使用说明

AI代理MCP-项目流程文档

🏗️ 架构概述

该项目实现了 干净+六边形架构 和 MCP（模型上下文协议） 人工智能操作的集成。

📊 高级系统流

┌─────────────────────────────────────────────────────────────────────┐
│                        USER INTERACTION                              │
└────────────┬────────────────────────────────────────────┬────────────┘
             │                                             │
             ▼                                             ▼
    ┌────────────────┐                          ┌──────────────────┐
    │   FastAPI      │                          │   MCP Server     │
    │   REST API     │                          │   (Tool Server)  │
    └────────┬───────┘                          └────────┬─────────┘
             │                                            │
             │                                            │
             ▼                                            ▼
    ┌─────────────────────────────────────────────────────────────────┐
    │              PRESENTATION LAYER (API Routes)                    │
    │  • /ai/chat           • /email/send-ai                         │
    │  • /charts/generate   • /pdf/extract                           │
    │  • /health            • /pdf/analyze                           │
    └────────────────────────┬────────────────────────────────────────┘
                             │
                             ▼
    ┌─────────────────────────────────────────────────────────────────┐
    │              APPLICATION LAYER (Use Cases)                      │
    │  • SendEmailUseCase                                            │
    │  • GenerateChartUseCase                                        │
    │  • ProcessPDFUseCase                                           │
    └────────────────────────┬────────────────────────────────────────┘
                             │
                             ▼
    ┌─────────────────────────────────────────────────────────────────┐
    │              DOMAIN LAYER (Business Logic)                      │
    │  • Email Entity & Repository Interface                         │
    │  • Chart Entity & Repository Interface                         │
    │  • PDF Entity & Repository Interface                           │
    │  • AI Service Interface                                        │
    └────────────────────────┬────────────────────────────────────────┘
                             │
                             ▼
    ┌─────────────────────────────────────────────────────────────────┐
    │           INFRASTRUCTURE LAYER (Implementations)                │
    │  • QwenAIService (Hugging Face)                               │
    │  • EmailService (SMTP)                                         │
    │  • ChartService (Plotly)                                       │
    │  • PDFService (PyPDF/pdfplumber)                              │
    └─────────────────────────┬────────────────────────────────────────┘
                             │
                             ▼
    ┌─────────────────────────────────────────────────────────────────┐
    │                  EXTERNAL SERVICES                              │
    │  • Hugging Face API (Llama 3.2)                               │
    │  • SMTP Server (Gmail)                                         │
    │  • File System (Charts/PDFs)                                   │
    └─────────────────────────────────────────────────────────────────┘

🔄 详细请求流

1️⃣ AI聊天流

graph TD
    A[User sends POST /ai/chat] --> B[API Route Handler]
    B --> C{Validate Request}
    C -->|Invalid| D[Return 422 Error]
    C -->|Valid| E[Extract prompt & context]
    E --> F[QwenAIService.generate_response]
    F --> G[Initialize InferenceClient]
    G --> H[Format as chat messages]
    H --> I[Call Hugging Face API]
    I --> J{API Response}
    J -->|Error| K[Log error & raise HTTPException]
    J -->|Success| L[Extract response text]
    L --> M[Return AIChatResponse]
    M --> N[User receives AI response]

代码路径：

User Request
    ↓
src/presentation/api/routes/ai.py::chat()
    ↓
src/infrastructure/services/ai_service.py::QwenAIService.generate_response()
    ↓
huggingface_hub.InferenceClient.chat_completion()
    ↓
Hugging Face Router API (meta-llama/Llama-3.2-3B-Instruct)
    ↓
Response → User

2️⃣ 电子邮件发送流程（AI增强）

graph TD
    A[User POST /email/send-ai] --> B[Email Route Handler]
    B --> C[Extract recipient, subject, template]
    C --> D[QwenAIService.generate_response]
    D --> E[AI generates email body]
    E --> F[SendEmailUseCase.execute]
    F --> G[Create Email Entity]
    G --> H[EmailService.send]
    H --> I[Connect to SMTP Server]
    I --> J{SMTP Authentication}
    J -->|Fail| K[Return Error]
    J -->|Success| L[Send Email via SMTP]
    L --> M[Return Success Response]

代码路径：

POST /email/send-ai
    ↓
src/presentation/api/routes/email.py::send_email_with_ai()
    ↓
src/infrastructure/services/ai_service.py::generate_response()
    ↓
src/application/use_cases/send_email.py::SendEmailUseCase.execute()
    ↓
src/domain/entities/email.py::Email (entity created)
    ↓
src/infrastructure/services/email_service.py::EmailService.send()
    ↓
aiosmtplib → SMTP Server

