自愈AIOps多代理系统

🚀 Self-Healing AIOps Multi-Agent System

Spring Boot • Multi-Agent Architecture • MCP Tool-Calling • Autonomous Healing

This project is a complete multi-agent AIOps system that continuously monitors a microservice, analyzes logs & metrics using AI-powered agents, detects anomalies, and triggers automated healing actions — orchestrated by a Supervisor Agent.

It serves as a production-style Proof of Concept (PoC) showing how modern enterprises implement AI-driven self-healing infrastructure.

🧠 System Architecture (High Level)

🟢 1. Metrics Analysis Agent

Analyzes live system metrics:

CPU usage

Memory usage

Latency

Error counts

AI-generated metric health summary

🟡 2. Logs Analysis Agent

Performs intelligent log classification:

Detects:

DB failures

Deadlocks

OOM errors

GC overhead

Slow SQL queries

Cache/Redis issues

Circuit breaker transitions

JWT failures

Network latency problems

Repeated authentication failures

Extracts:

Errors

Warnings

Root Cause

🔴 3. Anomaly Detection Agent

Correlates metrics + logs to detect:

Memory leaks

DB connection pool exhaustion

Network instability

CPU/Memory spikes

Latency anomalies

Security problems

🔧 4. Healing Agent

Performs autonomous healing:

Restarting microservice

Resetting DB connections

Clearing cache

Scaling actions

🧠 5. Supervisor Agent

Calls all agents via MCP tool-calling

Collects & merges all outputs

Performs anomaly assessment

Triggers self-healing

Produces final AIOps incident report

📡 6. Monitored Service

Simulates a real microservice by providing:

Random metrics

Realistic logs

Health status

🧩 Project Structure
self-healing-aiops-system/
│
├── supervisor-service/
├── metrics-agent/
├── logs-agent/
├── anomaly-agent/
├── healing-agent/
└── monitored-service/

Each folder contains its own Spring Boot microservice.

⚙️ How the Multi-Agent Workflow Runs

Supervisor → Metrics Agent

Supervisor → Logs Agent

Supervisor correlates data and sends it to Anomaly Agent

If anomaly detected → Healing Agent is triggered

Supervisor returns Final Combined JSON Report

📝 Example Final Output
{
  "metrics": {
    "cpu": 41,
    "memory": 76,
    "latency": 134
  },
  "logs": {
    "errors": [
      "TimeoutException: DB connection failed",
      "OutOfMemoryError: Java heap space"
    ],
    "warnings": [
      "High latency: 540ms",
      "Memory usage high: 82%"
    ],
    "rootCause": "Memory leak / heap exhaustion"
  },
  "anomaly": {
    "anomaly": true,
    "reason": "Critical errors found in logs."
  },
  "healingAction": {
    "action": "restart",
    "status": "SUCCESS",
    "message": "Service restarted successfully."
  },
  "finalStatus": "System healed successfully"
}

🛠️ Technologies Used
Layer	Tech
Language	Java 21
Framework	Spring Boot 3.x
AI	Spring AI (ChatClient + MCP Tool-Calling)
Protocol	MCP – Model Context Protocol
Build System	Maven
Communication	REST APIs

🚀 How to Run All Agents 1️⃣ Start Monitored Service cd monitored-service mvn spring-boot:run

2️⃣ Start Metrics Agent cd metrics-agent mvn spring-boot:run

3️⃣ Start Logs Agent cd logs-agent mvn spring-boot:run

4️⃣ Start Anomaly Agent cd anomaly-agent mvn spring-boot:run

5️⃣ Start Healing Agent cd healing-agent mvn spring-boot:run

6️⃣ Start Supervisor Service cd supervisor-service mvn spring-boot:run

🔍 Testing the System

Visit:

👉 http://localhost:8086/supervise

🐳 Run the Entire System with Docker

This project supports one-click multi-agent startup using Docker Compose — no need to run services manually.

Prerequisites

• Docker Desktop installed
• Docker Compose enabled
• API keys configured in environment variables (.env file or system env)

🚀 Start All Agents at Once

docker-compose up --build
Stop the system
bash
Copy code
docker-compose down
Once services start, open in browser:

📌 http://localhost:8086/supervise

This triggers the full AIOps workflow:

Metrics → Logs → Anomaly Detection → Healing → Final Report ✔

Container Overview
Service	Container Port	Purpose
monitored-service	8081 → 8080	Simulated target application
metrics-agent	5173 → 8080	Fetch metrics from monitored service
logs-agent	5174 → 8080	Analyze logs & classify issues
anomaly-agent	5175 → 8080	Detect abnormal behavior
healing-agent	5176 → 8080	Perform recovery actions
supervisor-service	8086 → 8080	Main orchestrator calling all agents

All containers communicate internally over a shared Docker network aiops-net.

🌍 Environment Variables
Create a .env file before running (without committing it to GitHub):

env

API_KEY=your_groq_or_openai_api_key_here


🔥 Advantages of Docker Mode
✔ Zero manual startup — one command boot
✔ Each service runs in its own isolated container
✔ Reproducible environment for demos & deployment
✔ Ready for Kubernetes migration later


---

If you want, I can also generate:

📌 **Docker badges** for README
📌 **Docker deploy script**
📌 **Kubernetes YAML next step**

Just say **"next: kube deployment"** or **"add docker badge

✔ Memory leak ✔ DB connection timeout ✔ Deadlocks ✔ Slow SQL queries ✔ High latency ✔ Authentication failure ✔ Circuit breaker OPEN state ✔ Redis timeouts ✔ Network latency issues

💡 All agents collaborate to detect problems, diagnose root cause, and autonomously heal the system.
