数据生产者消费者模式检测引擎

Producer returns:    { characterClass: "Fighter", hitPoints: 45 }
Consumer expects:    { class: "Fighter", hp: 45 }
Result:              ❌ Mismatch detected before runtime

# Clone the repository
git clone https://github.com/Mnehmos/mnehmos.trace.mcp.git

# Navigate to the directory
cd mnehmos.trace.mcp

# Install dependencies
npm install

# Build the project
npm run build

{
  "mcpServers": {
    "trace-mcp": {
      "command": "node",
      "args": ["/path/to/trace-mcp/dist/index.js"],
      "env": {}
    }
  }
}

server.tool(
  "get_character",
  "Fetch character data",
  {
    characterId: z.string().describe("Character ID"),
  },
  async (args) => {
    // implementation
  }
);

openapi: 3.0.0
info:
  title: Character API
  version: 1.0.0
paths:
  /characters/{id}:
    get:
      parameters:
        - name: id
          in: path
          schema:
            type: string
      responses:
        '200':
          content:
            application/json:
              schema:
                $ref: '#/components/schemas/Character'
components:
  schemas:
    Character:
      type: object
      properties:
        id:
          type: string
        name:
          type: string
        class:
          type: string
      required:
        - id
        - name
        - class

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.openapi.yaml", "**/*.swagger.json"],
});

export interface Character {
  id: string;
  name: string;
  class: "Fighter" | "Wizard" | "Rogue";
  hitPoints: number;
  stats: {
    strength: number;
    dexterity: number;
    constitution: number;
  };
}

export type ReadonlyCharacter = Readonly<Character>;

export enum CharacterClass {
  Fighter = "Fighter",
  Wizard = "Wizard",
  Rogue = "Rogue",
}

const result = await client.callTool("extract_schemas", {
  rootDir: "./shared",
  include: ["**/*.ts", "**/*.tsx"],
});
// Returns interfaces with ID format: interface:CharacterClass@./types.ts

import { z } from "zod";
import { publicProcedure, router } from "./trpc";

export const appRouter = router({
  users: router({
    getById: publicProcedure
      .input(z.string())
      .output(z.object({
        id: z.string(),
        name: z.string(),
        email: z.string().email(),
      }))
      .query(async ({ input }) => {
        // implementation
      }),

    create: publicProcedure
      .input(z.object({
        name: z.string(),
        email: z.string().email(),
      }))
      .output(z.object({
        id: z.string(),
        name: z.string(),
        email: z.string(),
      }))
      .mutation(async ({ input }) => {
        // implementation
      }),

    onChange: publicProcedure
      .output(z.object({
        userId: z.string(),
        action: z.enum(["created", "updated", "deleted"]),
      }))
      .subscription(async () => {
        // implementation
      }),
  }),
});

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend/trpc",
  include: ["**/*.router.ts"],
});
// Returns procedures with ID format: trpc:users.getById@./router.ts

import express from "express";
import { z } from "zod";

const app = express();

// Basic route with typed response
app.get("/users/:id", (req, res) => {
  const user: User = getUserById(req.params.id);
  res.json(user);
});

// Route with Zod validation middleware
app.post("/users",
  validate(z.object({
    name: z.string(),
    email: z.string().email(),
  })),
  (req, res) => {
    res.status(201).json({ id: "123", ...req.body });
  }
);

// Router-based routes
const router = express.Router();
router.get("/health", (req, res) => res.json({ status: "ok" }));
app.use("/api", router);

import Fastify from "fastify";

const fastify = Fastify();

// Route with JSON Schema validation
fastify.post("/users", {
  schema: {
    body: {
      type: "object",
      properties: {
        name: { type: "string" },
        email: { type: "string", format: "email" },
      },
      required: ["name", "email"],
    },
    response: {
      201: {
        type: "object",
        properties: {
          id: { type: "string" },
          name: { type: "string" },
        },
      },
    },
  },
}, async (request, reply) => {
  return { id: "123", name: request.body.name };
});

// Shorthand methods
fastify.get("/health", async () => ({ status: "ok" }));

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.ts"],
});
// Returns endpoints with ID format: rest:GET:/users/:id@./routes.ts

// Basic fetch with type assertion
const response = await fetch("/api/users");
const users: User[] = await response.json();