3️⃣ 图表生成流程

graph TD
    A[User POST /charts/generate] --> B[Chart Route Handler]
    B --> C[Extract chart_type, data, config]
    C --> D[GenerateChartUseCase.execute]
    D --> E[Create Chart Entity]
    E --> F[ChartService.generate]
    F --> G{Chart Type?}
    G -->|bar| H[Plotly Bar Chart]
    G -->|line| I[Plotly Line Chart]
    G -->|pie| J[Plotly Pie Chart]
    G -->|scatter| K[Plotly Scatter Plot]
    H --> L[Apply styling & config]
    I --> L
    J --> L
    K --> L
    L --> M[Export as PNG/HTML/JSON]
    M --> N[Save to output/charts/]
    N --> O[Return chart path & base64]

代码路径：

POST /charts/generate
    ↓
src/presentation/api/routes/charts.py::generate_chart()
    ↓
src/application/use_cases/generate_chart.py::GenerateChartUseCase.execute()
    ↓
src/domain/entities/chart.py::Chart (entity)
    ↓
src/infrastructure/services/chart_service.py::ChartService.generate()
    ↓
plotly.graph_objects → Chart file

4️⃣ PDF处理流程

graph TD
    A[User POST /pdf/extract] --> B[PDF Route Handler]
    B --> C[Receive uploaded PDF file]
    C --> D[Save to temp directory]
    D --> E[ProcessPDFUseCase.execute]
    E --> F[Create PDF Entity]
    F --> G[PDFService.extract_text]
    G --> H[pdfplumber opens PDF]
    H --> I[Extract text from all pages]
    I --> J[Count pages, chars, words]
    J --> K[Return extracted content]

    L[User POST /pdf/analyze] --> M[PDF Analyze Handler]
    M --> N[Extract text via PDFService]
    N --> O[QwenAIService.generate_response]
    O --> P[AI analyzes PDF content]
    P --> Q[Return analysis + metadata]

代码路径（提取）：

POST /pdf/extract
    ↓
src/presentation/api/routes/pdf.py::extract_pdf()
    ↓
src/application/use_cases/process_pdf.py::ProcessPDFUseCase.execute()
    ↓
src/domain/entities/pdf.py::PDF (entity)
    ↓
src/infrastructure/services/pdf_service.py::PDFService.extract_text()
    ↓
pdfplumber → Text extraction

代码路径（AI分析）：

POST /pdf/analyze
    ↓
src/presentation/api/routes/pdf.py::analyze_pdf()
    ↓
src/infrastructure/services/pdf_service.py::extract_text()
    ↓
src/infrastructure/services/ai_service.py::generate_response()
    ↓
Hugging Face API → AI Analysis

5️⃣ MCP服务器流

graph TD
    A[MCP Client connects] --> B[MCP Server initialized]
    B --> C[List available tools]
    C --> D{Tool requested}
    D -->|send_email| E[EmailService]
    D -->|generate_chart| F[ChartService]
    D -->|process_pdf| G[PDFService]
    D -->|ai_chat| H[QwenAIService]
    E --> I[Execute operation]
    F --> I
    G --> I
    H --> I
    I --> J[Return result to MCP client]

可用MCP工具：

send_email -通过SMTP发送电子邮件
generate_chart -创建可视化
process_pdf -提取/分析PDF
ai_chat -与AI模型交互

🗂️ 层职责

1.域层 (`src/domain/`)

目的： 核心业务逻辑，独立于框架
组件：
- 实体： Email, Chart, PDF
- 接口： IEmailRepository, IChartRepository, IPDFRepository, IAIService
规则： 无外部依赖，纯业务逻辑

2.应用层 (`src/application/`)

目的： 编排用例，协调领域对象
组件：
- SendEmailUseCase -电子邮件发送工作流
- GenerateChartUseCase -图表创建工作流程
- ProcessPDFUseCase -PDF处理工作流程
规则： 使用域接口，无基础结构详细信息

3.基础设施层 (`src/infrastructure/`)

目的： 实现与具体技术的接口
组件：
- QwenAIService -拥抱面部整合
- EmailService -SMTP实现
- ChartService -精心实施
- PDFService -PDF库实现
- Settings -配置管理
规则： 依赖于域接口，实现它们

4.表示层 (`src/presentation/`)

目的： 处理HTTP请求，公开API
组件：
- FastAPI应用程序
- API路线： /ai, /email, /charts, /pdf, /health
- 请求/响应模型（Pydantic）
规则： 薄层，委托给应用层

🔌 依赖注入流程

main.py
  ↓
Initialize FastAPI app
  ↓
Load Settings from .env
  ↓
Initialize Services:
  • QwenAIService(api_key, model)
  • EmailService(smtp_config)
  • ChartService()
  • PDFService()
  ↓
Initialize Use Cases:
  • SendEmailUseCase(email_service)
  • GenerateChartUseCase(chart_service)
  • ProcessPDFUseCase(pdf_service)
  ↓
Register API Routes
  ↓
Start Uvicorn Server (0.0.0.0:8000)

