design-system-mcp

An async MCP server that extracts design tokens (colors, typography, spacing, components) from a live website and serves them to an AI IDE (Cursor). Long operations go into a job queue and return immediately — no blocking tool calls.

Why async

A naive MCP server does the work synchronously: the agent calls a tool and waits. Fine for fast operations; wrong for long ones (browser automation, page crawling, ML inference) — you get timeouts, no horizontal scaling, and one heavy request holding a connection. This server splits submit from result: submit returns a job ID instantly, status is polled separately.

Architecture

Submit returns a job ID immediately, non-blocking; status is polled by ID.
Playwright in a container does the actual site analysis, isolated — the host's node_modules is explicitly excluded from the image.
Redis under the queue — task persistence and concurrency (MAX_CONCURRENT_ANALYSES, default 5).
HTTP API on port 3000 (PORT), MCP on port 3001 (MCP_PORT): HTTP / HTTPS / SSH tunnel — flexible deploy and Cursor integration.

Job lifecycle

POST /analyze              → 202 {"job_id": "…", "status": "pending"}
GET  /status/<job_id>      → 200 {"status": "in-progress", …}
GET  /status/<job_id>      → 200 {"status": "completed", "result_location": "designs/…/design-system.json"}
GET  /status/<job_id>      → 404   # status key is dropped ~5s after completed/failed

The result itself is a JSON file on disk (result_location), not the status payload. After completion the Redis status key is deleted on a short delay: a later poll returns 404 (completed, failed, or never existed). Collect result_location while the job is still completed, or read the file under designs/.

Quickstart

cp .env.example .env          # set API_KEYS, PORT, MCP_PORT, MCP_PROTOCOL, etc.
docker-compose up --build     # redis + api (ports 3000 and 3001)
curl http://localhost:3000/health
# point Cursor's MCP config at http://localhost:3001 (see below)

Stack

TypeScript · Docker / Compose · Redis · Playwright (E2E) · Jest.

Trade-offs (by design)

404 after completion. Job status is deleted shortly after the worker marks completed or failed. No long-lived job history in Redis — poll until you see completed (and result_location), do not come back “some time later” for status.
Max 5 concurrent (MAX_CONCURRENT_ANALYSES) protects against overload; under a spike, jobs queue — the client needs a backpressure contract.

Features

Website Analysis: Automatically extract design tokens (colors, typography, spacing, components) from websites
Async Processing: Submit analysis requests and track job status
MCP Integration: Query design systems via MCP protocol from Cursor IDE
CLI Support: Command-line interface for triggering analyses
Docker Ready: Fully containerized with docker-compose

Usage

API Endpoints

HTTP API listens on port 3000 by default. Send X-API-Key on /analyze and /status.

Submit Analysis Request

Submit a website for analysis. Returns immediately with a job ID.

curl -X POST http://localhost:3000/analyze \
  -H "Content-Type: application/json" \
  -H "X-API-Key: your-api-key" \
  -d '{
    "site_name": "example",
    "url": "https://example.com"
  }'

Response (202 Accepted):

{
  "job_id": "550e8400-e29b-41d4-a716-446655440000",
  "status": "pending",
  "message": "Analysis job submitted successfully",
  "correlation_id": "550e8400-e29b-41d4-a716-446655440001"
}

Check Job Status

curl http://localhost:3000/status/550e8400-e29b-41d4-a716-446655440000 \
  -H "X-API-Key: your-api-key"

Response (200 OK - In Progress):

{
  "job_id": "550e8400-e29b-41d4-a716-446655440000",
  "status": "in-progress",
  "site_name": "example",
  "url": "https://example.com",
  "submitted_at": "2025-11-13T10:00:00Z",
  "started_at": "2025-11-13T10:00:05Z"
}

Response (200 OK - Completed):

{
  "job_id": "550e8400-e29b-41d4-a716-446655440000",
  "status": "completed",
  "site_name": "example",
  "url": "https://example.com",
  "submitted_at": "2025-11-13T10:00:00Z",
  "started_at": "2025-11-13T10:00:05Z",
  "completed_at": "2025-11-13T10:00:45Z",
  "result_location": "designs/example/design-system.json"
}

Response (404 Not Found): Job status is deleted shortly after completion or failure. If you get 404, the job has completed, failed, or never existed.

