A2A RAG代理系统

cd RAG
./deployment/setup.sh
# Edit config/.env with Watsonx.ai credentials
./scripts/start_services.sh

# Test
curl -X POST http://localhost:8000/tools/rag_query \
  -H "Content-Type: application/json" \
  -d '{"query": "What is the A2A protocol?"}'

.
├── RAG/                    # A2A RAG Agent implementation
│   ├── agent/              # LangGraph-based A2A agent
│   ├── mcp_server/         # FastAPI MCP server
│   ├── services/           # Watsonx.ai, Milvus, document processing
│   ├── config/             # Configuration management
│   ├── deployment/         # Podman/Docker deployment
│   ├── scripts/            # Automation scripts
│   └── tests/              # Test suite (34 tests, 100% passing)
│
├── orchestrate/            # IBM watsonx Orchestrate integration
│   ├── rag-agent-config.yml  # Agent configuration
│   ├── scripts/            # Orchestrate startup scripts
│   └── .env                # Orchestrate credentials
│
└── docs/                   # MkDocs documentation
    └── docs/
        ├── rag/            # RAG agent documentation
        ├── architecture/   # System architecture
        ├── protocols/      # A2A and MCP specifications
        └── deployment/     # Deployment guides

graph TB
    subgraph "IBM watsonx Orchestrate"
        UI[Chat Interface]
        WF[Workflow Engine]
        AR[Agent Registry]
    end

    subgraph "A2A Agent Server"
        AC[Agent Card<br/>/.well-known/agent-card.json]
        RH[Request Handler]
        AE[Agent Executor]
        EQ[Event Queue]
    end

    subgraph "RAG Agent Core"
        LG[LangGraph Workflow]
        MCP[MCP Tool Client]
    end

    subgraph "Backend Services"
        MCPS[MCP Server<br/>FastAPI]
        MILVUS[Milvus<br/>Vector DB]
        WX[Watsonx.ai<br/>LLM + Embeddings]
    end

    UI --> WF
    WF -->|A2A 0.3.0<br/>JSON-RPC 2.0| AC
    AC --> RH
    RH --> AE
    AE --> LG
    AE --> EQ
    EQ -->|Task Updates| WF

    LG --> MCP
    MCP -->|HTTP/REST| MCPS
    MCPS --> MILVUS
    MCPS --> WX

    AR -.->|Discovery| AC

    style UI fill:#0f62fe
    style WF fill:#0f62fe
    style AC fill:#ff832b
    style RH fill:#ff832b
    style AE fill:#ff832b

# Watsonx.ai
WATSONX_API_KEY=your_api_key
WATSONX_PROJECT_ID=your_project_id
WATSONX_URL=https://us-south.ml.cloud.ibm.com

# Models
EMBEDDING_MODEL=ibm/granite-embedding-278m-multilingual
EMBEDDING_DIMENSION=768
LLM_MODEL=openai/gpt-oss-120b
LLM_MAX_TOKENS=16384

# RAG
RAG_CHUNK_SIZE=80          # words
RAG_CHUNK_OVERLAP=10       # words
RAG_TOP_K=5

# Milvus
MILVUS_HOST=localhost
MILVUS_PORT=19530
MILVUS_COLLECTION=rag_knowledge_base

cd RAG

# Run all tests
./scripts/run_tests.sh

# Run specific test suites
pytest tests/test_document_processor.py -v
pytest tests/test_e2e_shakespeare.py -v

# Run by marker
pytest -m unit -v
pytest -m integration -v

cd RAG
python -m venv venv
source venv/bin/activate
pip install -r requirements.txt
pytest tests/ -v
