blazing-art-mcp
An Adaptive Radix Tree (Leis et al. 2013) wired up as a Model Context Protocol server. Indexes tree-sitter ASTs of any codebase into microsecond-latency, prefix-scannable structured memory for coding agents.
The mission: make ART a defensible primitive for agentic memory by making it real and measurably better than the alternatives on the workload coding agents actually run — prefix scans over symbol-shaped keys.
What's actually here
| Component | Where |
|---|---|
Real ART backend (blart::TreeMap) |
src/memory.rs |
| JSON-RPC dispatch | src/protocol.rs |
| Stdio MCP transport | src/transport/stdio.rs |
| HTTP+SSE MCP transport (axum, spec 2025-06-18) | src/transport/http.rs |
| Tree-sitter AST ingestion (Rust, Python, TypeScript, TSX, Go, Java, C, C++, JavaScript — v0.2; Ruby — v0.3) | src/ingest.rs, queries/<lang>/tags.scm |
| Criterion benchmarks (point/prefix/insert + scaling sweep + real-data) | benches/art_benchmarks.rs |
| Per-backend isolated RSS measurement (macOS-only) | benches/memory_rss.rs |
| Shared synthetic key generator | benches/shared/keygen.rs |
| Integration tests against a 3-file fixture | tests/ingest_e2e.rs |
| Headline numbers + methodology | BENCHMARKS.md |
| Vanilla-JS web demo | static/index.html |
Tools exposed
| Tool | What it does |
|---|---|
lookupEntity(name) |
Exact-match entity fetch from in-memory store. |
addEntity(name, summary, born?, tags) |
Insert/update an entity. |
findEvents(prefix) |
ART prefix scan over event ids (capped by --event-limit). |
addEvent(id?, timestamp?, description, category) |
Insert/update an event. |
ingestRepo(path, repo_id?) |
Walk a repo, parse .rs/.py/.ts/.tsx/.go/.java/.c/.cpp/.js with tree-sitter, index every declaration and reference symbol via the tags.scm-driven engine (v0.2). Each declaration writes a primary + inverted key; each reference writes a ref\x01... key. Parse stage runs in parallel via rayon. |
findSymbols(prefix, limit?) |
ART prefix scan over the symbol index. See key schema below. |
findReferences(name, kind?, repo?, limit?) |
(v0.2) Find every call-site / use of a symbol by name across the index. Backed by a single prefix scan over the ref\x01<name>\x01... namespace; kind and repo further tighten the filter server-side. |
deleteRepo(repo_id) |
Remove every symbol entry for a repo (definitions and references). |
Key schema (locked — don't change without re-checking blart::NoPrefixesBytes)
The segment separator inside composite keys is \x01 (SOH), not \x00,
because blart::TreeMap::insert requires NoPrefixesBytes, which String
doesn't satisfy. We use CString::new(<bytes-with-internal-SOH-but-no-NUL>),
which appends the trailing \x00 that makes any inserted key prefix-free.
Primary : pri\x01<repo>\x01<rel_path>\x01<line5>:<col3>:<kind>\x01<name>
Inverted : sym\x01<kind>\x01<name>\x01<repo>\x01<rel_path>:<line>
Prefix scan examples:
| Prefix | Returns |
|---|---|
pri\x01myrepo\x01 |
every symbol in the repo (sorted by file, then line) |
pri\x01myrepo\x01src/auth.rs\x01 |
every symbol in that file (sorted by line) |
pri\x01myrepo\x01src/\x01 |
every symbol in src/ |
sym\x01function_item\x01parse_request\x01 |
every parse_request function across all repos |
sym\x01struct_item\x01Memory\x01 |
every Memory struct across all repos |
Build and run
cargo build --release # binary: target/release/blazing_art_mcp
cargo test # 13 tests (7 unit + 6 integration)
cargo clippy --all-targets -- -D warnings
# Default Criterion suite (point lookup, prefix scan, bulk insert,
# scaling sweep at 10k/100k/1M, real-data tier 1 = own src/):
cargo bench --bench art_benchmarks
# Add the 5M scaling tier (requires ~2.5 GB peak RSS):
BLAZING_ART_BENCH_SCALE=full cargo bench --bench art_benchmarks
# Real-data tiers 2 + 3 (require local repos):
CPYTHON_LIB_PATH=$HOME/cpython/Lib cargo bench --bench art_benchmarks
TYPESCRIPT_SRC_PATH=$HOME/typescript/src cargo bench --bench art_benchmarks
# Per-backend isolated RSS measurement (run all three for the table in BENCHMARKS.md):
BLAZING_ART_RSS_TARGET=art cargo bench --bench memory_rss -- --nocapture
BLAZING_ART_RSS_TARGET=btreemap cargo bench --bench memory_rss -- --nocapture
BLAZING_ART_RSS_TARGET=hashmap cargo bench --bench memory_rss -- --nocapture
Stdio transport (default — for Claude Code / Claude Desktop)
./target/release/blazing_art_mcp \
--entities data/entities.json \
--events data/events.json
HTTP+SSE transport (for browsers and HTTP-MCP clients)
