mlcartifact - The Shared Memory Layer for MCP Ecosystems

mlcgo.eu — tools, libraries and manuals · Product page

Don't route large data through the LLM. Let MCP servers write files to a shared store and exchange only an ID. The LLM decides what to do next - without ever seeing the raw data.

Copyright (c) 2026 Michael Lechner. Licensed under the MIT License.

Deutsche Version

The Problem: Large Data Doesn't Belong in LLM Context

Imagine a SQL MCP server that returns 50,000 rows. Or a report generator that produces a 2MB PDF. If these results flow through the LLM's context window, you:

• Waste tokens - massively
• Hit context limits - frequently
• Slow everything down - unnecessarily

mlcartifact is the solution: a shared artifact store. MCP servers write their output directly to it and tell the LLM only: "Done. Artifact ID: abc123. Columns: name, total, date."

Who Is This For?

mlcartifact is primarily meant for local LLM setups (for example via Ollama, llama.cpp or LM Studio) and for custom harnesses. These usually have no built-in way for tools to hand files to each other: every intermediate result would have to pass through the model's context, which is exactly what is scarce and slow on local hardware.

Professional platforms such as Claude (Anthropic) or Gemini (Google) usually ship a comparable mechanism of their own, such as a sandbox with a file system or a files API. Large files stay outside the model's context between tool calls and never have to travel over the network to the model and back. If you use such a platform, check its built-in solution first. There, mlcartifact mainly pays off when your own MCP servers should exchange data directly through a shared store.

The Pattern: MCP Server-to-Server Data Exchange

LLM: "Run the quarterly SQL report and turn it into a PDF."

  MCP Server A (SQL)       mlcartifact         MCP Server B (PDF)
       |                       |                       |
       |-- write_artifact() -->|                       |
       |   report.csv (2MB)    |                       |
       |<-- artifact ID: abc123|                       |
       |                       |                       |
       +-- tells LLM: "Done."  |                       |
                               |                       |
LLM: "PDF Server: generate a PDF from artifact abc123."
                               |                       |
                               |<-- read_artifact(id) -|
                               |    (reads 2MB CSV)    |
                               |---------------------->|

The big data never flows through the LLM. Only artifact IDs are exchanged. The LLM orchestrates - it doesn't carry data.

Why gRPC & The Artifact Pattern?

Moving beyond simple local file storage, mlcartifact uses a gRPC-first approach to solve the unique challenges of distributed MCP ecosystems:

• Seamless Portability: Services can run on the host, in Docker containers, or on remote servers. They all connect via gRPC without needing shared volumes or complex filesystem permissions.
• Enhanced Security (Sandboxing): MCP servers don't need broad access to your host's filesystem. They only interact with the Artifact API, providing a secure boundary between your data and potentially untrusted tools.
• Multi-Server Data Exchange: Enables the "Shared Memory" pattern where Server A writes data and Server B reads it, orchestrated by the LLM using only IDs.
• Rich Metadata & Lifecycle: Automatic handling of MIME types, source tracking, and automatic expiration.

Comparison: gRPC API vs. Local Filesystem

Tradeoffs: While gRPC introduces a small network latency and requires a running server process, the benefits in terms of security, multi-server orchestration, and simplified deployment usually far outweigh these costs in production MCP environments.

What's in This Repository

All four clients cover the full API: write, read, list, delete and the VFS operations (virtual paths, directory listing, patch, find).

Ecosystem & Related Projects

• wollmilchsau - A "Swiss Army Knife" MCP server that can execute JavaScript (TypeScript) scripts stored as artifacts in mlcartifact. It allows for dynamic tool execution where the LLM writes a script to the artifact store and wollmilchsau executes it in a secure environment.
• mcp-tester - A CLI testing tool and script runner for MCP servers. Used in mlcartifact to integration-test every MCP tool and parameter with declarative assertions.

Documentation

• Go Client Library Guide - Comprehensive guide for Go developers.
• Python Client - Implementation and usage for Python developers.
• gRPC API Reference - Detailed technical reference for the gRPC protocol.

