Frontend MCP Monorepo

Monorepo demonstrating a "near-production" architecture for a centralized design system with Storybook, standalone MCP HTTP server, and team apps consuming via workspace.

🎯 Overview

This monorepo simulates a production environment where:

  • packages/design-system is the central repository:

    • Design System (React components)
    • Storybook (design system documentation)
    • Standalone MCP HTTP server (reads Storybook static build)
    • Dockerfile for MCP server deployment

  • packages/demo-timeA and packages/demo-timeB are team apps that:

    • Consume the @org/design-system package via workspace
    • Don't know the internal code of the design system
    • Use the MCP HTTP endpoint exposed by the design system

Architecture

graph TB
    DS[packages/design-system<br/>Design System + Storybook + MCP Server]

    DS -->|npm workspace| TA[packages/demo-timeA<br/>Port 3000]
    DS -->|npm workspace| TB[packages/demo-timeB<br/>Port 3001]

    DS -->|HTTP MCP<br/>localhost:13316| TA
    DS -->|HTTP MCP<br/>localhost:13316| TB

    subgraph "Design System Package"
        DS1[React Components]
        DS2[Storybook Docs]
        DS3[MCP HTTP Server]
        DS4[Dockerfile]
    end

    DS -.-> DS1
    DS -.-> DS2
    DS -.-> DS3
    DS -.-> DS4

Architecture decisions

ADR-001 records why the MCP server builds its component catalog from Storybook's index.json instead of a hand-written list or the component source.

📋 Prerequisites

  • Node.js 18+ (recommended: 20+)
  • pnpm 8+ (or npm/yarn with workspaces)
  • Docker (for production mode)
  • Cursor or VS Code (with MCP support)

🚀 Dev Mode (Local)

1. Install Dependencies

pnpm install

2. Build Storybook for Design System

First, build the static Storybook build:

pnpm --filter @org/design-system storybook:build

This generates packages/design-system/storybook-static/ with the necessary files.

3. Start Local MCP Server

In a terminal, start the MCP server:

pnpm --filter @org/design-system mcp:dev

The server will be available at:

  • MCP endpoint: http://localhost:13316/mcp
  • Health check: http://localhost:13316/healthz

4. Start Storybook (optional, for visualization)

In another terminal:

pnpm storybook

Storybook will be at http://localhost:6006.

5. Start Team Apps

In separate terminals:

# Team A
pnpm demo-timeA:dev
# or: pnpm --filter demo-timeA dev
# App at http://localhost:3000

# Team B
pnpm demo-timeB:dev
# or: pnpm --filter demo-timeB dev
# App at http://localhost:3001

6. Configure Cursor/VS Code for MCP

Each app has its own .cursor/mcp.json pointing to the MCP server:

{
  "mcpServers": {
    "org-design-system-mcp": {
      "transport": "http",
      "url": "http://localhost:13316/mcp"
    }
  }
}

Reload the editor to detect the configuration.

🐳 "Simulated Production" Mode (Docker)

1. Build Storybook

pnpm --filter @org/design-system storybook:build

2. Build MCP Server

pnpm --filter @org/design-system mcp:build

3. Build Docker Image

pnpm --filter @org/design-system docker:build

This creates the image org/design-system-mcp:local.

4. Run Container

pnpm --filter @org/design-system docker:run

The container exposes the MCP server on port 13316.

5. In Real Production

In real production, you would have:

  • Terraform provisioning:

    • Kubernetes cluster (or Lambda/API Gateway)
    • Service/Ingress to expose https://design-system-mcp.your-company.com/mcp

  • CI/CD doing:

    • Storybook build
    • MCP server build
    • Docker image build
    • Push to registry
    • Deploy to cluster

  • Team apps using:

    • @org/design-system package from npm registry
    • MCP server URL via env var: MCP_STORYBOOK_URL

