Papilio Loader

Papilio Loader programs Papilio boards with FPGA bitstreams and ESP32 firmware. Use the Electron desktop application or the no-install browser-based Web Edition for USB and network-based workflows. MCP is an optional interface: the Electron app includes an MCP server, and a separate Python package remains available for Python-based workflows.

Desktop Application

The Electron desktop loader restores the Saved Files Library (save/load, rename, descriptions, delete, ZIP backup/import including Python exports) and the WiFi Log pop-out terminal (Stop/Reconnect/Clear, auto-scroll, ANSI colors). These are desktop-only extras in the shared UI; the hosted website still uses local file selection and USB logs. See Saved Files and Desktop Features.

The Windows desktop application includes system-tray integration and a simple interface for programming boards.

👉 Download Desktop App Installer

See DESKTOP_APP.md for installation and usage instructions.

Features

  • Electron Desktop Application: Windows app with system-tray integration
  • Web Edition: Browser-based loader for programming devices without installing a desktop app
  • USB and OTA programming: Flash over USB or, for compatible devices, WiFi/network
    • Discover OTA-capable devices on local network
    • Flash ESP32 firmware and FPGA bitstreams wirelessly
    • Supports devices with HTTP OTA endpoints (port 3232)
  • MCP integration: Available in the Electron app and through the separate Python package
  • Python REST API: FastAPI-based interface provided by the Python package
  • Saved Files Library: Save frequently-used firmware files with descriptions for easy reuse
  • Dual Programming Tools:
    • Official esptool for ESP32 programming (safe and stable)
    • pesptool (GadgetFactory fork) for FPGA programming only
  • Gowin FPGA Support: Flash Papilio boards (Gowin FPGA) with .bin files via pesptool
  • ESP32 Support: Flash ESP32 devices with bin/elf files using official esptool, supports multi-partition flashing

Quick Start

Option 1: Desktop Application (Easiest)

  1. Download and install PapilioLoader-Setup-x.x.x.exe from Releases
  2. Launch Papilio Loader from Start Menu
  3. System tray icon appears - right-click and select "Open Web Interface"

See DESKTOP_APP.md for details.

Option 2: Web Edition

Use the Papilio Loader Web Edition in a supported browser; nothing needs to be installed.

Option 3: Python MCP/API package

The separate Python package remains available for MCP, REST API, and its Python-hosted web interface:

uv pip install -e .
python start_combined_server.py

See Python installation and the MCP quick start for details.

Python Package Architecture

The following architecture describes the optional Python server package:

┌─────────────────┐         Network          ┌──────────────────┐
│   Web Browser   │ ◄────────────────────► │  Windows Host    │
│  WSL / Linux    │      HTTP/MCP           │ Combined Server  │
│  Build Machine  │                         │                  │
│ - Manual Upload │                         │ - Web UI         │
│ - Build FPGA    │                         │ - MCP Server     │
│ - Build ESP32   │                         │ - REST API       │
│ - Send files    │                         │ - pyserial       │
│                 │                         │ - esptool (ESP32)│
│                 │                         │ - pesptool (FPGA)│
└─────────────────┘                         └────────┬─────────┘
                                                     │ USB/Serial
                                                     ▼
                                            ┌─────────────────┐
                                            │ FPGA / ESP32    │
                                            │ Hardware        │
                                            └─────────────────┘

Python Package Installation

The Electron app is distributed through the GitHub Releases page. The following setup is for the separate Python package.

Prerequisites

  1. Python 3.12+: Required for running the server
  2. esptool: Official Espressif tool for ESP32 programming (installed automatically via pip)
  3. pesptool: GadgetFactory's fork for FPGA programming (included as git submodule)
    • Used ONLY for programming FPGA bitstreams to external flash
    • ESP32 uses official esptool for safety and stability

Setup

# Clone the repository
git clone https://github.com/papilio-labs/papilio-loader.git
cd papilio-loader

# Initialize submodules
git submodule update --init --recursive

# Create virtual environment using uv
uv venv

# Install dependencies
uv pip install -e .

Configuration

Set environment variables to configure the server:

