Book API MCP Bundle

This bundle provides a complete Docker Compose setup for running the Book API and its MCP (Model Context Protocol) server, along with all required infrastructure.

Repositories

Overview

The docker-compose.yml file orchestrates four services that work together to provide a complete Book API ecosystem:

  1. TimescaleDB - A PostgreSQL database with TimescaleDB extension for data storage
  2. pgAdmin - Web-based database administration tool
  3. BookApi - The main ASP.NET Core REST API for managing books
  4. bookapi-mcp-server - MCP server that exposes the Book API to Claude Desktop

Services

TimescaleDB

A PostgreSQL database with TimescaleDB extension running on PostgreSQL 17.

  • Image: timescale/timescaledb-ha:pg17
  • Database: propertydb (note: the BookApi connects to bookapi database)
  • User: admin
  • Password: Empty (no password set)
  • Health Check: Monitors database readiness every 10 seconds
  • Data Persistence: Uses a Docker volume (postgres-data) to persist data

pgAdmin

Web-based PostgreSQL administration interface for managing the database.

  • Image: dpage/pgadmin4
  • Access: http://localhost:5050
  • Email: admin@admin.com
  • Password: Empty (no password set)
  • Dependencies: Waits for TimescaleDB to be ready

Use pgAdmin to:

  • Run the books-data.sql script to set up the database schema
  • Create the bookapi database
  • Manage and query the books data

BookApi

The main REST API service built from the ../BookApi directory.

  • Build Context: ../BookApi
  • Environment: Development
  • Connection String: Connects to TimescaleDB at timescaledb:5432 using the bookapi database
  • Dependencies: Waits for TimescaleDB to be ready

The API provides endpoints for managing books (CRUD operations).

bookapi-mcp-server

MCP server that bridges Claude Desktop with the Book API.

  • Build Context: ../book-api-mcp-server-dotnet
  • Environment: Configures the Book API base URL to http://bookapi:8080
  • Dependencies: Waits for BookApi to be ready

This service exposes the Book API functionality through the Model Context Protocol, allowing Claude Desktop to interact with the book database.

Usage

Starting the Services

docker-compose up -d

This will start all services in detached mode. The services will start in dependency order:

  1. TimescaleDB first
  2. pgAdmin (waits for TimescaleDB)
  3. BookApi (waits for TimescaleDB)
  4. bookapi-mcp-server (waits for BookApi)

Setting Up the Database

  1. Access pgAdmin at http://localhost:5050
  2. Login with admin@admin.com (no password)
  3. Add a new server connection:
    • Host: timescaledb
    • Port: 5432
    • Database: propertydb (initial connection)
    • Username: admin
    • Password: (leave empty)
  4. Create the bookapi database (or use the SQL script)
  5. Run the books-data.sql script in the bookapi database to create the schema and sample data

Stopping the Services

docker-compose down

To also remove volumes (⚠️ this will delete all data):

docker-compose down -v

Viewing Logs

View logs for all services:

docker-compose logs -f

View logs for a specific service:

docker-compose logs -f bookapi

Configuration

Environment Variables

  • TimescaleDB: Uses default PostgreSQL environment variables
  • BookApi: Connection string is configured via ConnectionStrings__DefaultConnection
  • bookapi-mcp-server: Book API URL is configured via BookApi__BaseUrl

Volumes

Two named volumes are created:

  • postgres-data: Stores TimescaleDB data (persists across container restarts)
  • pgadmin_data: Stores pgAdmin configuration and settings

Network

All services run on the default Docker Compose network, allowing them to communicate using their service names as hostnames (e.g., timescaledb, bookapi).

Notes

  • The database password is empty by default. For production use, set secure passwords in the environment variables.
  • The BookApi service connects to a database named bookapi, but TimescaleDB initializes with propertydb. You'll need to create the bookapi database manually or via the SQL script.
  • The pgAdmin interface is accessible on port 5050 on your host machine.

Running with Skaffold and Minikube (Kubernetes)

If you'd like to run the services on a local Kubernetes environment rather than Docker Compose, you can use Skaffold with Minikube. Kubernetes resources are deployed to the book-api namespace.

1. Create a Self-Signed TLS Certificate and Private Key

Before running Envoy in Kubernetes, generate TLS certs for service encryption:

openssl req -x509 -newkey rsa:4096 -nodes -sha256 -days 365 \
    -keyout privkey.pem -out cert.pem -extensions san \
    -config \
    <(echo "[req]";
      echo distinguished_name=req;
      echo "[san]";
      echo subjectAltName=DNS:bookapi-mcp-server.book-api.svc.cluster.local
     ) \
    -subj '/CN=bookapi-mcp-server.book-api.svc.cluster.local'

This produces cert.pem and privkey.pem for use by Envoy to terminate TLS.

2. Create the Namespace and a Kubernetes Secret for Envoy

kubectl apply -f k8s/service-mesh/namespace.yaml

Store these files as a Kubernetes TLS secret for Envoy to mount:

kubectl -n book-api create secret tls envoy-certs \
    --key privkey.pem --cert cert.pem \
    --dry-run=client --output yaml | kubectl -n book-api apply --filename -

3. Start Minikube (if not already running)

minikube start

Check status with:

minikube status

To use Minikube's internal Docker registry for local builds:

eval $(minikube docker-env)

4. Build and Deploy All Services with Skaffold

From the project root:

skaffold run --tail

This will build and deploy all services (TimescaleDB, BookApi, MCP Server, Envoy, etc) into your Minikube cluster.

5. Expose Envoy via LoadBalancer and Tunnel

Envoy is exposed as a Kubernetes LoadBalancer service. To access it from your local machine, run:

minikube tunnel

This command keeps running and exposes LoadBalancer services at a local IP.

After tunnel is running, find the Envoy service’s external IP and port:

kubectl -n book-api get svc

Look for the envoy service—typically exposed on port 443.

6. Stopping Minikube & Cleaning Up

When done:

minikube stop

...to stop the cluster. To delete all cluster resources:

minikube delete

Additional Notes

  • The database is not persisted in Minikube unless you use persistent volumes in your Kubernetes manifests.
  • If you're testing locally, you may need to port-forward specific services (like TimescaleDB or pgAdmin) using kubectl port-forward for local debugging.
  • Make sure any environment variables for database connection or API URLs reflect the Kubernetes service names (e.g., bookapi, timescaledb).

See the k8s/ directory for configs and customize as needed for your local environment.
