🚀 DevKit Max-完整的MCP项目指南
📋 项目概述
项目名称：DevKit Max
标语：Claude中的完整开发人员工具箱
目标：在5小时内构建一个包含9个基本开发工具的MCP服务器
核心理念：“Vibe编码”-在享受过程的同时构建有用、美观的工具
🎯 完整的功能规格
工具1:JSON格式化程序/验证器 (json_formatter)
Purpose: Clean, validate, and prettify JSON data
Input Parameters:
- json_string: string (required) - Raw JSON
- indent: integer (optional, default: 2) - Indentation spaces
- sort_keys: boolean (optional, default: false) - Sort object keys
Output: Formatted JSON with syntax highlighting or error details
Example Input: {"name":"john","data":[1,2,3]}
Example Output:
```json
{
"name": "john",
"data": [1, 2, 3]
}
### **Tool 2: Base64 Encoder/Decoder** (`base64_tool`)
```yaml
Purpose: Bidirectional Base64 conversion
Input Parameters:
- operation: "encode" | "decode" (required)
- input: string (required) - Text to encode or base64 to decode
- url_safe: boolean (optional, default: false) - Use URL-safe encoding
- padding: boolean (optional, default: true) - Include padding characters
Output: Converted string with operation metadata
Example: "Hello World" ↔ "SGVsbG8gV29ybGQ="
工具3:UUID生成器 (uuid_generator)
Purpose: Generate unique identifiers
Input Parameters:
- count: integer (optional, default: 1, range: 1-50) - Number of UUIDs
- version: "v1" | "v4" (optional, default: "v4") - UUID version
- hyphens: boolean (optional, default: true) - Include hyphens
Output: List of UUIDs in copy-friendly format
Example Output:
Generated 3 UUIDv4:
1. `550e8400-e29b-41d4-a716-446655440000`
2. `6ba7b810-9dad-11d1-80b4-00c04fd430c8`
3. `123e4567-e89b-12d3-a456-426614174000`
工具4:JWT解码器 (jwt_decoder)
Purpose: Parse and inspect JWT tokens
Input Parameters:
- token: string (required) - JWT token
- verify_signature: boolean (optional, default: false) - Basic format check
Output: Decoded header, payload, and metadata
Example Output:
Header:
```json
{
"alg": "HS256",
"typ": "JWT"
}
有效载荷：
{
"sub": "1234567890",
"name": "John Doe",
"iat": 1516239022,
"exp": 1516242622
}
⚠️ 令牌已于2年前过期
### **Tool 5: Timestamp Converter** (`timestamp_tool`)
```yaml
Purpose: Convert between time formats
Input Parameters:
- input: string | number (required) - Time input
- input_format: "auto" | "unix" | "iso" | "rfc2822" (optional, default: "auto")
- output_format: "all" | "unix" | "iso" | "human" (optional, default: "all")
- timezone: string (optional, default: "UTC") - Target timezone
Output: Time in multiple formats
Example Output:
Input: 1672531200
Conversions:
• Unix: 1672531200
• ISO: 2023-01-01T00:00:00+00:00
• Human: January 1, 2023, 12:00:00 AM UTC
• Relative: 1 year ago
工具6：哈希生成器 (hash_generator)
Purpose: Generate cryptographic hashes
Input Parameters:
- input: string (required) - Text to hash
- algorithm: "md5" | "sha1" | "sha256" | "sha512" (optional, default: "sha256")
- encoding: "hex" | "base64" (optional, default: "hex")
Output: Hash value with algorithm info
Example Output:
SHA256 hash of "hello":
`2cf24dba5fb0a30e26e83b2ac5b9e29e1b161e5c1fa7425e73043362938b9824`
工具7:快速HTTP测试仪 (http_tester)
Purpose: Make HTTP requests from Claude
Input Parameters:
- method: "GET" | "POST" | "PUT" | "DELETE" | "PATCH" (required)
- url: string (required) - Full URL with protocol
- headers: object (optional) - Request headers as JSON
- body: string | object (optional) - Request body
- timeout: integer (optional, default: 10) - Timeout in seconds
Output: Response with status, headers, body, and timing
Example Output:
✅ GET https://api.github.com/users/octocat (200 OK)
⏱️ 342ms
Headers:
• content-type: application/json; charset=utf-8
• x-ratelimit-remaining: 59
Body (preview):
```json
{
"login": "octocat",
"id": 583231
}
### **Tool 8: SQL Formatter** (`sql_formatter`)
```yaml
Purpose: Format and prettify SQL queries
Input Parameters:
- sql: string (required) - Raw SQL query
- dialect: "mysql" | "postgresql" | "sqlite" | "tsql" (optional, default: "mysql")
- indent_width: integer (optional, default: 2) - Spaces per indent
- keyword_case: "upper" | "lower" | "preserve" (optional, default: "upper")
Output: Formatted SQL with syntax highlighting
Example Output:
```sql
SELECT
users.id,
users.name,
orders.total
FROM
users
JOIN orders ON users.id = orders.user_id
WHERE
users.active = TRUE
AND orders.date > '2023-01-01'
ORDER BY
orders.total DESC
LIMIT 10;
### **Tool 9: Color Converter** (`color_converter`)
```yaml
Purpose: Convert between color formats with visual preview
Input Parameters:
- color: string (required) - Color input
- from_format: "auto" | "hex" | "rgb" | "hsl" | "name" (optional, default: "auto")
- to_format: "all" | "hex" | "rgb" | "hsl" | "name" (optional, default: "all")
Output: Color in all formats with ASCII preview
Example Output:
🎨 Color: Deep Sky Blue
Preview: ████████████████████████████
• HEX: #00BFFF
