APS-MCP: Security Profile for Model Context Protocol

The first formal security standard for MCP tool integrations

Why This Matters

The Model Context Protocol (MCP) gives AI agents the ability to invoke external tools — databases, file systems, APIs, code execution environments. There is currently no formal security standard governing these integrations.

This means:

• No tool allowlisting. Agents can call any tool on any MCP server with no declared permission boundary.
• No egress control. MCP tools can make arbitrary outbound network requests, enabling data exfiltration.
• No data classification. Sensitive data (PII, credentials, financials) flows through tools with no tracking or enforcement.
• No server verification. Agents trust MCP servers blindly — no attestation, no hash verification, no supply-chain integrity.
• No audit trail. Tool invocations are not logged in a tamper-evident, standardized format.
• No exfiltration detection. There are no rate limits, volume caps, or pattern detection for data leaving the agent.

APS-MCP closes every one of these gaps with a single, machine-readable security policy that travels with the agent.

Quick Start

Add an mcp_security object to your agent passport's Security Envelope:

{
  "security_envelope": {
    "mcp_security": {
      "profile_version": "1.0.0",
      "mcp_tools_allowed": [
        {
          "server_hash": "e3b0c44298fc1c149afbf4c8996fb92427ae41e4649b934ca495991b7852b855",
          "tool_name": "read_file",
          "version": ">=1.0.0 <2.0.0",
          "data_classification_max": "internal"
        }
      ],
      "egress_policy": {
        "default": "deny",
        "allow": []
      },
      "data_classification_default": "restricted",
      "io_validation": {
        "max_input_bytes": 1048576,
        "max_output_bytes": 10485760
      },
      "exfiltration_guards": {
        "max_tool_calls_per_minute": 60,
        "response_action": "suspend"
      }
    }
  }
}

Validate against the schema:

# Using ajv-cli
ajv validate -s mcp-security-profile.schema.json -d your-policy.json

Integration Examples

Filesystem MCP Server

Lock an agent to read-only file access with no network egress:

{
  "profile_version": "1.0.0",
  "mcp_tools_allowed": [
    {
      "server_hash": "a1b2c3...64hex",
      "tool_name": "read_file",
      "version": ">=1.0.0 <2.0.0",
      "data_classification_max": "internal",
      "description": "Read files from project directory only"
    },
    {
      "server_hash": "a1b2c3...64hex",
      "tool_name": "list_directory",
      "version": ">=1.0.0 <2.0.0",
      "data_classification_max": "public",
      "description": "List directory contents"
    }
  ],
  "egress_policy": { "default": "deny", "allow": [] },
  "data_classification_default": "restricted",
  "io_validation": { "max_input_bytes": 1048576, "max_output_bytes": 10485760 },
  "exfiltration_guards": { "max_tool_calls_per_minute": 30, "response_action": "suspend" }
}

PostgreSQL MCP Server

Allow read-only database queries with egress limited to the database host:

{
  "profile_version": "1.0.0",
  "mcp_tools_allowed": [
    {
      "server_hash": "d4e5f6...64hex",
      "tool_name": "query",
      "version": "2.1.0",
      "data_classification_max": "confidential",
      "description": "Read-only SQL against analytics DB",
      "input_schema": {
        "type": "object",
        "required": ["sql"],
        "properties": { "sql": { "type": "string", "maxLength": 4096 } },
        "additionalProperties": false
      }
    }
  ],
  "egress_policy": {
    "default": "deny",
    "allow": [
      {
        "host": "analytics-db.internal.example.com",
        "ports": [5432],
        "protocol": "tcp",
        "justification": "PostgreSQL analytics database"
      }
    ]
  },
  "data_classification_default": "restricted",
  "io_validation": { "max_input_bytes": 524288, "max_output_bytes": 5242880, "max_nesting_depth": 16 },
  "exfiltration_guards": {
    "max_egress_bytes_per_hour": 5242880,
    "max_unique_domains_per_hour": 1,
    "response_action": "terminate"
  }
}

GitHub MCP Server

Allow issue management with egress limited to GitHub API:

{
  "profile_version": "1.0.0",
  "mcp_tools_allowed": [
    {
      "server_hash": "b2c3d4...64hex",
      "tool_name": "get_issues",
      "version": ">=1.0.0 <2.0.0",
      "data_classification_max": "internal"
    },
    {
      "server_hash": "b2c3d4...64hex",
      "tool_name": "create_comment",
      "version": ">=1.0.0 <2.0.0",
      "data_classification_max": "internal"
    }
  ],
  "egress_policy": {
    "default": "deny",
    "allow": [
      {
        "host": "api.github.com",
        "ports": [443],
        "protocol": "tcp",
        "justification": "GitHub REST API"
      }
    ]
  },
  "data_classification_default": "restricted",
  "io_validation": { "max_input_bytes": 1048576, "max_output_bytes": 10485760 },
  "exfiltration_guards": {
    "max_unique_domains_per_hour": 1,
    "max_tool_calls_per_minute": 30,
    "response_action": "suspend"
  }
}

Specification

1. Tool Allowlist

An agent passport MUST declare an explicit allowlist of MCP tools the agent is permitted to invoke via the mcp_tools_allowed array.

Each entry MUST contain:

Enforcement rules:

• The runtime MUST reject any tool invocation not in mcp_tools_allowed
• The runtime MUST verify server_hash matches the responding server before dispatch
• An empty array means the agent MUST NOT invoke any MCP tools

2. Egress Policy

All outbound network access from MCP tool executions is deny-by-default.

{
  "egress_policy": {
    "default": "deny",
    "allow": [
      {
        "host": "api.example.com",
        "ports": [443],
        "protocol": "tcp",
        "justification": "Required API endpoint"
      }
    ]
  }
}

Each allowed target specifies:

Enforcement: Network-layer enforcement (iptables, eBPF, sandbox firewall). DNS resolution must be restricted to prevent rebinding attacks.

3. Data Classification

Four levels, ordered by increasing sensitivity:

Key rules:

• If no classification tag is present, the runtime MUST treat data as restricted (fail-secure)
• Tools MUST NOT emit output at a level higher than their data_classification_max
• restricted data MUST NOT traverse egress targets unless restricted_allowed: true

4. MCP Server Attestation

Before invoking any tool, the runtime MUST verify the server's attestation bundle:

The server_hash is: sha256(canonicalize({binary_hash, config_hash, version}))

Attestation bundles SHOULD be refreshed every 24 hours. A trust_on_first_use mode MAY exist for development but MUST NOT be enabled in production.

5. Input/Output Validation

Injection detection is mandatory. Implementations MUST detect:

• Prompt injection — attempts to override agent instructions via tool inputs
• Command injection — shell metacharacters, path traversal (../), null bytes
• Serialization attacks — malformed JSON, excessive nesting, duplicate keys

6. Exfiltration Guards

Monitored patterns:

• Encoding escalation (plaintext → base64/compressed before egress)
• Chunked exfiltration (many small payloads to same destination)
• Classification escalation (outputs higher than inputs)
• Temporal anomaly (burst activity outside normal patterns)

Response actions: log, suspend, terminate, or notify

7. Audit Trail

Every MCP tool invocation produces a tamper-evident log entry:

Entries are Ed25519-signed and hash-chained (prev_entry_hash). Retention: 90 days minimum (1 year for confidential/restricted data).

8. Profile Hash & Versioning

mcp_security_hash = sha256(canonicalize(mcp_security))

This hash is included in the Security Envelope's snapshot.hash. Changes to the MCP Security Profile increment the envelope version. Current profile version: 1.0.0.

Example Policies

Schema

The full JSON Schema (draft 2020-12) is available at mcp-security-profile.schema.json.

Validate your policy:

# npm install -g ajv-cli
ajv validate -s mcp-security-profile.schema.json -d examples/strict-mcp-policy.json

# Or with Python jsonschema
pip install jsonschema
python -c "
import json, jsonschema
schema = json.load(open('mcp-security-profile.schema.json'))
policy = json.load(open('examples/strict-mcp-policy.json'))
jsonschema.validate(policy, schema)
print('✓ Valid')
"

Part of the Agent Passport Standard

APS-MCP is §17 of the Agent Passport Standard — a comprehensive identity, security, and accountability framework for AI agents.

The MCP Security Profile integrates with:

• Security Envelope (§3) — mcp_security is a child object of the envelope
• Work Receipts (§2) — MCP tool calls can be referenced from job deliverables
• Federation (§16) — Peers exchange MCP Security Profiles during capability discovery
• Attestation Exchange (§13) — Server attestation bundles as third-party attestations
• Anchoring (§4) — Audit trail hashes anchored to immutable ledgers

License

Apache 2.0 — See LICENSE for details.
