Windows x64 进程调试工具

donx64mcp-dbg

A powerful in-process debugging toolkit that lets AI agents (Claude, Codex) debug and inspect any Windows x64 process in real time. Inject a DLL, get 40+ debug commands over a named pipe, and control it all through MCP tools.

Designed for authorized security research, reverse engineering, and CTF challenges.

Features

Scalar hook signatures

dbg_hook(address, name="", argument_count=4) accepts the exact number of Windows x64 scalar integer/pointer arguments, from 0 through 16. For example, use argument_count=5 for GetDiskFreeSpaceA/W. The pipe equivalent is HOOK_TYPED <address> <argument_count> [name]. The log captures the first four arguments; all declared arguments are forwarded, including stack arguments. Logging preserves the function's incoming and outgoing LastError values.

The legacy HOOK command and scan/patch hook modes retain a four-argument signature. They must not be used for functions requiring stack arguments. Floating-point/vector arguments, aggregate returns and variadic signatures are not supported by scalar hooks. Use breakpoint/memory inspection for those calls.

tests/scalar_hooks.cpp and tests/test_scalar_hooks.py exercise all 17 supported arities in an owned process, checking argument forwarding, entry/return LastError and unhook restoration. Compile the fixture as C++17, then run the Python test with --probe, --dll and a new --output JSON path (requires pywin32).

• Memory — read, write, allocate, fill, pointer chain dereferencing
• Disassembly — Zydis-powered instruction and function disassembly
• Pattern scanning — IDA-style byte patterns with wildcards, string extraction
• Breakpoints — INT3 software breakpoints with hit counts, register context, wait-for-hit
• API hooking — MinHook-based function hooking with argument + return value logging
• Module inspection — enumerate loaded modules, exports, imports, PE sections
• Thread control — list, suspend, resume, get/set registers, call stacks
• Heap walking — enumerate heaps and walk allocations
• Anti-anti-debug — 3-tier stealth engine (18 hooks) defeating common debugger detection
• Stealth injection — manual map mode (no PEB entry, PE headers erased)

Quick Install

Prerequisites

• Windows 10/11 x64
• Visual Studio 2022 (Community, Professional, or Enterprise) with the "Desktop development with C++" workload
• Python 3.10+ on PATH with pip

One-command install

git clone https://github.com/d0nk3yhm/donx64mcp-dbg.git
cd donx64mcp-dbg
install.bat

The install script will:

1. Build mcp_debugger.dll and mcp_inject.exe from source
2. Install Python dependencies (pywin32, mcp SDK)
3. Register the MCP server globally with Claude Code (written to ~/.claude/settings.json)

After install, the dbg_* tools are available in every Claude Code session — no per-project config needed.

Manual build

If you prefer to build manually or use the Visual Studio IDE:

:: Option A: Command-line build
build_all.bat

:: Option B: Open in Visual Studio
:: Open mcp_debugger.sln, set to Release|x64, build solution

:: Install Python deps
pip install pywin32 mcp

Setup with Claude Code

Automatic (via install.bat)

The installer registers the MCP server globally using claude mcp add. After install, restart Claude Code and the dbg_* tools will be available in any project.

Manual (CLI)

claude mcp add donx64mcp-dbg -s user -- python "C:/path/to/donx64mcp-dbg/bridge/mcp_debugger_server.py"

The -s user flag registers it globally in ~/.claude/settings.json so it works from any project directory.

Manual (config file)

Add to %USERPROFILE%\.claude\settings.json (create the mcpServers key if it doesn't exist):

{
  "mcpServers": {
    "donx64mcp-dbg": {
      "command": "python",
      "args": ["C:/path/to/donx64mcp-dbg/bridge/mcp_debugger_server.py"]
    }
  }
}

Per-project only (optional)

If you only want the debugger available in a specific project, add a .mcp.json in the project root:

{
  "mcpServers": {
    "donx64mcp-dbg": {
      "command": "python",
      "args": ["C:/path/to/donx64mcp-dbg/bridge/mcp_debugger_server.py"]
    }
  }
}

Setup with Codex

Add to your Codex MCP configuration:

{
  "mcpServers": {
    "donx64mcp-dbg": {
      "command": "python",
      "args": ["C:/path/to/donx64mcp-dbg/bridge/mcp_debugger_server.py"]
    }
  }
}

How It Works

Claude / Codex
      |
      | MCP protocol (stdio)
      v
mcp_debugger_server.py        mcp_inject.exe
   (Python MCP bridge)          (injector)
      |                             |
      |  Named Pipe                 |  DLL injection
      |  \\.\pipe\mcp_dbg_<PID>    |  (LoadLibrary / Manual Map)
      v                             v
               mcp_debugger.dll
             (inside target process)

1. You call dbg_attach("target.exe") from Claude/Codex
2. The Python bridge finds the process, runs mcp_inject.exe to inject the DLL
3. The DLL starts a named pipe server inside the target process
4. The bridge connects to the pipe and forwards all dbg_* commands
5. Commands execute in-process and return JSON results

Usage

Once the MCP server is registered, use it from Claude or Codex:

1. dbg_attach("target.exe")     <- injects DLL, opens pipe, ready
2. dbg_info()                    <- process name, PID, base address
3. dbg_disasm("7FF612340000")    <- disassemble at address
4. dbg_stealth_on(2)             <- activate anti-anti-debug

Injection modes

# Inject into a running process
mcp_inject.exe --name target.exe --dll path\to\mcp_debugger.dll

# Manual map (stealth - DLL hidden from module lists)
mcp_inject.exe --name target.exe --dll path\to\mcp_debugger.dll --mm

# Launch suspended, inject before any user code runs
mcp_inject.exe --launch target.exe --dll path\to\mcp_debugger.dll --mm

# Wait for a DLL to load, then inject
mcp_inject.exe --wait-dll engine.dll --in target.exe --dll path\to\mcp_debugger.dll --mm --timeout 30000

Note: When using from Claude/Codex, dbg_attach() handles injection automatically using LoadLibrary mode. For manual map or advanced scenarios, use mcp_inject.exe directly.

