dnSpy MCP Server

git clone https://github.com/dnSpyEx/dnSpy --recursive
cd dnSpy

# Build only the MCP Server extension (Debug)
dotnet build Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj -c Debug

# Build only the MCP Server extension (Release)
dotnet build Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj -c Release

# Build the full dnSpy solution (both targets)
dotnet build dnSpy.sln -c Debug

# Build for a specific target framework only
dotnet build Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj -c Release -f net10.0-windows
dotnet build Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj -c Release -f net48

# Restore NuGet packages without building
dotnet restore Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj

# Clean build artifacts
dotnet clean Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj

# Check for errors (expects "Compilación correcta" or "Build succeeded")
dotnet build Extensions/dnSpy.MCP.Server/dnSpy.MCP.Server.csproj -c Release --nologo 2>&1 | tail -5

{
  "mcpServers": {
    "dnspy": {
      "type": "http",
      "url": "http://localhost:3100/mcp"
    }
  }
}

curl -X POST http://localhost:3100/mcp \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "id": 1,
    "method": "initialize",
    "params": {
      "protocolVersion": "2025-03-26",
      "capabilities": {},
      "clientInfo": { "name": "example-client", "version": "1.0" }
    }
  }'

{
  "id": "confuserex-unpacking",
  "name": "ConfuserEx Unpacking",
  "version": "1",
  "tags": ["packer", "confuserex", "unpacking"],
  "targets": ["MyProtectedApp.exe"],
  "description": "Step-by-step procedure to unpack ConfuserEx 1.x protected assemblies",
  "procedure": [
    { "step": 1, "tool": "detect_obfuscator", "prompt": "Detect which obfuscator was applied", "expected": "ConfuserEx v1.x" },
    { "step": 2, "tool": "start_debugging",   "prompt": "Launch under dnSpy with break_kind=EntryPoint", "expected": "Paused at entry point after .cctor" },
    { "step": 3, "tool": "dump_module_from_memory", "prompt": "Dump decrypted module from RAM", "expected": "Raw PE bytes" }
  ],
  "magic_values": { "key_offset": "0x1234", "xor_key": "0xDEADBEEF" },
  "crypto_keys": [],
  "algorithms": ["XOR", "AES-128-ECB"],
  "prompts": {
    "identify": "Use detect_obfuscator on the assembly. If ConfuserEx, proceed with this skill.",
    "apply": "Follow procedure steps 1-3. After dump, reload and deobfuscate.",
    "verify": "Decompile Main() — if readable C# appears, unpacking succeeded.",
    "troubleshoot": "If dump_module_from_memory fails, try dump_module_unpacked with fix_pe_header=true."
  }
}

// List all open dialogs
{ "tool": "list_dialogs" }

// Dismiss the first dialog by clicking OK
{ "tool": "close_dialog" }

// Dismiss a specific dialog by HWND, clicking Cancel
{ "tool": "close_dialog", "arguments": { "hwnd": "1A2B3C", "button": "cancel" } }

# Find all types whose name starts with "Player"
name_pattern: "Player*"

# Find all interfaces (start with I, followed by uppercase)
name_pattern: "^I[A-Z]"

# Find methods ending in "Async"
name_pattern: "Async$"

# Find all Get* or Set* methods
name_pattern: "^(Get|Set)[A-Z]"

{
  "items": [ ... ],
  "total_count": 312,
  "returned_count": 50,
  "nextCursor": "eyJvZmZzZXQiOjUwLCJwYWdlU2l6ZSI6NTB9"
}

1. list_assemblies                           → find "UnityEngine.CoreModule"
2. get_assembly_info  assembly=UnityEngine…  → see namespaces
3. list_types  assembly=…  namespace=UnityEngine  name_pattern="*Manager"
4. get_type_info  assembly=…  type=UnityEngine.NetworkManager
5. decompile_method  …  method=Awake

{ "tool": "search_types", "arguments": { "query": "^I[A-Z].*Repository$" } }

{ "tool": "list_runtime_modules", "arguments": { "name_filter": "Assembly-CSharp*" } }

{ "tool": "dump_module_from_memory", "arguments": {
    "module_name": "Assembly-CSharp.dll",
    "output_path": "C:\\dump\\Assembly-CSharp_dump.dll"
}}

{ "tool": "set_breakpoint", "arguments": {
    "assembly_name": "Assembly-CSharp",
    "type_full_name": "PlayerController",
    "method_name": "TakeDamage"
}}

{ "tool": "get_call_stack" }

{ "tool": "change_member_visibility", "arguments": {
    "assembly_name": "MyAssembly",
    "type_full_name": "MyNamespace.MyClass",
    "member_kind": "method",
    "member_name": "InternalHelper",
    "new_visibility": "public"
}}

