Multi-Agent Financial Analyst System

A Practice Laboratory for Building Multi-Agent Systems with MCP

This repository demonstrates how to build production-ready multi-agent systems using LangGraph, Model Context Protocol (MCP), and local LLMs. It showcases two different orchestration patterns for coordinating specialized AI agents to perform complex financial analysis tasks.

Table of Contents

  1. System Overview
  2. Architecture Components
  3. Two Orchestration Methods
  4. Repository Structure
  5. Quick Start
  6. Understanding MCP
  7. How the Agents Work
  8. Orchestration Deep Dive
  9. Example Outputs
  10. Testing & Comparison
  11. Troubleshooting

Repository Structure

multi_agent/
│
├── Core Orchestration Files (2)
│   ├── financial_analyst_system_manual_graph.py    # Method 1: Explicit control
│   └── financial_analyst_system_supervisor.py      # Method 2: Automatic routing
│
├── MCP Server Implementations (4)
│   └── mcp_servers/
│       ├── server_stock_data.py    # Yahoo Finance integration (3 tools)
│       ├── server_plot.py          # Chart generation (2 tools)
│       ├── server_news.py          # News retrieval (1 tool)
│       └── server_report.py        # Report saving (1 tool)
│
├── Testing & Scripts
│   ├── tests/
│   │   ├── README.md                 # Test documentation
│   │   ├── test_system.py            # Component validation
│   │   ├── test_manual_quick.py      # Manual graph quick test
│   │   ├── test_supervisor_quick.py  # Supervisor quick test
│   │   └── test_comprehensive.py     # Full workflow + report generation
│   └── scripts/
│       ├── compare_orchestrations.py # Side-by-side comparison
│       ├── demo_full_workflow.py     # Full pipeline demo
│       └── run_complex_test.py       # Complex test scenarios
│
├── Generated Outputs (auto-created)
│   └── outputs/
│       ├── charts/                 # PNG visualizations
│       └── reports/                # Markdown analysis reports
│
├── Configuration Files
│   ├── requirements.txt           # Python dependencies
│   ├── setup_conda_uv.sh          # Automated setup script
│   └── .gitignore                 # Git ignore rules
│
└── Documentation
    └── README.md

System Overview

What Does This System Do?

The Financial Analyst Multi-Agent System analyzes stocks by:

  1. Data Collection: Fetches real-time stock prices, historical data, and company information
  2. Visualization: Creates price charts and comparisons
  3. News Analysis: Retrieves and analyzes market news with sentiment scoring
  4. Report Generation: Produces markdown reports with all findings

Key Features

  • 4 Specialized Agents: Data Analyst, Chart Specialist, News Analyst, Report Writer
  • 4 MCP Servers and 7 Tools: Stock data, charts, news, report generation
  • 2 Orchestration Patterns: Manual graph construction vs. automatic supervision
  • Local LLM: Runs entirely on Ollama (no cloud APIs needed)
  • Production Ready: Proper error handling, state management, checkpointing

Architecture Components

1. LLM Backend: Ollama

Model: granite4:3b (IBM's open-source model)

from langchain_ollama import ChatOllama

model = ChatOllama(
    model="granite4:3b",
    base_url="http://localhost:11434"
)

2. MCP

The defined tools run as independent server processes communicating via STDIO.

Our MCP Servers:

mcp_servers/
├── server_stock_data.py    # Yahoo Finance API integration
├── server_plot.py          # Matplotlib chart generation
├── server_news.py          # Financial news retrieval
└── server_report.py        # Markdown report saving

Each server exposes tools that agents can invoke:

# Example: Stock Data Server
mcp = FastMCP("StockData")

@mcp.tool()
def get_stock_price(ticker: str) -> dict:
    """Get current stock price and trading data."""
    stock = yf.Ticker(ticker)
    return {
        "current_price": price,
        "day_high": high,
        "volume": volume,
        # ... more data
    }

mcp.run(transport="stdio")

3. LangGraph: Workflow Engine

LangGraph is a framework -- derived from LangChain -- for building stateful, multi-actor applications with LLMs.

Purpose: Orchestrates agent interactions, manages state, handles routing Key Concepts:

  • Nodes: Individual agents or functions
  • Edges: Connections between nodes
  • State: Shared data structure passed between nodes
  • Graph: The complete workflow definition

4. Specialized Agents

Each agent is a ReAct (Reasoning + Acting) agent with:

  • Specific tools for its domain
  • Custom system prompt defining its role
  • Access to conversation history
  • Ability to invoke tools and reason about results

Agent Roster:

Agent Tools Purpose
Supervisor None Routes queries to appropriate specialists
Data Analyst get_stock_price, get_historical_data, get_stock_info Retrieves and analyzes financial data
Chart Specialist create_chart, create_comparison Creates visualizations
News Analyst get_stock_news Fetches news and performs sentiment analysis
Report Writer save_report Compiles findings into markdown reports

Two Orchestration Methods

This repository provides implementations of two different approaches to multi-agent orchestration, each with distinct trade-offs.