// fetch with request options
const newUser = await fetch("/api/users", {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({ name: "Alice" }),
}).then(res => res.json()) as CreateUserResponse;

// Template literal URLs
const userId = "123";
const user = await fetch(`/api/users/${userId}`).then(r => r.json());

// Property access tracking
console.log(user.name, user.email, user.profile.avatar);

import axios from "axios";

// Basic GET request
const { data: users } = await axios.get<User[]>("/api/users");

// POST with typed response
const response = await axios.post<CreateUserResponse>("/api/users", {
  name: "Bob",
  email: "bob@example.com",
});

// Instance with base URL
const api = axios.create({ baseURL: "https://api.example.com" });
const profile = await api.get<Profile>("/me");

// Destructured property access
const { name, email } = response.data;

const result = await client.callTool("trace_usage", {
  rootDir: "./frontend/src",
  include: ["**/*.ts", "**/*.tsx"],
});
// Returns HTTP client calls with ID format: http-client:GET:/api/users@./api.ts

# schema.graphql
type User {
  id: ID!
  name: String!
  email: String!
  posts: [Post!]!
}

type Post {
  id: ID!
  title: String!
  content: String!
  author: User!
}

type Query {
  user(id: ID!): User
  users: [User!]!
  post(id: ID!): Post
}

type Mutation {
  createUser(name: String!, email: String!): User!
  createPost(title: String!, content: String!, authorId: ID!): Post!
}

import { ApolloServer } from "@apollo/server";

const resolvers = {
  Query: {
    user: async (_, { id }) => {
      return db.users.findById(id);
    },
    users: async () => {
      return db.users.findAll();
    },
  },
  Mutation: {
    createUser: async (_, { name, email }) => {
      return db.users.create({ name, email });
    },
  },
  User: {
    posts: async (parent) => {
      return db.posts.findByAuthor(parent.id);
    },
  },
};

const server = new ApolloServer({ typeDefs, resolvers });

import { useQuery, useMutation, gql } from "@apollo/client";

const GET_USER = gql`
  query GetUser($id: ID!) {
    user(id: $id) {
      id
      name
      email
    }
  }
`;

const CREATE_USER = gql`
  mutation CreateUser($name: String!, $email: String!) {
    createUser(name: $name, email: $email) {
      id
      name
    }
  }
`;

function UserProfile({ userId }: { userId: string }) {
  const { data, loading, error } = useQuery(GET_USER, {
    variables: { id: userId },
  });

  const [createUser] = useMutation(CREATE_USER);

  if (loading) return <Spinner />;
  if (error) return <Error message={error.message} />;

  return <div>{data.user.name}</div>;
}

// Extract GraphQL schemas
const schemas = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.graphql", "**/resolvers.ts"],
});

// Trace Apollo Client usage
const usage = await client.callTool("trace_usage", {
  rootDir: "./frontend/src",
  include: ["**/*.tsx"],
});

// Compare for mismatches
const report = await client.callTool("compare", {
  producerDir: "./backend",
  consumerDir: "./frontend/src",
  format: "markdown",
});

from fastapi import FastAPI, APIRouter
from pydantic import BaseModel
from typing import Optional, List

class Character(BaseModel):
    id: str
    name: str
    character_class: str
    level: int = 1
    skills: List[str] = []

class CreateCharacterRequest(BaseModel):
    name: str
    character_class: str
    background: Optional[str] = None

app = FastAPI()
router = APIRouter(prefix="/api/v1")

@app.get("/characters/{character_id}")
async def get_character(character_id: str) -> Character:
    return Character(id=character_id, name="Hero", character_class="Fighter")

@router.post("/characters")
async def create_character(request: CreateCharacterRequest) -> Character:
    return Character(id="123", name=request.name, character_class=request.character_class)

app.include_router(router)

from flask import Flask, Blueprint, request, jsonify

app = Flask(__name__)
api = Blueprint("api", __name__, url_prefix="/api")

@app.route("/health")
def health_check():
    return jsonify({"status": "ok"})

@api.route("/users/<user_id>", methods=["GET"])
def get_user(user_id):
    return jsonify({"id": user_id, "name": "Alice"})

@api.route("/users", methods=["POST"])
def create_user():
    data = request.get_json()
    return jsonify({"id": "123", **data}), 201

app.register_blueprint(api)

from mcp import Server

server = Server("character-tools")