🌐 API终结点摘要

端点	方法	目的	人工智能增强
`/health`	GET	健康检查	❌
`/ai/chat`	POST	与AI聊天	✅
`/email/send`	POST	发送普通电子邮件	❌
`/email/send-ai`	POST	人工智能生成的电子邮件	✅
`/charts/generate`	POST	创建图表	❌
`/pdf/extract`	POST	提取PDF文本	❌
`/pdf/analyze`	POST	人工智能PDF分析	✅

🔐 配置流程

.env file
  ↓
Load via python-dotenv
  ↓
Pydantic Settings class validates
  ↓
Settings injected into services
  ↓
Services use configuration at runtime

环境变量：

HUGGINGFACE_API_KEY → QwenAIService
SMTP_USERNAME, SMTP_PASSWORD → 电子邮件服务
AI_MODEL, AI_TEMPERATURE → AI配置
API_HOST, API_PORT → 服务器绑定

🔄 错误处理流程

Exception occurs
  ↓
Service logs error
  ↓
Raise to use case layer
  ↓
Use case catches & wraps
  ↓
Route handler catches
  ↓
FastAPI HTTPException raised
  ↓
JSON error response returned

例子：

try:
    result = await ai_service.generate_response(prompt)
except Exception as e:
    logger.error(f"AI generation failed: {e}")
    raise HTTPException(status_code=500, detail=str(e))

📈 数据流示例：AI增强电子邮件

1. User Request:
   POST /email/send-ai
   {
     "to": "user@example.com",
     "subject": "Welcome",
     "content_template": "Write a welcome email for new users"
   }

2. Route Handler (email.py):
   - Validates request
   - Calls QwenAIService

3. AI Service:
   - Formats prompt: "Write a welcome email for new users"
   - Calls Hugging Face: InferenceClient.chat_completion()
   - Returns: "Dear valued user, welcome to our platform..."

4. Use Case (SendEmailUseCase):
   - Creates Email entity with AI-generated body
   - Passes to EmailService

5. Email Service:
   - Connects to SMTP (Gmail)
   - Authenticates with credentials
   - Sends email via aiosmtplib

6. Response:
   {
     "message": "Email sent successfully",
     "to": "user@example.com",
     "generated_content": "Dear valued user..."
   }

🚀 启动顺序

1. main.py execution
   ↓
2. Load environment from .env
   ↓
3. Initialize Settings (Pydantic validation)
   ↓
4. Create FastAPI app instance
   ↓
5. Register startup event:
   - Log application start
   - Initialize services
   ↓
6. Register shutdown event:
   - Cleanup resources
   - Log shutdown
   ↓
7. Include API routers:
   - /ai routes
   - /email routes
   - /charts routes
   - /pdf routes
   - /health route
   ↓
8. Start Uvicorn server:
   - Host: 0.0.0.0
   - Port: 8000
   - Reload: True (development)
   ↓
9. Server ready for requests

🧪 测试流程

Test Script (test_llama.py)
  ↓
Direct import: QwenAIService
  ↓
Initialize with .env credentials
  ↓
Run test prompts:
  1. Simple greeting
  2. Math calculation
  3. Creative writing
  4. Explanation
  5. Fun fact
  ↓
Each test:
  - Calls generate_response()
  - Validates response
  - Reports success/failure
  ↓
Summary: 5/5 tests passed ✅

🔧 技术栈流程

┌─────────────────────────────────────────┐
│         Application Entry Point          │
│              main.py                     │
└──────────────┬──────────────────────────┘
               │
               ▼
┌─────────────────────────────────────────┐
│          Web Framework                   │
│      FastAPI + Uvicorn                   │
└──────────────┬──────────────────────────┘
               │
               ▼
┌─────────────────────────────────────────┐
│         Core Services                    │
│  • HuggingFace Hub 1.2.1                │
│  • aiosmtplib (Email)                   │
│  • Plotly + Kaleido (Charts)            │
│  • PyPDF + pdfplumber (PDF)             │
└──────────────┬──────────────────────────┘
               │
               ▼
┌─────────────────────────────────────────┐
│        External APIs                     │
│  • Hugging Face Router                  │
│    (meta-llama/Llama-3.2-3B-Instruct)   │
│  • SMTP Server (Gmail)                  │
└─────────────────────────────────────────┘

📝 总结

架构模式： 清洁+六角形（端口和适配器）

优点：

✅ 可测试： 独立于基础设施的域逻辑
✅ 可维护： 明确区分关注点
✅ 可扩展性： 易于交换的实现
✅ 灵活： AI提供商可以在不涉及业务逻辑的情况下进行更改

关键原则： 依赖关系指向内部（来自基础设施→ 应用→ 域）

这确保了核心业务逻辑保持纯粹，独立于外部框架或服务。