Method 1: Manual Graph Construction

File: financial_analyst_system_manual_graph.py

Philosophy: Explicit control over every aspect of agent coordination.

How It Works

  1. Custom State Definition
class FinancialAnalystState(TypedDict):
    messages: Annotated[list[BaseMessage], operator.add]
    next: str  # Which agent to route to
    analysis_context: dict  # Shared data across agents
  1. Supervisor Node with Routing Logic
async def supervisor_node(state: FinancialAnalystState) -> dict:
    """Decides which agent should handle the request."""
    messages = state["messages"]

    # Supervisor analyzes conversation and decides routing
    routing_messages = [SystemMessage(content=SUPERVISOR_PROMPT), *messages]
    response = await model.ainvoke(routing_messages)

    # Parse decision from response
    decision = response.content.strip().lower()
    valid_routes = ["data_analyst", "chart_specialist", "news_analyst", "report_writer", "finish"]

    if decision not in valid_routes:
        # Try to extract from response
        for route in valid_routes:
            if route in decision:
                decision = route
                break
        else:
            decision = "finish"  # Default to finish if unclear

    next_step = END if decision == "finish" else decision

    return {
        "next": next_step,
        "messages": [AIMessage(content=f"Routing to {decision}", name="supervisor")]
    }
  1. Explicit Graph Construction
from langgraph.graph import StateGraph, START, END

builder = StateGraph(FinancialAnalystState)

# Add all nodes
builder.add_node("supervisor", supervisor_node)
builder.add_node("data_analyst", create_agent_node(data_analyst, "data_analyst"))
builder.add_node("chart_specialist", create_agent_node(chart_specialist, "chart_specialist"))
builder.add_node("news_analyst", create_agent_node(news_analyst, "news_analyst"))
builder.add_node("report_writer", create_agent_node(report_writer, "report_writer"))

# Define routing edges
builder.add_edge(START, "supervisor")

# Conditional routing from supervisor
builder.add_conditional_edges(
    "supervisor",
    route_after_supervisor,  # Function that reads state["next"]
    {
        "data_analyst": "data_analyst",
        "chart_specialist": "chart_specialist",
        "news_analyst": "news_analyst",
        "report_writer": "report_writer",
        END: END
    }
)

# All agents return to supervisor
for agent in ["data_analyst", "chart_specialist", "news_analyst", "report_writer"]:
    builder.add_edge(agent, "supervisor")

# Compile the graph
app = builder.compile(checkpointer=MemorySaver())

Advantages

  • Full Control: Every routing decision is explicit and customizable
  • Custom State: Can add any fields to state for data sharing
  • Detailed Prompts: Complete control over supervisor reasoning
  • Debugging: Clear visibility into workflow execution
  • Flexibility: Easy to add custom logic or routing rules

Method 2: Supervisor Pattern (Automatic)

File: financial_analyst_system_supervisor.py

Philosophy: Let the framework handle orchestration automatically.

How It Works

  1. Create Specialized Agents
data_analyst = create_react_agent(
    model=model,
    tools=tools_by_category["data"],
    prompt=DATA_ANALYST_PROMPT, # < --- Custom system prompt
    name="data_analyst"  # Name is crucial for routing
)

chart_specialist = create_react_agent(
    model=model,
    tools=tools_by_category["chart"],
    prompt=CHART_SPECIALIST_PROMPT,
    name="chart_specialist"
)

# ... more agents
  1. Single Function Call for Supervision
from langgraph_supervisor import create_supervisor

# Build supervisor workflow
workflow = create_supervisor(
    agents,  # List of all specialized agents
    model=model,
)

app = workflow.compile()

That's it! The supervisor pattern automatically:

  • Creates a supervisor agent
  • Sets up routing logic
  • Manages state transitions
  • Handles agent coordination

Advantages

  • Simplicity: 75% less boilerplate code
  • Fast Development: Rapid prototyping and iteration
  • Automatic Routing: LLM decides agent delegation
  • Maintainability: Less code to maintain
  • Built-in Best Practices: Framework handles edge cases

Quick Start - Installation

bash setup_conda_uv.sh

# This script will:
# - Check/start Ollama
# - Pull the granite4:3b model
# - Create conda environment
# - Install all dependencies
# - Run system tests

Running the System

Method 1: Manual Graph

conda activate financial_analyst_env
python financial_analyst_system_manual_graph.py

Interactive prompt appears:

Your query: Analyze Apple stock and create a report with charts

Method 2: Supervisor Pattern

conda activate financial_analyst_env
python financial_analyst_system_supervisor.py

Compare Both Methods

python scripts/compare_orchestrations.py "What's Tesla's stock price?"

# Or interactive mode
python scripts/compare_orchestrations.py -i

Acknowledgements

This repository is based on the LangGraph library.

Author

Lorenzo Molfetta

Email: lorenzo.molfetta@unibo.it