@server.tool()
async def get_character(character_id: str) -> dict:
    """Fetch character data by ID."""
    return {"id": character_id, "name": "Hero", "class": "Fighter"}

@mcp.tool()
def roll_dice(dice: str, modifier: int = 0) -> dict:
    """Roll dice with optional modifier."""
    return {"result": 15, "expression": dice, "modifier": modifier}

from pydantic import BaseModel, Field
from typing import Optional, List, Dict, Union, Literal
from enum import Enum

class CharacterClass(str, Enum):
    FIGHTER = "Fighter"
    WIZARD = "Wizard"
    ROGUE = "Rogue"

class Stats(BaseModel):
    strength: int = Field(ge=1, le=20)
    dexterity: int = Field(ge=1, le=20)
    constitution: int = Field(ge=1, le=20)

class Character(BaseModel):
    id: str
    name: str
    character_class: CharacterClass
    level: int = Field(default=1, ge=1, le=20)
    stats: Stats
    equipment: List[str] = []
    metadata: Optional[Dict[str, str]] = None

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.py"],
});
// Returns endpoints with ID format: python:GET:/characters/{id}@./main.py

package models

type Character struct {
    ID        string   `json:"id"`
    Name      string   `json:"name"`
    Class     string   `json:"class"`
    Level     int      `json:"level"`
    HitPoints int      `json:"hp"`
    Skills    []string `json:"skills,omitempty"`
}

type Stats struct {
    Strength     int `json:"str"`
    Dexterity    int `json:"dex"`
    Constitution int `json:"con"`
}

// Embedded struct
type CharacterWithStats struct {
    Character
    Stats Stats `json:"stats"`
}

package services

type CharacterService interface {
    GetByID(id string) (*Character, error)
    Create(req CreateRequest) (*Character, error)
    Update(id string, req UpdateRequest) (*Character, error)
    Delete(id string) error
}

type Repository interface {
    Find(query Query) ([]Character, error)
    Save(character *Character) error
}

package main

import (
    "encoding/json"
    "net/http"
)

func main() {
    http.HandleFunc("/health", healthHandler)
    http.HandleFunc("/api/characters", charactersHandler)
    http.HandleFunc("/api/characters/", characterByIDHandler)
    http.ListenAndServe(":8080", nil)
}

func healthHandler(w http.ResponseWriter, r *http.Request) {
    json.NewEncoder(w).Encode(map[string]string{"status": "ok"})
}

func charactersHandler(w http.ResponseWriter, r *http.Request) {
    switch r.Method {
    case http.MethodGet:
        // List characters
    case http.MethodPost:
        // Create character
    }
}

package main

import (
    "github.com/go-chi/chi/v5"
    "net/http"
)

func main() {
    r := chi.NewRouter()

    r.Get("/health", healthHandler)

    r.Route("/api/characters", func(r chi.Router) {
        r.Get("/", listCharacters)
        r.Post("/", createCharacter)
        r.Get("/{id}", getCharacter)        // Chi param: {id}
        r.Put("/{id}", updateCharacter)
        r.Delete("/{id}", deleteCharacter)
    })

    http.ListenAndServe(":8080", r)
}

package main

import "github.com/gin-gonic/gin"

func main() {
    r := gin.Default()

    r.GET("/health", healthHandler)

    api := r.Group("/api")
    {
        api.GET("/characters", listCharacters)
        api.POST("/characters", createCharacter)
        api.GET("/characters/:id", getCharacter)  // Gin param: :id
        api.PUT("/characters/:id", updateCharacter)
        api.DELETE("/characters/:id", deleteCharacter)
    }

    r.Run(":8080")
}

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.go"],
});
// Returns structs, interfaces, and endpoints

syntax = "proto3";

package character;

message Character {
    string id = 1;
    string name = 2;
    CharacterClass character_class = 3;
    int32 level = 4;
    Stats stats = 5;
    repeated string skills = 6;
}

message Stats {
    int32 strength = 1;
    int32 dexterity = 2;
    int32 constitution = 3;
}

enum CharacterClass {
    CHARACTER_CLASS_UNSPECIFIED = 0;
    CHARACTER_CLASS_FIGHTER = 1;
    CHARACTER_CLASS_WIZARD = 2;
    CHARACTER_CLASS_ROGUE = 3;
}