• RGB: rgb(0, 191, 255)
• HSL: hsl(195°, 100%, 50%)
• CMYK: cmyk(100%, 25%, 0%, 0%)
• CSS: deepskyblue
🏗️ 技术架构
项目结构
devkit-max/
├── server.py # Main MCP server entry point
├── requirements.txt # Dependencies
├── config.yaml # Configuration file
├── README.md # Documentation
├── tools/ # All tool implementations
│ ├── __init__.py
│ ├── json_formatter.py
│ ├── base64_tool.py
│ ├── uuid_generator.py
│ ├── jwt_decoder.py
│ ├── timestamp_tool.py
│ ├── hash_generator.py
│ ├── http_tester.py
│ ├── sql_formatter.py
│ └── color_converter.py
├── utils/ # Shared utilities
│ ├── __init__.py
│ ├── formatters.py # Output formatting
│ ├── validators.py # Input validation
│ ├── errors.py # Error handling
│ └── constants.py # Constants and config
└── tests/ # Quick smoke tests
└── test_quick.py
依赖项
mcp>=1.0.0 # MCP protocol implementation
fastapi>=0.104.0 # Web framework for MCP
python-dateutil>=2.8.2 # Time parsing
pyjwt>=2.8.0 # JWT decoding
httpx>=0.25.0 # Async HTTP client
pydantic>=2.4.0 # Data validation
colorama>=0.4.6 # Color handling (optional)
MCP服务器骨架
# server.py
from mcp.server import Server, NotificationOptions
import mcp.server.stdio
import asyncio
from typing import List
import importlib
import os
# Initialize server
server = Server("devkit-max")
# Dynamically load all tools
def load_tools():
tools = []
tool_files = [f[:-3] for f in os.listdir("tools")
if f.endswith(".py") and f != "__init__.py"]
for tool_file in tool_files:
try:
module = importlib.import_module(f"tools.{tool_file}")
if hasattr(module, "register_tool"):
module.register_tool(server)
tools.append(tool_file)
except Exception as e:
print(f"⚠️ Failed to load {tool_file}: {e}")
print(f"✅ Loaded {len(tools)} tools: {', '.join(tools)}")
return tools
@server.list_tools()
async def handle_list_tools():
# Tools will be registered by individual modules
return []
async def main():
# Load all tools
load_tools()
# Run MCP server
async with mcp.server.stdio.stdio_server() as (read_stream, write_stream):
await server.run(read_stream, write_stream, NotificationOptions())
if __name__ == "__main__":
asyncio.run(main())
⏱️ 5小时实施计划
第1小时：基础和设置 (0:00-1:00)
15分钟：项目引导
# Create project structure
mkdir devkit-max && cd devkit-max
uv init .
echo "mcp>=1.0.0" >> requirements.txt
echo "fastapi>=0.104.0" >> requirements.txt
echo "python-dateutil>=2.8.2" >> requirements.txt
echo "pyjwt>=2.8.0" >> requirements.txt
# Create directory structure
mkdir tools utils tests
touch tools/__init__.py utils/__init__.py
# Create main server file
touch server.py
30分钟：核心服务器和第一个工具
# server.py - Complete with dynamic loading
# (See skeleton above)
# tools/json_formatter.py - Start with the simplest tool
import json
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "json_formatter",
"description": "Format and validate JSON with pretty printing",
"inputSchema": {
"type": "object",
"properties": {
"json_string": {"type": "string", "description": "Raw JSON string"},
"indent": {"type": "integer", "description": "Indentation spaces", "default": 2},
"sort_keys": {"type": "boolean", "description": "Sort dictionary keys", "default": False}
},
"required": ["json_string"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "json_formatter":
try:
data = json.loads(arguments["json_string"])
indent = arguments.get("indent", 2)
sort_keys = arguments.get("sort_keys", False)
formatted = json.dumps(data, indent=indent, sort_keys=sort_keys, ensure_ascii=False)
return {
"content": [{
"type": "text",
"text": f"```json\n{formatted}\n```"
}]
}
except json.JSONDecodeError as e:
return {
"content": [{
"type": "text",
"text": f"❌ Invalid JSON: {e.msg}\nLine {e.lineno}, Column {e.colno}"
}]
}
15分钟：工具2和3-速胜
# tools/uuid_generator.py
import uuid
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "uuid_generator",
"description": "Generate UUIDs (version 1 or 4)",
"inputSchema": {
"type": "object",
"properties": {
"count": {"type": "integer", "description": "Number of UUIDs to generate", "default": 1, "minimum": 1, "maximum": 50},
"version": {"type": "string", "description": "UUID version", "enum": ["v1", "v4"], "default": "v4"},
"hyphens": {"type": "boolean", "description": "Include hyphens in output", "default": True}
}
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "uuid_generator":
count = arguments.get("count", 1)
version = arguments.get("version", "v4")
hyphens = arguments.get("hyphens", True)
uuids = []
for _ in range(count):
if version == "v1":
uid = str(uuid.uuid1())
else:
uid = str(uuid.uuid4())
if not hyphens:
uid = uid.replace("-", "")
uuids.append(uid)
output = "\n".join([f"{i+1}. `{uid}`" for i, uid in enumerate(uuids)])
return {
"content": [{
"type": "text",
"text": f"Generated {count} UUID{version}:\n{output}"
}]
}
第2小时：核心工具实施 (1:00-2:00)