{ "tool": "save_assembly", "arguments": {
    "assembly_name": "MyAssembly",
    "output_path": "C:\\patched\\MyAssembly.dll"
}}

{ "tool": "read_process_memory", "arguments": {
    "address": "0x7FFE00001000",
    "size": 256
}}

1. scan_pe_strings  assembly_name=MyApp  → confirm it's packed (few readable strings)
2. unpack_from_memory  exe_path=C:\MyApp.exe  output_path=C:\MyApp_unpacked.exe
3. detect_obfuscator  file_path=C:\MyApp_unpacked.exe  → identify remaining obfuscation
4. deobfuscate_assembly  file_path=C:\MyApp_unpacked.exe  output_path=C:\MyApp_clean.dll

1. list_pinvoke_methods  assembly=MyApp  type=AntiDebugClass
   → finds "CheckRemoteDebuggerPresent" → kernel32.dll
2. patch_method_to_ret  assembly=MyApp  type=AntiDebugClass  method=CheckRemoteDebuggerPresent
3. save_assembly  assembly=MyApp  output_path=C:\MyApp_patched.exe

// Load a .NET DLL from disk
{ "tool": "load_assembly", "arguments": {
    "file_path": "C:\\dump\\MyApp_unpacked.dll"
}}

// Load a raw memory-layout dump (VAs instead of file offsets)
{ "tool": "load_assembly", "arguments": {
    "file_path": "C:\\dump\\MyApp_memdump.bin",
    "memory_layout": true
}}

// Dump from a running process and load directly into dnSpy
{ "tool": "load_assembly", "arguments": {
    "pid": 1234,
    "module_name": "MyPlugin.dll"
}}

{ "tool": "list_dialogs" }
// → [1] Title: "Error de depuración"
//       Hwnd: 1A2B3C  |  Type: Win32 (#32770)
//       Message: "No se puede continuar la operación."
//       Buttons: Aceptar, Cancelar

{ "tool": "close_dialog", "arguments": { "hwnd": "1A2B3C", "button": "aceptar" } }
// → Clicked 'Aceptar' in dialog 'Error de depuración'.

{ "tool": "find_who_uses_type", "arguments": {
    "assembly_name": "MyAssembly",
    "type_full_name": "MyNamespace.ObfuscatedLicenseChecker"
}}

{ "tool": "find_who_writes_field", "arguments": {
    "assembly_name": "MyAssembly",
    "type_full_name": "MyNamespace.ObfuscatedLicenseChecker",
    "field_name": "isValid"
}}

dnSpy.MCP.Server/
├── dnSpy.MCP.Server.csproj   # Multi-target: net48 + net10.0-windows
├── CHANGELOG.md
├── README.md
├── RELEASE_NOTES.md
└── src/
    ├── Application/
    │   ├── AssemblyTools.cs         # Assembly & type listing
    │   ├── TypeTools.cs             # Type internals + IL
    │   ├── EditTools.cs             # Metadata editing, method patching
    │   ├── DebugTools.cs            # Debugger integration
    │   ├── DumpTools.cs             # Memory dump & PE tools
    │   ├── MemoryInspectTools.cs    # Local variable inspection
    │   ├── UsageFindingCommandTools.cs  # IL usage analysis
    │   ├── CodeAnalysisHelpers.cs   # Call-graph & dependency analysis
    │   ├── De4dotTools.cs           # de4dot deobfuscation (all builds)
    │   ├── SkillsTools.cs           # Skills knowledge base (MD + JSON)
    │   ├── ScriptTools.cs           # Roslyn C# scripting
    │   ├── WindowTools.cs           # Win32/WPF dialog management
    │   └── McpTools.cs              # Tool registry & routing
    ├── Communication/
    │   └── McpServer.cs             # streamable HTTP server
    ├── Contracts/
    │   └── McpProtocol.cs           # DTO types
    ├── Helper/
    │   └── McpLogger.cs
    └── Presentation/
        ├── TheExtension.cs          # MEF export / entry point
        ├── ToolbarCommands.cs
        ├── McpSettings.cs
        └── McpSettingsPage.cs

{
  "host": "localhost",
  "port": 3100,
  "requireApiKey": false,
  "apiKey": "",
  "enableRunScript": false,
  "de4dotExePath": "",
  "de4dotSearchPaths": [],
  "de4dotMaxSearchDepth": 6
}

# Windows (PowerShell)
Invoke-RestMethod http://localhost:3100

# Windows (cmd)
curl http://localhost:3100

# Check port is listening
netstat -ano | findstr :3100