🔧 Available Scripts

Monorepo Root

  • pnpm dev - Starts all apps in dev mode
  • pnpm build - Builds all packages
  • pnpm storybook - Starts Storybook for design system
  • pnpm storybook:build - Static Storybook build
  • pnpm mcp:dev - Starts MCP server in dev mode
  • pnpm mcp:build - Builds MCP server

Design System (packages/design-system)

  • pnpm --filter @org/design-system storybook - Storybook dev
  • pnpm --filter @org/design-system storybook:build - Static build
  • pnpm --filter @org/design-system mcp:dev - MCP server dev
  • pnpm --filter @org/design-system mcp:build - Build MCP
  • pnpm --filter @org/design-system mcp:start - Starts MCP (production)
  • pnpm --filter @org/design-system docker:build - Build Docker
  • pnpm --filter @org/design-system docker:run - Runs container

Apps

  • pnpm demo-timeA:dev - Team A dev
  • pnpm demo-timeB:dev - Team B dev

🔌 MCP Endpoint

The MCP server exposes:

  • POST /mcp - MCP Protocol

    • tools/list - Lists available tools
    • tools/call - Executes tools:
      • list-all-components - Lists all components
      • find-component-by-name - Finds component by name
      • get-component-stories - Gets stories for a component
      • get-component-documentation - Gets component documentation
      • suggest-composition - Suggests composition for a use case

  • GET /healthz - Health check

    • Returns status, number of loaded stories, etc.

🌍 Environment Variables

MCP Server

  • PORT - Server port (default: 13316)
  • STORYBOOK_STATIC_PATH - Static build path (default: storybook-static)
  • STORYBOOK_URL - Storybook dev URL (default: http://localhost:5173)
  • LOG_LEVEL - Log level: debug, info, warn, error (default: info)
  • NODE_ENV - Environment: development or production

Apps (Production)

  • MCP_STORYBOOK_URL - MCP server URL in production
    • Example: https://design-system-mcp.internal/mcp

📖 How to Use with AI

See AI_RULES.md for:

  • AI behavior rules
  • Ready-to-use commands
  • Recommended workflow

Quick Example

  1. Start the MCP server: pnpm mcp:dev
  2. Open Cursor/VS Code in one of the apps
  3. In the chat, type:
    Use the org-design-system-mcp MCP to list all available components and suggest an onboarding screen.
  4. The AI will use the MCP to discover components and generate code

🐛 Troubleshooting

MCP Server can't find Storybook

  1. Make sure you ran storybook:build:
    pnpm --filter @org/design-system storybook:build
  2. Check if packages/design-system/storybook-static/index.json exists
  3. Check the STORYBOOK_STATIC_PATH variable in the server

Apps can't find @org/design-system

  1. Make sure you ran pnpm install at the root
  2. Check if the workspace is configured correctly in the root package.json

Docker build fails

  1. Make sure Storybook was built first
  2. Check if all necessary files are present
  3. Adjust the Dockerfile if necessary for your environment

MCP icon is yellow in Cursor

  1. Check if the MCP server is running: curl http://localhost:13316/healthz
  2. Verify the .cursor/mcp.json configuration
  3. Restart Cursor completely (not just reload the window)
  4. Check server logs for errors

🎓 Next Steps

  1. Explore components in Storybook: http://localhost:6006
  2. Test the MCP server: http://localhost:13316/healthz
  3. Try the commands from AI_RULES.md
  4. Create new components in the design system
  5. Use components in team apps
  6. Simulate production deployment with Docker

📝 Important Notes

  • Don't use @storybook/mcp: This project implements its own MCP HTTP server
  • MCP server reads static build: The server reads storybook-static/index.json to discover components
  • Local workspace: In production, apps would install @org/design-system from an npm registry
  • Fixed ports in dev:
    • Storybook: 5173 (dev) or 6006 (explicit)
    • MCP: 13316
    • Team A: 3000
    • Team B: 3001

📄 License

This is a demonstration project. Feel free to use it as a base.

Developed to demonstrate centralized design system architecture with MCP in a near-production environment.