30分钟：Base64和哈希工具
# tools/base64_tool.py
import base64
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "base64_tool",
"description": "Encode or decode Base64 strings",
"inputSchema": {
"type": "object",
"properties": {
"operation": {"type": "string", "description": "Operation to perform", "enum": ["encode", "decode"], "default": "encode"},
"input": {"type": "string", "description": "Text to encode or Base64 to decode"},
"url_safe": {"type": "boolean", "description": "Use URL-safe encoding", "default": False}
},
"required": ["operation", "input"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "base64_tool":
operation = arguments["operation"]
input_text = arguments["input"]
url_safe = arguments.get("url_safe", False)
try:
if operation == "encode":
encoded = base64.b64encode(input_text.encode()).decode()
if url_safe:
encoded = encoded.replace('+', '-').replace('/', '_').rstrip('=')
result = encoded
action = "Encoded"
else: # decode
if url_safe:
input_text = input_text.replace('-', '+').replace('_', '/')
# Add padding if needed
padding = 4 - len(input_text) % 4
if padding != 4:
input_text += '=' * padding
decoded = base64.b64decode(input_text).decode()
result = decoded
action = "Decoded"
return {
"content": [{
"type": "text",
"text": f"{action} result:\n```\n{result}\n```"
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"❌ Error: {str(e)}"
}]
}
# tools/hash_generator.py
import hashlib
import base64
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "hash_generator",
"description": "Generate cryptographic hashes (MD5, SHA1, SHA256, SHA512)",
"inputSchema": {
"type": "object",
"properties": {
"input": {"type": "string", "description": "Text to hash"},
"algorithm": {"type": "string", "description": "Hash algorithm", "enum": ["md5", "sha1", "sha256", "sha512"], "default": "sha256"},
"encoding": {"type": "string", "description": "Output encoding", "enum": ["hex", "base64"], "default": "hex"}
},
"required": ["input"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "hash_generator":
input_text = arguments["input"]
algorithm = arguments.get("algorithm", "sha256")
encoding = arguments.get("encoding", "hex")
# Select hash algorithm
if algorithm == "md5":
hash_obj = hashlib.md5()
elif algorithm == "sha1":
hash_obj = hashlib.sha1()
elif algorithm == "sha256":
hash_obj = hashlib.sha256()
else: # sha512
hash_obj = hashlib.sha512()
# Compute hash
hash_obj.update(input_text.encode())
# Encode output
if encoding == "hex":
result = hash_obj.hexdigest()
else:
result = base64.b64encode(hash_obj.digest()).decode()
return {
"content": [{
"type": "text",
"text": f"{algorithm.upper()} hash ({encoding}):\n`{result}`"
}]
}
30分钟：JWT解码器
# tools/jwt_decoder.py
import jwt
import json
from datetime import datetime
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "jwt_decoder",
"description": "Decode and inspect JWT tokens",
"inputSchema": {
"type": "object",
"properties": {
"token": {"type": "string", "description": "JWT token to decode"},
"verify_signature": {"type": "boolean", "description": "Check token format (not cryptographic verification)", "default": False}
},
"required": ["token"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "jwt_decoder":
token = arguments["token"]
verify = arguments.get("verify_signature", False)
try:
# Decode without verification (or with simple format check)
if verify:
decoded = jwt.decode(token, options={"verify_signature": False})
else:
decoded = jwt.decode(token, options={"verify_signature": False})
# Split token parts
parts = token.split('.')
if len(parts) != 3:
return {
"content": [{
"type": "text",
"text": "❌ Invalid JWT format: Expected 3 parts separated by dots"
}]
}
# Decode header and payload
import base64
import json
# Add missing padding if needed
def decode_part(part):
padding = 4 - len(part) % 4
if padding != 4:
part += '=' * padding
return json.loads(base64.b64decode(part).decode())
header = decode_part(parts[0])
payload = decoded # Already decoded
# Build response
response_text = "## 🔐 JWT Decoded\n\n"
# Header
response_text += "### Header\n```json\n"
response_text += json.dumps(header, indent=2)
response_text += "\n```\n\n"
# Payload
response_text += "### Payload\n```json\n"
response_text += json.dumps(payload, indent=2)
response_text += "\n```\n\n"
# Check expiration
if 'exp' in payload:
exp_time = datetime.fromtimestamp(payload['exp'])
now = datetime.now()
if exp_time < now:
response_text += f"⚠️ **Token expired** on {exp_time.strftime('%Y-%m-%d %H:%M:%S')}\n"
else:
response_text += f"✅ Token valid until {exp_time.strftime('%Y-%m-%d %H:%M:%S')}\n"
# Signature preview
response_text += f"\n### Signature (preview)\n`{parts[2][:20]}...`\n"
return {
"content": [{
"type": "text",
"text": response_text
