CAD-AI集成工具

{
  "providers": {
    "anthropic": {
      "enabled": true,
      "model": "claude-sonnet-4",
      "thinking_mode": true,
      "max_tokens": 64000
    },
    "openai": {
      "enabled": true,
      "model": "gpt-4o",
      "max_tokens": 32000
    },
    "google": {
      "enabled": true,
      "model": "gemini-2.0-flash-001",
      "thinking_mode": true
    },
    "openrouter": {
      "enabled": true,
      "model": "anthropic/claude-sonnet-4",
      "free_models": ["deepseek/deepseek-r1"]
    }
  }
}

# Using specific provider
from freecad_ai import CADAssistant

# Initialize with Claude Sonnet 4
assistant = CADAssistant(provider="anthropic", model="claude-sonnet-4")

# Create complex geometry
result = assistant.generate_cad_script(
    "Create a parametric gear with 20 teeth, 5mm module, and 20° pressure angle"
)

# Using OpenRouter for cost optimization
assistant_free = CADAssistant(
    provider="openrouter",
    model="deepseek/deepseek-r1"
)

# Quick operations with free model
result = assistant_free.create_primitive("box", length=10, width=5, height=3)

# Clone the repository
git clone https://github.com/jango-blockchained/mcp-freecad.git
cd mcp-freecad

# Install dependencies
pip install -r requirements.txt

# Start the MCP server
python mcp_server.py

# Or with FastMCP mode (lightweight, ideal for Cursor IDE)
python mcp_server.py --mode fastmcp

# Or with custom config and debug logging
python mcp_server.py --config my_config.json --debug

### Option 3: FastMCP Server (Cursor IDE & Latest Best Practices)

**✨ NEW: Updated to FastMCP 2.13.0.2** - Modern, declarative MCP server implementation.

```bash
# Start the FastMCP server for Cursor IDE
python cursor_mcp_server.py

# Or run the example to see available tools
python example_fastmcp_usage.py --all

src/mcp_freecad/
├── main.py                 # Main entry point
├── __init__.py            # Package exports and registry
├── client/                # FreeCAD connection management
│   └── freecad_connection_manager.py
├── server/                # MCP server implementation
│   └── freecad_mcp_server.py
├── tools/                 # Tool providers
│   ├── base.py           # Base tool provider class
│   ├── primitives.py     # Primitive shapes (box, cylinder, etc.)
│   ├── model_manipulation.py # Transform, boolean ops, etc.
│   ├── export_import.py  # File format handling
│   ├── measurement.py    # Analysis tools
│   └── code_generator.py # Code generation
├── core/                  # Core infrastructure
│   ├── server.py         # FastAPI-based server
│   ├── cache.py          # Resource caching
│   ├── diagnostics.py    # Performance monitoring
│   └── recovery.py       # Connection recovery
└── connections/           # Connection backends

from src.mcp_freecad import FreeCADConnection, PrimitiveToolProvider

# Create connection (auto-selects best method)
fc = FreeCADConnection(auto_connect=True)

if fc.is_connected():
    print(f"Connected via: {fc.get_connection_type()}")

    # Create a document
    doc_name = fc.create_document("MyProject")

    # Create objects
    box = fc.create_box(length=20, width=10, height=5)
    cylinder = fc.create_cylinder(radius=3, height=10)

    # Export
    fc.export_stl(box, "my_box.stl")

from src.mcp_freecad.tools.primitives import PrimitiveToolProvider

# Initialize tool provider
primitives = PrimitiveToolProvider()

# Execute tools
result = await primitives.execute_tool("create_box", {
    "length": 10.0,
    "width": 5.0,
    "height": 3.0
})

print(f"Created: {result.result['object_id']}")

from src.mcp_freecad.core.server import MCPServer
from src.mcp_freecad import TOOL_PROVIDERS

# Setup server
server = MCPServer()

# Register tool providers
server.register_tool("primitives", TOOL_PROVIDERS["primitives"]())
server.register_tool("model_manipulation", TOOL_PROVIDERS["model_manipulation"]())

# Initialize and run
await server.initialize()

{
  "server": {
    "name": "mcp-freecad-server",
    "version": "0.7.11"
  },
  "freecad": {
    "connection_method": "auto",
    "host": "localhost",
    "port": 12345,
    "freecad_path": "freecad"
  },
  "tools": {
    "enable_primitives": true,
    "enable_model_manipulation": true,
    "enable_export_import": true
  }
}

{
  "freecad": {
    "connection_method": "launcher",
    "use_apprun": true,
    "apprun_path": "/path/to/squashfs-root/AppRun",
    "script_path": "/path/to/freecad_launcher_script.py"
  }
}

from .base import ToolProvider, ToolResult, ToolSchema

class MyToolProvider(ToolProvider):
    @property
    def tool_schema(self) -> ToolSchema:
        return ToolSchema(
            name="my_tool",
            description="My custom tool",
            parameters={...},
            returns={...}
        )

    async def execute_tool(self, tool_id: str, params: Dict[str, Any]) -> ToolResult:
        # Implementation
        return self.format_result(status="success", result=result)

# Run tests
python -m pytest tests/

# Run with coverage
python -m pytest tests/ --cov=src --cov-report=html

# Run specific test
python -m pytest tests/test_primitives.py -v

# Build and run with Docker Compose
docker compose up

# Build from scratch
docker compose build --no-cache
docker compose up
