使用说明

Google Drive MCP Server

A custom Model Context Protocol (MCP) server for Google Drive, Docs, and Sheets. Built for powerful document editing and file management with Claude Code.

Author: Nick Feamster

Quick setup / update (any Mac)

This server is installed and registered for Claude Code and Claude Desktop by setup-mcp.sh in the dotfiles repo, along with all the other MCP servers:

cd ~/dotfiles && git pull && ./setup-mcp.sh

Then restart Claude Code and Claude Desktop. (More detail, including upgrading an older Mac: the laptop-setup README.) The script clones or pulls every server repo into ~/src, builds each environment from its uv.lock, writes the config, and checks that each server starts. It's safe to re-run anytime.

After that, a plain git pull in this repo is enough: the server launches with uv run --frozen, which installs any changed dependencies on the next start. Credentials live in ~/.mcp-auth (synced from Box with unison mcp_auth).

Features

Drive Operations

List files with filtering and sorting
Search files by content or name
Get file metadata
List documents and spreadsheets

Document Operations

Get full document structure and content
Extract plain text from documents
Create new documents
Insert, append, and replace text
Delete content ranges
Apply text formatting (bold, italic, underline, font size/family)
Batch update documents with custom requests

Spreadsheet Operations

Get spreadsheet metadata and structure
Read cell values from ranges
Update cell values
Create new spreadsheets

Prerequisites

Python 3.10+
Box Drive sync (for credential storage)
A Google Cloud project with OAuth credentials
Claude Code installed

Architecture Overview

This MCP server uses a distributed credential storage approach:

Code Repository (~/src/google-drive-mcp/) - Cloned from GitHub
Credentials Storage (~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/) - OAuth credentials in Box (synced across machines)
MCP Configuration (~/.claude/.mcp.json) - Can be managed via dotfiles repo

This allows:

Code updates via git pull
Automatic credential sync via Box
Easy setup on new machines

Google Cloud Setup (One-time)

1. Create Google Cloud Project

Go to Google Cloud Console
Create a new project (or use existing)
Enable the following APIs:
- Google Docs API
- Google Drive API
- Google Sheets API

2. Configure OAuth Consent Screen

Go to "APIs & Services" → "OAuth consent screen"
Choose "External" user type
Fill in required app info:
- App name: "Google Drive MCP"
- Support email: your email
Add scopes:
- https://www.googleapis.com/auth/documents
- https://www.googleapis.com/auth/drive
- https://www.googleapis.com/auth/spreadsheets
- https://www.googleapis.com/auth/script.external_request
Add your email as a Test User (important!)
Save and continue

3. Create OAuth 2.0 Credentials

Go to "APIs & Services" → "Credentials"
Click "Create Credentials" → "OAuth 2.0 Client ID"
Application type: Desktop app
Name it (e.g., "Google Drive MCP Client")
Click "Create"
Save the Client ID and Client Secret

Credentials Storage in Box

All OAuth credentials are stored in Box for automatic sync across machines.

Directory Structure

~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/
├── credentials.json       # OAuth Client ID and Secret
└── tokens/
    └── token.json        # OAuth refresh token (auto-generated)

Create credentials.json

Create the file in Box with your OAuth credentials:

# Create directory structure
mkdir -p ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/tokens

# Create credentials.json (replace with your actual credentials from Google Cloud Console)
cat > ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/credentials.json <<'EOF'
{
  "client_id": "YOUR_CLIENT_ID.apps.googleusercontent.com",
  "client_secret": "YOUR_CLIENT_SECRET"
}
EOF

Important: The credentials.json file contains the OAuth Client ID and Secret from your Google Cloud project. These are the same credentials used across all your machines.

Installation

First Machine Setup

Clone the repository:

cd ~/src
git clone https://github.com/feamster/google-drive-mcp.git
cd google-drive-mcp

Install the package:

python3 -m pip install -e .