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"❌ Error decoding JWT: {str(e)}"
}]
}
第3小时：高级工具-第1部分 (2:00-3:00)
45分钟：时间戳转换器
# tools/timestamp_tool.py
from datetime import datetime, timezone
import dateutil.parser
import time
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "timestamp_tool",
"description": "Convert between timestamp formats (Unix, ISO, human readable)",
"inputSchema": {
"type": "object",
"properties": {
"input": {"type": "string", "description": "Timestamp input (Unix, ISO, or human date)"},
"input_format": {"type": "string", "description": "Input format", "enum": ["auto", "unix", "iso", "human"], "default": "auto"},
"output_format": {"type": "string", "description": "Output format", "enum": ["all", "unix", "iso", "human"], "default": "all"},
"timezone": {"type": "string", "description": "Target timezone (e.g., 'UTC', 'America/New_York')", "default": "UTC"}
},
"required": ["input"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "timestamp_tool":
input_str = arguments["input"]
input_format = arguments.get("input_format", "auto")
output_format = arguments.get("output_format", "all")
tz = arguments.get("timezone", "UTC")
try:
# Parse input based on format
dt = None
if input_format == "auto":
# Try different formats
try:
# Try Unix timestamp (integer or float)
timestamp = float(input_str)
dt = datetime.fromtimestamp(timestamp, timezone.utc)
except ValueError:
try:
# Try ISO format
dt = dateutil.parser.isoparse(input_str)
except ValueError:
# Try human date
dt = dateutil.parser.parse(input_str)
elif input_format == "unix":
timestamp = float(input_str)
dt = datetime.fromtimestamp(timestamp, timezone.utc)
elif input_format == "iso":
dt = dateutil.parser.isoparse(input_str)
else: # human
dt = dateutil.parser.parse(input_str)
# Convert to target timezone
from dateutil import tz as tzutil
try:
target_tz = tzutil.gettz(tz)
if target_tz:
dt = dt.astimezone(target_tz)
except:
pass # Keep UTC if timezone invalid
# Generate outputs
unix_timestamp = int(dt.timestamp())
iso_format = dt.isoformat()
human_format = dt.strftime("%B %d, %Y, %I:%M:%S %p %Z")
# Relative time
now = datetime.now(timezone.utc)
diff = now - dt.replace(tzinfo=timezone.utc)
seconds = diff.total_seconds()
if seconds < 60:
relative = "just now"
elif seconds < 3600:
minutes = int(seconds / 60)
relative = f"{minutes} minute{'s' if minutes != 1 else ''} ago"
elif seconds < 86400:
hours = int(seconds / 3600)
relative = f"{hours} hour{'s' if hours != 1 else ''} ago"
elif seconds < 2592000:
days = int(seconds / 86400)
relative = f"{days} day{'s' if days != 1 else ''} ago"
else:
months = int(seconds / 2592000)
relative = f"{months} month{'s' if months != 1 else ''} ago"
# Build response based on output format
if output_format == "all":
response = f"""## 🕐 Timestamp Conversion
**Input:** `{input_str}`
**Parsed as:** {dt.strftime('%Y-%m-%d %H:%M:%S %Z')}
**Conversions:**
• **Unix timestamp:** `{unix_timestamp}`
• **ISO 8601:** `{iso_format}`
• **Human readable:** {human_format}
• **Relative time:** {relative}"""
elif output_format == "unix":
response = f"Unix timestamp: `{unix_timestamp}`"
elif output_format == "iso":
response = f"ISO 8601: `{iso_format}`"
else: # human
response = f"Human readable: {human_format}"
return {
"content": [{
"type": "text",
"text": response
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"❌ Error parsing timestamp: {str(e)}\n\nTry formats:\n- Unix: 1672531200\n- ISO: 2023-01-01T00:00:00Z\n- Human: 'January 1, 2023'"
}]
}
第4小时：高级工具-第2部分 (3:00-4:00)
30分钟：SQL格式化程序
# tools/sql_formatter.py
import re
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "sql_formatter",
"description": "Format SQL queries with proper indentation",
"inputSchema": {
"type": "object",
"properties": {
"sql": {"type": "string", "description": "SQL query to format"},
"dialect": {"type": "string", "description": "SQL dialect", "enum": ["mysql", "postgresql", "sqlite", "tsql", "generic"], "default": "generic"},
"indent_width": {"type": "integer", "description": "Spaces per indent level", "default": 2},
"keyword_case": {"type": "string", "description": "Case for SQL keywords", "enum": ["upper", "lower", "preserve"], "default": "upper"}
},
"required": ["sql"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "sql_formatter":
sql = arguments["sql"].strip()
dialect = arguments.get("dialect", "generic")
indent_width = arguments.get("indent_width", 2)
keyword_case = arguments.get("keyword_case", "upper")
try:
# Simple SQL formatter (for 5-hour project)
keywords = [
'SELECT', 'FROM', 'WHERE', 'JOIN', 'LEFT', 'RIGHT', 'INNER', 'OUTER',
'ON', 'AND', 'OR', 'NOT', 'IN', 'BETWEEN', 'LIKE', 'IS', 'NULL',
'GROUP BY', 'ORDER BY', 'HAVING', 'LIMIT', 'OFFSET', 'INSERT INTO',