Command Reference

Core

Memory Operations

Disassembly (Zydis)

Pattern Scanning

Breakpoints

Module Inspection

API Hooking (MinHook)

Thread Control

Heap Inspection

Stealth / Anti-Anti-Debug

Anti-Anti-Debug Engine

Three tiers of anti-debug stealth via STEALTH_ON <level>:

Tier 1 (Basic): PEB patching (BeingDebugged, NtGlobalFlag, heap flags), ETW disable, hooks on IsDebuggerPresent, CheckRemoteDebuggerPresent, NtQueryInformationProcess, NtClose.

Tier 2 (Full, includes Tier 1): Debug register sanitization (NtGetContextThread, NtSetContextThread, NtContinue), timing hooks (QueryPerformanceCounter, GetTickCount, GetTickCount64), thread hooks (NtSetInformationThread, NtCreateThreadEx), window/process filtering (FindWindowA/W, EnumWindows), ntdll hooks (NtQueryObject, NtQuerySystemInformation).

Tier 3 (Max, includes Tier 2): Instrumentation callback kill (NtSetInformationProcess class 40 block).

Total hooks at max level: 18.

Analyzing Timing-Based Checks

Many binaries use timing functions to detect debugger interference. The debugger slows execution, causing timestamp checks to fail. This toolkit provides multiple approaches:

Approach 1: Use Timing Stealth (Automatic)

Activate Tier 2 stealth to automatically spoof timing functions:

dbg_stealth_on(2)  # GetTickCount, QueryPerformanceCounter return fake values

The target sees consistent time even while you're debugging.

Approach 2: Analyze and Patch the Check (Manual)

1. Hook the timing function with a breakpoint:
   复制

   dbg_exports("kernel32.dll") → find GetTickCount address
   dbg_bp_set(gtc_address, halt=True)


2. Resume and wait for the breakpoint to hit:
   复制

   dbg_thread_resume(main_thread_id)
   dbg_bp_wait(gtc_address, timeout_ms=10000)


3. Inspect the caller's code (what happens after the return):
   复制

   dbg_bp_ctx(gtc_address) → get RIP/RSP
   dbg_disasm(return_address, 20) → see the comparison/check


4. Identify the check pattern (cmp, test, conditional jump), then patch it:
   复制

   dbg_hook_scan_caller(gtc_address, scan_window=4096, pattern="...", replacement="...")


5. Release and continue:
   复制

   dbg_bp_continue(gtc_address)


The tool will automatically fire the hook on every subsequent call to the timing function, patching the check in-process with zero MCP latency.

Source Layout

donx64mcp-dbg/
├── dll/                        # DLL source code
│   ├── mcp_debugger.cpp        # Entry point, pipe server
│   ├── commands.cpp/h          # Command dispatcher
│   ├── memory_ops.cpp/h        # Memory read/write/alloc
│   ├── breakpoints.cpp/h       # INT3 breakpoints + VEH
│   ├── disasm.cpp/h            # Zydis disassembly
│   ├── threads.cpp/h           # Thread enumeration/control
│   ├── modules.cpp/h           # Module/export/import/section info
│   ├── hooks.cpp/h             # MinHook API hooking
│   ├── scanner.cpp/h           # Pattern scanning + strings
│   ├── heap.cpp/h              # Heap walking
│   ├── anti_debug.cpp/h        # Anti-anti-debug engine
│   ├── globals.h               # Global state
│   ├── response.h              # JSON response helpers
│   ├── lib/minhook/            # MinHook (vendored)
│   └── lib/zydis/              # Zydis disassembler (vendored)
├── injector/                   # Injector source
│   └── mcp_inject.cpp          # LoadLibrary + manual map injector
├── bridge/                     # Python MCP bridge
│   └── mcp_debugger_server.py  # MCP server (all dbg_* tools)
├── scripts/                    # Utility scripts
│   └── quick_test.py           # Pipe connectivity test
├── build_all.bat               # Build DLL + injector
├── install.bat                 # Build + install + register
├── mcp_debugger.sln            # Visual Studio solution
└── .mcp.json                   # MCP server config (project-local)

Named Pipe Protocol

After injection, the DLL creates a named pipe at \\.\pipe\mcp_dbg_<PID>.

• Format: Send UTF-8 command string, receive JSON response
• Mode: Message-mode pipe
• Buffer: 64 KB

Manual Map Technical Details

The manual mapper (--mm flag) performs stealth injection:

1. Read PE from disk and validate (x64 DLL check)
2. Allocate memory in target (prefers original ImageBase)
3. Map sections with correct RVA offsets
4. Process base relocations (IMAGE_REL_BASED_DIR64)
5. Pre-load non-system dependencies (e.g. dbghelp.dll) via LoadLibrary
6. Resolve imports with remote base delta
7. Write mapped image and set per-section memory protections
8. Call exported ManualMapInit via CreateRemoteThread
9. Erase PE headers (zero first 0x1000 bytes)

The DLL uses static CRT (/MT). ManualMapInit calls _CRT_INIT() to bootstrap the C runtime before starting the pipe server, since _DllMainCRTStartup cannot be called from a manually-mapped context.
