Homelab Automation Stack

Full-stack homelab monitoring and automation system running on a single Docker-capable LXC on Proxmox. Manages Proxmox VE, Unraid NAS, UniFi networking, and Home Assistant through MCP servers, Prometheus monitoring, automated remediation, and Home Assistant notifications.

Architecture

┌─────────────────────────────────────────────────────────┐
│  Docker LXC on Proxmox                                  │
│                                                         │
│  MCP Servers (Claude Desktop connects via HTTP)         │
│  ├── proxmox-mcp    :3001  ← bsahane/mcp-proxmox       │
│  ├── unraid-mcp     :3002  ← jmagar/unraid-mcp         │
│  ├── unifi-mcp      :3003  ← sirkirby/unifi-network-mcp│
│  ├── ha-mcp         :3005  ← homeassistant-ai/ha-mcp   │
│  ├── arr-mcp        :3006  ← mcp-arr via supergateway  │
│  ├── pihole-mcp     :3007  ← mcp-pihole via supergateway│
│  ├── uptimekuma-mcp :3008  ← lefty3382/uptime-kuma-mcp │
│  ├── jellyfin-mcp   :3009  ← jellyfin-mcp (jellyctrl)  │
│  ├── jellyseerr-mcp :3010  ← aserper/jellyseerr-mcp    │
│  └── garmin-mcp     :3011  ← Taxuspt/garmin_mcp        │
│                                                         │
│  Monitoring                                             │
│  ├── prometheus      :9090  ← scrapes exporters         │
│  ├── grafana         :3000  ← dashboards                │
│  ├── alertmanager    :9093  ← routes to alert-bridge    │
│  ├── pve-exporter    :9221  ← Proxmox metrics           │
│  ├── node-exporter   :9100  ← host metrics              │
│  └── unpoller        :9130  ← UniFi metrics             │
│                                                         │
│  Custom Services                                        │
│  ├── alert-bridge    :3004  ← Alertmanager → HA notify  │
│  ├── n8n             :5678  ← auto-remediation          │
│  └── immich-poller          ← health checks → HA        │
└─────────────────────────────────────────────────────────┘

Quick Start

1. Clone and configure:

   复制

   cp .env.example .env
   # Edit .env with your actual IPs, tokens, and credentials


2. Update Prometheus targets: Edit monitoring/prometheus/prometheus.yml and replace placeholder IPs with your Proxmox host IP.

3. Start the stack:

   复制

   docker compose up -d


4. Configure Claude Desktop (~/.config/claude/claude_desktop_config.json):

   复制

   {
     "mcpServers": {
       "proxmox":        { "url": "http://<lxc-ip>:3001/mcp" },
       "unraid":         { "url": "http://<lxc-ip>:3002/mcp" },
       "unifi":          { "url": "http://<lxc-ip>:3003/mcp" },
       "home-assistant": { "url": "http://<lxc-ip>:3005/mcp" },
       "arr":            { "url": "http://<lxc-ip>:3006/mcp" },
       "pihole":         { "url": "http://<lxc-ip>:3007/mcp" },
       "uptimekuma":     { "url": "http://<lxc-ip>:3008/mcp" },
       "jellyfin":       { "url": "http://<lxc-ip>:3009/mcp" },
       "jellyseerr":     { "url": "http://<lxc-ip>:3010/mcp" },
       "garmin":         { "url": "http://<lxc-ip>:3011/mcp" }
     }
   }


5. Set up Grafana dashboards: Open Grafana at http://<lxc-ip>:3000, go to Dashboards → Import, and enter IDs:

   • 10347 — Proxmox VE
   • 11315 — UniFi
   • 1860 — Node Exporter

6. Import n8n workflows: Open n8n at http://<lxc-ip>:5678, import JSONs from n8n/workflows/.

7. Authenticate Garmin (one-time): Garmin has no official personal API, so the MCP server logs in as you and caches OAuth tokens. This login is interactive because Garmin may demand an MFA code, so it cannot be done from the compose file:

   复制

   docker compose run --rm garmin-mcp garmin-mcp-auth


   Tokens are written to the garmin_tokens volume and last roughly a year. Note the container still starts and serves HTTP without them — it looks healthy and lists all 150 tools, but every tool call fails until this login has been run once. Re-run it when tokens expire; docker compose logs garmin-mcp names the problem explicitly.

8. Add HA automations: Copy homeassistant/automations.yaml entries into your Home Assistant config and update entity IDs.

Services

Directory Structure

homelab/
├── docker-compose.yml
├── .env.example
├── monitoring/
│   ├── prometheus/
│   │   ├── prometheus.yml
│   │   └── alerting_rules.yml
│   ├── alertmanager/
│   │   └── alertmanager.yml
│   └── grafana/provisioning/
│       ├── datasources/prometheus.yml
│       └── dashboards/dashboards.yml
├── alert-bridge/          # Alertmanager → HA bridge
├── immich-poller/         # Immich health checker
├── n8n/workflows/         # Auto-remediation workflows
└── homeassistant/         # HA automation YAML
