MySQL数据库MCP服务器

MySQL MCP Server

A production-ready Model Context Protocol (MCP) server for MySQL database integration with AI agents

Last Updated: 2026-10-26 16:39:47

Installation · Quick Start · Configuration · Remote Access · Permissions · Tools · Documentation

TL;DR - Quick Setup

Run directly with npx:

npx @berthojoris/mcp-mysql-server mysql://user:pass@localhost:3306/mydb "list,read,utility"

Add to your AI agent config (.mcp.json, .cursor/mcp.json, etc.):

{
  "mcpServers": {
    "mysql": {
      "command": "npx",
      "type": "stdio",
      "args": [
        "-y",
        "@berthojoris/mcp-mysql-server",
        "mysql://user:pass@localhost:3306/mydb",
        "list,read,utility"
      ]
    }
  }
}

For dual-layer and environment-variable configuration, see DOCUMENTATIONS.md → Configuration. To connect remote clients such as ChatGPT over HTTP, see Remote Access.

Installation

Option 1: Quick Start with npx (Recommended)

No installation required - run directly:

npx @berthojoris/mcp-mysql-server mysql://user:pass@localhost:3306/db "list,read,utility"

Option 2: Global Installation

npm install -g @berthojoris/mcp-mysql-server
mcp-mysql mysql://user:pass@localhost:3306/db "list,read,utility"

Credentials with special characters: if your username or password contains characters that have a special meaning in URLs (@, :, /, ?, #, %, &, etc.), URL-encode them before putting them in the connection string. For example, the password p@ss:w0rd becomes p%40ss%3Aw0rd, giving mysql://user:p%40ss%3Aw0rd@host:3306/db. The server decodes both the username and password before connecting.

Quick Start

1. Set Up Environment (Optional)

Create .env file for local development:

DB_HOST=localhost
DB_PORT=3306
DB_USER=root
DB_PASSWORD=yourpassword
DB_NAME=yourdatabase
MCP_CONFIG=list,read,utility

2. Build Project (If Cloned Locally)

npm install
npm run build

3. Configure Your AI Agent

See AI Agent Configuration section below.

4. Restart Your AI Agent

Completely restart your AI agent application to load the MCP server.

5. Test It!

Try asking your AI:

"What databases are available?" "Show me all tables in my database" "What's the structure of the users table?" "Show me the first 5 records from users"

AI Agent Configuration

Standard JSON Configuration

Most AI agents use a similar JSON configuration format (the file location varies by tool).

The examples below use the default stdio transport, where the AI agent starts the server itself. Remote clients connect over HTTP instead; see Remote Access.

Universal Configuration Template:

Option 1: Single-Layer (Permissions Only) - Simple Setup

{
  "mcpServers": {
    "mysql": {
      "command": "npx",
      "type": "stdio",
      "args": [
        "-y",
        "@berthojoris/mcp-mysql-server",
        "mysql://user:password@localhost:3306/database",
        "list,read,utility,create,update,ddl"
      ]
    }
  }
}

Option 2: Dual-Layer (Permissions + Categories) - Recommended for Fine Control

{
  "mcpServers": {
    "mysql": {
      "command": "npx",
      "type": "stdio",
      "args": [
        "-y",
        "@berthojoris/mcp-mysql-server",
        "mysql://user:password@localhost:3306/database_name_here",
        "list,read,utility,create,update,ddl,transaction",
        "database_discovery,crud_operations,custom_queries,schema_management,index_management,constraint_management,table_maintenance,query_optimization,analysis,seed_operations"
      ]
    }
  }
}

💡 Tip: The dual-layer approach provides granular control. The 4th argument (permissions) controls broad access levels, while the 5th argument (categories) fine-tunes which specific tools are available.

Environment Variables Configuration

Alternative approach using environment variables instead of connection string:

Option 1: Permissions Only (Simple)

{
  "mcpServers": {
    "mysql": {
      "command": "npx",
      "type": "stdio",
      "args": ["-y", "@berthojoris/mcp-mysql-server"],
      "env": {
        "DB_HOST": "localhost",
        "DB_PORT": "3306",
        "DB_USER": "root",
        "DB_PASSWORD": "your_password",
        "DB_NAME": "your_database",
        "MCP_PERMISSIONS": "list,read,utility,create,update,delete"
      }
    }
  }
}

Option 2: Permissions + Categories (Recommended)

{
  "mcpServers": {
    "mysql": {
      "command": "npx",
      "type": "stdio",
      "args": ["-y", "@berthojoris/mcp-mysql-server"],
      "env": {
        "DB_HOST": "localhost",
        "DB_PORT": "3306",
        "DB_USER": "root",
        "DB_PASSWORD": "your_password",
        "DB_NAME": "your_database",
        "MCP_PERMISSIONS": "list,read,utility,create,update,delete",
        "MCP_CATEGORIES": "database_discovery,custom_queries,analysis"
      }
    }
  }
}

More configuration details are in DOCUMENTATIONS.md → Configuration.