'VALUES', 'UPDATE', 'SET', 'DELETE FROM', 'CREATE TABLE', 'DROP TABLE',
'ALTER TABLE', 'ADD', 'COLUMN', 'PRIMARY KEY', 'FOREIGN KEY', 'REFERENCES',
'UNION', 'ALL', 'DISTINCT', 'AS', 'CASE', 'WHEN', 'THEN', 'ELSE', 'END',
'EXISTS', 'ANY', 'ALL', 'SOME', 'WITH', 'RECURSIVE'
]
# Apply keyword case
if keyword_case == "upper":
def upper_keywords(match):
return match.group(0).upper()
# Simple regex to find SQL keywords
pattern = r'\b(' + '|'.join([re.escape(kw.lower()) for kw in keywords]) + r')\b'
sql = re.sub(pattern, upper_keywords, sql, flags=re.IGNORECASE)
elif keyword_case == "lower":
pattern = r'\b(' + '|'.join(keywords) + r')\b'
sql = re.sub(pattern, lambda m: m.group(0).lower(), sql, flags=re.IGNORECASE)
# Basic formatting
indent = ' ' * indent_width
lines = []
current_indent = 0
in_parentheses = 0
# Split by clauses
sql_lower = sql.lower()
clause_patterns = [
r'(\bselect\b)', r'(\bfrom\b)', r'(\bwhere\b)', r'(\bjoin\b)',
r'(\bgroup by\b)', r'(\border by\b)', r'(\blimit\b)', r'(\boffset\b)',
r'(\bunion\b)', r'(\bintersect\b)', r'(\bexcept\b)'
]
# Add newlines before major clauses
formatted_sql = sql
for pattern in clause_patterns:
formatted_sql = re.sub(pattern, r'\n\1', formatted_sql, flags=re.IGNORECASE)
# Handle commas in SELECT
formatted_sql = re.sub(r',\s*', ',\n' + indent, formatted_sql)
# Clean up multiple newlines
formatted_sql = re.sub(r'\n\s*\n', '\n', formatted_sql)
# Add indentation
lines = formatted_sql.split('\n')
formatted_lines = []
current_indent = 0
for line in lines:
line = line.strip()
if not line:
continue
# Decrease indent for closing parentheses
if line.startswith(')'):
current_indent = max(0, current_indent - 1)
formatted_lines.append((' ' * indent_width * current_indent) + line)
# Increase indent for opening parentheses
if '(' in line and not line.startswith('('):
current_indent += 1
result = '\n'.join(formatted_lines)
return {
"content": [{
"type": "text",
"text": f"```sql\n{result}\n```"
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"```sql\n{sql}\n```\n\nNote: Could not format fully. Error: {str(e)}"
}]
}
30分钟：颜色转换器
# tools/color_converter.py
import re
import colorsys
from mcp.server import Server
# CSS color names
CSS_COLORS = {
'aliceblue': '#F0F8FF', 'antiquewhite': '#FAEBD7', 'aqua': '#00FFFF',
'aquamarine': '#7FFFD4', 'azure': '#F0FFFF', 'beige': '#F5F5DC',
'bisque': '#FFE4C4', 'black': '#000000', 'blanchedalmond': '#FFEBCD',
'blue': '#0000FF', 'blueviolet': '#8A2BE2', 'brown': '#A52A2A',
'burlywood': '#DEB887', 'cadetblue': '#5F9EA0', 'chartreuse': '#7FFF00',
'chocolate': '#D2691E', 'coral': '#FF7F50', 'cornflowerblue': '#6495ED',
'cornsilk': '#FFF8DC', 'crimson': '#DC143C', 'cyan': '#00FFFF',
'darkblue': '#00008B', 'darkcyan': '#008B8B', 'darkgoldenrod': '#B8860B',
'darkgray': '#A9A9A9', 'darkgreen': '#006400', 'darkgrey': '#A9A9A9',
'darkkhaki': '#BDB76B', 'darkmagenta': '#8B008B', 'darkolivegreen': '#556B2F',
'darkorange': '#FF8C00', 'darkorchid': '#9932CC', 'darkred': '#8B0000',
'darksalmon': '#E9967A', 'darkseagreen': '#8FBC8F', 'darkslateblue': '#483D8B',
'darkslategray': '#2F4F4F', 'darkslategrey': '#2F4F4F', 'darkturquoise': '#00CED1',
'darkviolet': '#9400D3', 'deeppink': '#FF1493', 'deepskyblue': '#00BFFF',
'dimgray': '#696969', 'dimgrey': '#696969', 'dodgerblue': '#1E90FF',
'firebrick': '#B22222', 'floralwhite': '#FFFAF0', 'forestgreen': '#228B22',
'fuchsia': '#FF00FF', 'gainsboro': '#DCDCDC', 'ghostwhite': '#F8F8FF',
'gold': '#FFD700', 'goldenrod': '#DAA520', 'gray': '#808080',
'green': '#008000', 'greenyellow': '#ADFF2F', 'grey': '#808080',
'honeydew': '#F0FFF0', 'hotpink': '#FF69B4', 'indianred': '#CD5C5C',
'indigo': '#4B0082', 'ivory': '#FFFFF0', 'khaki': '#F0E68C',
'lavender': '#E6E6FA', 'lavenderblush': '#FFF0F5', 'lawngreen': '#7CFC00',
'lemonchiffon': '#FFFACD', 'lightblue': '#ADD8E6', 'lightcoral': '#F08080',
'lightcyan': '#E0FFFF', 'lightgoldenrodyellow': '#FAFAD2', 'lightgray': '#D3D3D3',
'lightgreen': '#90EE90', 'lightgrey': '#D3D3D3', 'lightpink': '#FFB6C1',
'lightsalmon': '#FFA07A', 'lightseagreen': '#20B2AA', 'lightskyblue': '#87CEFA',
'lightslategray': '#778899', 'lightslategrey': '#778899', 'lightsteelblue': '#B0C4DE',
'lightyellow': '#FFFFE0', 'lime': '#00FF00', 'limegreen': '#32CD32',
'linen': '#FAF0E6', 'magenta': '#FF00FF', 'maroon': '#800000',
'mediumaquamarine': '#66CDAA', 'mediumblue': '#0000CD', 'mediumorchid': '#BA55D3',
'mediumpurple': '#9370DB', 'mediumseagreen': '#3CB371', 'mediumslateblue': '#7B68EE',
'mediumspringgreen': '#00FA9A', 'mediumturquoise': '#48D1CC', 'mediumvioletred': '#C71585',
'midnightblue': '#191970', 'mintcream': '#F5FFFA', 'mistyrose': '#FFE4E1',
'moccasin': '#FFE4B5', 'navajowhite': '#FFDEAD', 'navy': '#000080',