# Network settings
PAPILIO_BIND_ADDRESS=0.0.0.0  # Use 0.0.0.0 for remote access, 127.0.0.1 for local only
PAPILIO_PORT=8000

# Security
PAPILIO_API_KEY=your-secret-key-here  # Optional API authentication
PAPILIO_CORS_ORIGINS=["http://localhost:3000"]  # Comma-separated list

# Limits
PAPILIO_MAX_UPLOAD_SIZE=52428800  # 50 MB in bytes
PAPILIO_RATE_LIMIT=60  # Requests per minute

# Serial settings
PAPILIO_DEFAULT_BAUD_RATE=115200
PAPILIO_SERIAL_TIMEOUT=10

Usage

As Standalone HTTP/SSE Server (Recommended for Remote Access)

The HTTP/SSE server runs as a standalone Windows process and allows VS Code (or other MCP clients) to connect over HTTP with Server-Sent Events (SSE) transport.

Benefits:

  • No need for VS Code to spawn the server process
  • Server runs continuously, independent of VS Code
  • Can be set up as a Windows service
  • Multiple clients can connect to the same server instance
  • Better for remote/network access scenarios

Start the server:

# Using the startup script
python start_mcp_server.py

# Or run the module directly
python -m papilio_loader_mcp.http_server --port 8765

# Or with custom host/port
python -m papilio_loader_mcp.http_server --host 0.0.0.0 --port 8765

The server will start on http://127.0.0.1:8000 with the SSE endpoint at /sse.

Configure VS Code:

Update .vscode/mcp.json in your project:

{
  "servers": {
    "papilio-loader": {
      "type": "sse",
      "url": "http://127.0.0.1:8000/sse"
    }
  }
}

Note: VS Code uses "servers" at the top level (not "mcpServers" which is for Claude Desktop).

For network access from other machines, use "url": "http://YOUR_WINDOWS_IP:8000/sse".

Set up as Windows Service (Optional):

To run the server automatically on Windows startup, you can use NSSM (Non-Sucking Service Manager) or Task Scheduler:

# Download NSSM from https://nssm.cc/download
nssm install PapilioMCP "C:\Python314\python.exe" "C:\development\papilio-loader-mcp\start_mcp_server.py"
nssm start PapilioMCP

As MCP Server (GitHub Copilot in VS Code - stdio mode)

This project is pre-configured for GitHub Copilot MCP integration. After installation:

  1. Reload VS Code window (Ctrl+Shift+P → "Developer: Reload Window")
  2. Open GitHub Copilot Chat
  3. The MCP tools will be available automatically

See VSCODE_SETUP.md for detailed setup instructions.

As MCP Server (Claude Desktop)

  1. Add to your Claude Desktop configuration (%APPDATA%\Claude\claude_desktop_config.json):
{
  "mcpServers": {
    "papilio-loader": {
      "type": "sse",
      "url": "http://localhost:8000/sse"
    }
  }
}

Note: Claude Desktop uses "mcpServers" at the top level (not "servers" which is for VS Code).

  1. Restart Claude Desktop

  2. Use natural language to interact:

    • "List available serial ports"
    • "Flash this bit file to COM3"
    • "Get ESP32 chip information on /dev/ttyUSB0"

As REST API Server

# Start the API server
python -m papilio_loader_mcp.api

# Or use uvicorn directly
uvicorn papilio_loader_mcp.api:api --host 0.0.0.0 --port 8000

API Endpoints

Health Check

curl http://localhost:8000/health

List Serial Ports

curl -H "X-API-Key: your-key" http://localhost:8000/ports

Get Device Info

curl -X POST http://localhost:8000/device/info \
  -H "Content-Type: application/json" \
  -H "X-API-Key: your-key" \
  -d '{"port": "COM3", "device_type": "esp32"}'

Flash Device

curl -X POST http://localhost:8000/flash/upload \
  -H "X-API-Key: your-key" \
  -F "file=@firmware.bin" \
  -F "port=COM3" \
  -F "device_type=esp32" \
  -F "address=0x1000" \
  -F "verify=true"

MCP Tools

The server provides these MCP tools:

USB/Serial Programming

  • list_serial_ports: List all available COM ports
  • get_device_info: Query device information (FPGA/ESP32)
  • get_flash_status: Get flash memory status and info
  • flash_device: Flash firmware to device with verification via USB/serial

