MCP Bubble Wrap

A sophisticated MCP (Model Context Protocol) server with React-based interactive widgets, inspired by the OpenAI Apps SDK examples.

Features

• 🫧 Interactive Bubble Wrap Widget: Pop virtual bubbles with smooth CSS animations
• ⚡ Modern Build System: Vite-powered development and production builds
• 🎨 React-based Widgets: Easy to create and maintain UI components
• 🎨 Tailwind CSS: Utility-first CSS framework with theme support
• 🔄 Hot Module Replacement: Fast development with instant updates
• 📦 Optimized Builds: Inlined assets for easy deployment
• 🌐 Apps SDK Compatible: Works seamlessly with ChatGPT and OpenAI Apps SDK
• 🧩 MCP Apps (SEP-1865): Native support for MCP Apps hosts such as Goose via @modelcontextprotocol/ext-apps
• 🪟 Display modes: Declares inline, fullscreen, pip, plus Goose's split-right, split-bottom and standalone

Project Structure

mcp-bubble-wrap/
├── src/
│   ├── shared/
│   │   └── display-modes.ts    # Display modes shared by server + widgets
│   ├── widgets/                # React-based widgets
│   │   ├── styles.css          # Shared Tailwind styles
│   │   ├── components/         # Shared widget components
│   │   │   ├── DisplayModeControls.tsx
│   │   │   └── Layout.tsx
│   │   ├── hooks/              # Shared hooks
│   │   │   ├── types.ts
│   │   │   ├── use-display-mode.ts   # Host-agnostic display mode state
│   │   │   ├── use-mcp-app.ts        # MCP Apps (ext-apps) connection
│   │   │   └── use-openai-global.ts  # ChatGPT (OpenAI Apps SDK) globals
│   │   └── bubble-wrap/
│   │       ├── BubbleWrap.tsx  # Widget component
│   │       ├── index.tsx       # Widget entry point
│   │       └── types.ts        # Widget types
│   ├── utils/                  # Shared utilities
│   │   ├── load-widget-html.ts
│   │   └── logger.ts
│   ├── mcp-server.ts           # /mcp route: OpenAI Apps SDK + mcp-ui
│   ├── mcp-app-server.ts       # /mcp-app route: MCP Apps (SEP-1865)
│   └── index.ts                # Server entry point
├── build-widgets.mts           # Widget build orchestrator
├── assets/                     # Built widget assets (generated)
├── dist/                       # Compiled server code (generated)
├── vite.config.mts             # Vite configuration for dev/build
├── tailwind.config.mjs         # Tailwind CSS configuration
├── postcss.config.mjs          # PostCSS configuration
└── package.json

Setup

Requires Node.js 20+ (the MCP TypeScript SDK v2 packages need it). An .nvmrc is included.

pnpm install

Development

Start Everything

Run the complete development stack with hot reloading:

pnpm dev

This starts:

1. Widget Dev Server (port 4444) - Vite dev server with HMR
2. MCP Server (port 5678) - TypeScript server with vite-node
3. MCP Inspector - Interactive testing UI

Individual Commands

# Widget development only
pnpm dev:widgets

# Build widgets
pnpm build:widgets

# Type-check server and widgets
pnpm typecheck

# Build server
pnpm build:server

# Serve built widgets
pnpm serve:widgets

Build

Build both the server and widgets for production:

pnpm build

This will:

1. Compile TypeScript server code to dist/
2. Bundle React widgets to assets/ with hashed filenames
3. Generate HTML files for each widget

Environment Variables

• BASE_URL - Base URL for widget assets in HTML generation (default: http://localhost:5678)
  • Note: Not currently used as assets are inlined in HTML
  • For production, set this to your deployed assets URL if serving external resources
• PORT - MCP server port (default: 5678)

Example:

BASE_URL=https://your-cdn.com pnpm run build:widgets
PORT=3000 pnpm start

Production

pnpm start

Creating New Widgets

1. Create a new directory under src/widgets/:

src/widgets/my-widget/
├── MyWidget.tsx    # React component
└── index.tsx       # Entry point (imports shared styles.css)

2. Entry point template (index.tsx):

import { createRoot } from "react-dom/client"
import MyWidget from "./MyWidget"

const rootEl = document.getElementById("my-widget-root")
if (rootEl) {
  createRoot(rootEl).render(<MyWidget />)
}

export { MyWidget }
export default MyWidget

3. Widget component template (MyWidget.tsx):

import { useOpenAiGlobal } from "../hooks/use-openai-global.js"
import { Layout } from "../components/Layout.js"

interface MyWidgetProps {
  // Your props from the MCP tool
  message?: string
}

export function MyWidget() {
  // Get the structured content passed from the MCP tool
  const toolOutput = useOpenAiGlobal("toolOutput") as MyWidgetProps

  return (
    <Layout>
      <div className="p-6 text-center">
        <h1 className="text-2xl font-bold text-gray-900">
          {toolOutput?.message || "Hello World"}
        </h1>
      </div>
    </Layout>
  )
}

export default MyWidget

4. Build and test:

pnpm build:widgets
pnpm dev

The widget will automatically be discovered and built!

