juicebox-mcp

AI control for the juicebox.js Hi-C contact map viewer, as a plug-in. An MCP client (Claude Desktop, Claude Code, ChatGPT, Cursor, …) drives juicebox.js on a web page, and every page in the same room stays in sync.

MCP client ──/mcp──▶ Worker ──▶ room (Durable Object) ──/ws──▶ page: juicebox-view + @aidenlab/juicebox-remote
  • packages/server — the MCP server: a Cloudflare Worker on /mcp, with a Durable Object per room behind /ws. Deployed with wrangler, never published.
  • packages/remote — @aidenlab/juicebox-remote: the browser library that attaches a juicebox.js viewer to a room. The API is in packages/remote/README.md.

The page is juicebox-view, a thin wrapper around juicebox.js with a Room indicator and the join link in its header (ADR-0010). The viewer and the page are separate repositories; neither is vendored here.

Read next: GLOSSARY.md (glossary: room, join link, snapshot link, session, …), docs/design/ARCHITECTURE_V2.md (the design), docs/adr/ (decisions).

Connect an MCP client

The production server is https://juicebot-mcp.3dg.io/mcp (Streamable HTTP, no auth).

  • Claude Desktop — Settings → Connectors → Add custom connector, URL https://juicebot-mcp.3dg.io/mcp.

  • Claude Code — claude mcp add --transport http juicebox https://juicebot-mcp.3dg.io/mcp

  • Any stdio-only client — bridge with mcp-remote, e.g. in claude_desktop_config.json:

    {
  "mcpServers": {
    "juicebox": {
      "command": "npx",
      "args": ["-y", "mcp-remote", "https://juicebot-mcp.3dg.io/mcp"]
    }
  }
}

Then ask for the Juicebox link. get_juicebox_url returns a join link (https://juicebot.3dg.io/?room=…); open it, and ask the client to load a map and go to a locus. An open page can be handed to another chat by pasting its join link; the client calls join_room.

Tools

A page can hold several panels (juicebox.js viewers side by side), numbered 1, 2, … from the left. Every tool marked panel takes panel: that position, a map name that is unique among the panels, or "all" (not on load_map, load_control_map, list_tracks, close_panel). With one panel open it may be omitted; with several it is required, and the error lists the panels (ADR-0007).

Tool Does panel
get_juicebox_url, join_room join link for the session's room; bind the session to another room
load_map load a .hic map; panel: "new" opens it in a new panel beside the others new, one
load_control_map load a control map (display mode AOB) one
close_panel close a panel; the ones to its right move left; never the last one
list_panels the panels left to right: map, genome, control map, track count, locus; whether the Juicebox Panel Controls are shown
show_panel_controls hide or show the Juicebox Panel Controls on every panel of the page (show: true|false)
goto_locus, zoom_in, zoom_out navigate yes
set_map_foreground_color, set_map_background_color, set_color_scale, select_normalization map look yes
load_track, remove_track, set_track_color, set_track_name, set_track_data_range, set_track_autoscale, set_track_log_scale tracks, by name or 1-based number (by name only with "all") yes
list_tracks one panel's 1D and 2D tracks one
load_session, save_session, create_shareable_url session JSON in and out; snapshot link
search_encode_hic live ENCODE portal: Hi-C experiments (tissues, intact Hi-C, cell lines) with their map and track files
search_encode live ENCODE portal: any other assay, annotation, biosample, file
search_map_catalogs the curated ENCODE and 4DN catalogs on igv-data (was search_maps)
get_map_details, get_data_source_statistics, list_data_sources catalog details and counts
juicebox_help, get_server_status examples; server status

Run everything locally

docs/juicebox-view-development.md runs this repo's server (wrangler dev) and juicebox-view (vite) side by side and connects Claude to them. It expects juicebox-view cloned next to this repo.

Develop

npm test                 # vitest watch: remote in Node, server inside workerd
npm run test:run         # single run
npm run dev:server       # wrangler dev on :8787

Project conventions are in CLAUDE.md.

Deploy

Every deploy runs from a maintainer's machine with wrangler; nothing deploys from GitHub. There are two stacks, each a Worker paired with a juicebox-view Page ([env.*] in packages/server/wrangler.toml):

Stack Page MCP server Deployed by
Production https://juicebot.3dg.io/ https://juicebot-mcp.3dg.io/mcp scripts/deploy-prod.sh prod-YYYY-MM-DD, from a tag pushed on both this repo and juicebox-view
Dev https://juicebot-view-dev.pages.dev/ https://juicebot-view-mcp-dev.3dg.io/mcp scripts/deploy-dev.sh <juicebox-view clone> [branch-or-tag] (docs/test-deployment.md)

scripts/deploy-wizard.sh walks a maintainer through login, the two secrets, the dev Worker deploy, probing /mcp and /ws, and connecting each client end to end. How the pieces fit: docs/how-juicebot-deploys.html.

Each stack's settings in wrangler.toml:

Why
route, custom domain wrangler attaches the domain and its DNS record on deploy
workers_dev, preview_urls = false one public hostname per Worker; no *.workers.dev second entry point for clients or pages to drift onto
BROWSER_URL the stack's Page, where join and snapshot links open (the trailing slash matters)
ALLOWED_ORIGINS exact-match Origin check on /ws, listing the stack's Page; WebSockets are not covered by CORS
TINYURL_DOMAIN, TINYURL_ENDPOINT t.3dg.io and the TinyURL API, for snapshot-link shortening in create_shareable_url
secret SESSION_HMAC_SECRET keys room ids derived from ChatGPT's x-openai-session; unset → that path fails
secret TINYURL_API_KEY unset → create_shareable_url returns the long link

Secrets are set per stack with wrangler secret put <NAME> --env <env>. For wrangler dev, the top-level [vars] point at a local juicebox-view on localhost:5173, and packages/server/.dev.vars stands in for the secrets.

History

This repository started as the first Juicebox MCP server (tags v0.0.1-mvp to v1.1.0). Development of v2 continued in the fork weiszd/juicebox-mcp from 0149fd1 and was moved back here at 4c0ecaa (October 2026), with its full history; that fork's issues and pull requests remain there.

The prototype

The pre-v2 prototype (Node .mcpb server, vendored viewer, Vite frontend) and its notes (docs/mcp-notes/, docs/datasource-notes/, docs/development-notes/, docs/usage-scenerios/) are on branch prototype and tag v1.1.0-prototype.

License

MIT. See LICENSE.