OTA (Over-The-Air) Programming

  • discover_ota_devices: Scan local network for OTA-capable devices (HTTP endpoint on port 3232)
  • check_device_ip: Check if a specific IP address has an OTA endpoint available
  • flash_device_ota: Flash ESP32 firmware or FPGA bitstream via WiFi/network

OTA Usage Examples

Discover devices on network:

# Returns list of devices with their IP addresses and endpoints
discover_ota_devices(timeout=2, port=3232)

Check specific device:

# Verify device at known IP has OTA capability
check_device_ip(ip="10.0.4.35", port=3232)

Flash via OTA:

# Flash ESP32 firmware
flash_device_ota(
    ip="10.0.4.35",
    device_type="esp32",
    file_path="build/fpga_companion.bin",
    port=3232
)

# Flash FPGA bitstream
flash_device_ota(
    ip="10.0.4.35",
    device_type="fpga",
    file_path="impl/pnr/a2600nano_retrocade.bin",
    port=3232
)

Note: OTA flashing requires:

  • Device must be running firmware with HTTP OTA server on port 3232
  • Device must be connected to same network
  • ESP32 OTA endpoint: POST http://IP:3232/update
  • FPGA OTA endpoint: POST http://IP:3232/fpga-update

Development

Project Structure

papilio-loader/
├── src/
│   └── papilio_loader_mcp/
│       ├── __init__.py
│       ├── server.py          # MCP server implementation
│       ├── api.py             # FastAPI REST API
│       ├── config.py          # Configuration management
│       └── tools/             # Tool implementations
│           ├── serial_ports.py
│           ├── device_info.py
│           ├── flash_status.py
│           ├── fpga_flash.py
│           └── esp_flash.py
├── tools/
│   └── pesptool/             # Git submodule (GadgetFactory/esptool)
├── temp/                     # Temporary file uploads
├── logs/                     # Application logs
├── pyproject.toml
└── README.md

Running Tests

# TODO: Add tests
uv run pytest

Client Examples

Python Client

import requests

API_URL = "http://windows-host:8000"
API_KEY = "your-key"

headers = {"X-API-Key": API_KEY}

# List ports
response = requests.get(f"{API_URL}/ports", headers=headers)
print(response.json())

# Flash ESP32
with open("firmware.bin", "rb") as f:
    files = {"file": f}
    data = {
        "port": "COM3",
        "device_type": "esp32",
        "address": "0x1000",
        "verify": "true"
    }
    response = requests.post(
        f"{API_URL}/flash/upload",
        headers=headers,
        files=files,
        data=data
    )
    print(response.json())

WSL/Linux Client

#!/bin/bash
# flash_from_wsl.sh

WINDOWS_HOST="192.168.1.100:8000"
API_KEY="your-key"

# Build your project
make build

# Flash to device via Windows host
curl -X POST "http://${WINDOWS_HOST}/flash/upload" \
  -H "X-API-Key: ${API_KEY}" \
  -F "file=@build/firmware.bin" \
  -F "port=COM3" \
  -F "device_type=esp32" \
  -F "address=0x1000"

curl Examples

# List ports
curl http://localhost:8000/ports

# Get device info
curl -X POST http://localhost:8000/device/info \
  -H "Content-Type: application/json" \
  -d '{"port": "COM3", "device_type": "fpga"}'

# Flash FPGA
curl -X POST http://localhost:8000/flash/upload \
  -F "file=@design.bit" \
  -F "port=COM3" \
  -F "device_type=fpga"

Troubleshooting

Port Access Issues

  • Ensure no other programs are using the serial port
  • On Windows, check Device Manager for COM port assignments
  • Verify USB drivers are installed for your device

Permission Errors

  • Run as Administrator on Windows if accessing USB ports fails
  • Check firewall settings for network access

pesptool Not Found

  • Ensure git submodules are initialized: git submodule update --init
  • Check that tools/pesptool/esptool.py exists
  • pesptool is the unified tool for both FPGA and ESP32 programming

License

[Add your license here]

Contributing

Contributions welcome! Please open issues or pull requests.
