execute commands locally under bash. For development/testing only.
delegate — Multi-user mode; run as a privileged process and delegate commands to authenticated users via sudo. Requires JWT or OIDC authentication.

In every mode a command runs in a login bash (/bin/bash -l), whatever the user's login shell, so module and the site's tools behave the same for everyone. No startup file reads a file's content or changes where a command starts, and nothing the login initialisation prints is returned, with one exception: over ssh, a background job started by the remote login shell's own rc file (zsh's .zshenv, say) can write into a result while the command runs (issues/startup-background-jobs.md). A result holds all of the command's output, however slowly it arrives: the launcher reports the command's end on both streams, and the call returns there, so a background job the command or a startup file leaves running never holds it, and what such a job prints afterwards is not returned. A command killed by signal N (or exiting 128+N) has exit code -N. write_file and sbatch's job script are written byte for byte; over ssh their content never rides a command's stdin but goes by SFTP to a private temporary file beside the target, which is checked against the bytes sent (its size and checksum) and then moved into place, so the file is replaced whole and keeps its permissions (but setuid and setgid, as cat > leaves them). A transfer that fails or falls short (a full filesystem, a spent quota) leaves the file untouched and says why, and a write refuses what cat > refuses (a file you may not write, a link whose target's directory is missing). A command that exceeds its timeout returns what it printed so far with exit code -1001; over ssh, a connection lost before the command's end was reported gives -1003: the command may have run.

See SECURITY.md for detailed architecture and configuration.

Hosted HTTP Server

For a shared hosted instance with authentication:

Basic HTTP Server

rcac-mcp -t http --ssh-host cluster.rcac.purdue.edu

With JWT Authentication

export JWT_SECRET="your-secret-key-at-least-32-characters"
rcac-mcp -t http -a jwt -e delegate

# Generate a token for clients
rcac-mcp --generate-token --lifetime 86400

Docker Compose with TLS

For production-like deployments with HTTPS:

# Install mkcert if needed
brew install mkcert
mkcert -install

# Generate certificates
mkdir -p certs
mkcert -cert-file certs/cert.pem -key-file certs/key.pem mcp.rcac.dev localhost 127.0.0.1

# Add to /etc/hosts
echo "127.0.0.1 mcp.rcac.dev" | sudo tee -a /etc/hosts

# Run
docker compose up

The server will be available at https://mcp.rcac.dev:8443.

RCAC Documentation

This server does not search RCAC documentation. The separate rcac-docs-mcp service at https://docs.rcac.purdue.edu/mcp does: add it to your MCP client alongside this server.

Available Tools

Shell & Filesystem

run_command(command, cwd, timeout) — Execute a shell command on the remote system
list_directory(path, show_hidden) — List contents of a directory
read_file(path, encoding, max_size) — Read contents of a file
write_file(path, content, append, create_dirs, encoding) — Write content to a file, byte for byte (encoding="base64" for binary)
upload_file(local_path, remote_path) — Upload a file to the remote system
download_file(remote_path, local_path) — Download a file from the remote system

Site context

cluster_context() — The cluster's rules from /etc/agents.d, in full, as read at startup

RCAC Cluster

myquota() — Show storage usage and quota limits
storage_paths() — Get resolved paths for home, scratch, and depot
jobinfo(job_id) — Detailed job information
jobcmd(job_id) — Command submitted for a job
jobenv(job_id) — Environment variables for a job
jobscript(job_id) — Full submission script for a job
showpartitions() — Available partitions and their status
average_wait(partition, account) — Queue wait time statistics

Slurm

sbatch(...) — Submit a batch job (from script path or inline content, written byte for byte); args are the job script's arguments, extra_args more sbatch options, each a list with one argument per element
squeue(...) — View the job queue
scancel(...) — Cancel jobs
sacct(...) — Query job accounting history
sinfo(...) — Cluster and partition status

The extra_args of sbatch, squeue, scancel, sacct and sinfo is a list of options, one argument per element (extra_args=["--long"]); a string is refused.

scontrol_show_job(job_id) — Detailed Slurm job info
scontrol_show_node(node) — Detailed node info
slist() — Slurm accounts and usage (RCAC-specific)
sfeatures() — Node hardware features and constraints (RCAC-specific)

Development

uv sync
rcac-mcp -e local

Run the test suite:

pytest

License

MIT
