Common MCP Gateway

One MCP (Model Context Protocol) endpoint for all your MCP servers. Add your servers once, use them from every AI client (Claude Desktop, Devin, Cursor, Windsurf, VS Code, ...) and every project, with per-project tool filtering, timeouts, retries and circuit breakers.

Features

• Aggregates many MCP servers under a single endpoint, tools are exposed as serverId__toolName
• Shared background daemon: every downstream server runs once, however many clients are open (see below)
• Lazy start and tool cache: servers start on the first tool call, the tool list comes from a disk cache
• Per-project policy (gate): enable or disable servers and single tools per project
• Timeout watchdog, exponential backoff retry with jitter, circuit breaker (Closed / Open / Half-Open), optional fallback servers
• Live config reload when config.json or a project policy changes
• Gateway Manager: web UI to edit servers, tools and policies
• Structured JSON logging (Winston, daily rotation)
• Windows friendly: no empty console windows, whole process trees are cleaned up on exit

Installation

Requires Node.js 18 or newer.

cd Common_MCP
npm install
npm run build

Optionally install the common-mcp command globally:

npm install -g .

Configuration file

The gateway reads ~/.common-mcp/config.json (Windows: C:\Users\<you>\.common-mcp\config.json), or the file named in COMMON_MCP_CONFIG. Start from config/default.json:

mkdir ~/.common-mcp
cp config/default.json ~/.common-mcp/config.json

{
  "common-mcp": {
    "version": "1.0.0",
    "globalDefaults": {
      "timeout": 30000,
      "retryAttempts": 3,
      "retryDelay": 1000,
      "circuitBreaker": { "enabled": true, "failureThreshold": 5, "resetTimeout": 60000 }
    },
    "downstreamServers": {
      "memory": { "command": "npx", "args": ["-y", "@modelcontextprotocol/server-memory"] }
    },
    "logging": { "level": "INFO", "format": "json", "file": "logs/common-mcp.log", "maxSize": "10MB", "maxFiles": 5 }
  }
}

Never put real API keys into files that are committed to git. Keep local snapshots (for example Valid_Config.json) out of version control, this repository ignores that file name.

Connect your AI client

In every client, register only the gateway and disable the individual servers there, the gateway manages them.

Use the built entry point (path to your clone), or the common-mcp command if installed globally:

{
  "mcpServers": {
    "common-mcp-gateway": {
      "command": "node",
      "args": ["/path/to/Common_MCP/dist/index.js"]
    }
  }
}

Where the client keeps this file:

• Windsurf: ~/.codeium/windsurf/mcp_config.json
• Cursor: %APPDATA%\Cursor\User\mcp.json (Windows), ~/.config/Cursor/User/mcp.json (Linux), ~/Library/Application Support/Cursor/User/mcp.json (macOS)
• Claude Desktop: claude_desktop_config.json, normally in %APPDATA%\Claude\ (Windows). The Microsoft Store build reads its own copy under %LOCALAPPDATA%\Packages\Claude_*\LocalCache\Roaming\Claude\, edit that one if you installed it from the Store. Quit Claude Desktop completely before editing, it rewrites the file on exit.
• Devin: %APPDATA%\devin\mcp_config.json on Windows. Paths on other systems are not verified here, check the Devin documentation.

Tool names

Tools are named serverId__toolName (double underscore), for example time__get_current_time or filesystem__read_file. Clients such as Windsurf require names matching ^[a-zA-Z0-9_-]{1,64}$, so / cannot be used as a separator.

Shared daemon mode (default)

Every client still starts the gateway with node dist/index.js, but that process is only a thin stdio bridge. The first bridge starts a shared background daemon on 127.0.0.1:47831, protected by a token in ~/.common-mcp/daemon.token, and all bridges connect to it. Each client gets its own session (own project context and policy), while every downstream server runs once, no matter how many clients are open. This also makes servers that accept only one connection (some Unity MCP servers, for example) usable from several clients at once.