./target/release/blazing_art_mcp --http 127.0.0.1:4242
# Then visit http://127.0.0.1:4242/ for the demo UI,
# or POST JSON-RPC to http://127.0.0.1:4242/mcp.
# /health returns {"status":"ok"}.
The --http flag is restricted to loopback addresses by design, per MCP spec
guidance for local servers (defends against DNS rebinding). The handler also
validates the Origin header.
Smoke test
./test-mcp.sh # exercises all four legacy tools over stdio
python3 /tmp/blazing_art_demo.py # exercises ingestRepo / findSymbols / deleteRepo over HTTP
# (requires server running with --http 127.0.0.1:4242)
Hooking it up to a coding agent
Claude Code (stdio)
Add to ~/.claude/claude_code_config.json:
{
"mcpServers": {
"blazing-art": {
"command": "/abs/path/to/blazing-art-mcp/target/release/blazing_art_mcp",
"args": [
"--entities", "/abs/path/to/blazing-art-mcp/data/entities.json",
"--events", "/abs/path/to/blazing-art-mcp/data/events.json"
]
}
}
}
Then in any Claude Code session, the agent can call ingestRepo on a path,
followed by findSymbols with prefix scans — see the schema table above.
Claude Code (HTTP)
Run the server once with --http 127.0.0.1:4242, then in
~/.claude/claude_code_config.json:
{
"mcpServers": {
"blazing-art": {
"transport": "http",
"url": "http://127.0.0.1:4242/mcp"
}
}
}
The HTTP path lets you share one server process across multiple agent sessions.
kiro-cli (stdio)
kiro-cli mcp add \
--name blazing-art \
--scope workspace \
--command /abs/path/to/blazing-art-mcp/target/release/blazing_art_mcp \
--args "--entities,/abs/path/to/data/entities.json,--events,/abs/path/to/data/events.json"
# Optional but recommended for slow first-ingest:
kiro-cli settings mcp.noInteractiveTimeout 60000
Then in any kiro-cli chat session, the agent has ingestRepo, findSymbols,
findReferences, and the rest. To remove later: kiro-cli mcp remove --name blazing-art.
Codex CLI (stdio)
OpenAI's Codex CLI supports MCP servers over stdio only (no remote HTTP). Add
this to ~/.codex/config.toml:
[mcp_servers.blazing_art]
command = "/abs/path/to/blazing-art-mcp/target/release/blazing_art_mcp"
args = ["--entities", "/abs/path/to/data/entities.json",
"--events", "/abs/path/to/data/events.json"]
Browser-based chatbots
Open http://127.0.0.1:4242/ for the bundled demo. Or POST JSON-RPC straight
from your own JS — see static/index.html for a 200-line vanilla-JS reference.
async function lookup(name) {
const r = await fetch("http://127.0.0.1:4242/mcp", {
method: "POST",
headers: { "Content-Type": "application/json" },
body: JSON.stringify({
jsonrpc: "2.0", id: 1, method: "tools/call",
params: { name: "lookupEntity", arguments: { name } },
}),
});
return r.json();
}
Why ART for agent memory? (the proof)
BENCHMARKS.md has the full methodology, raw Criterion output, and honest
caveats. The shortest version of the story is two charts:
Prefix-scan latency vs N — the workload coding agents actually run:
| N (keys) | ART | BTreeMap | HashMap full-scan | ART/BTree | ART vs HashMap |
|---|---|---|---|---|---|
| 10k | 547 ns | 1,487 ns | 221 µs | 2.7× faster | 404× faster |
| 100k | 569 ns | 1,519 ns | 3,297 µs | 2.7× faster | 5,795× faster |
| 1M | 573 ns | 1,448 ns | 58,800 µs | 2.5× faster | 102,605× faster |
ART and BTreeMap stay roughly constant as N grows. HashMap full-scan grows linearly — the only way to "prefix scan" a hash table is iterate every key and string-match. By 1M keys, the gap is 5 orders of magnitude. The choice of backing index matters more as the dataset grows, exactly the regime agentic codebase indexing is heading toward.
RSS at 1M keys — measured per-backend in isolated processes (because
getrusage returns a process-lifetime high watermark, not current):
| Backend | Peak RSS delta | vs ART |
|---|---|---|
ART (blart::TreeMap) |
187 MB | smallest |
| HashMap | 223 MB | +19% |
| BTreeMap | 225 MB | +20% |
ART is ~16% smaller than either alternative — path compression stores shared key prefixes once per branch instead of redundantly per key.