Styling with Tailwind CSS

All widgets have access to Tailwind CSS utility classes. The Layout component automatically handles:

• Theme detection: Automatically detects and applies theme from OpenAI global data
• Layout constraints: Reports size changes to parent window
• Responsive design: Full Tailwind responsive utilities available

Example styling:

<div className="flex items-center justify-center min-h-[200px]">
  <p className="text-gray-500 animate-pulse">Loading...</p>
</div>

Widget Gallery

During development, visit http://localhost:4444 to see all available widgets.

MCP Inspector

The MCP Inspector provides an interactive UI for testing your MCP server:

# Development mode (connects to local server)
pnpm inspect:dev

# Production mode
pnpm inspect:prod

Architecture

Widget Build System

The build system is inspired by the OpenAI Apps SDK examples:

1. Discovery: Automatically finds all src/widgets/**/index.{tsx,jsx} files
2. Bundling: Each widget is bundled as a standalone module with Vite
3. Hashing: Assets are versioned with content hashes for cache busting
4. HTML Generation: Creates standalone HTML files that can be served directly

MCP Server Integration

The server exposes the same widget on two Streamable HTTP routes:

Both routes load the built widget HTML from assets/. The /mcp-app route registers the UI resource and tool with registerAppResource / registerAppTool from the ext-apps server helpers, which emit the text/html;profile=mcp-app MIME type and _meta.ui metadata for you.

Display Modes

The widget declares every display mode it can render in through the MCP Apps ui/initialize handshake (appCapabilities.availableDisplayModes). The list lives in src/shared/display-modes.ts:

The three Goose modes are not part of the MCP Apps spec; Goose accepts them and other hosts ignore them. At runtime the widget renders one control per mode the host actually offers (DisplayModeControls), so the split-right / split-bottom buttons only appear under a host that advertises them. The controls are fixed to the bottom of the viewport so they stay reachable when the grid is taller than the viewport. In ChatGPT the controls fall back to window.openai.requestDisplayMode with the three spec modes.

Non-spec modes and the ext-apps SDK. The App class in @modelcontextprotocol/ext-apps validates every host message against the spec schemas, whose display-mode enum is exactly inline | fullscreen | pip. A host that puts split-right in hostContext.availableDisplayModes would otherwise make App.connect() reject the whole ui/initialize result. src/widgets/lib/display-mode-compat-transport.ts wraps the PostMessageTransport, records the real values the host sent, and hands the SDK a spec-conformant copy. useDisplayMode() reads the real values from that side channel and falls back to hostContext for spec-only hosts.

Theme and Layout

• Theme comes from the host (window.openai.theme in ChatGPT, hostContext.theme in MCP Apps hosts, updated via ui/notifications/host-context-changed) and falls back to prefers-color-scheme. Layout applies it to <html> as the dark class plus data-theme; colours are CSS variables in src/widgets/styles.css.
• Scrolling is disabled only in inline mode, where the host sizes the iframe to the content. Every other mode gives the app a fixed viewport, so the document scrolls normally there.
• Grid sizing (useBubbleLayout) derives the column count and bubble size from the measured container width. Outside inline mode it also tries to pick the largest bubble size at which every bubble fits the viewport height, so fullscreen and split modes usually need no scrolling at all.
• The resource sets prefersBorder: false and the app paints a full-bleed background, so the host draws no frame around it.

Props Communication

Widgets receive data via the OpenAI global object:

// In your widget - access toolOutput from OpenAI globals
const toolOutput = useOpenAiGlobal("toolOutput") as MyProps

// The server passes data via structuredContent
return {
  structuredContent: {
    bubbleCount: validBubbleCount,
  },
}

// This structuredContent becomes available as toolOutput in the widget

Deployment

Render.com

The project includes a render.yaml for easy deployment to Render:

1. Push your code to GitHub
2. Connect your repository to Render
3. Set environment variables:
   • BASE_URL: URL where your assets will be served

Custom Deployment

1. Build the project:

pnpm run build

2. Deploy:
   • Upload dist/ directory to your server
   • Upload assets/ directory (HTML files with inlined JS/CSS)
   • Start the server: node dist/index.js
   • Server will run on port 5678 by default (configure with PORT env var)

Dependencies

Runtime

• react & react-dom: UI framework
• @modelcontextprotocol/server / @modelcontextprotocol/node: MCP TypeScript SDK v2 (server + Node Streamable HTTP transport)
• @modelcontextprotocol/ext-apps: MCP Apps (SEP-1865) server helpers and the widget-side App client
• @modelcontextprotocol/client / @modelcontextprotocol/core: peer packages required by ext-apps in the widget bundle
• @mcp-ui/server: mcp-ui resource creation with the OpenAI Apps SDK adapter (used by the /mcp route)
• express: HTTP server for MCP protocol
• cors: CORS middleware
• zod: Schema validation
• chalk: Terminal colors and logging

Development

• vite: Build tool and dev server
• @vitejs/plugin-react: React support for Vite
• tsx: TypeScript execution
• vite-node: Run TypeScript server with hot reload
• fast-glob: File discovery for build system
• tailwindcss: Utility-first CSS framework
• postcss: CSS transformation tool
• autoprefixer: Automatic vendor prefix handling
• concurrently: Run multiple commands in parallel
• prettier: Code formatting

Inspiration

This project structure is heavily inspired by the excellent OpenAI Apps SDK Examples, particularly their approach to:

• Widget build orchestration
• Multi-entry point development
• Asset hashing and versioning
• Development server setup

License

MIT