Verify Box credentials exist:

ls -la ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/
# Should show: credentials.json and tokens/ directory

Run authentication:

python3 -m google_drive_mcp.auth

This will:

Open a browser for Google authorization
Ask you to sign in and grant permissions
Save the refresh token to Box at ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/tokens/token.json

Configure Claude Code:

Add to ~/.claude/.mcp.json:

{
  "mcpServers": {
    "google-drive": {
      "command": "python",
      "args": ["-m", "google_drive_mcp.server"],
      "cwd": "/Users/YOUR_USERNAME/src/google-drive-mcp"
    }
  }
}

Note: If you manage .mcp.json via a dotfiles repo, add this configuration there instead.

Restart Claude Code

New Machine Setup

When setting up on a new machine (assuming Box is already synced):

Clone the repository:

cd ~/src
git clone https://github.com/feamster/google-drive-mcp.git
cd google-drive-mcp

Install the package:

python3 -m pip install -e .

Verify Box is synced with credentials:

ls -la ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/
# Should show: credentials.json and tokens/token.json

If the token exists in Box, you're done! The server will use it automatically.

If the token is missing (first-time Box sync), run authentication:

python3 -m google_drive_mcp.auth

Configure Claude Code (if not using dotfiles):

Add to ~/.claude/.mcp.json (adjust username):

{
  "mcpServers": {
    "google-drive": {
      "command": "python",
      "args": ["-m", "google_drive_mcp.server"],
      "cwd": "/Users/YOUR_USERNAME/src/google-drive-mcp"
    }
  }
}

Restart Claude Code

Testing

Test the server before using it with Claude Code:

cd ~/src/google-drive-mcp
python3 test_server.py

This will:

Initialize the DocsClient
List your recent Google Docs and Sheets
Read content from your first document
Verify all capabilities are working

Expected output:

Testing Google Drive MCP Server
==================================================

1. Initializing DocsClient...
   ✓ Client initialized successfully

2. Listing recent Google Docs...
   ✓ Found 5 documents
   ...

All tests passed! ✓

Available Tools (18 total)

Drive Tools (5)

list_files(query?, maxResults?, orderBy?) - List files with optional filtering and sorting
list_documents(maxResults?) - List Google Docs documents
list_spreadsheets(maxResults?) - List Google Sheets spreadsheets
search_files(searchTerm, maxResults?) - Search for files by name or content
get_file_metadata(fileId) - Get metadata for a specific file

Document Tools (9)

get_document(documentId) - Get full document structure and content
get_document_text(documentId) - Get plain text content from a document
create_document(title) - Create a new Google Docs document
insert_text(documentId, text, index?) - Insert text at a specific index
append_text(documentId, text) - Append text to the end of a document
replace_all_text(documentId, findText, replaceText, matchCase?) - Replace all occurrences of text
delete_content_range(documentId, startIndex, endIndex) - Delete content in a specific range
format_text(documentId, startIndex, endIndex, bold?, italic?, underline?, fontSize?, fontFamily?) - Apply formatting to a text range
batch_update_document(documentId, requests) - Execute batch updates (advanced - requires knowledge of Docs API)

Spreadsheet Tools (4)

get_spreadsheet(spreadsheetId) - Get spreadsheet metadata and structure
get_sheet_values(spreadsheetId, range) - Get values from a spreadsheet range (A1 notation)
update_sheet_values(spreadsheetId, range, values) - Update values in a spreadsheet range
create_spreadsheet(title) - Create a new Google Sheets spreadsheet

Usage Examples

List Recent Documents

Claude: "List my 10 most recent Google Docs"

Read a Document

Claude: "Read the content of document ID 1Bdjo1UJSoxUMyr__zaaNU8Dgmlkmtoq3tRCdGcQLM0k"

Edit a Document

Claude: "In document 1Bdjo1UJSoxUMyr__zaaNU8Dgmlkmtoq3tRCdGcQLM0k, replace all instances of 'old text' with 'new text'"