Quick Start

Install

# via install script (Linux/macOS)
curl -sfL https://raw.githubusercontent.com/hmsoft0815/mlcartifact/main/scripts/install.sh | sh

# or via Go
go install github.com/hmsoft0815/mlcartifact/cmd/artifact-server@latest
go install github.com/hmsoft0815/mlcartifact/cmd/artifact-cli@latest

Pre-built .deb, .rpm, and binaries on GitHub Releases.

Start the Server

# stdio mode (for Claude Desktop / MCP)
artifact-server -data-dir ~/mlcartifact/storage

# HTTP mode: Streamable HTTP on /mcp, legacy SSE on /sse
artifact-server -addr :8082 -grpc-addr :9590 -data-dir ~/mlcartifact/storage

Use the Go Library in Your MCP Server

See the Go Client Library Guide for detailed usage and examples.

import "github.com/hmsoft0815/mlcartifact/client"

// Connect (reads ARTIFACT_GRPC_ADDR env var, defaults to :9590)
c, _ := client.NewClient()
defer c.Close()

// Store a large result - returns an ID, not the data
resp, _ := c.Write(ctx, "report.csv", csvData,
    client.WithMimeType("text/csv"),
    client.WithExpiresHours(24),
)

// Tell the LLM: "Done. ID: abc123. Columns: name, total, date."
fmt.Println("artifact_id:", resp.Id)

Claude Desktop & MCP Client Integration

1. Stdio Mode (Local Subprocess)

Direct execution by the MCP client without network ports (no token needed):

{
  "mcpServers": {
    "mlcartifact": {
      "command": "/path/to/artifact-server",
      "args": ["-data-dir", "/your/artifacts"]
    }
  }
}

2. HTTP Mode (With Authentication Token)

Recommended for production, remote servers, or whenever -require-token-localhost is enabled:

{
  "mcpServers": {
    "mlcartifact": {
      "type": "http",
      "url": "http://localhost:8082/mcp",
      "headers": {
        "Authorization": "Bearer <YOUR_TOKEN>"
      }
    }
  }
}

Note: For local development directly on localhost, connections without a token are accepted by default (zero-config), provided -require-token-localhost is not set. Older clients that only speak SSE can use http://localhost:8082/sse.

MCP Tools

All tools except read_artifact return structured results with an output schema; errors are reported as tool errors (isError). The prompt vfs_usage explains the virtual file system to the model.

CLI Usage

# Upload, download, list, delete
artifact-cli create ./report.csv --name "Q1 Report" --expires 72
artifact-cli create -q ./script.sh             # quiet mode: prints only the artifact ID
artifact-cli download abc123 ./local-copy.csv
artifact-cli list
artifact-cli delete abc123

Global options:

• -addr: gRPC server address (default: ARTIFACT_GRPC_ADDR or localhost:9590)
• -token: Authentication token for remote access (default: ARTIFACT_GRPC_TOKEN or ARTIFACT_TOKEN)
• -user: User ID scope (default: ARTIFACT_USER_ID)

Server Configuration

Environment variables (library & server):

Authentication & Security

mlcartifact is designed for secure-by-default operation:

• Localhost by default (Zero Config): Connections originating from loopback addresses (127.0.0.1, ::1) do not require an authentication token by default. You can run the server locally and connect immediately with CLI or SDKs.
• Remote Access (Authentication Required): If the server listens on a non-loopback interface (e.g. 0.0.0.0 or a public IP), the server requires authentication for all remote requests via either -grpc-token or -auth-endpoint.
• Enforcing Token on Localhost: To require a token even for loopback connections (e.g. on shared developer machines), pass -require-token-localhost or set ARTIFACT_REQUIRE_TOKEN_LOCALHOST=true.
• CORS Protection: Cross-origin browser requests are blocked by default. Specific allowed origins can be configured with -cors-origins "https://example.com".

Pluggable Token Validation (mlcauth & Supabase)

In addition to static tokens (-grpc-token), mlcartifact supports dynamic HTTP token validation via -auth-endpoint. When configured, incoming bearer tokens are validated in real-time with automatic in-memory TTL caching.

