ConnectwiseMCP

ConnectWise MCP server migrating from the legacy Docker/FastAPI gateway to a secure Cloudflare Worker v2.

Migration status: v2 is implemented in src/ with Entra OAuth, rotating refresh, immutable identity mapping, structured sanitized tool audit events, and a bounded purpose-built ConnectWise business catalog. Every invocation resolves exactly one CW_PROFILE_<ALIAS> Worker secret, requires its origin in CONNECTWISE_ALLOWED_ORIGINS, rejects redirects, and creates a fresh request-scoped client. The mapped user's ConnectWise API-member Security Role remains the final authority for both reads and writes. Generic raw API/debug tools remain excluded. Document downloads are capped at 6 MB; image uploads use an inline MCP App, client-side resizing, a 1 MB server cap, fixed Ticket/TimeEntry targets, MIME-signature verification, and non-retried multipart writes. The legacy deployment under deploy/ remains available for rollback until v2 passes staging, isolation, observability, and rollback acceptance. See docs/v2-foundation.md.

Structure

.
├── src/                       # Cloudflare Worker v2 foundation
├── tests/                     # v2 security and OAuth tests
├── ui/                        # bundled inline MCP attachment uploader
├── scripts/                   # staging smoke and deterministic UI embedding
├── package.json               # exact v2 dependency versions and checks
├── wrangler.jsonc             # non-secret Worker configuration
├── deploy/                    # legacy Docker/FastAPI rollback path
│   ├── cwm-mcp/              # Core MCP tools (ConnectWise API gateway)
│   └── http-gateway/         # Supported rollback image and HTTP gateway
├── docs/
│   ├── README.md             # Docs index
│   ├── chatgpt-connector.md  # ChatGPT V2 boundary and rollback reference
│   ├── claude-setup.md       # Claude V2 and localhost setup
│   ├── azure-ad-checklist.md # Legacy Azure AD checklist
│   ├── troubleshooting.md    # Legacy gateway checks
│   └── n8n-setup.md          # n8n support status
└── README.md

Architecture

See the proposed Cloudflare Worker v2 architecture and standalone HTML visual. The diagram below describes the current Docker deployment.

┌──────────────────────────┐    HTTPS    ┌──────────────────────┐    HTTP    ┌──────────────────────┐
│ MCP Clients              │────────────▶│ Cloudflare Tunnel     │──────────▶│ HTTP Gateway (FastAPI)│
│ (ChatGPT / Claude / etc) │             │ connectwisemcp...     │           │ - OAuth 2.1 + PKCE    │
└──────────────────────────┘             └──────────────────────┘           │ - DCR endpoints       │
                                                                            │ - Azure AD login      │
                                                                            │ - /mcp + /sse         │
                                                                            └───────────┬──────────┘
                                                                                        │
                                                                                        ▼
                                                                            ┌──────────────────────┐
                                                                            │ MCP Tools (cwm-mcp)  │
                                                                            │ ConnectWise API      │
                                                                            └──────────────────────┘

Legacy rollback safety boundary

The Docker/FastAPI gateway under deploy/ is retained only as a controlled emergency rollback path while Worker v2 completes live acceptance. Its OAuth boundary is hardened to:

• return a generated client secret only once during bounded dynamic registration;
• cap registration bodies at 16 KiB, redirect lists at 10 entries, individual redirects at 2,048 characters, names at 128 characters, caller state at 512 characters, Azure subject IDs at 256 characters, and each process-local client/auth-request/auth-code store at 1,000 entries;
• expire newly registered clients after 24 hours and evict expired entries before admitting more registrations;
• expose no unauthenticated client-registration readback or management URI;
• reject unknown clients instead of authorization-time auto-provisioning;
• allow only client_secret_post, authorization-code grants, code responses, bounded allowlisted scopes, and S256 PKCE;
• require strict absolute HTTPS callback URIs and literal redirect/resource binding;
• consume callback state and authorization codes once;
• sanitize upstream OAuth failures and Azure verification logs;
• require signed RS256 Entra tokens with exact issuer/audience, mandatory exp/iat, time validation, and rate-limited JWKS refresh on key rotation;
• require mcp:tools:execute on local or Entra OAuth tokens before either broad legacy MCP transport is exposed; the static bearer token remains an explicitly privileged rollback credential;
• require at least 32 ASCII bytes for the local JWT signing secret and static bearer token.

It still has material legacy limitations:

• dynamic registration remains unauthenticated, has no redirect allowlist or application-level rate limit, and therefore requires perimeter access control;
• clients, callback state, and authorization codes are process-local; client registrations expire after 24 hours, and all state disappears on restart;
• locally issued access tokens expire after one hour and the gateway has no refresh-token grant;
• one deployment-wide ConnectWise credential set and static bearer token remain available;
• OAuth scope claims do not provide per-tool authorization;
• it does not provide Worker v2's immutable six-user identity mapping, request-scoped profile secrets, narrow tool authorization, or structured audit model;
• broad legacy MCP tools remain present.