• Downstream servers start lazily on the first tool call. The tool list comes from a cache in ~/.common-mcp/tools-cache: 24 hours for pinned or local commands, 4 hours for unpinned launchers (npx pkg, uvx pkg, mcp-remote to a URL, whose tools can change without the command changing), and it is invalidated when the server command changes. Every time a server is actually started it reports its current tools, which refreshes the cache. COMMON_MCP_TOOLS_TTL_MS changes the default lifetime. A server that failed to start is not retried for 10 minutes.
• Idle downstream servers stop after 10 minutes (COMMON_MCP_IDLE_MS). The daemon exits after 15 minutes without sessions (COMMON_MCP_DAEMON_IDLE_MS).
• Updates: the daemon reports its version. A newer bridge asks an older daemon to exit and starts a fresh one, but only while no client is connected, otherwise it keeps using the running daemon (the protocol is unchanged) and prints a notice on stderr. The update is then applied when the clients are restarted. COMMON_MCP_FORCE_DAEMON_RESTART=1 replaces a busy daemon immediately and drops its sessions.
• Downgrades: an older bridge never replaces a newer daemon.
• Daemon restarts are invisible to clients: when the daemon was restarted, updated or crashed, the bridge starts a daemon if none runs, repeats the client's initialize handshake on a fresh session, replays the request that found the session gone, answers requests that were in flight with a retryable error and sends tools/list_changed. The client keeps its connection and no manual reconnect is needed. Bridges from before this behavior (older installs) exit instead, so restart the clients once after updating.
• Dead clients: a session whose bridge was killed without a goodbye is closed after 3 minutes without any open connection (COMMON_MCP_SESSION_TTL_MS), so it cannot keep the daemon and its servers alive.
• COMMON_MCP_PORT changes the port. COMMON_MCP_MODE=standalone runs the previous in-process gateway without a daemon, which is also the automatic fallback if the daemon cannot start.
• http://127.0.0.1:47831/health answers { "ok": true } to anyone on the machine. With the token from ~/.common-mcp/daemon.token as Authorization: Bearer <token> it also shows the version, the number of sessions and the downstream connections.

Project policy (gate)

The optional gate section of config.json decides which servers and tools a project may see:

{
  "common-mcp": {
    "gate": {
      "knownProjects": { "my-project": "/path/to/my-project" },
      "unknownProjectDefaults": { "defaultAllow": true, "alwaysVisibleTools": [] }
    }
  }
}

• The project is detected from the client's working directory, or from COMMON_MCP_PROJECT_PATH. Without a match, unknownProjectDefaults apply and every client lists all enabled servers and tools.
• Optional strict mode for Claude Desktop (no usable working directory): set "requireContextDeclaration": true in the gate section. Claude Desktop then sees only gate__set_project_context (plus alwaysVisibleTools) until it calls that meta tool with the project root path. The default is false, no client has to declare a project.
• A project's policy is read from <project>/.ai/mcp_gate_policy.json (defaultAllow, per server enabled and per tool switches). A missing file allows everything, but a file that exists and is damaged, unreadable or carries another project's projectId is never treated as "no policy": a new session gets no tools until the file is fixed, and a live session keeps its previous policy.
• A downstream server marked "projectOnly": true is off everywhere unless a policy enables it explicitly.
• The complete tool list of all servers, including policy-disabled ones, is written to ~/.common-mcp/tool-catalog.json for UIs.

Downstream server options

{
  "downstreamServers": {
    "server-id": {
      "command": "npx",
      "args": ["-y", "package-name"],
      "timeout": 45000,
      "retryAttempts": 3,
      "circuitBreakerThreshold": 5,
      "fallbackServers": ["other-server-id"],
      "projectOnly": false,
      "disabled": false,
      "env": { "API_KEY": "your-key-here" }
    }
  }
}

Timeout, retry and circuit breaker values override globalDefaults per server.

