TiGL CPACS工作流MCP服务

tigl-mcp

tigl-mcp is a Model Context Protocol server for CPACS-oriented TiGL workflows. CAD and mesh export drive the real TiGL library (natively, or in a container). Geometry queries that need a TiGL kernel raise a structured GeometryUnavailable error when none is present; nothing returns synthetic values.

Overview

The project currently provides:

• A FastMCP-powered server with stdio and HTTP-compatible transports
• A curated set of CPACS lifecycle, inspection, export, sampling, and parameter tools
• Pydantic-backed tool validation with structured MCP error payloads
• Structured GeometryUnavailable errors when no TiGL kernel is present, never synthetic geometry

Quickstart

Requires Python 3.12+.

python3 -m venv .venv
source .venv/bin/activate
make dev
make test
make ci

Start the server over stdio:

tigl-mcp --transport stdio

Inspect the non-blocking HTTP transport configuration example:

PYTHONPATH=src python3 examples/server/http_launch_config.py

Examples

The examples are deterministic and do not need a TiGL kernel: geometry tools raise a structured error rather than returning made-up values.

• Examples index: examples/README.md
• Tool discovery: examples/client/tool_discovery.py
• Session lifecycle: examples/cpacs/session_lifecycle.py
• Export snapshot: examples/cpacs/export_snapshot.py

Docs

• Docs source: docs/index.rst
• Published docs: https://cmudrc.github.io/tigl-mcp/

Build the docs locally with:

make docs

Current Capability Boundaries

This is the authoritative statement of which paths run real TiGL and which do not. Nothing here estimates geometry.

Real TiGL, always. CAD export (export_configuration_cad, STEP and IGES) and mesh export (export_component_mesh) drive the real TiGL library, either through native tigl3/tixi3 bindings or through the tigl-mcp:dev Docker image. The route actually taken is recorded in CPACS as stepExportSource, so exported geometry is traceable. On the D150 this produces a 3.2 MB STEP file and per-component surface meshes of a few thousand triangles.

Read from the CPACS file, so always available. Component UIDs, names, symmetry flags, wing/fuselage/rotor/engine counts, per-component section and segment counts, and the reference area and length. These are values the file states directly.

Computed by real TiGL, natively or inside the Docker image. Bounding boxes, wing spans, planform and wetted areas, fuselage length and volume come from check_geometry and the exports. These run TiGL scripts through the native tigl3/tixi3 bindings when they are installed in the server's Python (DLR's conda package; the route for a Windows laptop without Docker, added 2026-10-28) and otherwise in the tigl-mcp:dev container; the result says which (geometry_source, stepExportSource). Deriving any of these means evaluating profile geometry through the CPACS positioning and transformation chain, which is what TiGL is for. Without either kernel these tools raise a structured error naming the missing dependency; nothing returns an estimate.

The former get_wing_summary, get_fuselage_summary, sample_component_surface, intersect_with_plane and intersect_components tools were removed on 2026-10-22. They needed the native TiGL bindings, which no install provided at the time, so they could only refuse; every participant of a user-study pilot saw that refusal as an error before the assistant found the values through check_geometry.

Until 2026-08-15 several of these returned values derived from a component's index in an array — a wing's bounding box was literally its position in the list. Those were removed, along with a synthetic single-triangle mesh and a CAD "export" that returned the CPACS text relabelled. If you are reading older notes or output that mention stub geometry, they predate this.

Shared-CPACS Integration

This MCP includes a CPACS adapter (src/tigl_mcp/cpacs_adapter.py) that bridges TiGL to the shared-CPACS aircraft analysis pipeline.

What it does

The adapter reads CPACS geometry (wings, fuselages, profiles) and writes analysis results — component counts, per-component section and segment counts, and STEP export metadata — into //analysisResults/tigl. A boundingBox element is written only when a real geometry kernel supplied one, and is omitted otherwise.

Running as part of the pipeline

# As part of the full five-MCP pipeline (with SU2, pyCycle, NSEG)
python pipeline/shared_cpacs_orchestrator.py D150_v30.xml --mcps tigl su2 pycycle nseg

# TiGL only
python pipeline/shared_cpacs_orchestrator.py D150_v30.xml --mcps tigl

See cmudrc/aircraft-analysis for full pipeline documentation, versioning details, and installation instructions.

Related MCP servers

Contributing

Contribution guidelines live in CONTRIBUTING.md.

Maintainers

Mayank Dixit (@Kugel-Blitz-13), Carnegie Mellon University — mayankd@cmu.edu Christopher McComb, Carnegie Mellon University — Design Research Collective