Do not treat this gateway as the production target or leave it generally exposed after v2 cutover. Any rollback must be time-bounded, access-controlled, monitored, and reversed after the incident. Never commit .env or registration responses, and never copy real client, Entra, ConnectWise, Cloudflare, or JWT secrets into logs or issue reports.

The rollback build uses hash-locked Python dependencies and digest-pinned Python and cloudflared images. legacy-oauth-ci rebuilds, audits, and scans the gateway, then packages, reloads, and smoke-tests both the gateway and cloudflared images. It retains the exact tested archives, SHA-256 checksums, and release manifest for 90 days so rollback does not depend on registry availability or a pre-populated host cache. Use the successful canonical main run for the reviewed release commit; locally rebuilt or separately pulled images are not equivalent evidence. Dependency changes start in deploy/http-gateway/requirements.txt and deploy/cwm-mcp/requirements.txt; regenerate requirements.lock with the exact uv pip compile command recorded at the top of that file and review the resolved versions and hashes. Image changes require the same reviewed CI path. Before rollback, follow the artifact verification and --no-build --pull never procedure in the cutover and rollback runbook. Do not replace a digest with a floating image reference during an incident.

Local development Docker setup (gateway only)

Development only: The commands in this section build the broad legacy gateway locally. They are not the supported emergency rollback procedure and must not be used to expose a rollback deployment. For rollback, use the successful canonical main artifact and the runbook's verified --no-build --pull never procedure.

The local Docker setup lives in deploy/http-gateway/docker-compose.yml; start only mcp-gateway (the FastAPI HTTP gateway). Do not start the cloudflared service for local development.

Steps:

1. Copy env template and fill values:

cp deploy/http-gateway/.env.example deploy/http-gateway/.env

Required values:

• MCP_STATIC_TOKEN (strong random token)
• JWT_SECRET_KEY (required for OAuth tokens)
• CONNECTWISE_* variables
• SERVER_URL=http://127.0.0.1:8000
• MCP_RESOURCE_URL=http://127.0.0.1:8000

2. Build and run the local-only gateway:

cd deploy/http-gateway
docker compose up -d --build mcp-gateway

3. Verify:

curl http://127.0.0.1:8000/health

Note: the gateway binds to 127.0.0.1:8000. Keep this local development instance private; do not attach a tunnel or public route.

Local macOS install (Homebrew + Docker)

Use this if you want to run the MCP gateway locally and connect Claude to 127.0.0.1.

1. Install Homebrew + tooling:

/bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/HEAD/install.sh)"
brew install git
brew install --cask docker

Open Docker Desktop once and wait for it to finish starting.

2. Clone the repo:

git clone https://github.com/luckyludev/ConnectwiseMCP.git
cd ConnectwiseMCP

3. Configure local env:

cp deploy/http-gateway/.env.example deploy/http-gateway/.env

Edit deploy/http-gateway/.env and set:

• MCP_STATIC_TOKEN (strong random token)
• JWT_SECRET_KEY (strong random secret)
• CONNECTWISE_* values
• SERVER_URL=http://127.0.0.1:8000
• MCP_RESOURCE_URL=http://127.0.0.1:8000

4. Start the local gateway (Docker):

cd deploy/http-gateway
docker compose up -d --build mcp-gateway

Verify:

curl http://127.0.0.1:8000/health

5. Add the local MCP server in Claude:

• Name: ConnectwiseMCP (Local)
• Server URL: http://127.0.0.1:8000/sse
• Auth: Bearer token
• Token: your MCP_STATIC_TOKEN

Quick start (local token auth)

Test locally:

curl -H "Authorization: Bearer ***" http://127.0.0.1:8000/mcp

Legacy-only JSON-RPC example

This request targets the broad Docker/FastAPI rollback surface and is not a Worker V2 capability or recommendation. Worker V2 intentionally does not expose generic API discovery tools such as search_api_endpoints; see docs/legacy-read-surface-classification.md.

List tools:

{
  "jsonrpc": "2.0",
  "id": 1,
  "method": "tools/list",
  "params": {}
}

Call a tool:

{
  "jsonrpc": "2.0",
  "id": 2,
  "method": "tools/call",
  "params": {
    "name": "search_api_endpoints",
    "arguments": {
      "query": "tickets",
      "max_results": 5
    }
  }
}

Client support and operator references

• ChatGPT V2 boundary and rollback reference: docs/chatgpt-connector.md
• Claude V2 and localhost-development setup: docs/claude-setup.md
• n8n support status: docs/n8n-setup.md
• Copilot Studio support status: docs/copilot-studio-azure.md
• Legacy Azure AD checklist: docs/azure-ad-checklist.md
• Legacy troubleshooting: docs/troubleshooting.md

These pages do not authorize an independent legacy deployment. Production onboarding remains gated by the V2 staging checklist; emergency rollback follows docs/cutover-rollback-runbook.md.

Security notes

• Do not commit .env files.
• Rotate any credentials that were previously committed.

Legacy

The only supported legacy deployment is the controlled Docker/FastAPI rollback path under deploy/http-gateway, backed by deploy/cwm-mcp. Unsupported Supergateway and mcpo reference images are intentionally excluded so every executable deployment descriptor is covered by rollback CI.