Health Check

curl http://localhost:3000/health

Response (200 OK):

{
  "status": "healthy",
  "service": "design-system-analyzer",
  "version": "1.0.0",
  "uptime_seconds": 3600,
  "queue_depth": 2,
  "active_jobs": 1,
  "max_concurrent_jobs": 5
}

Using CLI Script

The CLI script handles job submission and status polling automatically:

./scripts/analyze.sh example https://example.com

Or with API key as argument:

./scripts/analyze.sh example https://example.com your-api-key

Error Responses

All endpoints return standard error responses:

401 Unauthorized:

{
  "error": "Unauthorized: Invalid or missing API key",
  "code": "unauthorized"
}

400 Bad Request:

{
  "error": "Invalid request: site_name is required",
  "code": "validation_error"
}

404 Not Found:

{
  "error": "Job not found",
  "code": "not_found"
}

500 Internal Server Error:

{
  "error": "Internal server error",
  "code": "internal_error"
}

MCP Server Configuration

The MCP (Model Context Protocol) server allows Cursor IDE to query design systems directly. The server runs on port 3001 by default (configurable via MCP_PORT).

For Cursor IDE (HTTP)

Add to your Cursor IDE MCP configuration:

{
  "mcpServers": {
    "design-system-analyzer": {
      "url": "http://localhost:3001",
      "apiKey": "your-api-key-1"
    }
  }
}

For Cursor IDE (HTTPS)

For remote servers with HTTPS:

{
  "mcpServers": {
    "design-system-analyzer": {
      "url": "https://your-server.com:3001",
      "apiKey": "your-api-key-1"
    }
  }
}

Set MCP_PROTOCOL=https in your .env file and configure SSL certificates.

For Cursor IDE (SSH Tunnel)

Establish SSH tunnel:

ssh -L 3001:localhost:3001 user@remote-server

Configure Cursor IDE to use local stdio:

{
  "mcpServers": {
    "design-system-analyzer": {
      "command": "ssh",
      "args": ["user@remote-server", "cd /path/to/service && node dist/src/mcp/transport/stdio-transport.js"],
      "env": {
        "API_KEY": "your-api-key-1"
      }
    }
  }
}

Troubleshooting

Connection refused: Verify MCP server is running on the configured port
Unauthorized: Check that your API key matches the API_KEYS environment variable
Timeout: Ensure network connectivity and firewall rules allow access to the MCP port

See Quickstart Guide and MCP_USAGE.md for more detailed configuration examples.

Development

Install Dependencies

Note: For Docker-based development, you don't need to install dependencies on the host. All dependencies are installed in containers.

If you want to develop locally without Docker:

npm install

Important:

node_modules on the host is not used by containers
Test containers use isolated node_modules via anonymous Docker volumes
The api container uses node_modules from the Docker image (production dependencies only)
If you have node_modules on the host, it's safe to delete it when using Docker

Run Tests

Tests run in Docker containers. The test infrastructure includes:

test-server: Serves test fixture HTML pages on port 3002
test: Runs Playwright E2E tests

# Start test infrastructure
docker-compose --profile test up -d redis api test-server

# All tests
docker-compose --profile test run --rm test npm test

# Unit tests only
docker-compose --profile test run --rm test npm run test:unit

# Integration tests
docker-compose --profile test run --rm test npm run test:integration

# E2E tests
docker-compose --profile test run --rm test npm run test:e2e

See Quickstart Guide - Testing for detailed information about test services.

Linting and Formatting

# Lint
npm run lint

# Fix linting issues
npm run lint:fix

# Format code
npm run format

Documentation

License

MIT
