InDesign脚本MCP服务

InDesign Scripting MCP (DOM + Exec)

Two MCP servers for Adobe InDesign:

• InDesign DOM MCP (server.py): query InDesign DOM + ExtendScript JavaScript Core + ScriptUI classes from a local SQLite database built from XML sources.
• InDesign Exec MCP (exec_server.py): execute ExtendScript (JSX) or UXP JavaScript in a running InDesign instance via Windows COM/OLE and return structured JSON results.

What This Is

This project exposes two complementary servers to agents:

• DOM server: fast, read-only access to the object model without loading the entire DOM into the model context.
• Exec server: safe script execution with undo grouping, dual-engine support (ExtendScript ES3 & UXP ES6+), automatic modal dialog protection, and safe JSON serialization.

Script Engines & Language Selection

run_jsx supports two script engines via the language parameter:

Language Selection Policy for Agents

• DEFAULT to ExtendScript (language="javascript"): Decades of documentation and community solutions give LLMs unmatched accuracy for InDesign DOM operations.
• USE UXP (language="uxp") selectively: When modern JS data manipulation (map, filter, reduce, Set, Map, destructuring, async microtasks) significantly simplifies the task before layout placement.

Architecture

flowchart LR
  DOM_XML["omv$indesign-*.xml"] --> Parser[parser.py]
  JS_XML[javascript.xml] --> Parser
  SUI_XML[scriptui.xml] --> Parser
  Parser --> SQLite[(extendscript.db)]
  SQLite --> DomServer["server.py (InDesign DOM MCP)"]
  Agent[Agent] --> DomServer
  Agent --> ExecServer["exec_server.py (InDesign Exec MCP)"]
  ExecServer --> COM[COM/OLE DoScript]
  COM --> InDesign["Adobe InDesign (running)\n[ExtendScript ES3 / UXP V8]"]

Core files:

• server.py: MCP tools for querying the DOM database
• exec_server.py: MCP tools for script execution in InDesign (ExtendScript & UXP)
• parser.py: OMV XML parser + database builder (SQLite + FTS5)
• db.py: database query layer for DOM tools
• manage.py: CLI to analyze/build/update/validate the database
• indesign_com.py: COM/OLE automation layer + safe JSX/UXP wrapper + modal dialog watchdog
• json_polyfill.jsx: ExtendScript JSON polyfill + __safeStringify() (DOM-safe)
• gotchas.json: curated gotchas and best-practice knowledge base (community growth via PRs)

MCP Tools Reference

InDesign DOM MCP (server.py)

• lookup_class(name, source?): Look up class description, hierarchy, properties, and methods.
• get_properties(class_name, source?, filter?, include_inherited?): Get properties of a class.
• get_methods(class_name, source?, filter?, include_inherited?): Get methods of a class.
• get_method_detail(class_name, method_name, source?): Get detailed parameter types and return type for a method.
• get_enum_values(enum_name, source?): Get all member names and numeric values for an enumeration.
• get_hierarchy(class_name, source?): Get inheritance chain and direct subclasses.
• search_dom(query, source?): Full-text search across class names, properties, methods, and descriptions.
• list_classes(suite?, type=all, source?): List classes filtered by suite or type (class | enum | all).
• dom_info(): Database metadata and statistics.
• list_sources(): List indexed knowledge sources (dom, javascript, scriptui).
• knowledge_overview(): High-level overview of the scripting knowledge base.

InDesign Exec MCP (exec_server.py)

• run_jsx(code, undo_name="Agent Script", undo_mode="entire", language="javascript"|"uxp"): Execute ExtendScript (ES3) or UXP (ES6+/V8) code with undo grouping and safety wrapping.
• get_document_info(): Overview of the active document (pages, items, styles, active view/spread context).
• get_selection(detail_level="basic"|"full"): Information about the current selection in InDesign.
• eval_expression(expression): Quickly evaluate a short read-only expression without undo overhead.
• undo(steps=1): Undo the last operation(s) in the active document.
• report_learning(problem, solution, triggers, category?, severity?, error_message?, jsx_context?): Submit a local learning entry to the pending queue.
• get_gotchas(context?): Retrieve curated gotchas and pitfalls, ranked by relevance to a task context.
• get_quick_reference(): Comprehensive DOM cheatsheet with common access paths, collection patterns, and dynamic gotchas.

Agentic Usage / Key Patterns

1) Knowledge overview -> lookup -> code generation -> execution

1. Use DOM MCP to look up the correct class/method signature.
2. For ambiguous class names (Window, Group, Panel, Event) pass source="dom" or source="scriptui".
3. For ExtendScript-specific APIs (UnitValue, $, File, Folder, Socket, XML, XMLList) use source="javascript".
4. Write script code that assigns a plain value to __result (do not return).
5. Execute with run_jsx (defaulting to language="javascript", or language="uxp" for ES6+ data transformations).
6. Verify with eval_expression or get_document_info.
7. If needed, rollback with undo.

2) The __result Convention

The execution wrapper intercepts and serializes __result to JSON.

ExtendScript (language="javascript", default):

var doc = app.activeDocument;
__result = { name: doc.name, pages: doc.pages.length };

UXP Scripting (language="uxp"):

const { app, Justification } = require('indesign');
const doc = app.activeDocument;
const titles = doc.stories.everyItem().paragraphs.everyItem().contents
  .map(text => text.trim())
  .filter(text => text.length > 0);

__result = { totalParagraphs: titles.length, sample: titles.slice(0, 5) };

3) Undo Grouping

Use undo_mode="entire" (default) and a descriptive undo_name so one Ctrl+Z reverts the whole operation cleanly.