enum DamageType {
    DAMAGE_TYPE_UNSPECIFIED = 0;
    DAMAGE_TYPE_SLASHING = 1;
    DAMAGE_TYPE_PIERCING = 2;
    DAMAGE_TYPE_FIRE = 3;
}

message Equipment {
    string id = 1;
    string name = 2;

    oneof item_type {
        Weapon weapon = 10;
        Armor armor = 11;
        Consumable consumable = 12;
    }
}

message Inventory {
    string character_id = 1;
    map<string, int32> item_counts = 2;
    map<string, Equipment> equipped = 3;
}

service CharacterService {
    // Unary RPC
    rpc GetCharacter(GetCharacterRequest) returns (Character);

    // Server streaming
    rpc ListCharacters(ListRequest) returns (stream Character);

    // Client streaming
    rpc UploadInventory(stream Item) returns (UploadResponse);

    // Bidirectional streaming
    rpc Chat(stream ChatMessage) returns (stream ChatMessage);
}

message GetCharacterRequest {
    string id = 1;
}

message ListRequest {
    int32 page_size = 1;
    string page_token = 2;
}

import "google/protobuf/timestamp.proto";
import "google/protobuf/duration.proto";
import "google/protobuf/any.proto";
import "google/protobuf/struct.proto";

message CharacterEvent {
    string character_id = 1;
    string event_type = 2;
    google.protobuf.Timestamp created_at = 3;
    google.protobuf.Duration duration = 4;
    google.protobuf.Any payload = 5;
    google.protobuf.Struct metadata = 6;
}

const result = await client.callTool("extract_schemas", {
  rootDir: "./proto",
  include: ["**/*.proto"],
});
// Returns messages, enums, and services

import requests

# Basic GET
response = requests.get("https://api.example.com/characters")
characters = response.json()

# GET with path parameter
character = requests.get(f"https://api.example.com/characters/{char_id}").json()

# POST with JSON body
new_char = requests.post(
    "https://api.example.com/characters",
    json={"name": "Hero", "class": "Fighter"}
).json()

# Session with base URL
session = requests.Session()
session.headers.update({"Authorization": "Bearer token"})
user = session.get("https://api.example.com/me").json()

# Property access tracking
print(character["name"], character["stats"]["strength"])

import httpx

# Sync client
response = httpx.get("https://api.example.com/characters")
data = response.json()

# Async client
async with httpx.AsyncClient(base_url="https://api.example.com") as client:
    response = await client.get("/characters")
    characters = response.json()

    response = await client.post("/characters", json={"name": "Hero"})
    new_char = response.json()

import aiohttp

async with aiohttp.ClientSession() as session:
    # GET request
    async with session.get("https://api.example.com/characters") as response:
        characters = await response.json()

    # POST request
    async with session.post(
        "https://api.example.com/characters",
        json={"name": "Hero", "class": "Fighter"}
    ) as response:
        new_char = await response.json()

    # Property access
    print(new_char["id"], new_char["name"])

const result = await client.callTool("trace_usage", {
  rootDir: "./python-client",
  include: ["**/*.py"],
});
// Returns HTTP client calls with property access patterns

src/patterns/
├── base.ts          # BasePattern abstract class
├── types.ts         # PatternMatch, PatternContext interfaces
├── registry.ts      # PatternRegistry for plugin management
├── extractors.ts    # Node extractors for AST traversal
├── errors.ts        # Pattern-specific error types
├── rest/            # Express, Fastify patterns
├── http-clients/    # fetch, axios patterns
└── graphql/         # Apollo patterns

const result = await client.callTool("extract_schemas", {
  rootDir: "./backend/src",
});
// Returns: { success: true, count: 12, schemas: [...] }

# mnehmos.trace.mcp Analysis Report

**Generated**: 2025-12-11T02:11:48.624Z

## Summary

| Metric      | Count |
| ----------- | ----- |
| Total Tools | 12    |
| Total Calls | 34    |
| Matches     | 31    |
| Mismatches  | 3     |

## Mismatches

### get_character

- **Type**: MISSING_PROPERTY
- **Description**: Consumer expects "characterClass" but producer has "class"
- **Consumer**: ./components/CharacterSheet.tsx:45
- **Producer**: ./tools/character.ts:23

