iOS开发自动化平台

Swift iOS Development Automation Platform

Status: inactive — archived

This was built to close the 90-second Xcode build-feedback loop before coding agents could do it on their own. They caught up. The workflow this server existed to solve is now handled directly by agent tooling, so there was no reason to keep developing it.

Left public as a technical reference — Swift 6 strict concurrency, an MCP server implementation in Swift rather than Node, and multi-simulator orchestration. Not maintained; issues and pull requests aren't monitored. Fork it freely.

High-performance Swift-based MCP server for Xcode automation with hybrid architecture

Transform your iOS development workflow through real-time build intelligence, advanced automation, and native macOS integration—eliminating 90+ second build feedback delays while providing capabilities no Node.js solution can match.

🚀 Core Value Proposition

• ⚡ 10x Faster Build Cycles: Real-time error detection in <5 seconds vs 90+ second baseline
• 🔋 Native Performance: 2-3x improvement over Node.js implementations
• 🔒 Maximum Security: App Sandbox compliance with user-controlled access
• 🏗️ Hybrid Architecture: Best patterns from proven solutions + Swift enhancements
• 💪 Mac Studio Optimized: Dynamic 85-90% resource utilization

🎯 Target Hardware

Recommended: Mac Studio M2 Max (32GB RAM, 12-core CPU)
Minimum: Apple Silicon Mac with 16GB RAM, 8+ cores
OS: macOS 14+ (Sonoma or later)

✨ Key Features

🧠 Real-Time Build Intelligence

• Sub-5 second error detection with DispatchSource file monitoring
• Intelligent error categorization and fix suggestions
• Performance regression detection with automatic optimization

📱 Advanced Multi-Simulator Management

• 6+ concurrent simulators with intelligent resource allocation
• Native UI automation with Accessibility API integration
• Visual documentation generation with screenshot/video capture

🔄 Hybrid Pattern Extraction

• XcodeBuildMCP patterns: xcodemake integration, UI automation
• r-huijts patterns: Project management, security framework
• Swift enhancements: Native performance, direct API access

🛡️ Security-First Design

• App Sandbox compliance for sensitive code protection
• User-controlled permissions with security bookmarks
• Local-only processing - no data leaves your Mac

🏗️ Architecture

┌─────────────────────────────────────────────────────────────┐
│                  Swift MCP Server Core                     │
│                    (SwiftMCP Framework)                    │
└─────────────────────┬───────────────────────────────────────┘
                      │
┌─────────────────────┴───────────────────────────────────────┐
│              Hybrid Pattern Extraction Layer               │
│  ┌─────────────────┬─────────────────┬─────────────────┐   │
│  │ XcodeBuildMCP   │   r-huijts      │  Swift Enhanced │   │
│  │ Patterns        │   Patterns      │  Capabilities   │   │
│  │ • xcodemake     │ • Project Mgmt  │ • Native APIs   │   │
│  │ • UI Automation │ • File Ops      │ • Performance   │   │
│  │ • Build Logic   │ • Security      │ • Integration   │   │
│  └─────────────────┴─────────────────┴─────────────────┘   │
└─────────────────────┬───────────────────────────────────────┘
                      │
┌─────────────────────┴───────────────────────────────────────┐
│                Native Swift Integration                    │
│  ┌─────────────────┬─────────────────┬─────────────────┐   │
│  │ Subprocess Mgmt │ DispatchSource  │ Framework APIs  │   │
│  │ xcodebuild      │ File Monitoring │ XcodeKit        │   │
│  │ simctl          │ Real-time Logs  │ Accessibility   │   │
│  │ Git operations  │ Change Events   │ Core Foundation │   │
│  └─────────────────┴─────────────────┴─────────────────┘   │
└─────────────────────────────────────────────────────────────┘

🚀 Quick Start

Prerequisites

# Verify your setup
xcodebuild -version  # Should be 16.5+
swift --version      # Should be 6.0+
system_profiler SPHardwareDataType | grep -E "Total Number of Cores|Memory"

Installation

# 1. Clone the repository
git clone https://github.com/cbvibe69/swift-ios-automation-platform.git
cd swift-ios-automation-platform

# 2. Run setup script
chmod +x Scripts/setup.sh
./Scripts/setup.sh

# 3. Build the project
./Scripts/build.sh

# 4. Run the automation server
./Scripts/run.sh --log-level debug --max-resource-utilization 85

First Automation

# Start the MCP server
swift run XcodeAutomationServer

# In another terminal, test with an MCP client
echo '{"jsonrpc": "2.0", "method": "tools/list", "id": 1}' | swift run XcodeAutomationServer

📊 Performance Targets

📖 Documentation

🛠️ Development

Build Commands

# Development build
swift build

# Release build (optimized for M2 Max)
./Scripts/build.sh

# Run tests
./Scripts/test.sh

# Start development server
./Scripts/run.sh

Development Phases

• Phase 1 (Weeks 1-2): Foundation + Core Extraction ← Current
• Phase 2 (Weeks 3-4): Enhanced Swift Implementation
• Phase 3 (Weeks 5-6): Advanced Features + Optimization
• Phase 4 (Weeks 7-8): Security Hardening + Production

📄 License

This project is licensed under the MIT License - see the LICENSE file for details. For our security policy and vulnerability reporting guidelines, see SECURITY.md.

🙏 Acknowledgments

• Anthropic for the Model Context Protocol specification
• XcodeBuildMCP for xcodemake and UI automation patterns
• r-huijts for comprehensive project management patterns
• Swift Community for excellent tooling and frameworks

Transform your iOS development with native Swift performance and intelligence! 🚀