Cursor Compatibility Bridge

If a Cursor MCP wrapper can call tools but cannot send arguments, use the no-argument cursor_execute_request bridge. Create .cursor/mysql-mcp-request.json in the workspace, then call cursor_execute_request:

{
  "tool": "execute_ddl",
  "arguments": {
    "query": "DROP TABLE IF EXISTS spark_processes;"
  }
}

For direct SQL, the bridge can infer the right SQL tool:

{
  "query": "DROP TABLE IF EXISTS spark_processes;",
  "mode": "auto"
}

Set MYSQL_MCP_CURSOR_REQUEST_FILE to override the request file path.

AI Agent Tool Discovery

For Codex, Claude Code CLI, Cursor, Droid CLI, and other MCP agents, call list_all_tools first. It returns the live runtime catalog, enabled/disabled status, active permission/category profile, and recommended workflows for schema exploration, safe SELECT queries, CSV exports, transactions, and data changes.

Use export_table_to_csv for table-based exports and export_query_to_csv for SELECT query exports.

Remote Access (ChatGPT & other remote MCP clients)

stdio stays the default. For remote clients such as ChatGPT connectors / developer mode, you can enable the Streamable HTTP transport with a flag or an environment variable, the same way you set permissions. Remove the flag, or set MCP_TRANSPORT=stdio, to turn it off again.

# Read-only MySQL account + bearer token, bound to localhost
export MCP_HTTP_AUTH=token
export MCP_HTTP_AUTH_TOKENS=$(openssl rand -hex 32)   # give this token to your clients
npx -y @berthojoris/mcp-mysql-server mysql://mcp_reader:pass@localhost:3306/app "list,read,utility" --transport=http --port=3000

• Endpoint: http://127.0.0.1:3000/mcp, plus GET /health. Publish it over HTTPS with a reverse proxy or tunnel, and set MCP_HTTP_PUBLIC_URL.
• Auth: MCP_HTTP_AUTH=token (bearer tokens) or oauth (OAuth 2.1 JWT validation against your authorization server, with RFC 9728 metadata, as needed by ChatGPT). none only works on loopback.
• Isolation: Host/Origin checks (DNS-rebinding protection). Each session is bound to its identity, and each transaction to its session. A session's open transactions are rolled back when it closes or expires.
• Startup checks: invalid or unsafe HTTP settings stop the server with an error. MCP_HTTP_* settings are ignored over stdio.
• Tool annotations: every tool reports readOnlyHint and destructiveHint.

Protection defaults

Protections are on by default in HTTP mode and off by default over stdio, so existing stdio setups behave as before. Every value can be overridden with an environment variable on either transport.

HTTP settings

In HTTP mode the server runs as a standalone service, so put the settings in .env (or your process manager) instead of an MCP client's command config:

DB_HOST=localhost
DB_USER=mcp_reader
DB_PASSWORD=pass
DB_NAME=app
MCP_PERMISSIONS=list,read,utility
MCP_TRANSPORT=http
MCP_HTTP_PORT=3000
MCP_HTTP_AUTH=token
MCP_HTTP_AUTH_TOKENS=<64-hex-token>
MCP_QUERY_TIMEOUT_MS=15000
MCP_AUDIT_LOG=logs/mcp-audit.log

From the directory that holds .env, start it with node dist/mcp-server.js (from a clone) or the npx command above (a connection string argument overrides the DB_* values). Then point clients that support remote MCP servers at the URL. For example, in Claude Code's .mcp.json:

{
  "mcpServers": {
    "mysql-remote": {
      "type": "http",
      "url": "http://127.0.0.1:3000/mcp",
      "headers": { "Authorization": "Bearer <64-hex-token>" }
    }
  }
}

Full details (OAuth setup, sessions, read-only user SQL) are in DOCUMENTATIONS.md → Remote Access.