'oldlace': '#FDF5E6', 'olive': '#808000', 'olivedrab': '#6B8E23',
'orange': '#FFA500', 'orangered': '#FF4500', 'orchid': '#DA70D6',
'palegoldenrod': '#EEE8AA', 'palegreen': '#98FB98', 'paleturquoise': '#AFEEEE',
'palevioletred': '#DB7093', 'papayawhip': '#FFEFD5', 'peachpuff': '#FFDAB9',
'peru': '#CD853F', 'pink': '#FFC0CB', 'plum': '#DDA0DD',
'powderblue': '#B0E0E6', 'purple': '#800080', 'rebeccapurple': '#663399',
'red': '#FF0000', 'rosybrown': '#BC8F8F', 'royalblue': '#4169E1',
'saddlebrown': '#8B4513', 'salmon': '#FA8072', 'sandybrown': '#F4A460',
'seagreen': '#2E8B57', 'seashell': '#FFF5EE', 'sienna': '#A0522D',
'silver': '#C0C0C0', 'skyblue': '#87CEEB', 'slateblue': '#6A5ACD',
'slategray': '#708090', 'slategrey': '#708090', 'snow': '#FFFAFA',
'springgreen': '#00FF7F', 'steelblue': '#4682B4', 'tan': '#D2B48C',
'teal': '#008080', 'thistle': '#D8BFD8', 'tomato': '#FF6347',
'turquoise': '#40E0D0', 'violet': '#EE82EE', 'wheat': '#F5DEB3',
'white': '#FFFFFF', 'whitesmoke': '#F5F5F5', 'yellow': '#FFFF00',
'yellowgreen': '#9ACD32'
}
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "color_converter",
"description": "Convert between color formats (HEX, RGB, HSL, CSS names) with visual preview",
"inputSchema": {
"type": "object",
"properties": {
"color": {"type": "string", "description": "Color input in any format"},
"from_format": {"type": "string", "description": "Input format", "enum": ["auto", "hex", "rgb", "hsl", "name"], "default": "auto"},
"to_format": {"type": "string", "description": "Output format", "enum": ["all", "hex", "rgb", "hsl", "name"], "default": "all"}
},
"required": ["color"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "color_converter":
color_input = arguments["color"].strip().lower()
from_format = arguments.get("from_format", "auto")
to_format = arguments.get("to_format", "all")
try:
# Parse color
r, g, b = 0, 0, 0
hex_color = ""
color_name = ""
if from_format == "auto":
# Try to auto-detect format
# Check if it's a CSS color name
if color_input in CSS_COLORS:
hex_color = CSS_COLORS[color_input]
color_name = color_input
# Check if it's hex
elif re.match(r'^#?[0-9a-f]{6}$', color_input.replace('#', '')):
hex_color = '#' + color_input.replace('#', '')
# Check if it's rgb/rgba
elif re.match(r'^rgb\(', color_input):
from_format = "rgb"
# Check if it's hsl
elif re.match(r'^hsl\(', color_input):
from_format = "hsl"
else:
from_format = "name" # Try as name
if from_format == "hex" or (from_format == "auto" and hex_color):
if not hex_color:
hex_color = '#' + color_input.replace('#', '')
# Validate hex
if len(hex_color) != 7:
hex_color = '#' + hex_color[1:].zfill(6)
r = int(hex_color[1:3], 16)
g = int(hex_color[3:5], 16)
b = int(hex_color[5:7], 16)
elif from_format == "rgb":
# Parse rgb(r, g, b) or rgba(r, g, b, a)
match = re.match(r'rgba?\((\d+),\s*(\d+),\s*(\d+)', color_input)
if match:
r = int(match.group(1))
g = int(match.group(2))
b = int(match.group(3))
hex_color = f"#{r:02x}{g:02x}{b:02x}"
elif from_format == "hsl":
# Parse hsl(h, s%, l%)
match = re.match(r'hsl\((\d+),\s*(\d+)%,\s*(\d+)%', color_input)
if match:
h = int(match.group(1)) / 360.0
s = int(match.group(2)) / 100.0
l = int(match.group(3)) / 100.0
# Convert HSL to RGB
r, g, b = [int(x * 255) for x in colorsys.hls_to_rgb(h, l, s)]
hex_color = f"#{r:02x}{g:02x}{b:02x}"
elif from_format == "name":
if color_input in CSS_COLORS:
hex_color = CSS_COLORS[color_input]
color_name = color_input
r = int(hex_color[1:3], 16)
g = int(hex_color[3:5], 16)
b = int(hex_color[5:7], 16)
else:
# Try to find closest color
import math
def color_distance(c1, c2):
r1, g1, b1 = c1
r2, g2, b2 = c2
return math.sqrt((r1-r2)**2 + (g1-g2)**2 + (b1-b2)**2)
# Try to parse as hex anyway
if re.match(r'^#?[0-9a-f]{3,6}$', color_input.replace('#', '')):
hex_input = color_input.replace('#', '')
if len(hex_input) == 3:
hex_input = ''.join([c*2 for c in hex_input])
hex_color = '#' + hex_input.zfill(6)
r = int(hex_color[1:3], 16)
g = int(hex_color[3:5], 16)
b = int(hex_color[5:7], 16)
else:
return {
"content": [{
"type": "text",
"text": f"❌ Unknown color name: '{color_input}'\nTry: red, #FF0000, rgb(255,0,0), or hsl(0, 100%, 50%)"
}]
}
# Generate outputs
if not hex_color:
hex_color = f"#{r:02x}{g:02x}{b:02x}"
# RGB
rgb_str = f"rgb({r}, {g}, {b})"
# HSL
h, l, s = colorsys.rgb_to_hls(r/255.0, g/255.0, b/255.0)
hsl_str = f"hsl({int(h*360)}, {int(s*100)}%, {int(l*100)}%)"
# CMYK (approximation)
if r == 0 and g == 0 and b == 0:
c, m, y, k = 0, 0, 0, 100
else:
c = 1 - (r / 255.0)
m = 1 - (g / 255.0)
y = 1 - (b / 255.0)
k = min(c, m, y)
if k == 1:
c = m = y = 0
else:
c = (c - k) / (1 - k)
m = (m - k) / (1 - k)
y = (y - k) / (1 - k)
cmyk_str = f"cmyk({int(c*100)}%, {int(m*100)}%, {int(y*100)}%, {int(k*100)}%)"