1. Forward-Auth (mlcauth)

Validates tokens against an internal Forward-Auth service. The caller's identity (X-User-ID, X-User-Role) is automatically extracted from response headers, and the user's storage scope is strictly locked to their verified identity:

artifact-server -addr 0.0.0.0:8082 -grpc-addr 0.0.0.0:9590 \
  -auth-endpoint "http://mlcauth:8080/auth/forward?svc=mlcartifact"

If the user lacks permission for mlcartifact, the auth service returns 403 Forbidden, which mlcartifact rejects.

2. Supabase Auth (OAuth2 / UserInfo)

Validates tokens against Supabase's Auth API and checks user permissions:

artifact-server -addr 0.0.0.0:8082 -grpc-addr 0.0.0.0:9590 \
  -auth-endpoint "https://<your-project-id>.supabase.co/auth/v1/user" \
  -auth-header "apikey:<SUPABASE_ANON_KEY>" \
  -auth-service-name "mlcartifact"

The user ID is extracted from the JSON response (id/sub), and app_metadata.services is checked for the specified service name.

Configuring Tokens in Clients

All clients automatically check the ARTIFACT_GRPC_TOKEN (or ARTIFACT_TOKEN) environment variable and provide programmatic options:

• CLI: artifact-cli -token "<token>" ... or via ARTIFACT_GRPC_TOKEN
• Go: client.NewClientWithAddr(addr, client.WithToken("<token>"))
• TypeScript: new ArtifactClient(addr, undefined, "<token>")
• Python: ArtifactClient(addr, token="<token>")
• Rust: ArtifactClient::connect_with_token(addr, "<token>") or via ARTIFACT_GRPC_TOKEN
• HTTP / MCP: Provide the Authorization: Bearer <token> header

Storage Layout

~/mlcartifact/storage/
├── global/
│   ├── {id}_{filename}
│   └── {id}_{filename}.json   # metadata sidecar
└── users/
    └── {user_id}/
        ├── {id}_{filename}
        └── {id}_{filename}.json

Development & Testing

# Run unit tests across all components (Go, TS, Python, Rust)
task test:all             # or: make test-all

# Run integration tests with mcp-tester
task test:integration     # or: make test-integration

# Build binaries
task build                # or: make build

MCP Server Integration Testing with mcp-tester

The MCP server implementation is thoroughly tested against the MCP specification and tool contracts using mcp-tester (tested against v1.6.2).

• Test Suite: tests/integration.mcp
• Score: 54 / 54 assertions passed (100% pass rate, 0 failed)
• Coverage:
  • All 7 MCP tools: write_artifact, read_artifact, list_artifacts, vfs_ls, vfs_find, vfs_patch, delete_artifact
  • Every required and optional parameter (virtual_path, mime_type, description, expires_in_hours, metadata, user_id, line_start, line_end, append)
  • Multi-user / multi-tenant data isolation (user_id separation between users)
  • VFS line patching (precise line replacement and append mode)
  • Negative tests and error handling (missing required fields, empty payloads, invalid IDs/paths)

Run the integration test suite:

task test:integration
# or
make test-integration

Roadmap

• [x] TypeScript / Node.js SDK
• [x] Python SDK (httpx, Connect protocol)
• [x] Docker Image - pre-configured server
• [x] Rust SDK (Tonic based)
• [ ] Web Dashboard - browse & manage artifacts visually

Reference

The MCP Handbook explains the Model Context Protocol from the ground up — tools, resources, prompts, transports, security and the artifact pattern. Available in English and German.

License

MIT License - Copyright (c) 2026 Michael Lechner

Project documentation (.mlcai/)

.mlcai/ is a private git submodule: internal planning, backlog and work notes, maintained with the MLC Doc Hub. It is not publicly accessible — clone without --recurse-submodules; the build does not need it. Links into .mlcai/ only work with access (git submodule update --init .mlcai).

Who is "Claude" in the commits?

Some commits in this repository are co-authored by Claude, Anthropic's AI model. It helps write code, keeps our documentation and backlog up to date and digs through failing builds — every change is reviewed before it is merged. We don't hide it: how we work with Claude.