Permission System

Control database access with a dual-layer filtering system that provides both broad and fine-grained control:

• Layer 1 (Permissions): Broad operation-level control using legacy categories
• Layer 2 (Categories): Optional fine-grained tool-level filtering using documentation categories

Filtering Logic: Tool enabled = (Has Permission) AND (Has Category OR No categories specified)

Permissions

Security changes in v1.46.0 (review before upgrading):

• optimize_table, repair_table, flush_table, and optimize_fulltext now require ddl instead of utility, so the read-only default no longer includes them. flush_table is limited to the connected database and no longer accepts with_read_lock.
• run_select_query drops invalid optimizer hint values and validates the query again after hints are applied.
• System schema names are detected with whitespace around the dot (e.g. mysql . user).

Changes in v1.44.0 (review before upgrading):

• Read-only by default: with no permissions and no categories, the server now enables only list,read,utility (previously every tool). To keep full access, pass list,read,create,update,delete,execute,ddl,utility,transaction,procedure.
• No implicit mysql schema: without a database in the connection string or DB_NAME, database-scoped tools report "No database specified" instead of using the mysql system schema.
• Query cache off by default: opt in with CACHE_ENABLED=true. Any write and every transaction commit now clears the cache.
• SQL validation: #, ;, and -- inside string values (e.g. '#fff') are no longer rejected. WITH (CTE) queries are supported and, like derived tables, need execute in read queries.

Security changes in v1.43.4:

• EXPLAIN ANALYZE runs the statement it wraps (MySQL 8.0.18+), so it now requires that statement's permission: delete for DELETE, update or execute for UPDATE, read for SELECT. Plan-only EXPLAIN still needs just list or read.

Security changes in v1.43.3:

• CSV exports require both utility and read; enable the utilities category when filtering categories.
• SQL within a transaction requires the corresponding operation permission. transaction alone does not permit reads or writes.
• execute_write_query accepts only INSERT/UPDATE/DELETE. DDL requires enabled DDL tools.
• Disabled tools cannot be called directly or through the Cursor bridge. The bridge requires utility and an enabled destination tool.
• execute does not bypass mandatory SQL safety restrictions, including file access and account/privilege changes.

Report suspected security issues privately via Private Vulnerability Reporting; see SECURITY.md for the policy.

Filtering rules and per-permission details are documented in DOCUMENTATIONS.md → Permission System.

Documentation Categories (Recommended)

Use documentation categories to fine-tune which tools are exposed (Layer 2):

database_discovery,crud_operations,bulk_operations,seed_operations,custom_queries,schema_management,utilities,transaction_management,stored_procedures,views_management,triggers_management,index_management,constraint_management,table_maintenance,query_optimization,analysis

Tool descriptions per category are in DOCUMENTATIONS.md → Tool Categories.

Available Tools

The server exposes 88 tools organized into categories (CRUD, seed, schema, discovery, and utilities).

• Complete list of tools: DOCUMENTATIONS.md → Tool Categories
• Every tool carries MCP annotations (readOnlyHint, destructiveHint, idempotentHint); see DOCUMENTATIONS.md → Tool annotations

Detailed Documentation

For comprehensive documentation, see DOCUMENTATIONS.md:

• Remote Access - Streamable HTTP transport, bearer/OAuth authentication, sessions, protection settings, audit log

• DDL Operations - Create, alter, and drop tables

• Data Export Tools - Export data to CSV format

• Relational Data Seeder - Plan, preview, execute, validate, infer rules, and template FK-aware dummy data

• Full-Text Search - Create and search FULLTEXT indexes with multiple search modes

• Transaction Management - ACID transactions

• Stored Procedures - Create and execute with IN/OUT/INOUT parameters

• Views & Triggers - Manage database views and triggers

• Index & Constraint Management - Optimize performance and enforce data integrity

• Table Maintenance - Analyze, optimize, check, and repair tables

• Query Logging - See all SQL queries executed automatically

• Security Features - Built-in security and best practices

• Bulk Operations - High-performance batch processing

• Troubleshooting - Common issues and solutions

MySQL MCP vs Manual Database Access

This MySQL MCP is a powerful intermediary layer between AI assistants and MySQL databases.

For full feature coverage and usage examples, see DOCUMENTATIONS.md.

License

MIT License - see LICENSE file for details.

Made with care for the AI development community

Enabling AI agents to interact with MySQL databases safely and efficiently

Report Bug · Request Feature · Documentation
