firmware-mcp
MCP server for firmware image extraction and analysis. Handles unpacking, binary inventory, security file discovery, version diffing, and entropy analysis.
What it does
- fw_extract -- Unpack firmware images automatically using binwalk. Handles SquashFS, CramFS, JFFS2, CPIO, UBI, gzip, LZMA, XZ, and more. Detects architecture from extracted ELF headers.
- fw_scan -- Signature scan without extraction. Identifies embedded filesystems, compression types, and content offsets.
- fw_list_binaries -- Inventory all ELF binaries in an extracted filesystem. Categorizes by function (CGI handlers, HTTP daemons, remote access services, SUID binaries, UPnP, SMB, DNS) with architecture and size info.
- fw_find_interesting -- Quick security scan of extracted firmware. Finds hardcoded credentials (passwd/shadow), SSH keys baked into firmware, SSL/TLS private keys, config files containing secrets, CGI scripts, startup scripts, SUID binaries.
- fw_diff_versions -- Compare two firmware versions side by side. Reports added, removed, and modified files with size deltas. Prioritizes changed binaries and security-relevant files.
- fw_entropy -- Shannon entropy analysis to detect encrypted or compressed regions. Produces an ASCII entropy map and identifies high-entropy blocks.
Requirements
- Python 3.10+
- binwalk installed and in PATH
- Dependencies:
pip install -r requirements.txt
Setup
pip install -r requirements.txt
python server.py
Security
- Output directory validation prevents path traversal during extraction
- Post-extraction symlink escape check removes symlinks pointing outside the output directory (Zip-Slip mitigation)
- File size limit of 2 GB
- Set
FIRMWARE_ALLOWED_DIRSenvironment variable to restrict where extracted files can be written
Architecture
firmware/
server.py # MCP server, all tools and helpers
Standalone single-file server. ELF header parsing is done natively without external tools. File hashing uses SHA-256 for diffing.
License
CC BY-NC-SA 4.0 -- see LICENSE.