What ART is not: ART loses point-lookup to HashMap by ~5× at 100k (148 µs vs 32 µs). ART is not a hash-table replacement. It's the right primitive when prefix queries are part of the workload — which is exactly what coding agents doing structured codebase navigation produce.
Tests (three layers — v0.2)
# Layer 1 — unit + e2e + property/fuzz (fast; runs on every push).
cargo test --all-targets
# ↳ 30 tests:
# 15 unit (memory + ingest)
# 8 e2e (sample-repo + multilang fixtures)
# 3 proptest (oracle vs BTreeMap, key round-trip, concurrent chaos)
# 4 handcurated_schema (gold-set sanity)
# Layer 2 — gold-set retrieval eval (runs on every push; gates merges).
cargo run --release --bin eval_goldset
bash scripts/check_eval_threshold.sh
# ↳ Recall@1 / @5 / @20, MRR, p50/p99, per-category breakdowns;
# fails if any metric below floors in eval/threshold.json.
# Layer 3 — live coding-agent harnesses (manual; cost real LLM API calls).
bash tests/harness/run_claude_code.sh # skips if `claude` not installed
bash tests/harness/run_kiro_cli.sh # skips if `kiro-cli` not installed
# ↳ Drives each agent through 10 scripted prompts under
# treatment (MCP enabled) vs control (no MCP); regex assertions
# in tests/harness/asserts.txt require treatment to match the
# correct answer AND control to MISS it.
CI workflow: see .github/workflows/ci.yml. Layers 1 + 2 run on every push and
PR; layer 3 is gated to workflow_dispatch because it costs real API credits.
Repository layout
src/
├── lib.rs # module declarations
├── main.rs # CLI + transport dispatch
├── memory.rs # ART-backed Memory (entities, events, symbols) + 7 unit tests
├── protocol.rs # JSON-RPC 2.0 dispatch (transport-agnostic)
├── ingest.rs # tree-sitter walker + key encoder
└── transport/
├── mod.rs
├── stdio.rs # newline-delimited JSON-RPC over stdin/stdout
└── http.rs # axum: POST /mcp, GET /mcp (405), GET /health, GET /
benches/
├── art_benchmarks.rs # Criterion: point/prefix/insert + scaling sweep + real-data
├── memory_rss.rs # standalone (harness=false), macOS-only via getrusage
└── shared/keygen.rs # synthetic key generator + index builders, shared by both
tests/
├── ingest_e2e.rs # 6 integration tests against the fixture
└── fixtures/sample-repo/src/ # 3-file Rust fixture (10 known declarations)
static/index.html # vanilla-JS web demo (no framework)
data/ # 2,758 entities + 896 events (AI/ML papers from Qdrant)
examples/ # smaller sample dataset
BENCHMARKS.md # publication-ready numbers + methodology
CLAUDE.md # docs-vs-reality table for future sessions
Honest limits
- In-memory only. No persistence yet. Restart = empty index. Re-ingest from source.
- Single-threaded writes.
Arc<RwLock<TreeMap>>. No concurrent-write story. (Swap tocongeefor lock-free ART-OLC if multi-writer becomes a real workload.) - No auth/TLS. Bound to loopback. Don't expose this to the internet.
- Declaration nodes only. Identifiers, expressions, statements aren't indexed — only function/struct/class/trait/type definitions. Saves ~100× memory at the cost of no "find every reference" capability (use an LSP for that).
- No incremental re-ingestion.
ingestRepodoes a full re-parse. For large repos this is a few seconds; for monorepos it could take minutes. - macOS-only RSS bench.
getrusage(ru_maxrss)units differ by platform — bytes on macOS, kilobytes on Linux. The harnesscompile_error!s on non-macOS to prevent silent 1024× errors. Latency benches run anywhere.
v0.1 milestone
The five /goal success criteria are met with reproducible evidence:
- ✅
BTreeMapgone, realblart::TreeMapis the index, clippy clean, 13 tests - ✅
ingestRepo<500 ms /findSymbols<1 ms (ownsrc/ingests in 18 ms; prefix scan ~570 ns) - ✅ Stdio + HTTP+SSE transports both green against the same
Memory - ✅ ART prefix-scan ≥1.5× over
BTreeMapand uses less RSS thanHashMap(~16% smaller at 1M) - ✅ ART exact lookup faster than embeddings (sub-µs vs typical 50ms+ — the math is in
BENCHMARKS.md)
Natural follow-ups for v0.2 (deliberately out of scope for v0.1): persistence
(snapshot on shutdown / WAL), congee for concurrent writes, Go/Java/C grammars,
LSIF compatibility, side-by-side embeddings benchmark.
License
MIT — see LICENSE.