# Find closest CSS color name
if not color_name:
import math
min_dist = float('inf')
closest_name = ""
for name, hex_val in CSS_COLORS.items():
cr = int(hex_val[1:3], 16)
cg = int(hex_val[3:5], 16)
cb = int(hex_val[5:7], 16)
dist = math.sqrt((r-cr)**2 + (g-cg)**2 + (b-cb)**2)
if dist < min_dist:
min_dist = dist
closest_name = name
color_name = closest_name
# Build response
# Create ASCII color block
color_block = "██" * 10
response = f"""## 🎨 Color Converter
**Input:** `{color_input}`
**Preview:** `{color_block}`
**Formats:**
• **HEX:** `{hex_color.upper()}`
• **RGB:** `{rgb_str}`
• **HSL:** `{hsl_str}`
• **CMYK:** `{cmyk_str}`
• **CSS Name:** `{color_name}`"""
if to_format != "all":
if to_format == "hex":
response = f"HEX: `{hex_color.upper()}`"
elif to_format == "rgb":
response = f"RGB: `{rgb_str}`"
elif to_format == "hsl":
response = f"HSL: `{hsl_str}`"
elif to_format == "name":
response = f"CSS Name: `{color_name}`"
return {
"content": [{
"type": "text",
"text": response
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"❌ Error converting color: {str(e)}\n\nTry formats:\n- HEX: #FF5733 or FF5733\n- RGB: rgb(255, 87, 51)\n- HSL: hsl(11, 100%, 60%)\n- Name: red, blue, green"
}]
}
第5小时：最终工具和抛光 (4:00-5:00)
45分钟：HTTP测试器（最复杂的工具）
# tools/http_tester.py
import httpx
import json
import time
from mcp.server import Server
def register_tool(server: Server):
@server.list_tools()
async def handle_list_tools():
return [{
"name": "http_tester",
"description": "Make HTTP requests (GET, POST, PUT, DELETE) and inspect responses",
"inputSchema": {
"type": "object",
"properties": {
"method": {"type": "string", "description": "HTTP method", "enum": ["GET", "POST", "PUT", "DELETE", "PATCH", "HEAD"], "default": "GET"},
"url": {"type": "string", "description": "Full URL with protocol (http:// or https://)"},
"headers": {"type": "object", "description": "Request headers as JSON object", "default": {}},
"body": {"type": "string", "description": "Request body (for POST, PUT, PATCH)", "default": ""},
"params": {"type": "object", "description": "Query parameters as JSON object", "default": {}},
"timeout": {"type": "integer", "description": "Timeout in seconds", "default": 10},
"follow_redirects": {"type": "boolean", "description": "Follow HTTP redirects", "default": True}
},
"required": ["method", "url"]
}
}]
@server.call_tool()
async def handle_call_tool(name: str, arguments: dict):
if name == "http_tester":
method = arguments["method"].upper()
url = arguments["url"]
headers = arguments.get("headers", {})
body = arguments.get("body", "")
params = arguments.get("params", {})
timeout = arguments.get("timeout", 10)
follow_redirects = arguments.get("follow_redirects", True)
# Validate URL
if not url.startswith(('http://', 'https://')):
return {
"content": [{
"type": "text",
"text": f"❌ Invalid URL: Must start with http:// or https://\nYou provided: {url}"
}]
}
try:
# Prepare request
request_headers = dict(headers)
if body and 'content-type' not in [k.lower() for k in request_headers.keys()]:
request_headers['Content-Type'] = 'application/json'
# Prepare request data
request_data = None
if body:
try:
# Try to parse as JSON
json.loads(body)
request_data = body
except:
# Use as plain text
request_data = body
# Make request
start_time = time.time()
async with httpx.AsyncClient(
timeout=timeout,
follow_redirects=follow_redirects
) as client:
response = await client.request(
method=method,
url=url,
headers=request_headers,
content=request_data,
params=params
)
end_time = time.time()
response_time = int((end_time - start_time) * 1000) # ms
# Parse response
status_emoji = "✅" if 200 <= response.status_code < 300 else "⚠️" if 300 <= response.status_code < 400 else "❌"
# Try to parse response body
response_body = response.text
content_type = response.headers.get('content-type', '').lower()
# Format response body
formatted_body = response_body
if 'application/json' in content_type:
try:
json_data = json.loads(response_body)
formatted_body = json.dumps(json_data, indent=2)
language = "json"
except:
language = "text"
elif 'html' in content_type:
language = "html"
# Truncate large HTML
if len(formatted_body) > 1000:
formatted_body = formatted_body[:1000] + "\n... [truncated]"
elif 'xml' in content_type:
language = "xml"
else:
language = "text"
# Build response
response_text = f"""## 🌐 HTTP Response
{status_emoji} **{method} {url}** ({response.status_code} {response.reason_phrase})
⏱️ {response_time}ms
### Request Details
**Method:** {method}
**URL:** `{url}`
**Timeout:** {timeout}s
**Redirects:** {'✅ Followed' if follow_redirects else '❌ Not followed'}
### Response Headers
"""
# Add headers
for key, value in response.headers.items():
if key.lower() not in ['set-cookie', 'cookie']: # Skip sensitive headers