Format Text

Claude: "Make the first paragraph of document XYZ bold and increase font size to 14pt"

Create a New Document

Claude: "Create a new Google Doc titled 'Meeting Notes' and add an agenda with 3 bullet points"

Work with Spreadsheets

Claude: "Read cells A1:D10 from spreadsheet 1IkXxxTBw7onokE0ZEH4RAVrFZBQQOtOEb2F9U6xZ_DE"
Claude: "Update cell A1 in that spreadsheet to say 'Total Revenue'"

Development

Project Structure

google-drive-mcp/
├── google_drive_mcp/
│   ├── __init__.py       # Package initialization
│   ├── auth.py           # OAuth2 authentication with Box integration
│   ├── docs_client.py    # Google API client (Drive, Docs, Sheets)
│   └── server.py         # MCP server implementation
├── test_server.py        # Testing script
├── setup.py              # Package setup
├── requirements.txt      # Python dependencies
├── .gitignore           # Git ignore rules
└── README.md            # This file

Adding New Features

The client (docs_client.py) can be extended with additional Google API methods. The server (server.py) exposes these as MCP tools.

Steps to add a new tool:

Add method to DocsClient class in google_drive_mcp/docs_client.py:

def my_new_feature(self, document_id: str, param: str) -> Dict[str, Any]:
    """Description of what this does."""
    # Implementation using Google API
    ...

Add tool definition to TOOLS list in google_drive_mcp/server.py:

Tool(
    name="my_new_feature",
    description="Brief description for Claude",
    inputSchema={
        "type": "object",
        "properties": {
            "documentId": {"type": "string", "description": "Document ID"},
            "param": {"type": "string", "description": "Parameter description"}
        },
        "required": ["documentId", "param"]
    }
)

Add handler in call_tool() function in google_drive_mcp/server.py:

elif name == "my_new_feature":
    result = docs.my_new_feature(
        document_id=arguments["documentId"],
        param=arguments["param"]
    )
    return [TextContent(type="text", text=json.dumps(result, indent=2))]

Test and commit:

python3 test_server.py  # Verify it works
git add .
git commit -m "Add my_new_feature capability"
git push

Planned Features

Features to add (based on comparison with other MCP servers):

Priority 1:

[ ] Comments system (list, create, reply, resolve, delete)
[ ] Image insertion (from URLs or files)
[ ] Tables and page breaks
[ ] Advanced text formatting (colors, links, alignment, spacing)
[ ] File management (move, copy, rename, delete, folders)

Priority 2:

[ ] Markdown conversion and round-trip
[ ] Sheets formatting (cell colors, alignment, freeze panes, dropdowns)
[ ] Template support
[ ] Multi-tab document support

Troubleshooting

Authentication Issues

Problem: "No valid credentials found"

Solution:

Verify Box is synced: ls ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/
Check credentials.json exists and is valid JSON
Ensure your email is listed as a Test User in OAuth consent screen
Verify all required APIs are enabled in Google Cloud Console
Re-run authentication: python3 -m google_drive_mcp.auth

Token Not Found

# Verify Box is synced
ls ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/tokens/

# Check token contents (should have refresh_token)
cat ~/Library/CloudStorage/Box-Box/mcp-auth/google-drive-mcp/tokens/token.json

# Re-authenticate if needed
python3 -m google_drive_mcp.auth

MCP Server Not Loading

Check Claude Code logs for errors

Verify the cwd path in .mcp.json matches your username:

whoami  # Check your username
cat ~/.claude/.mcp.json | grep google-drive

Test the server manually:

cd ~/src/google-drive-mcp
python3 -m google_drive_mcp.server
# Should start without errors (use Ctrl+C to exit)

Verify package is installed:

python3 -c "import google_drive_mcp; print(google_drive_mcp.__version__)"
# Should print: 0.1.0

Box Sync Issues

Problem: Credentials or tokens not syncing