4) Collection Patterns (PREFER over loops)

InDesign collections support collective specifiers via everyItem() and direct accessors like itemByName(), itemByID(), itemByRange(). These are vastly more efficient because they execute as one command in InDesign rather than $N$ round-trips:

// Bulk property write — single operation
doc.textFrames.everyItem().fillColor = "None";

// Read all page names at once — returns Array
__result = doc.pages.everyItem().name;

// Direct accessor by name — no loop needed
var headingStyle = doc.paragraphStyles.itemByName("Heading 1");

5) UXP Scripting Notes & Constraints

• Imports: In UXP, always import DOM classes and enums with const { app, ...enums } = require('indesign');.
• Top-Level await: User code is automatically wrapped in an async IIFE. Top-level await Promise.all(...) and async helper functions work natively.
• Modal Dialog Protection: Unhandled runtime exceptions and syntax errors are caught by the MCP layer. Any InDesign modal dialogs are auto-dismissed to prevent COM lockups.
• Timer & Socket Limitations: Standalone InDesign scripts executed via COM do not pump main-thread macrotasks for setTimeout() or fetch(). Perform network requests and HTTP API calls in the external Python/Agent environment and pass the data into InDesign.

Data Sources

The parser supports three XML sources:

• InDesign DOM OMV XML (omv$indesign-*.xml)
• ExtendScript JavaScript Core (javascript.xml)
• ScriptUI (scriptui.xml)

Common source locations:

• macOS:
  • /Library/Application Support/Adobe/Scripting Dictionaries CC/CommonFiles
  • ~/Library/Preferences/ExtendScript Toolkit/4.0/omv$indesign-9.064$9.0.xml
• Windows:
  • \\Users\\[Username]\\AppData\\Roaming\\Adobe\\ExtendScript Toolkit\\4.0\\omv$indesign-10.064$10.0.xml
  • C:\\Program Files (x86)\\Common Files\\Adobe\\Scripting Dictionaries CC\\CommonFiles

Build Commands

Build all sources (recommended)

python manage.py build-all --dom "C:\\path\\to\\omv$indesign-21.064$21.0.xml" --js "C:\\path\\to\\javascript.xml" --sui "C:\\path\\to\\scriptui.xml"

Build single source

python manage.py build --source dom --xml "C:\\path\\to\\omv$indesign-21.064$21.0.xml"

Validate source coverage

python manage.py validate --expect-sources dom,javascript,scriptui

Prerequisites

• Windows (Exec server uses COM/OLE)
• Adobe InDesign Desktop (running)
• Python 3.11+
• uv (recommended) or pip
• OMV XML from the ExtendScript Toolkit cache, e.g.:
  • Windows: %APPDATA%\\Adobe\\ExtendScript Toolkit\\4.0\\omv$indesign-*.xml

Installation

1) Create/update the DOM database

python manage.py build-all --dom "C:\\path\\to\\omv$indesign-21.064$21.0.xml" --js "C:\\path\\to\\javascript.xml" --sui "C:\\path\\to\\scriptui.xml"

The resulting extendscript.db is generated locally and should not be committed.

2) Run the MCP servers (stdio transport)

With uv:

uv run server.py
uv run exec_server.py

With pip / plain Python:

python server.py
python exec_server.py

MCP Client Configuration

Cursor

Add two servers that run from this repo directory (use stdio transport):

{
  "mcpServers": {
    "indesign-dom": {
      "command": "uv",
      "args": ["run", "server.py"],
      "cwd": "D:\\path\\to\\indesign_scripting_MCP"
    },
    "indesign-exec": {
      "command": "uv",
      "args": ["run", "exec_server.py"],
      "cwd": "D:\\path\\to\\indesign_scripting_MCP"
    }
  }
}

Claude Desktop

Add the same server definitions to claude_desktop_config.json (the exact file location depends on your OS install).

Claude & Cursor Agent Skills

To maximize agent competence and enforce an inspect-lookup-execute-verify workflow, agent skills are provided for both platforms:

• Cursor Agent Skill: .cursor/skills/indesign-mcp-operator/SKILL.md (automatically detected by Cursor).
• Claude Skill: claude-skills/indesign-mcp-operator/SKILL.md and indesign-mcp-operator.skill.

Contributing Gotchas

The gotchas system is a shared debugging memory for this MCP:

• gotchas.json is the curated, versioned knowledge base committed to Git.
• Entries describe recurring pitfalls, fixes, and trigger keywords for context matching.
• Agents will query relevant items with get_gotchas(context, min_severity?, top_n?) before writing scripts.
• get_quick_reference() includes static guidance and appends community gotchas at runtime.
• During troubleshooting, agents can and will submit newly resolved issues via report_learning(...).

Contribution Paths

A) Direct curated updates via GitHub PR

1. Fork + clone this repository
2. Edit gotchas.json and add a new entry
3. Open a PR with the new gotcha
4. Maintainer review and merge

B) Agent submission -> maintainer review

1. Your agent calls report_learning(...)
2. Entry is written to submissions/pending.jsonl (local queue, not committed)
3. Maintainer runs:

python manage.py review-submissions

4. Approved entries are promoted to gotchas.json
5. Commit and open a PR to share the curated learning

License

MIT. See LICENSE.

Third-Party Notices

This repository references safety/serialization patterns inspired by IdExtenso (Marc Autret, MIT). See THIRD_PARTY_NOTICES.md.

Acknowledgements

• Gregor Fellenz: https://github.com/grefel/extendscriptApiDocTransformations
• This project adopts conceptual learnings from that repository:
  • XML merge strategy across InDesign DOM + JavaScript + ScriptUI
  • namespace normalization before parsing
  • explicit handling of ScriptUI naming collisions
  • reference-aware transformation mindset
