OllyDbg MCP Bridge

A hardened MCP bridge for OllyDbg 1.10. It connects an MCP client to a small native OllyDbg plugin over a local Windows named pipe.

Current native plugin: 2.8
Bridge protocol: 2

The repository is source-first. Compiled DLLs, SDK files, caches, samples and machine-specific paths are intentionally excluded.

Project status

The Python server, native bridge source, strict parsers, pipe transport and controlled x86 target are covered by automated linting, portable C89 harnesses, Windows Python 3.10/3.12 tests, real Windows named-pipe tests and a complete x86 DLL compile/link/export check. Final ABI and debugger-behaviour confirmation still requires the supplied genuine-SDK runtime smoke test inside an actual OllyDbg 1.10 installation.

Architecture

MCP client
    |
    | stdio / streamable HTTP / SSE
    v
Python MCP server
    |
    | newline-framed JSON over \\.\pipe\OllyBridge110
    v
OllyDbg 1.10 plugin
    |
    v
OllyDbg debugger APIs

The Python package validates and normalizes tool arguments before sending a request to the native bridge. Addresses are represented canonically as unsigned 32-bit hexadecimal values such as 0x00401000.

Features

• debugger status and decoded pause metadata
• register, memory, stack and disassembly reads
• complete module, thread and breakpoint enumeration through bounded pages
• software and hardware breakpoint management
• pause, continue, run, step and run-to-address helpers
• native run, step and continue result validation
• debugger operations marshalled through OllyDbg's UI thread
• event-driven native pause sequencing with an automatic legacy fallback
• strict bounded native JSON parsing with UTF-8 and Unicode-escape validation
• strict native 32-bit address and byte-payload validation
• hardware-breakpoint logical-slot, size, index and alignment validation
• address-based deletion of bridge-owned hardware breakpoints
• per-debuggee reset of bridge-owned native state
• command-aware retries that never replay ambiguous state-changing requests
• strict UTF-8 validation for native responses
• address lookup, labels and comments
• guarded debuggee-memory writes
• combined debugger snapshots
• bridge capability and protocol-version reporting
• bounded native response construction
• serialized Python requests with deadline-bound cancellable overlapped I/O
• one shared request deadline covering client writes and response reads
• newline-framed native request accumulation across fragmented or bytewise writes
• bounded rejection of overlong unterminated requests before debugger dispatch
• owner-restricted, local-only named-pipe access
• interruptible overlapped native pipe I/O for clean plugin shutdown
• bounded response-drain handshake before the server disconnects
• native read-only-by-default gate for debugger mutations
• reproducible 32-bit MSVC build and export validation
• controlled x86 runtime target with a structured smoke-test report

Safety defaults

Operations that can unexpectedly destroy debugger state require explicit confirmation:

• olly_write_memory(..., confirm=true)
• olly_clear_all_breakpoints(confirm=true)
• olly_prepare_session(clear_breakpoints=true, confirm_clear=true)

Session preparation no longer clears breakpoints by default.

The native plugin independently blocks memory writes, software and hardware breakpoint changes, labels and comments unless OllyDbg was started with OLLYBRIDGE_ALLOW_MUTATIONS=1. The supplied launcher forces this setting to 0 by default and enables it only with -EnableNativeMutations. This protects direct same-user pipe access as well as MCP calls; MCP confirmation remains a second, separate safety layer.

The native pipe rejects remote clients and applies an owner-only Windows access rule. This reduces accidental cross-user access, but it is not a substitute for running the debugger and MCP server under a trusted Windows account. Do not expose the MCP server to untrusted networks or users.

Requirements

• Windows
• Python 3.10 or newer
• OllyDbg 1.10
• 32-bit Microsoft Visual C++ build tools
• the genuine OllyDbg 1.10 Plugin.h header

The Python dependency is pinned to the compatible MCP Python SDK v1 line until the project is deliberately migrated to SDK v2.

Install the Python server

From the repository root:

py -m venv .venv
.\.venv\Scripts\Activate.ps1
python -m pip install --upgrade pip
python -m pip install -e .

