Switchboard
Cross-team communication and devcontainer coordination for Claude agent teams. Teams running in separate Dev Containers (and host sessions) reach each other through a central gateway, which also federates with the gateways on other machines and bridges a native Android console.
Who it's for
This is aimed at people who already use Dev Containers and want agent teams in different containers to talk to each other. If you don't use Dev Containers, this project won't help you.
How it works
Teams register with the gateway over WebSocket. Any agent can call crosstalk_send to reach another team. The gateway handles message delivery, the response lifecycle, and request serialization.
- Agents use channel mode: messages arrive as push notifications and replies push back automatically, so there is no polling.
- The gateway connects to a self-hosted Federation Router (a content-blind relay) to reach the gateways on other machines and to relay the Android console. The Router forwards end-to-end-sealed frames between gateways without reading them.
See skills/crosstalk/SKILL.md for the full tool reference and response format.
Architecture
Host Machine
start-host-daemon.sh
Host daemon (headless) - devcontainer wake, console terminal view, session spawn
Claude Code session (spawned on demand via create_session) - joins the gateway as a loose peer
MCP Plugin (main-mcp.ts): crosstalk_* / channel_reply* / notify_human
Docker: switchboard (port 20000)
Gateway (main-gateway.ts)
HTTP routes + WebSocket hub
Router WS client, direct TLS (bearer token + owner-signed admission)
cross-gateway federation routing + Android console relay
DevContainers (one per project)
Claude Code
MCP Plugin (main-mcp.ts): crosstalk_* / channel_reply* / notify_human
Game client connector (port 20002)
Port Map
| Port | Service |
|---|---|
| 20000 | Gateway (HTTP + WS bridge) |
| 20001 | Federation Router (TLS) |
| 20002 | MCP Connector (game client WS) |
| 20003 | Enrollment TLS (arming only) |
Starting the gateway
./start-gateway.sh
The gateway listens on port 20000 on the external network switchboard, which the script creates.
Setup
1. Install the plugin. In Claude Code:
claude plugin marketplace add atelier-nyaarium/claude-marketplace
claude plugin install switchboard@atelier-nyaarium
Autoupdate is a settings flag. One-line jq version:
tmp=$(mktemp) && jq '. * {extraKnownMarketplaces: {"atelier-nyaarium": {autoUpdate: true}}}' ~/.claude/settings.json > "$tmp" && mv "$tmp" ~/.claude/settings.json
2. Set environment variables in your devcontainer - this is what lets your team's MCP plugin find its gateway, and is required for every devcontainer regardless of whether that gateway is enrolled into federation:
PROJECT_NAME- Your team's name on the bridge (e.g.my-project)BRIDGE_ROUTER_URL- Router URL (default:http://switchboard:20000)
3. Rebuild the Devcontainer.
- F1 then
Dev Containers: Rebuild Container
The host daemon attaches each devcontainer it wakes to switchboard, aliased by project.
Optional: Android console app and cross-machine federation
The steps above are everything you need for local crosstalk between devcontainers on one machine - a gateway that is never enrolled still boots in "arming mode" and routes that traffic fine. If you also want the native Android console app, or to link multiple machines' gateways together, the gateway's owner (a one-time action per gateway, not something each devcontainer does) runs ./setup.sh - see the "Deploying the federation" section of AGENTS.md for the full enrollment flow.
MCP Tools
Every session registers the same core tools; the game-client connector is the only container-only addition.
Every session
| Tool | Description |
|---|---|
crosstalk_send |
Send a request to another team |
crosstalk_discover |
List all teams on the bridge |
crosstalk_wait |
Wait N seconds before retrying a deferred request |
channel_reply |
Reply to an incoming channel message |
channel_reply_structured |
Reply with a native-object payload, only when the inbound tag carries a reply_schema |
notify_human |
Push a notice to the owner's consoles |
reload_plugins |
Run the plugin update + MCP reconnect sequence |
set_effort_level |
Set the session's effort level |
compact_session |
Compact the session's context |
Container-only
| Tool | Description |
|---|---|
mcpConnectorStatus / mcpConnectorServe / mcpConnectorUnserve |
Game client connector control |
| Project tools | Dynamic tools from the project's mcp-schema.js |
Federation Router
When a direct transport (transport.json, delivered by enrollment) is present in the gateway's federation dir, the gateway connects to the self-hosted Federation Router over TLS. The transport's bearer token authenticates the WS upgrade, the Router's leaf certificate fingerprint is pinned for TLS, and registration is gated by the owner-signed admission.
The Router is content-blind: it relays sealed frames without reading them. It carries:
- Cross-gateway federation: a gateway reaches teams on another machine's gateway through the Router, which routes each end-to-end-sealed frame by destination gateway id and never parses the payload.
- Console relay: the native Android console reaches the gateway through the Router, which relays the console's opaque frames over the same WebSocket.
Circular dependency warning
If Team A is waiting on Team B, Team B must not call back to Team A. Both will deadlock until timeout.