response_text += f"• **{key}:** {value}\n"
response_text += f"\n### Response Body"
# Truncate very large responses
if len(formatted_body) > 3000:
preview = formatted_body[:3000]
response_text += f" (first 3000 chars):\n```{language}\n{preview}\n... [truncated]\n```"
else:
response_text += f":\n```{language}\n{formatted_body}\n```"
# Add size info
size_kb = len(response_body) / 1024
response_text += f"\n**Size:** {size_kb:.1f} KB"
return {
"content": [{
"type": "text",
"text": response_text
}]
}
except httpx.TimeoutException:
return {
"content": [{
"type": "text",
"text": f"⏱️ Request timed out after {timeout} seconds"
}]
}
except httpx.ConnectError:
return {
"content": [{
"type": "text",
"text": f"🔌 Connection failed. Check:\n1. URL is correct\n2. Server is running\n3. Network connection"
}]
}
except httpx.HTTPStatusError as e:
return {
"content": [{
"type": "text",
"text": f"❌ HTTP Error: {e.response.status_code}\nResponse: {e.response.text[:500]}"
}]
}
except Exception as e:
return {
"content": [{
"type": "text",
"text": f"❌ Error: {str(e)}"
}]
}
15分钟：最终集成和错误处理
# utils/errors.py - Add this file
class ToolError(Exception):
def __init__(self, message, tool_name=None, user_friendly=True):
self.message = message
self.tool_name = tool_name
self.user_friendly = user_friendly
super().__init__(self.message)
def create_error_response(error_msg, suggestion=""):
"""Create consistent error responses"""
base = f"❌ {error_msg}"
if suggestion:
base += f"\n💡 Tip: {suggestion}"
return {
"content": [{
"type": "text",
"text": base
}]
}
# utils/formatters.py - Add this file
def format_success_response(data, tool_name, metadata=None):
"""Format successful tool responses consistently"""
if metadata is None:
metadata = {}
response = {
"content": [{
"type": "text",
"text": data
}]
}
if metadata:
response["metadata"] = metadata
return response
# Update all tools to use these utilities
最后10分钟：庆祝与测试
# 1. Create a quick test script
echo '#!/usr/bin/env python3
import asyncio
import sys
sys.path.append(".")
from server import main
if __name__ == "__main__":
print("🚀 Starting DevKit Max Server...")
print("Loaded tools: JSON, Base64, UUID, JWT, Time, Hash, HTTP, SQL, Color")
print("Press Ctrl+C to stop")
asyncio.run(main())
' > run.py
# 2. Create README
echo '# DevKit Max 🚀
Complete developer toolbox as an MCP server for Claude Desktop.
## Features
- JSON Formatter/Validator
- Base64 Encoder/Decoder
- UUID Generator
- JWT Decoder
- Timestamp Converter
- Hash Generator
- HTTP Tester
- SQL Formatter
- Color Converter
## Quick Start
```bash
# Install dependencies
uv pip install -r requirements.txt
# Run the server
python run.py
# In Claude Desktop, add MCP server:
# Protocol: stdio
# Command: python /path/to/run.py
使用示例
- 格式化此JSON:｛“test”：1｝
- “生成3个UUID”
- “解码此JWT:eyJ0eXAiOiJKV1Qi…”
- “将时间戳1672531200转换为人类日期”
- “向发出GET请求https://api.github.com"
内置于❤️ 在5小时的vibe编码中。'>README.md
3.庆祝！
回声”🎉 DevKit Max在5小时内完成！" 回声”✨ Claude Desktop中准备使用的9个工具” 回声”🚀 去创造一些令人惊叹的东西！"
---
## 🎯 Final Checklist Before Hour 5 Ends
### **Technical Completion**
- [ ] All 9 tools implemented
- [ ] Server runs without errors
- [ ] Tools accessible through MCP
- [ ] Basic error handling in place
- [ ] Response formatting looks good
### **User Experience**
- [ ] Clear tool descriptions
- [ ] Helpful error messages
- [ ] Pretty output formatting
- [ ] Works in Claude Desktop
### **Documentation**
- [ ] README with setup instructions
- [ ] Example usage for each tool
- [ ] One-line run command
### **Celebration**
- [ ] Take a screenshot of working tool
- [ ] Test your favorite tool
- [ ] Share with a friend
- [ ] Tweet your accomplishment! 🚀
---
## 🎮 The Vibe Coding Experience
### **Why This Will Be Epic**
1. **Hour 1**: "I built something!" - JSON & UUID tools working
2. **Hour 2**: "This is getting cool" - Base64, Hash, JWT done
3. **Hour 3**: "Time wizardry!" - Timestamp converter with relative time
4. **Hour 4**: "Making it pretty" - SQL formatting & color conversion
5. **Hour 5**: "Full power!" - HTTP tester completes the suite
### **Pro Tips for Maximum Vibe**
```python
# Keep the energy high:
# 1. Play your favorite coding playlist 🎵
# 2. Take 5-minute breaks every hour 🚶
# 3. Celebrate each completed tool 🎉
# 4. Keep water/snacks nearby 🍵
# 5. Remember: This is FUN, not work! ✨
当你完成
print("""
╔═══════════════════════════════════════╗
║ 🎉 DEVKIT MAX COMPLETE! 🎉 ║
╠═══════════════════════════════════════╣
║ 9 tools built in 5 hours ║
║ Your developer workflow just leveled ║
║ up! ║
║ ║
║ Go use your new powers! 🚀 ║
╚═══════════════════════════════════════╝
""")
🚀 准备就绪，设定，编码！
你的任务：按照本指南，构建所有9个工具，并在5小时内运行一个完整的MCP服务器。
记住:
- 开始简单（JSON格式化程序）
- 建立势头（速赢）
- 迎接挑战（HTTP测试人员）
- 完成牢固（抛光和庆祝）
