使用说明

MCP系统后端

物料收集点（MCP）系统的强大后端系统，用于管理合作伙伴、提货、订单和钱包交易。

概述

该服务器为MCP系统实现RESTful API，允许合作伙伴管理、提货计划、订单处理和钱包交易。它是用Node.js、Express和MongoDB构建的。

目录结构

server/
├── config/             # Configuration files
│   └── db.js           # Database connection configuration
├── controllers/        # Route controllers
│   ├── authController.js      # Authentication logic
│   ├── orderController.js     # Order management
│   ├── partnerController.js   # Partner management
│   ├── pickupController.js    # Pickup scheduling
│   └── walletController.js    # Wallet operations
├── middleware/         # Express middleware
│   └── auth.js         # Authentication & authorization middleware
├── models/             # MongoDB data models
│   ├── Order.js        # Order schema
│   ├── Partner.js      # Partner schema
│   ├── Pickup.js       # Pickup schema
│   ├── Transaction.js  # Transaction schema
│   ├── User.js         # User schema
│   └── Wallet.js       # Wallet schema
├── routes/             # API routes
│   ├── auth.js         # Authentication routes
│   ├── order.js        # Order management routes
│   ├── partner.js      # Partner management routes
│   ├── pickup.js       # Pickup scheduling routes
│   └── wallet.js       # Wallet operation routes
├── scripts/            # Utility scripts
│   └── seed.js         # Database seeding script
├── .env                # Environment variables
├── package.json        # Project dependencies and scripts
└── server.js           # Main application entry point

设置

安装依赖项:
```
npm install
```
设置环境变量: 创建一个 .env 根目录中的文件，包含以下变量：
```
PORT=5000
MONGO_URI=mongodb://localhost:27017/mcp-system
JWT_SECRET=your_jwt_secret
```
运行开发服务器:
```
npm run dev
```
为数据库添加种子 （可选）：
```
npm run seed
```

API终点

所有API回复均遵循标准格式：

{
  "success": true|false,
  "message": "Description of the result",
  "data": { /* Response data object */ }
}

认证

注册新用户

端点: POST /api/auth/register

请求正文:

{
  "name": "John Doe",
  "email": "john@example.com",
  "password": "securePassword123",
  "phone":"6201693634",
  "role": "user"
}

响应:

{
  "success": true,
  "message": "Registration successful",
  "data": {
    "token": "eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...",
    "user": {
      "_id": "60d21b4667d0d8992e610c85",
      "name": "John Doe",
      "email": "john@example.com",
      "phone":"6201693634",
    }
  }
}

伙伴

注册合作伙伴

端点: POST /api/partners/register

请求正文:

{
  "name": "EcoRecycle Inc",
  "email": "contact@ecorecycle.com",
  "password": "securePassword123",
  "role": "MCP"
}

响应:

{
  "success": true,
  "message": "Partner registered successfully",
  "data": {
    "partner": {
      "_id": "60d21b4667d0d8992e610c85",
      "name": "EcoRecycle Inc",
      "email": "contact@ecorecycle.com",
      "role": "MCP",
      "walletBalance": 0
    }
  }
}

获取合作伙伴详细信息

端点: GET /api/partners/:id

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

响应:

{
  "success": true,
  "data": {
    "partner": {
      "_id": "60d21b4667d0d8992e610c85",
      "name": "EcoRecycle Inc",
      "email": "contact@ecorecycle.com",
      "role": "MCP",
      "walletBalance": 500,
      "createdAt": "2023-04-05T14:30:45.123Z"
    }
  }
}

拾音器

创建提货

端点: POST /api/pickups/create

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

访问：仅限MCP合作伙伴

请求正文:

{
  "title": "Weekly Recyclables Pickup",
  "description": "Collection of plastic and paper materials",
  "address": "123 Green St, Eco City",
  "date": "2023-04-10T09:00:00.000Z",
  "assignedTo": "60d21b4667d0d8992e610c86",
  "commission": 50
}

响应:

{
  "success": true,
  "message": "Pickup created successfully",
  "data": {
    "pickup": {
      "_id": "60d21b4667d0d8992e610c87",
      "title": "Weekly Recyclables Pickup",
      "description": "Collection of plastic and paper materials",
      "address": "123 Green St, Eco City",
      "date": "2023-04-10T09:00:00.000Z",
      "status": "pending",
      "assignedTo": "60d21b4667d0d8992e610c86",
      "commission": 50,
      "createdAt": "2023-04-05T16:30:22.789Z"
    }
  }
}

取我的皮卡

端点: GET /api/pickups/my

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

访问：任何经过身份验证的用户

响应:

{
  "success": true,
  "data": {
    "pickups": [
      {
        "_id": "60d21b4667d0d8992e610c87",
        "title": "Weekly Recyclables Pickup",
        "description": "Collection of plastic and paper materials",
        "address": "123 Green St, Eco City",
        "date": "2023-04-10T09:00:00.000Z",
        "status": "pending",
        "assignedTo": "60d21b4667d0d8992e610c86",
        "commission": 50,
        "createdAt": "2023-04-05T16:30:22.789Z"
      }
    ]
  }
}

更新取货状态

端点: PUT /api/pickups/:id/status

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

请求正文:
```
{
  "status": "completed"
}
```

响应:

{
  "success": true,
  "message": "Pickup status updated successfully",
  "data": {
    "pickup": {
      "_id": "60d21b4667d0d8992e610c87",
      "status": "completed",
      "updatedAt": "2023-04-10T14:25:10.789Z"
    }
  }
}

过滤器拾音器

端点: GET /api/pickups/filter

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

访问：仅限MCP合作伙伴
查询参数:
- status：按状态筛选（待定、已完成、失败）
- date：按日期筛选

响应:

{
  "success": true,
  "data": {
    "pickups": [
      {
        "_id": "60d21b4667d0d8992e610c87",
        "title": "Weekly Recyclables Pickup",
        "description": "Collection of plastic and paper materials",
        "address": "123 Green St, Eco City",
        "date": "2023-04-10T09:00:00.000Z",
        "status": "completed",
        "assignedTo": "60d21b4667d0d8992e610c86",
        "commission": 50,
        "createdAt": "2023-04-05T16:30:22.789Z"
      }
    ]
  }
}

订单

创建订单

端点: POST /api/orders/create

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

请求正文:

{
  "items": [
    {
      "product": "Recycled Paper",
      "quantity": 20,
      "price": 5.50
    }
  ],
  "shippingAddress": "789 Client St, Client City",
  "paymentMethod": "wallet"
}

响应:

{
  "success": true,
  "message": "Order created successfully",
  "data": {
    "order": {
      "_id": "60d21b4667d0d8992e610c88",
      "orderNumber": "ORD-20230405-001",
      "items": [
        {
          "product": "Recycled Paper",
          "quantity": 20,
          "price": 5.50,
          "total": 110
        }
      ],
      "totalAmount": 110,
      "shippingAddress": "789 Client St, Client City",
      "paymentMethod": "wallet",
      "status": "pending",
      "createdAt": "2023-04-05T17:15:33.123Z"
    }
  }
}

获取我的订单

端点: GET /api/orders/my

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

响应:

{
  "success": true,
  "data": {
    "orders": [
      {
        "_id": "60d21b4667d0d8992e610c88",
        "orderNumber": "ORD-20230405-001",
        "items": [
          {
            "product": "Recycled Paper",
            "quantity": 20,
            "price": 5.50,
            "total": 110
          }
        ],
        "totalAmount": 110,
        "status": "pending",
        "createdAt": "2023-04-05T17:15:33.123Z"
      }
    ]
  }
}

钱包

获取我的钱包

端点: GET /api/wallet/balance

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

响应:

{
  "success": true,
  "data": {
    "balance": 1250.75
  }
}

向钱包充值

端点: POST /api/wallet/deposit

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

请求正文:

{
  "amount": 500,
  "paymentMethod": "credit_card"
}

响应:

{
  "success": true,
  "message": "Deposit successful",
  "data": {
    "transaction": {
      "_id": "60d21b4667d0d8992e610c90",
      "type": "deposit",
      "amount": 500,
      "description": "Wallet deposit via credit card",
      "createdAt": "2023-04-06T14:25:10.789Z"
    },
    "balance": 1750.75
  }
}

交易历史记录

端点: GET /api/wallet/transactions

标头:

Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

响应:

{
  "success": true,
  "data": {
    "transactions": [
      {
        "_id": "60d21b4667d0d8992e610c90",
        "type": "deposit",
        "amount": 500,
        "description": "Wallet deposit via credit card",
        "createdAt": "2023-04-06T14:25:10.789Z"
      },
      {
        "_id": "60d21b4667d0d8992e610c91",
        "type": "withdrawal",
        "amount": 110,
        "description": "Payment for order ORD-20230405-001",
        "createdAt": "2023-04-05T17:30:45.123Z"
      }
    ]
  }
}

身份验证流程

注册/登录:
- 用户或合作伙伴使用各自的端点注册或登录
- 服务器使用JWT令牌进行响应
令牌使用情况:
- 在所有受保护请求的Authorization标头中包含令牌：
```
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
```
基于角色的访问:
- 某些端点根据用户角色受到限制
- 系统支持“MCP”和“皮卡伙伴”等角色
- 未经授权的访问尝试将被拒绝，并显示403错误

数据模型

用户

{
  name: String,         // User's full name
  email: String,        // User's email (unique)
  password: String,     // Hashed password
  role: String,         // Role for authorization
  status: String,       // 'ACTIVE', 'INACTIVE'
  createdAt: Date,
  updatedAt: Date
}

搭档

{
  name: String,          // Partner name
  email: String,         // Contact email (unique)
  password: String,      // Hashed password
  role: String,          // 'MCP', 'PickupPartner'
  walletBalance: Number, // Current wallet balance
  createdAt: Date,
  updatedAt: Date
}

拾取

{
  title: String,         // Pickup title
  description: String,   // Pickup description
  address: String,       // Pickup location
  date: Date,            // Scheduled date and time
  status: String,        // 'pending', 'completed', 'failed'
  assignedTo: ObjectId,  // Reference to User/Partner
  commission: Number,    // Commission amount
  createdAt: Date,
  updatedAt: Date
}

订单

{
  orderNumber: String,   // Formatted order number
  items: [{
    product: String,     // Product name
    quantity: Number,    // Quantity
    price: Number,       // Price per unit
    total: Number        // Calculated total
  }],
  totalAmount: Number,   // Order total
  shippingAddress: String, // Delivery address
  paymentMethod: String, // Payment method
  status: String,        // 'pending', 'processing', 'completed', 'cancelled'
  createdAt: Date,
  updatedAt: Date
}

交易

{
  type: String,          // 'deposit', 'withdrawal', 'transfer'
  amount: Number,        // Transaction amount
  description: String,   // Transaction description
  status: String,        // 'completed', 'failed', 'pending'
  createdAt: Date
}

错误处理

所有API端点返回标准化错误响应：

{
  "success": false,
  "message": "Error message describing what went wrong",
  "error": {
    "details": "Additional error details (development mode only)"
  }
}

常见错误代码

400:错误请求-输入无效
401：未经授权-需要身份验证
403：禁止-用户缺乏权限
404：未找到-资源不存在
500：内部服务器错误-服务器端错误

环境变量

PORT -服务器端口（默认值：5000）
MONGO_URI -MongoDB连接字符串
JWT_SECRET -JWT身份验证密钥
NODE_ENV -环境（开发、生产）

数据库

该系统使用MongoDB作为其数据库。通过Mongoose使用环境变量中指定的连接字符串建立连接。

型号包括：

用户：用于身份验证和用户信息
合作伙伴：材料收集合作伙伴和取货合作伙伴
取货：预定材料取货
订单：订单处理
交易：金融交易记录