Run it through the installed console command:

ollydbg-mcp --transport stdio

The source-checkout entry point remains available:

python .\server.py --transport stdio

Optional configuration:

$env:OLLYDBG_PIPE_NAME = '\\.\pipe\OllyBridge110'
$env:OLLYDBG_TIMEOUT_SECONDS = '5'

Equivalent command-line options are available:

ollydbg-mcp --pipe-name '\\.\pipe\OllyBridge110' --timeout 5

Build the plugin

The native source lives at:

plugin_stub/ollydbg110_bridge.c
plugin_stub/bridge_framing.h
plugin_stub/bridge_json.h
plugin_stub/bridge_values.h

Open a 32-bit Visual Studio Native Tools PowerShell or command prompt, then run the supplied build script with the directory containing the genuine OllyDbg 1.10 Plugin.h:

.\plugin_stub\build_plugin.ps1 `
  -SdkDir 'C:\Path\To\OllyDbg110SDK' `
  -OutputDir '.\build\native'

The build script:

• refuses to use the repository's test-only SDK shim for a real build
• compiles C code with unsigned-character mode (/J)
• treats compiler warnings as errors
• links an x86 Windows DLL
• links Kernel32, User32 and Advapi32
• verifies the PE image is 32-bit x86
• verifies all nine required OllyDbg callback exports

A successful real build produces:

build/native/OllyBridge110.dll

Copy that DLL into the plugin directory configured by ollydbg.ini and restart OllyDbg.

CI native build validation

GitHub Actions compiles and links the complete DLL on a Windows x86 MSVC environment using tests/ollydbg_sdk_stub/Plugin.h. That header is a clearly marked test-only compile shim containing only the names and fields needed to check this source tree. CI verifies syntax, warning cleanliness, linking, x86 machine type and all nine callback exports, then deletes the generated DLL without uploading it.

The CI DLL must never be distributed or loaded into OllyDbg. It does not prove binary compatibility with the real SDK. Only the genuine-SDK command above produces a candidate plugin for runtime testing.

Safer launcher

The helper script validates paths, backs up ollydbg.ini before changing its plugin path and does not terminate an existing OllyDbg process unless -RestartOlly is explicitly supplied.

powershell -ExecutionPolicy Bypass -File .\start_olly_bridge.ps1 `
  -OllyDir 'C:\Tools\OllyDbg' `
  -PluginDir 'C:\Tools\OllyDbg\Plugins' `
  -RestartOlly

# Explicitly enable native writes, breakpoint changes, labels and comments.
.\start_olly_bridge.ps1 `
  -OllyDir 'C:\Tools\OllyDbg' `
  -PluginDir 'C:\Tools\OllyDbg\Plugins' `
  -EnableNativeMutations `
  -RestartOlly

Pass -TargetExe to open a specific executable. -PluginDllPath selects a DLL outside the repository root, and -SkipServer launches only OllyDbg when a direct named-pipe client such as the smoke runner is being used.

Genuine-SDK runtime smoke test

The runtime harness builds the plugin with the genuine SDK, builds a controlled 32-bit target, launches that target in OllyDbg and writes a structured JSON report. From an ordinary PowerShell prompt:

.\integration\run_runtime_smoke.ps1 `
  -OllyDir 'C:\Tools\OllyDbg' `
  -PluginDir 'C:\Tools\OllyDbg\Plugins' `
  -SdkDir 'C:\Path\To\OllyDbg110SDK' `
  -RestartOlly

The controlled executable is linked at the fixed 0x00400000 image base with ASLR disabled. It exports a probe function and counter. The target build records their virtual addresses in olly_smoke_manifest.json, so the smoke runner can validate the loaded module, memory reads, address lookup and disassembly without hard-coded guesses.

The default run is read-only. Two independent opt-ins extend it:

# Temporarily set, verify and clear a software breakpoint.
.\integration\run_runtime_smoke.ps1 ... -AllowMutations

# Run to the exported probe and execute one single step.
.\integration\run_runtime_smoke.ps1 ... -AllowExecution

The mutation check automatically launches OllyDbg with the native mutation gate enabled and preserves a breakpoint that already existed at the probe. The execution-only check does not enable native mutations. The execution check changes debuggee state and therefore remains separate. The launcher still refuses to terminate an existing OllyDbg instance unless -RestartOlly is supplied. Pass -SkipIniUpdate only when the configured plugin directory is already correct.

Generated files are placed below build/runtime-smoke/. The final report is:

build/runtime-smoke/olly_smoke_report.json

The runner can also be called directly after the target and genuine-SDK plugin have been built and loaded:

ollydbg-smoke `
  --manifest .\build\runtime-smoke\target\olly_smoke_manifest.json `
  --timeout 30

python .\test_olly_bridge.py remains a compatibility entry point for the same structured runner.