/**
 * Get character data
 * @trace-contract CONSUMER
 * Producer: ./server/character-tools.ts:23
 */
export async function getCharacter(
  client: McpClient,
  args: GetCharacterArgs
): Promise<GetCharacterResult> {
  try {
    const result = await client.callTool("get_character", args);
    return JSON.parse(result.content[0].text);
  } catch (error) {
    console.error("Error calling get_character:", error);
    throw error;
  }
}

import { z } from "zod";

// Tool: get_character
// Scaffolded from consumer at ./components/CharacterSheet.tsx:14
// @trace-contract PRODUCER (scaffolded)

server.tool(
  "get_character",
  "TODO: Add description",
  {
    characterId: z.string(),
  },
  async (args) => {
    // TODO: Implement handler
    // Consumer expects: name, race, level, stats, characterClass
    return {
      content: [
        {
          type: "text",
          text: JSON.stringify({
            name: null, // TODO
            race: null, // TODO
            level: null, // TODO
          }),
        },
      ],
    };
  }
);

// Producer comment:
/*
 * @trace-contract PRODUCER
 * Tool: get_character
 * Consumer: ./components/CharacterSheet.tsx:14
 * Args: characterId
 * Validated: 2025-12-11
 */

// Consumer comment:
/*
 * @trace-contract CONSUMER
 * Tool: get_character
 * Producer: ./server/character-tools.ts:23
 * Required Args: characterId
 * Validated: 2025-12-11
 */

const result = await client.callTool("init_project", {
  projectDir: "./my-app",
  producerPath: "./backend/src",
  consumerPath: "./frontend/src",
});
// Creates: ./my-app/.trace-mcp/config.json

{
  "success": true,
  "exists": true,
  "projectDir": "/path/to/project",
  "config": {
    "producer": { "path": "./server", "language": "typescript" },
    "consumer": { "path": "./client", "language": "typescript" }
  },
  "isWatching": true,
  "watcherStatus": { "running": true, "pendingChanges": 0 }
}

// Compare backend vs frontend, get markdown report
const result = await client.callTool("compare", {
  producerDir: "./backend/src",
  consumerDir: "./frontend/src",
  format: "markdown",
});

// Initialize project
await client.callTool("init_project", {
  projectDir: ".",
  producerPath: "./server",
  consumerPath: "./client",
});

// Start watching
await client.callTool("watch", {
  projectDir: ".",
  action: "start",
});

// Later: poll for results
const status = await client.callTool("watch", {
  projectDir: ".",
  action: "poll",
});

// Generate client code from server schema
const consumer = await client.callTool("scaffold_consumer", {
  producerDir: "./server",
  toolName: "get_character",
  target: "react-hook",
});

// Or generate server stub from client usage
const producer = await client.callTool("scaffold_producer", {
  consumerDir: "./client",
  toolName: "save_settings",
});

// Extract from MCP server
const mcpSchemas = await client.callTool("extract_schemas", {
  rootDir: "./backend/mcp",
  include: ["**/*.ts"],
});

// Extract from OpenAPI specification
const openApiSchemas = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.openapi.yaml"],
});

// Extract from tRPC router
const trpcSchemas = await client.callTool("extract_schemas", {
  rootDir: "./backend/trpc",
  include: ["**/*.router.ts"],
});

// Extract TypeScript interfaces
const interfaceSchemas = await client.callTool("extract_schemas", {
  rootDir: "./shared",
  include: ["**/*.types.ts"],
});

// Extract REST endpoints (Express/Fastify)
const restSchemas = await client.callTool("extract_schemas", {
  rootDir: "./backend/routes",
  include: ["**/*.ts"],
});

// Extract GraphQL schemas
const graphqlSchemas = await client.callTool("extract_schemas", {
  rootDir: "./backend/graphql",
  include: ["**/*.graphql", "**/resolvers.ts"],
});

// Extract GraphQL schema and resolvers
const producer = await client.callTool("extract_schemas", {
  rootDir: "./backend",
  include: ["**/*.graphql", "**/resolvers/**/*.ts"],
});

// Trace Apollo Client hooks
const consumer = await client.callTool("trace_usage", {
  rootDir: "./frontend/src",
  include: ["**/*.tsx"],
});

// Compare for schema drift
const report = await client.callTool("compare", {
  producerDir: "./backend",
  consumerDir: "./frontend/src",
  format: "markdown",
});