Downstream server on another machine (ssh stdio)

A downstream server can run on a remote machine when command is ssh and the remote command is the server itself. The ssh process is the stdio transport, so nothing else changes for the clients:

{
  "downstreamServers": {
    "nektaria-shader-lab": {
      "command": "ssh",
      "args": ["-T", "-o", "BatchMode=yes", "-o", "ServerAliveInterval=15", "my-server", "node", "/path/on/server/mcp/server.js"],
      "timeout": 120000,
      "projectOnly": true
    }
  }
}

• -T (no terminal) and BatchMode=yes (no password prompt) keep the stream clean JSON-RPC, ServerAliveInterval detects a dead connection. ssh diagnostics go to stderr, which is separate from the JSON-RPC stdout.
• When the ssh connection drops, the connection is marked disconnected and the next call spawns a new ssh process, so a restarted remote server reconnects without restarting the gateway.
• projectOnly: true hides the server everywhere except in projects whose .ai/mcp_gate_policy.json enables it, for example { "servers": { "nektaria-shader-lab": { "enabled": true, "tools": {} } } } (tools without an explicit switch follow defaultAllow).
• Large results (such as base64 PNGs of capture_render) arrive as one JSON-RPC line, raise timeout if the remote render is slow.

Gateway Manager (web UI)

A web admin UI for config.json: add, edit, enable, disable and delete servers, browse the tool catalog, view the project policy (gate) and shared settings, with live updates over WebSocket. It edits ~/.common-mcp/config.json, not the client's own MCP config, and keeps sections it does not know (such as gate).

# Windows
start-gateway-manager.cmd

# Linux, macOS, Git Bash
./start-gateway-manager.sh

The scripts install missing dependencies, start backend (port 1525) and frontend (port 5173) and open the browser. Manual start: npm run dev in gateway-manager/backend and gateway-manager/frontend. For an auto-starting setup use PM2 with ecosystem.config.js. Details: docs/EN/GATEWAY_MANAGER.md.

Development

npm run build     # compile TypeScript to dist/
npm run dev       # watch mode
npm test          # unit tests
npm run test:e2e  # real bridge, daemon and downstream process in an isolated HOME and port

Architecture

• Bridge (src/daemon/bridge.ts): stdio to daemon proxy started by every client
• Daemon (src/daemon/daemon.ts): shared gateway, one session per client, one shared connection pool
• Gateway (src/gateway/server.ts): one client session, project policy and context
• Tool list (src/gateway/tool-list.ts) and tool executor (src/gateway/tool-executor.ts): cache backed tool list, policy check, retry, timeout and fallback for every call
• Connection pool (src/gateway/connection-pool.ts): downstream lifecycle, idle stop, process tree cleanup
• Middleware (src/middleware/): timeout watchdog, retry engine, circuit breaker
• Utils (src/utils/): config loader, policy watcher, tool catalog, tools cache, logger

More: docs/EN/ARCHITECTURE.md, Hungarian versions in docs/HU/.

Troubleshooting

• A server does not start: run its command and args by hand (for example npx -y package-name). A failing server is skipped for 10 minutes, delete its file from ~/.common-mcp/tools-cache (<id>.fail.json) to retry at once.
• Timeout errors: raise timeout globally or per server.
• Circuit breaker open: wait for resetTimeout (60 s by default) or restart the client.
• Changed server command has no effect: the running daemon keeps the old process until it is idle. Stop the daemon (end its node process) or wait for the idle timeout.
• A new tool of a server does not show up: delete ~/.common-mcp/tools-cache/<id>.json, or wait for the cache lifetime. Starting the server (any tool call) refreshes it too.
• Logs: ~/.common-mcp/logs/common-mcp-*.log

Contributing

Contributions are welcome. Fork the repository, create a feature branch, test thoroughly and open a pull request.

License

The project is dual-licensed:

Using the gateway privately, on your own machines and projects, does not oblige you to publish anything. If you distribute it or a modified version, or offer it to others as a network service, the AGPL v3 requires publishing the corresponding source code. For closed-source or commercial use without those obligations, a commercial license is required. Contact: support@bmsoft1024.com. See LICENSE for the full text.

Links

• Model Context Protocol
• MCP TypeScript SDK
• Issues: github.com/BMSoft1024/Common_MCP_Gateway/issues

Author

BMSoft1024 (github.com/BMSoft1024)
