认证授权服务原型

Client (Claude Code, MCP client)
  │
  │  Authorization: Bearer <jwt>
  ▼
┌─────────────────────────────────┐
│  FastMCP Server (port 8080)     │
│                                 │
│  ┌───────────────────────────┐  │
│  │  AuthMiddleware           │  │
│  │  1. Extract Bearer token  │  │
│  │  2. Validate JWT (sig+exp)│  │
│  │  3. Filter tools by scope │  │
│  │  4. Block unauthorized    │  │
│  └───────────────────────────┘  │
│                                 │
│  ┌───────────┐ ┌─────────────┐  │
│  │ get_public│ │get_confiden-│  │
│  │ _info     │ │tial_info    │  │
│  │           │ │             │  │
│  │ scope:    │ │ scope:      │  │
│  │ public:   │ │ confidenti- │  │
│  │ read      │ │ al:read     │  │
│  └───────────┘ └─────────────┘  │
│                                 │
│  /health  /ready  /mcp          │
└─────────────────────────────────┘

# Install dependencies
uv sync

# Start the server
uv run python -m src.server

# Public access only
uv run python -m scripts.generate_token --sub alice --scope public:read

# Full access
uv run python -m scripts.generate_token --sub bob --scope public:read confidential:read

# Expired token (for testing rejection)
uv run python -m scripts.generate_token --sub charlie --scope public:read --exp-hours -1

# Generate a token
TOKEN=$(uv run python -m scripts.generate_token --sub myuser --scope public:read confidential:read 2>&1 | grep "^Token:" | cut -d' ' -f2)

# Add the MCP server to Claude Code
claude mcp add --transport http mcp-auth-prototype http://localhost:8080/mcp \
  --header "Authorization: Bearer $TOKEN"

# Generate a token
TOKEN=$(uv run python -m scripts.generate_token --sub alice --scope public:read 2>&1 | grep "^Token:" | cut -d' ' -f2)

# Initialize MCP session
curl -X POST http://localhost:8080/mcp \
  -H "Content-Type: application/json" \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer $TOKEN" \
  -d '{"jsonrpc":"2.0","id":1,"method":"initialize","params":{"protocolVersion":"2025-03-26","capabilities":{},"clientInfo":{"name":"test","version":"1.0"}}}'

# Run tests
uv run pytest -v

# Lint
uv run ruff check .

# Build the Docker image
docker build -t mcp-auth-prototype:local .

# Run with a custom JWT secret (required for production)
docker run -p 8080:8080 -e MCP_JWT_SECRET_KEY=my-secret mcp-auth-prototype:local

# Run with debug logging
docker run -p 8080:8080 \
  -e MCP_JWT_SECRET_KEY=my-secret \
  -e MCP_LOG_LEVEL=debug \
  mcp-auth-prototype:local

# Verify health endpoint
curl http://localhost:8080/health

# Verify readiness endpoint
curl http://localhost:8080/ready

# Generate a token (must use --secret matching the container's MCP_JWT_SECRET_KEY)
TOKEN=$(uv run python -m scripts.generate_token --sub alice --scope public:read --secret my-secret 2>&1 | grep "^Token:" | cut -d' ' -f2)

# Test MCP initialization against the container
curl -X POST http://localhost:8080/mcp \
  -H "Content-Type: application/json" \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer $TOKEN" \
  -d '{"jsonrpc":"2.0","id":1,"method":"initialize","params":{"protocolVersion":"2025-03-26","capabilities":{},"clientInfo":{"name":"test","version":"1.0"}}}'

mcp-auth-prototype/
├── src/
│   ├── server.py          # MCP server, auth middleware, health endpoints
│   ├── auth.py            # JWT validation and scope extraction
│   ├── tools.py           # Tool-to-scope mapping registry
│   └── config.py          # Environment-based configuration (pydantic-settings)
├── documents/
│   ├── public.md          # Sample public company document
│   └── confidential.md    # Sample confidential strategy document
├── scripts/
│   └── generate_token.py  # CLI utility to mint JWT tokens
├── tests/
│   ├── conftest.py        # Shared test fixtures (token factories)
│   ├── test_auth.py       # Unit tests for JWT validation (16 tests)
│   └── test_tools.py      # Integration tests for tool authorization (6 tests)
├── helm/
│   └── mcp-server/            # Helm chart for Kubernetes deployment
│       ├── Chart.yaml         # Chart metadata (name, version)
│       ├── values.yaml        # Default configuration values
│       ├── values-dev.yaml    # Dev environment overrides
│       └── templates/
│           ├── _helpers.tpl       # Reusable Go template helpers
│           ├── deployment.yaml    # Deployment (2 replicas, probes, env vars)
│           ├── service.yaml       # ClusterIP Service on port 8080
│           ├── configmap.yaml     # Document content (public.md, confidential.md)
│           ├── serviceaccount.yaml # K8s ServiceAccounts with Workload Identity
│           ├── secretstore.yaml   # ESO connection to GCP Secret Manager
│           └── externalsecret.yaml # Syncs JWT key from GCP to K8s Secret
├── terraform/             # Infrastructure as Code
│   ├── main.tf            # Provider and backend configuration
│   ├── variables.tf       # Input variables
│   ├── outputs.tf         # Output values
│   ├── gke.tf             # GKE cluster definition
│   ├── artifact-registry.tf  # Container registry
│   ├── secret-manager.tf  # Secret Manager resources
│   ├── iam.tf             # Service accounts and IAM bindings
│   └── github-wif.tf     # Workload Identity Federation for GitHub Actions
├── .github/
│   └── workflows/
│       └── ci.yaml        # CI pipeline (lint, test, build, push, update Helm)
├── argocd/
│   └── application.yaml   # ArgoCD Application (GitOps auto-sync)
├── pyproject.toml         # Dependencies and tool configuration
└── uv.lock                # Locked dependency versions

git push ──▶ GitHub Actions ──▶ ArgoCD ──▶ GKE Cluster
              │                   │
              ├─ Lint (ruff)      ├─ Detects values.yaml change
              ├─ Test (pytest)    ├─ Renders Helm chart
              ├─ Build image      └─ Rolling update (zero downtime)
              ├─ Push to Artifact Registry (git SHA tag)
              └─ Update helm/mcp-server/values.yaml
